Model Whirlpool GX5SHDXTS00 REFRIGERATOR – Common Parts &amp; Diagrams

285006 Whirlpool Spray In Stock WPL 285006 $29.65

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.94

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $27.52

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $100.80

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.99

KIT, FOA WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

Ice Container Assembly WPL 4343700 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

Enamel, Black (1 Qt. Uncut) WPL 799340 Contact Us For Availability

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability

WPL ARI152115A WPL ARI152115A Contact Us For Availability

WPL ARI152116A WPL ARI152116A Contact Us For Availability

WPL ARI152117A WPL ARI152117A Contact Us For Availability

WPL ARI152118A WPL ARI152118A Contact Us For Availability

WPL ARI152119A WPL ARI152119A Contact Us For Availability

WPL ARI152120A WPL ARI152120A Contact Us For Availability

1

12992301 Whirlpool Refrigerator Screw Backorder WPL 12992301 $13.89

1

Owners Manual WPL 12828178 Contact Us For Availability

1

Tag, Energy WPL 12863068 Contact Us For Availability

1

Tech Sheet WPL 16025690 Contact Us For Availability

1

Mold & Heater Assembly (Not Available -- Orde WPL ARI152111A Contact Us For Availability

1

Door, Left (Black) WPL 13024006B Contact Us For Availability

1

Door, Left (Stainless Steel) WPL 13024006S Contact Us For Availability

1

Door, Left (White) WPL 13024006W Contact Us For Availability

1

Liner (Not A Seviceable Part) WPL ARI152105A Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI152107A Contact Us For Availability

1

Freezer Door (Includes Insulation) (Stainless WPL 8171178 Contact Us For Availability

1

Freezer Door (Includes Insulation) (Black) WPL 8171179 Contact Us For Availability

1

Freezer Door (Includes Insulation) (White) WPL 8171181 Contact Us For Availability

