Model Whirlpool KSCS25FVBL03 REFRIGERATOR – Common Parts &amp; Diagrams

1

WP2182120 Whirlpool Refrigerator Scroll Fan In Stock WPL WP2182120 $32.96

1

CONTROL BOX (INCLUDES No.3) WPL W10175591 Contact Us For Availability

1

Ice Bin WPL W10139482 Contact Us For Availability

2

WPW10139483 Whirlpool Refrigerator Condenser In Stock WPL WPW10139483 $28.58

2

FRONT ROLLER ASM (LEFT SIDE) WPL W10199222 Contact Us For Availability

2

FRONT ROLLER ASM (RIGHT SIDE) WPL W10199223 Contact Us For Availability

2

HANDLE (INCLUDES No.6) (STAINLESS STEEL) WPL 2319727S Contact Us For Availability

2

Fitting, Water Tube WPL 2303216 Contact Us For Availability

2

TRIM, SHELF WPL 2203087 Contact Us For Availability

3

W10193018 Whirlpool Refrigerator Condenser Backorder WPL W10193018 $180.89

3

W10852517 Whirlpool Refrigerator Ice Auger Backorder WPL W10852517 $79.82

3

WP2305202 Whirlpool Refrigerator Bracket Backorder WPL WP2305202 $37.95

3

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

3

Control Board Asm WPL 2307037 Contact Us For Availability

3

Dairy Door WPL 2255421 Contact Us For Availability

4

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

4

WP2223506 Whirlpool Refrigerator Light Lens Backorder WPL WP2223506 $52.72

4

WP2305242 Whirlpool Refrigerator Connector In Stock WPL WP2305242 $30.40

4

Washer WPL 2258220 Contact Us For Availability

5

3400524 Whirlpool Refrigerator Screw Backorder WPL 3400524 $7.80

5

W11545866 Whirlpool Refrigerator Clip Backorder WPL W11545866 $4.39

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

5

WP2188820 Whirlpool Refrigerator Thermistor In Stock WPL WP2188820 $18.70

5

WPW10184813 Whirlpool Refrigerator Motor In Stock WPL WPW10184813 $37.00

5

WPW10270150 Whirlpool Crisper Drawer Cover Backorder WPL WPW10270150 $211.76

5

Air Duct Freezer WPL 2223297 Contact Us For Availability

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

6

WP2305258 Whirlpool Dispenser Door Assembly Backorder WPL WP2305258 $7.69

6

WPA3073101 Whirlpool Light Bulb In Stock WPL WPA3073101 $5.97

6

WPW10170540 Whirlpool Screw In Stock WPL WPW10170540 $4.58

6

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $19.51

6

Housing, Control Board WPL 2223703 Contact Us For Availability

7

2301234 Whirlpool Refrigerator Control Backorder WPL 2301234 $29.19

7

2301548 Whirlpool Refrigerator Glide Backorder WPL 2301548 $98.93

7

W10278733 Whirlpool Refrigerator Blade Backorder WPL W10278733 $30.30

7

WP2305204 Whirlpool Refrigerator Support In Stock WPL WP2305204 $27.69

8

2223545 Whirlpool Refrigerator Shim Backorder WPL 2223545 $31.71

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

8

WP2319727B Whirlpool Refrigerator Handle Backorder WPL WP2319727B $122.04

8

WP4449745 Whirlpool Screw Backorder WPL WP4449745 $2.51

8

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.51

8

Window, Crisper Pan WPL 2301001 Contact Us For Availability

9

2307008B Whirlpool Refrigerator Butt Hinge Backorder WPL 2307008B $15.96

9

2307008T Whirlpool Refrigerator Butt Hinge Backorder WPL 2307008T $44.38

9

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $3.70

9

W11366418 Whirlpool Screw In Stock WPL W11366418 $9.59

9

Blade, Fixed WPL 2257020 Contact Us For Availability

9

Cover, Crisper (Includes 2, 3, 4, 11, 12, 13, WPL 2301567 Contact Us For Availability

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $30.30

WP2223879 Whirlpool Refrigerator Compressor D Backorder WPL WP2223879 $54.88

Spigot WPL W10187441 Contact Us For Availability

Glass, Cover WPL 2301028 Contact Us For Availability

2317239 Whirlpool Refrigerator Blade Block Backorder WPL 2317239 $4.78

WPW10272168 Whirlpool Refrigerator Water Fill Backorder WPL WPW10272168 $30.62

HARNESS, FAN EVAPORATOR (INCLUDES No.6) WPL W10297478 Contact Us For Availability

Door Closer, Upper Cam WPL 2307050 Contact Us For Availability

Clip, Thermistor WPL 2209204 Contact Us For Availability

Front, Basket WPL 2224053 Contact Us For Availability

2215676 Whirlpool Refrigerator Terminal Cover Backorder WPL 2215676 $28.80

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $27.12

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

HINGE ASSEMBLY, BOTTOM-RC (INCLUDES No.34) WPL 2307179 Contact Us For Availability

