Model Whirlpool LA3300XPW1 AUTOMATIC WASHER – Common Parts & Diagrams
Common parts from model Whirlpool LA3300XPW1 AUTOMATIC WASHER
1
Nut, Push-In (2) WPL 358473 Contact Us For Availability
1
Clip, Harness WPL 62732 Contact Us For Availability
2
Clip, Harness WPL 62749 Contact Us For Availability
4
Clip, Harness (2) WPL 387551 Contact Us For Availability
4
Support & Brake, Tub WPL 63815 Contact Us For Availability
4
Tub Ring & Gasket WPL 63223 Contact Us For Availability
5
Bracket, Spring Outer (L.F.) WPL 64065 Contact Us For Availability
5
Spacer, Drive Tube WPL 356937 Contact Us For Availability
6
Link, Leveling Mechanism (2) WPL 63138 Contact Us For Availability
6
Protector, Harness WPL 63523 Contact Us For Availability
6
Clothes Guard Repair Kit WPL 285350 Contact Us For Availability
7
Wiring Harness & Pressure Switch Hose WPL 64110 Contact Us For Availability
7
Clip, Clothes Guard (6) WPL 63552 Contact Us For Availability
8
Ring, Retaining (2) WPL 90369 Contact Us For Availability
9
Terminal, Female WPL 352088 Contact Us For Availability
9
Washer, Nylon (6) WPL 680829 Contact Us For Availability
10
Spring, Agitator WPL 62676 Contact Us For Availability
10
Locknut (6) WPL 285348 Contact Us For Availability
10
Screw, Gearcase To Base (3) (5/16-24 x 3/4) WPL 62735 Contact Us For Availability
12
Switch, Water Level WPL 64102 Contact Us For Availability
12
Basket & Clothes Guard (Includes Illus. 6) WPL 63780 Contact Us For Availability
13
Plate, Restrictor WPL 63546 Contact Us For Availability
14
Lock, Filter WPL 62942 Contact Us For Availability
15
Clip, Motor Disconnect Block WPL 386838 Contact Us For Availability
16
LUBRICANT (USE ONLY IN BRAKE SHOE ASSEMBLY ON WPL 285208 Contact Us For Availability
16
Washer, Cam Thrust WPL 62618 Contact Us For Availability
17
Tub WPL 63125 Contact Us For Availability
17
Bumper, Lid Hinge WPL 19119 Contact Us For Availability
19
Lid (White) WPL 386027 Contact Us For Availability
19
Base Assembly (Includes Illus, 6, 7, 8, 9, 18 WPL 63808 Contact Us For Availability
19
Spin Pinion WPL 63167 Contact Us For Availability
20
Gear, Main Drive WPL 62528 Contact Us For Availability
20
Switch, Main Drive Motor WPL 62851 Contact Us For Availability
23
Handle, Lid (White) WPL 379889 Contact Us For Availability
23
Ring, Retaining WPL 95082 Contact Us For Availability
24
Spring & Button, Lid ((R.H.)) WPL 53748 Contact Us For Availability
24
Spring & Button, Lid ((L.H.)) WPL 53749 Contact Us For Availability
24
Washer Kit, Thrust WPL 285292 Contact Us For Availability
25
Plug, Button (2) WPL 54690 Contact Us For Availability
26
Stop, Push-In Top WPL 358472 Contact Us For Availability
27
Plug, Terminal (3-Way) WPL 62888 Contact Us For Availability
30
Rivet, Serial Nameplate WPL 354239 Contact Us For Availability
× ![]()