2

W10156818 Whirlpool Refrigerator Fan Blade In Stock WPL W10156818 $50.17

2

W10856123 Whirlpool Refrigerator Gasket Backorder WPL W10856123 $3.70

2

W11176463 Whirlpool Refrigerator Water Tube In Stock WPL W11176463 $44.76

2

WP2254600B Whirlpool Refrigerator Handle Backorder WPL WP2254600B $114.12

2

WP2254600W Whirlpool Refrigerator Handle Backorder WPL WP2254600W $155.75

2

WP67004028 Whirlpool Refrigerator Shut-Off Ar In Stock WPL WP67004028 $33.86

2

Handle (Stainless Steel) WPL 2319729S Contact Us For Availability

2

Bracket, Control and Lights WPL 8208277 Contact Us For Availability

3

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $9.68

3

12991101 Whirlpool Refrigerator Screw Backorder WPL 12991101 $9.59

3

WP12744905 Whirlpool Refrigerator Compressor Backorder WPL WP12744905 $55.71

3

WP628356 Whirlpool Refrigerator Fill Cup In Stock WPL WP628356 $17.39

3

WP67003405 Whirlpool Pivot Block In Stock WPL WP67003405 $4.70

3

Base WPL 67005889 Contact Us For Availability

3

Overlay WPL W10117528 Contact Us For Availability

4

W10436252 Whirlpool Door Gasket In Stock WPL W10436252 $129.24

4

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $30.25

4

WP67001279 Whirlpool Refrigerator Dairy Tray Backorder WPL WP67001279 $48.97

4

GASKET WPL 8170924 Contact Us For Availability

4

Cover, Light WPL 8208205 Contact Us For Availability

4

Housing Electronic Control WPL 67004005 Contact Us For Availability

4

Gasket, Door (White) WPL 8171185 Contact Us For Availability

5

W11028221 Whirlpool Refrigerator Shaft In Stock WPL W11028221 $12.13

5

WP10450603 Whirlpool Refrigerator Roller In Stock WPL WP10450603 $3.04

5

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $28.15

5

WP3387230 Whirlpool Screw In Stock WPL WP3387230 $3.46

5

WP67004954 Whirlpool Refrigerator Screw Backorder WPL WP67004954 $2.51

5

WPW10371194 Whirlpool Refrigerator Door Shelf In Stock WPL WPW10371194 $44.12

5

WPW10503278 Whirlpool Refrigerator Electronic In Stock WPL WPW10503278 $125.44

6

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $14.06

6

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $38.96

6

WP9740848 Whirlpool Dishwasher Screw Backorder WPL WP9740848 $2.51

6

Clip, Grille WPL 4344155 Contact Us For Availability

7

10712401 Whirlpool Refrigerator Vent Plug (Wh Backorder WPL 10712401 $4.50

7

67004838 Whirlpool Refrigerator Button Vent P Backorder WPL 67004838 $4.72

7

W11284721 Whirlpool Refrigerator Cover Backorder WPL W11284721 $38.12

7

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

7

Harness, Evap Heater WPL 12870501 Contact Us For Availability

8

12806601 Whirlpool Refrigerator Light Housing Backorder WPL 12806601 $45.48

8

W10830189 Whirlpool Refrigerator Door Gasket In Stock WPL W10830189 $137.01

8

W11368721 Whirlpool Refrigerator French Door In Stock WPL W11368721 $116.56

8

WP12579803 Whirlpool Refrigerator Drain Pan Backorder WPL WP12579803 $160.93

8

Thermostat (Not Available -- Order 8170937) WPL ARI152112A Contact Us For Availability

