Model Whirlpool KSSS36QMW00 36`` BUILT IN REFRIGERATOR – Common Parts &amp; Diagrams

1

W10175904 Whirlpool Wire Shelf Backorder WPL W10175904 $40.70

1

W10629033 Whirlpool Refrigerator Inverter Con In Stock WPL W10629033 $226.28

1

Top Grille Assembly (Black) WPL 2257401B Contact Us For Availability

1

Top Grille Assembly (White) WPL 2257401W Contact Us For Availability

1

Top Grille Assembly (Etched Aluminum) WPL 2257401X Contact Us For Availability

1

Ice Bin WPL 2222960 Contact Us For Availability

1

Cabinet, Trim (Right Side) (Black) WPL 2222552B Contact Us For Availability

1

Cabinet, Trim (Right Side) (White) WPL 2222552W Contact Us For Availability

1

Cabinet, Trim (Right Side) (Etched Aluminum) WPL 2222552X Contact Us For Availability

1

Control Box WPL 2215715 Contact Us For Availability

1

Housing, Dispenser (Not Serviced) WPL ARI106911A Contact Us For Availability

2

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

2

Cover, Unit WPL 2259320 Contact Us For Availability

2

Crusher Bin WPL 2222959 Contact Us For Availability

2

Cover-Bottom, Electrical WPL 2300104 Contact Us For Availability

2

Insert, Control Box WPL 2215670 Contact Us For Availability

3

2208970 Whirlpool Refrigerator Air Duct Backorder WPL 2208970 $51.19

3

2302882 Whirlpool Refrigerator Wire Shelf Backorder WPL 2302882 $114.67

3

W10841139 Whirlpool Refrigerator Compressor In Stock WPL W10841139 $319.55

3

W11624204 Whirlpool Screw Backorder WPL W11624204 $9.59

3

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

3

WP2198574 Whirlpool Refrigerator Ice Auger In Stock WPL WP2198574 $75.59

3

Wire Assembly, Icemaker WPL 2187744 Contact Us For Availability

3

Circuit Board, Housing Control WPL 2252110 Contact Us For Availability

3

Wire Assembly WPL 2187755 Contact Us For Availability

4

2252354 Whirlpool Spacer Assembly Backorder WPL 2252354 $8.66

4

2256466 Whirlpool Refrigerator Unit Cover Backorder WPL 2256466 $151.83

4

2259081 Whirlpool Refrigerator Basket Backorder WPL 2259081 $139.50

4

WP2155590 Whirlpool Refrigerator Retainer Backorder WPL WP2155590 $2.51

4

Clip, Thermistor WPL 2209204 Contact Us For Availability

4

Blade, Stirring WPL 2198603 Contact Us For Availability

4

Cabinet, Trim (Bottom) WPL 2254724 Contact Us For Availability

4

Housing, Control Board WPL 2257354 Contact Us For Availability

4

Control Box Wire Harness WPL 2187424 Contact Us For Availability

4

Cover, Dispenser (Not Available- Order Item 2 WPL ARI106912A Contact Us For Availability