9

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $3.71

9

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.33

9

WP8281196 Whirlpool Screw In Stock WPL WP8281196 $4.52

9

Stud, Handle WPL 8171220 Contact Us For Availability

9

Grommet WPL 8171209 Contact Us For Availability

12456801V Whirlpool Refrigerator Bracket Backorder WPL 12456801V $31.38

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $5.40

WP67001255 Whirlpool Ice Bucket Backorder WPL WP67001255 $86.21

WP67002493 Whirlpool Refrigerator Defrost Hea In Stock WPL WP67002493 $72.92

Housing, Light WPL 8170838 Contact Us For Availability

11

67003900 Whirlpool Refrigerator Insert Damper In Stock WPL 67003900 $4.52

11

W11727809 Whirlpool Evaporator Cover Backorder WPL W11727809 $34.44

11

WP67006380 Whirlpool Screw Backorder WPL WP67006380 $3.33

71003131 Whirlpool Oven Screw Backorder WPL 71003131 $4.85

W10613606 Whirlpool Refrigerator Start Device In Stock WPL W10613606 $36.61

WP400021-1 Whirlpool Screw In Stock WPL WP400021-1 $5.38

WP67003753 Whirlpool Refrigerator Inlet Valve In Stock WPL WP67003753 $63.11

WPW10289497 Whirlpool Refrigerator Shelf Bin In Stock WPL WPW10289497 $55.62

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $39.73

WP854334 Whirlpool Air Conditioner Sealing St Backorder WPL WP854334 $5.71

WPA3223101 Whirlpool Refrigerator Insert PL Backorder WPL WPA3223101 $3.70

Cover, Left Hinge (White) WPL 8208247 Contact Us For Availability

Cover, Left Hinge (Black) WPL 8208248 Contact Us For Availability

Bracket, Door (Left) WPL 8171232 Contact Us For Availability

Bracket, Door (Right) WPL 8171233 Contact Us For Availability

67003906 Whirlpool Refrigerator Control Modul Backorder WPL 67003906 $51.55

W10823511 Whirlpool Refrigerator Water Tube In Stock WPL W10823511 $13.43

WP12722803B Whirlpool Door Guide In Stock WPL WP12722803B $143.65

WP12722803W Whirlpool Door Support In Stock WPL WP12722803W $141.12

WP489349 Whirlpool Refrigerator Screw In Stock WPL WP489349 $3.33

WP67003426 Whirlpool Refrigerator Thermostat In Stock WPL WP67003426 $36.55

WPW10235370 Whirlpool Refrigerator Glide Backorder WPL WPW10235370 $114.56

Insulation WPL 8208194 Contact Us For Availability

67005680 Whirlpool Refrigerator Condenser Gro Backorder WPL 67005680 $10.76

W10918164 Whirlpool Refrigerator Door Hinge Backorder WPL W10918164 $49.19

WP67003903 Whirlpool Refrigerator Damper Cont In Stock WPL WP67003903 $103.66

WP67005633 Whirlpool Refrigerator Bracket Backorder WPL WP67005633 $3.70

WPD7813010 Whirlpool Refrigerator Wire Harnes In Stock WPL WPD7813010 $23.36

Hinge, Center (RT) (White) WPL 67006379 Contact Us For Availability

12002355 Whirlpool Refrigerator Thermistor Ki In Stock WPL 12002355 $23.46

W11396033 Whirlpool Refrigerator Rocker Switc In Stock WPL W11396033 $15.68

WP2256087 Whirlpool Refrigerator Bracket Backorder WPL WP2256087 $30.25

WP67003638 Whirlpool Closing Cam In Stock WPL WP67003638 $4.52

WP67003639 Whirlpool Refrigerator Closer In Stock WPL WP67003639 $42.09

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $29.10

67003484 Whirlpool Refrigerator White Corner Backorder WPL 67003484 $10.25

67003485 Whirlpool Refrigerator Corner Cover Backorder WPL 67003485 $10.76

W11478401 Whirlpool Refrigerator Housing Backorder WPL W11478401 $88.31

W11708403 Whirlpool Door Stop Backorder WPL W11708403 $5.07

WP12868601 Whirlpool Refrigerator Wire Harnes Backorder WPL WP12868601 $50.71

WP33001882 Whirlpool Screw In Stock WPL WP33001882 $27.52

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $4.56

Clip, Capacitor WPL 67007052 Contact Us For Availability

Following Parts Not Illustrated WPL ARI152108A Contact Us For Availability

WP12566607ED Whirlpool Refrigerator Door Hing Backorder WPL WP12566607ED $30.91

WP67006131 Whirlpool Refrigerator Condenser Backorder WPL WP67006131 $153.47

WPW10280608 Whirlpool Refrigerator Bracket Backorder WPL WPW10280608 $36.87

WPW10280613 Whirlpool Refrigerator Bracket Backorder WPL WPW10280613 $36.87

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.64

67002722 Whirlpool Refrigerator White Door Bu Backorder WPL 67002722 $10.76

67004978 Whirlpool Refrigerator Black Door Bu Backorder WPL 67004978 $10.76

Bracket, Foot (2) WPL 67007174 Contact Us For Availability

Module Assembly (Not Available -- Order 81709 WPL ARI152113A Contact Us For Availability