4

Bracket WPL 2215508 Contact Us For Availability

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

5

WP2256269 Whirlpool Refrigerator Front Basket Backorder WPL WP2256269 $61.02

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

5

WPW10224328 Whirlpool Refrigerator Spring Backorder WPL WPW10224328 $30.85

5

Cover-Unit, Front WPL 2259095 Contact Us For Availability

5

Bracket, Fan Motor WPL 2215641 Contact Us For Availability

5

Panel Control, Meat Pan WPL 2258914 Contact Us For Availability

5

Side Support WPL 2259244 Contact Us For Availability

6

2221121 Whirlpool Refrigerator Support Backorder WPL 2221121 $32.68

6

2259317 Whirlpool Refrigerator Slide Backorder WPL 2259317 $106.19

6

2302878 Whirlpool Refrigerator Door Hinge Backorder WPL 2302878 $34.92

6

520965 Whirlpool Refrigerator Support Backorder WPL 520965 $10.14

6

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

6

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $7.69

6

WP2259318 Whirlpool Refrigerator Slide Backorder WPL WP2259318 $144.34

6

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

6

Suction Tube WPL 2259303 Contact Us For Availability

6

Cover, Crusher WPL 2255460 Contact Us For Availability

6

Tube, Filter Inlet WPL 2214613 Contact Us For Availability

6

Cabinet, Trim Top WPL 2257366 Contact Us For Availability

7

2222795 Whirlpool Refrigerator Rail Backorder WPL 2222795 $31.71

7

W10278733 Whirlpool Refrigerator Blade Backorder WPL W10278733 $30.30

7

W11474472 Whirlpool Screw In Stock WPL W11474472 $2.51

7

WP488920 Whirlpool Refrigerator Screw Backorder WPL WP488920 $2.51

7

Wire Assembly RC/FC Light Switch WPL 2187429 Contact Us For Availability

7

Water Inlet Tube Assembly WPL 2252393 Contact Us For Availability

7

Cabinet Trim (Left Side) (Black) WPL 2222553B Contact Us For Availability

7

Cabinet Trim (Left Side) (White) WPL 2222553W Contact Us For Availability

7

Cabinet Trim (Left Side) (Etched Aluminum) WPL 2222553X Contact Us For Availability

7

Shroud, Condenser (Right) WPL 2266803 Contact Us For Availability

7

Ice Door Mechanism WPL 2206423 Contact Us For Availability

8

2215910 Whirlpool Refrigerator Grommet Backorder WPL 2215910 $28.80

8

2259464 Whirlpool Refrigerator Wedge Backorder WPL 2259464 $33.31

8

W11724512 Whirlpool Door Hinge In Stock WPL W11724512 $111.87

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

8

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $7.21

8

WP2186494B Whirlpool Refrigerator Filter Cap In Stock WPL WP2186494B $25.25

8

WP2186494W Whirlpool Water Filter Cap Backorder WPL WP2186494W $29.76

8

WP2222981 Whirlpool Refrigerator Gasket Backorder WPL WP2222981 $88.67

8

Seal Gasket WPL 2302758 Contact Us For Availability

8

Bracket, Switch WPL 2259096 Contact Us For Availability

8

Touch Pad, Meat Pan WPL 2252067 Contact Us For Availability

8

Tube, Connect (Drier/Restrictor) WPL 2300191 Contact Us For Availability

9

2215676 Whirlpool Refrigerator Terminal Cover Backorder WPL 2215676 $28.80

9

489348 Whirlpool Refrigerator Tube Clamp Backorder WPL 489348 $5.38

9

WP2266901 Whirlpool Door Gasket In Stock WPL WP2266901 $249.67

9

WP2306086 Whirlpool Refrigerator Electronic C Backorder WPL WP2306086 $195.04

9

WP3400906 Whirlpool Refrigerator Screw Backorder WPL WP3400906 $2.51

9

Spacer-Door, Top WPL 2256381 Contact Us For Availability

9

Seal, Side Trim WPL 2005925 Contact Us For Availability

9

Blade, Fixed WPL 2198601 Contact Us For Availability

9

Tube, Filter Outlet WPL 2254800 Contact Us For Availability

9

Heater, Drain Pan WPL 2259329 Contact Us For Availability

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $30.30

Lever, Ice Dispenser (Black) WPL 2259396B Contact Us For Availability

Valve, Solenoid WPL 2302814 Contact Us For Availability

Enclosure, Connector WPL 2221297 Contact Us For Availability

Shroud, Condenser (Left) WPL 2259369 Contact Us For Availability

Clip, Retainer WPL 2302712 Contact Us For Availability

Lever, Ice Dispenser (White) WPL 2259396W Contact Us For Availability

Hanger, Heater WPL 2209450 Contact Us For Availability

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $30.80

W10823805-includeCORE Whirlpool W10823805 Ref Backorder WPL W10823805-includeCORE $380.03

Cam, Door Closer WPL 2005783 Contact Us For Availability

Block, Blade WPL 2198602 Contact Us For Availability

Trim, Glass Rear Side WPL 2257611 Contact Us For Availability

Handle, Door (Etched Aluminum) WPL 2256473 Contact Us For Availability

Handle, Door (Black) WPL 2256473B Contact Us For Availability

Handle, Door (White) WPL 2256473W Contact Us For Availability

Switch Assembly (Not Available Order Item 25) WPL ARI106913A Contact Us For Availability

Shield, Drain Pan WPL 2005908 Contact Us For Availability

2171846 Whirlpool Refrigerator Release Valve Backorder WPL 2171846 $10.76

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $27.12

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.56

W10833902 Whirlpool Refrigerator Clamp Backorder WPL W10833902 $4.45

W10856124 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10856124 $111.61

WP2203075 Whirlpool Refrigerator Spacer Backorder WPL WP2203075 $6.59

WP2209022 Whirlpool Refrigerator Housing In Stock WPL WP2209022 $91.73

Washer WPL 2001230 Contact Us For Availability

Lever, Water Dispenser (White) WPL 2259395W Contact Us For Availability

2256328 Whirlpool Bracket Assembly Backorder WPL 2256328 $28.20

W10278731 Whirlpool Refrigerator Blade Backorder WPL W10278731 $30.29

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

Tube, Discharge WPL 2259352 Contact Us For Availability

W11254898 Whirlpool Refrigerator Scroll Fan Backorder WPL W11254898 $115.82

WP2188820 Whirlpool Refrigerator Thermistor In Stock WPL WP2188820 $18.70

WP2198641 Whirlpool Refrigerator Ice Maker Co In Stock WPL WP2198641 $2.51

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

Screw WPL 3400525 Contact Us For Availability

Delay Mechanism WPL 2205686 Contact Us For Availability

WP2180226 Whirlpool Ice Dispenser Control Swi In Stock WPL WP2180226 $6.38

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $4.61

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

OVERLAY WPL 2257518 Contact Us For Availability

Clip, Thermistor WPL 2257639 Contact Us For Availability

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.38

WP2220457 Whirlpool Refrigerator Ice Bin Coup In Stock WPL WP2220457 $10.82

WP2306092 Whirlpool Refrigerator Evaporator In Stock WPL WP2306092 $174.42

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

CONDENSER WPL 2259307 Contact Us For Availability

Clamp, Tube WPL 488937 Contact Us For Availability

Trim, Top (Etched Aluminum) WPL 2005010 Contact Us For Availability

Trim (Top) (White) WPL 2005013 Contact Us For Availability

Trim, Top (Black) WPL 2005839 Contact Us For Availability

2259209 Whirlpool Refrigerator Bracket Backorder WPL 2259209 $35.78

W10460127 Whirlpool Refrigerator Inlet Tube Backorder WPL W10460127 $121.41

SCREW Backorder WPL W11769878 $7.72

WP2221296 Whirlpool Air Baffle In Stock WPL WP2221296 $177.39

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $4.56

Grommet (4) WPL 943447 Contact Us For Availability

Heater, Defrost WPL 2006749 Contact Us For Availability

1113048 Whirlpool Refrigerator Clamp Backorder WPL 1113048 $4.81

2180200 Whirlpool Refrigerator Socket Backorder WPL 2180200 $31.40

2257644 Whirlpool Refrigerator Door Hinge Backorder WPL 2257644 $62.10

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $2.51

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $2.51

Door, Spacer WPL 2257637 Contact Us For Availability

Cover WPL 2257538 Contact Us For Availability

Wire, Jumper WPL 2187679 Contact Us For Availability

Trim, Side (Etched Aluminum) WPL 2005967 Contact Us For Availability

Trim (Side) (White) WPL 2005968 Contact Us For Availability