Slide, Drawer (2) WPL 8171228 Contact Us For Availability

12028601W Whirlpool Refrigerator Hinge Bushin Backorder WPL 12028601W $8.78

67006564 Whirlpool Refrigerator Screw Backorder WPL 67006564 $3.33

W11159728 Whirlpool Refrigerator Gasket In Stock WPL W11159728 $10.93

WP67002731 Whirlpool Refrigerator Door Bushin Backorder WPL WP67002731 $3.70

Tray, Drip WPL 8171081 Contact Us For Availability

WP98165 Whirlpool Screw In Stock WPL WP98165 $2.51

Shim, Hinge WPL 8208257 Contact Us For Availability

Bracket, Slide (Left) WPL 8208215 Contact Us For Availability

Bracket, Slide (Right) WPL 8208216 Contact Us For Availability

12002041 Whirlpool Refrigerator Evaporator Re In Stock WPL 12002041 $201.99

WPW10175909 Whirlpool Grille Assembly In Stock WPL WPW10175909 $40.86

WPW10534153 Whirlpool Refrigerator Black Kick In Stock WPL WPW10534153 $69.64

WPW10534154 Whirlpool Refrigerator Front Gril Backorder WPL WPW10534154 $57.79

Door, Right (Black) WPL 13024005B Contact Us For Availability

Door, Right (White) WPL 13024005W Contact Us For Availability

Door, Right (Stainless Steel) WPL 67006650 Contact Us For Availability

Dam (Left Side) WPL 8171154 Contact Us For Availability

Dam (Right Side) WPL 8171155 Contact Us For Availability

Shroud, Evap.Fan WPL 8171153 Contact Us For Availability

67006442 Whirlpool Refrigerator Center Hinge Backorder WPL 67006442 $51.88

W10918113 Whirlpool Refrigerator Door Hinge Backorder WPL W10918113 $41.43

W11613295 Whirlpool Condenser Motor In Stock WPL W11613295 $50.82

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $27.11

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $3.33

W11673433 Whirlpool Clip Backorder WPL W11673433 $62.75

WP67002780 Whirlpool Refrigerator Grommet Backorder WPL WP67002780 $3.70

NAMEPLATE WPL 8170797 Contact Us For Availability

26

12002225 Whirlpool Refrigerator Evaporator Fa Backorder WPL 12002225 $111.91

26

12726003 Whirlpool Refrigerator Water Cover Backorder WPL 12726003 $7.16

26

Harness, Unit WPL 8208233 Contact Us For Availability

27

W10815413 Whirlpool Refrigerator Funnel Backorder WPL W10815413 $29.08

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $15.50

27

Cover, Water Valve WPL 12479803 Contact Us For Availability

28

W10309989 Whirlpool Refrigerator Compressor In Stock WPL W10309989 $345.51

28

W11233072 Whirlpool Screw In Stock WPL W11233072 $10.41

28

WPM0500703 Whirlpool Refrigerator O-Ring Seal Backorder WPL WPM0500703 $4.72

29

WPB8381501 Whirlpool Refrigerator Door Gasket In Stock WPL WPB8381501 $4.52

30

Cover, Unit WPL 8170910 Contact Us For Availability

31

W11181718 Whirlpool Refrigerator Water Tube Backorder WPL W11181718 $45.71

31

WP67003924 Whirlpool Refrigerator Cover Backorder WPL WP67003924 $3.70

31

SHROUD WPL 8170906 Contact Us For Availability

32

WP489474 Whirlpool Refrigerator Screw Backorder WPL WP489474 $2.75

32

WP67004953 Whirlpool Refrigerator Bracket Backorder WPL WP67004953 $30.89

32

Cord, Power WPL 67007121 Contact Us For Availability

67003796 Whirlpool Refrigerator Fiber Acousti Backorder WPL 67003796 $10.76

W10709797 Whirlpool Refrigerator Screw Backorder WPL W10709797 $9.59

Harness, Lights (Freezer) WPL 67006095 Contact Us For Availability

Following Parts Not Illustrated WPL ARI152106A Contact Us For Availability

34

10547003 Whirlpool Refrigerator Dryer Clip Backorder WPL 10547003 $4.59

34

W11177593 Whirlpool Leveling Feet In Stock WPL W11177593 $7.08

35

Bolt, Adjusting (Rear) WPL 67006612 Contact Us For Availability

35

Grommet (4) WPL 4343845 Contact Us For Availability

36

WPM0104106 Whirlpool Refrigerator Clip Backorder WPL WPM0104106 $2.51

36

Clip, Evaporator WPL 4344219 Contact Us For Availability

37

WPW10326469 Whirlpool Drawer Slide Rail In Stock WPL WPW10326469 $12.19

37

Tube, Drain WPL 8170861 Contact Us For Availability

38

12846902 Whirlpool Refrigerator Screw Backorder WPL 12846902 $9.13

38

67001067 Whirlpool Refrigerator Drain Tube Cl Backorder WPL 67001067 $4.41

38

WP12603701 Whirlpool Refrigerator Support In Stock WPL WP12603701 $5.90

39

W10833902 Whirlpool Refrigerator Clamp In Stock WPL W10833902 $4.45

39

WP67002759 Whirlpool Refrigerator Divider In Stock WPL WP67002759 $29.28

39

Screw WPL 67006573 Contact Us For Availability

40

WP12866903 Whirlpool Refrigerator Discharge T Backorder WPL WP12866903 $75.40

40

Cabinet (Not A Servicable Part) WPL ARI152104A Contact Us For Availability

41

WP12566606ED Whirlpool Refrigerator Door Hing Backorder WPL WP12566606ED $16.98

41

WP67005149 Whirlpool Roller In Stock WPL WP67005149 $10.76

67006434 Whirlpool Axle Pin In Stock WPL 67006434 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $34.75

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.02

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Cover, Right Hinge (White) WPL 8208261 Contact Us For Availability

Cover, Right Hinge (Black) WPL 8208262 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

Following Parts Not Illustrated and Optional WPL ARI152109A Contact Us For Availability

REFRIGERANT CHARGE 5.0 Ozs. (R-134A) WPL ARI152110A Contact Us For Availability

43

A3076901 Whirlpool Refrigerator Plug Backorder WPL A3076901 $5.53

44

Pin WPL M1205302 Contact Us For Availability

45

M0286708 Whirlpool Refrigerator Holder Nut As Backorder WPL M0286708 $28.09

46

Roller Assembly WPL 8170886 Contact Us For Availability

681390 Whirlpool Refrigerator Screw Backorder WPL 681390 $9.13

D7824706Q Whirlpool Refrigerator Ice Maker As In Stock WPL D7824706Q $78.49

Screw, Bracket WPL 8170943 Contact Us For Availability

Retainer, Tube WPL 8170944 Contact Us For Availability

Following Parts Not Illustrated WPL ARI152114A Contact Us For Availability