Trim, Side (Black) WPL 2005971 Contact Us For Availability

2209066 Whirlpool Refrigerator Fan Block Backorder WPL 2209066 $28.80

WP2252265 Whirlpool Refrigerator Ice Bin Butt In Stock WPL WP2252265 $14.37

Screw WPL 487522 Contact Us For Availability

Trim (Bottom) (Etched Aluminum) WPL 2215993 Contact Us For Availability

Trim (Bottom) (Black) WPL 2215993B Contact Us For Availability

Trim (Bottom) (White) WPL 2215993W Contact Us For Availability

WP2215650 Whirlpool Refrigerator Cover Backorder WPL WP2215650 $83.22

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

WPW10122550 Whirlpool Refrigerator Ice Mold Backorder WPL WPW10122550 $93.41

Gasket, Evaporator WPL 2220832 Contact Us For Availability

Latch, Bin WPL 2252206 Contact Us For Availability

Wire Assembly WPL 2187680 Contact Us For Availability

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $52.25

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

WP2004994 Whirlpool Refrigerator Hinge Bushin Backorder WPL WP2004994 $3.70

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $6.95

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $3.70

WPW10323172 Whirlpool Refrigerator Retainer E Backorder WPL WPW10323172 $3.70

WPW10323173 Whirlpool Refrigerator Retainer E Backorder WPL WPW10323173 $3.70

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

2198671 Whirlpool Refrigerator Screw Backorder WPL 2198671 $4.58

W10169509 Whirlpool Refrigerator Clip Backorder WPL W10169509 $28.80

WP22002263 Whirlpool Dryer 10W Light Bulb In Stock WPL WP22002263 $7.83

WP628356 Whirlpool Refrigerator Fill Cup In Stock WPL WP628356 $15.77

Bushing WPL 2002903 Contact Us For Availability

2259025 Whirlpool Refrigerator Air Cover Backorder WPL 2259025 $33.67

626753 Whirlpool Refrigerator Ejector Arm Backorder WPL 626753 $8.53

W10181323 Whirlpool Refrigerator Condenser Fa In Stock WPL W10181323 $165.56

WP2206670B Whirlpool Dispenser Tray In Stock WPL WP2206670B $20.18

WP2206670W Whirlpool Dispenser Tray In Stock WPL WP2206670W $30.46

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

2256250 Whirlpool Refrigerator Shelf Trim Backorder WPL 2256250 $29.55

W10297245 Whirlpool Refrigerator Arm Stripper Backorder WPL W10297245 $38.45

WP2004517 Whirlpool Refrigerator Spring In Stock WPL WP2004517 $30.85

Blade, Fan WPL 2190685 Contact Us For Availability

Holder WPL 2212369 Contact Us For Availability

Overlay, Cover (Not Available- Order Item 25) WPL ARI106914A Contact Us For Availability

2256222 Whirlpool Refrigerator Track Backorder WPL 2256222 $30.65

2256223 Whirlpool Refrigerator Track Backorder WPL 2256223 $28.99

WP2001264 Whirlpool Refrigerator Drip Pan In Stock WPL WP2001264 $88.94

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $37.11

WP2220458 Whirlpool Drive Cam In Stock WPL WP2220458 $11.97

WPW10323035 Whirlpool Refrigerator Cantilever Backorder WPL WPW10323035 $44.03

Orifice, Fan WPL 2003169 Contact Us For Availability

Front Cover Assembly (Includes Items 4,11,20, WPL 2257555B Contact Us For Availability

Front Cover Assembly (Includes Items 4,11,20, WPL 2257555W Contact Us For Availability

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.01

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

WPW10131132 Whirlpool Refrigerator Door Compr Backorder WPL WPW10131132 $40.92

Tube, Drier Transition WPL 2300190 Contact Us For Availability

Trim, Front (White) WPL 2208917 Contact Us For Availability

Trim, Front (Black) WPL 2208926 Contact Us For Availability

Bracket, Drain Pan (Left) WPL 1113206 Contact Us For Availability

Bracket, Drain Pan (Right) WPL 1113207 Contact Us For Availability

8281160 Whirlpool Screw Backorder WPL 8281160 $5.33

W10323598 Whirlpool Refrigerator Cantilever B Backorder WPL W10323598 $55.04

W10851443 Whirlpool Refrigerator Screw In Stock WPL W10851443 $2.51

WP2158826 Whirlpool Refrigerator Dampener Backorder WPL WP2158826 $0.90

WP2212370 Whirlpool Washer Backorder WPL WP2212370 $7.45

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $41.93

WP8281250 Whirlpool Refrigerator Screw In Stock WPL WP8281250 $4.56

Screw 8-15 x 1/2 (White) WPL 8281251 Contact Us For Availability

2215648 Whirlpool Refrigerator Dampener Backorder WPL 2215648 $7.78

2259398 Whirlpool Refrigerator Seal Backorder WPL 2259398 $7.69

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $27.27

F.C. (3) WPL ARI106910A Contact Us For Availability

Tube, Heat Loop Transition WPL 2259301 Contact Us For Availability

Butter Tray WPL 2165792 Contact Us For Availability

Trim, Front (Black) WPL 2266918B Contact Us For Availability

Trim, Front (White) WPL 2266918W Contact Us For Availability

8201537 Whirlpool Water Tubing Assembly In Stock WPL 8201537 $52.10

W10527053 Whirlpool Refrigerator Door Hinge Backorder WPL W10527053 $70.12

W10852956 Whirlpool Refrigerator Spring In Stock WPL W10852956 $8.14

WP2006780 Whirlpool Refrigerator Door Hinge Backorder WPL WP2006780 $102.66

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

WP8533928 Whirlpool Refrigerator Screw In Stock WPL WP8533928 $2.51

W10323746 Whirlpool Refrigerator Cantilever B Backorder WPL W10323746 $54.08

WP2188917 Whirlpool Drive Shaft In Stock WPL WP2188917 $53.75

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $2.51

Housing, Power Supply WPL 2259349 Contact Us For Availability

Harness, Switch Jumper Assembly WPL 2187623 Contact Us For Availability

W10504752 Whirlpool Refrigerator Ice Door Backorder WPL W10504752 $48.06

W11721628 Whirlpool Screw Assembly Backorder WPL W11721628 $8.11

WP2196483 Whirlpool Refrigerator Shelf Stud Backorder WPL WP2196483 $4.34

WP2259350 Whirlpool Refrigerator Electronic C Backorder WPL WP2259350 $70.57

32

WP2209024B Whirlpool Refrigerator Front Grill Backorder WPL WP2209024B $67.86

32

WP2212363 Whirlpool Refrigerator Motor In Stock WPL WP2212363 $91.59

32

Sleeve, Condenser WPL 2000645 Contact Us For Availability

33

COVER WPL 2222862 Contact Us For Availability

33

Cover, Electrical WPL 2259463 Contact Us For Availability

34

2220904 Whirlpool Refrigerator Gasket Backorder WPL 2220904 $8.31

34

W10528578 Whirlpool Refrigerator Tube Backorder WPL W10528578 $14.62

35

WPL 2005921 WPL 2005921 Contact Us For Availability

2006616 Whirlpool Refrigerator Bracket Backorder WPL 2006616 $28.80

2259493 Whirlpool Refrigerator Cover Backorder WPL 2259493 $28.80

WP2212365 Whirlpool Refrigerator Sleeve Backorder WPL WP2212365 $10.43

Cover, Fan WPL 2209495 Contact Us For Availability

37

Water Valve Mounting Bracket WPL 2004914 Contact Us For Availability

37

Cover, Condenser WPL 2259092 Contact Us For Availability

38

2006617 Whirlpool Refrigerator Bracket Backorder WPL 2006617 $28.80

38

Grommet, Flexible WPL 2266857 Contact Us For Availability

39

WP2006346 Whirlpool Refrigerator Washer In Stock WPL WP2006346 $4.59

39

Service Cord WPL 2259197 Contact Us For Availability

41

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

41

WP1163283 Whirlpool Air Conditioner Screw Backorder WPL WP1163283 $2.51

42

WP2266802 Whirlpool Refrigerator Switch In Stock WPL WP2266802 $30.80

43

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $4.56

2300167 Whirlpool Bracket Backorder WPL 2300167 $55.49

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

Front Panel Kit (White) WPL 2220866 Contact Us For Availability

Front Panel Kit (Black) WPL 2220869 Contact Us For Availability

Front Panel Kit Black Acrylic Static Cleaner WPL 2220873 Contact Us For Availability

FOLLOWING PARTS NOT ILLUSTRATED WPL ARI106918A Contact Us For Availability

(Optional Parts Only) WPL ARI106919A Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Wiring Harness, Unit Compartment WPL 2187625 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

FOLLOWING PARTS NOT ILLUSTRATED WPL ARI106915A Contact Us For Availability

and Optional Parts Not Included WPL ARI106916A Contact Us For Availability

REFRIGERANT CHARGE 7.75 oz. (R-134A) WPL ARI106917A Contact Us For Availability

50

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $5.44

52

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $14.42

56

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $4.56