W10278731 Whirlpool Refrigerator Blade Backorder WPL W10278731 $30.29

WPW10272161 Whirlpool Refrigerator Stripper A Backorder WPL WPW10272161 $29.61

Pad, Water (White) WPL 2305307CE Contact Us For Availability

Eyelet, Roller WPL 2174478 Contact Us For Availability

14

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

14

Grille (Midnight Grey) WPL W10194061 Contact Us For Availability

14

Grille (Biscuit) WPL W10194058 Contact Us For Availability

2306940 Whirlpool Refrigerator Bracket Backorder WPL 2306940 $32.79

2306940B Whirlpool Refrigerator Bracket Backorder WPL 2306940B $13.10

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $4.61

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $4.56

Gasket, Air Baffle WPL 2304597 Contact Us For Availability

2307007B Whirlpool Refrigerator Butt Hinge Backorder WPL 2307007B $44.38

W10916292 Whirlpool Refrigerator Crisper Pan Backorder WPL W10916292 $99.22

WP2220457 Whirlpool Refrigerator Ice Bin Coup In Stock WPL WP2220457 $10.82

WP2223860 Whirlpool Refrigerator Door Shelf B In Stock WPL WP2223860 $51.22

WP2321746 Whirlpool Refrigerator Electronic C Backorder WPL WP2321746 $163.94

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

WP3400012 Whirlpool Refrigerator Screw Backorder WPL WP3400012 $2.51

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $4.56

Pad, Ice (White) WPL 2305306CE Contact Us For Availability

Meat Pan (Includes 13, 14, 19 & 22) WPL 2223790 Contact Us For Availability

Air Diffuser Assembly WPL 2224076 Contact Us For Availability

2301544 Whirlpool Refrigerator Glide Backorder WPL 2301544 $116.07

2301545 Whirlpool Refrigerator Glide Backorder WPL 2301545 $58.23

2305219 Whirlpool Refrigerator Cover Backorder WPL 2305219 $28.80

W11566763 Whirlpool Fitting In Stock WPL W11566763 $18.87

WP2220377 Whirlpool Refrigerator Air Baffle In Stock WPL WP2220377 $173.69

WP2224173 Whirlpool Refrigerator Cantilever B In Stock WPL WP2224173 $45.64

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $2.51

Glide Assembly (Snack Pan) (Left Side) WPL 2301551 Contact Us For Availability

WP2187467 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187467 $46.19

WP2305382 Whirlpool Refrigerator Washer In Stock WPL WP2305382 $4.19

WPW10243391 Whirlpool Refrigerator Nameplate Backorder WPL WPW10243391 $26.90

WPW10243392 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243392 $33.09

WPW10243393 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243393 $35.74

Cover, Emitter WPL 2259487 Contact Us For Availability

Tube, Extension WPL 2254566 Contact Us For Availability

20

W10222215 Whirlpool Refrigerator Light Indica Backorder WPL W10222215 $57.63

20

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

20

BRACKET, ICEMAKER MOUNTING WPL 2303583 Contact Us For Availability

21

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $3.70

21

Support Assembly (Right Side) WPL 2301569 Contact Us For Availability

21

Cover, Unit WPL 2223409 Contact Us For Availability

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $192.85

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $27.27

Wire Harness, IDI Motor WPL 2187813 Contact Us For Availability

Handle WPL 2203031 Contact Us For Availability

Trim, Housing (Nickel Alloy) WPL 2315109NA Contact Us For Availability

Trim, Housing (Black) WPL 2315109B Contact Us For Availability

Trim, Housing (White) WPL 2315109W Contact Us For Availability

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $5.44

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

Light Lens WPL 2223663 Contact Us For Availability

Front Cover Assembly (Includes Items 13,14,16 WPL 2326256NO Contact Us For Availability

Front Cover Assembly (Includes Items 13,14,16 WPL 2326256W Contact Us For Availability

Clamp WPL 2161324 Contact Us For Availability

Front Cover Assembly (Includes Items 13,14,16 WPL 2326256B Contact Us For Availability

24

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $59.32

24

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

24

Holder WPL 2212369 Contact Us For Availability

25

WP2220458 Whirlpool Drive Cam In Stock WPL WP2220458 $11.97

25

Hinge Assembly, Bottom-FC WPL 2307152 Contact Us For Availability

2260503MG Whirlpool Refrigerator Button Backorder WPL 2260503MG $12.11

2260503W Whirlpool Refrigerator Button Backorder WPL 2260503W $13.30

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.01

Shelf, Snack Pan WPL 2301566 Contact Us For Availability

27

WP2212370 Whirlpool Washer Backorder WPL WP2212370 $7.45

27

WPW10121140 Whirlpool Refrigerator Housing In Stock WPL WPW10121140 $106.14

27

WPW10185438 Whirlpool Ice Maker Cover In Stock WPL WPW10185438 $42.16

28

everydrop® Filter 3 EDR3RXD1 Whirlpool Refri In Stock WPL EDR3RXD1 $55.44

28

W10852956 Whirlpool Refrigerator Spring In Stock WPL W10852956 $8.14

28

Slide, Ice Maker Mounting (Right Side) WPL 2212321 Contact Us For Availability

WP2305243 Whirlpool Refrigerator Shaft Backorder WPL WP2305243 $88.31

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

WPW10191952 Whirlpool Refrigerator Screw Backorder WPL WPW10191952 $3.70

Door Closer, FC WPL 2307051 Contact Us For Availability

30

WP2252130 Whirlpool Refrigerator Motor In Stock WPL WP2252130 $115.68

30

WP2260518MG Whirlpool Water Filter Cap Backorder WPL WP2260518MG $27.21

30

Window, Snack Pan WPL 2301006 Contact Us For Availability

31

WP2310122 Whirlpool Refrigerator Wire Harness Backorder WPL WP2310122 $143.57

31

Bracket, Motor WPL 2305208 Contact Us For Availability

32

WP2212365 Whirlpool Refrigerator Sleeve Backorder WPL WP2212365 $10.43

32

WP489483 Whirlpool Screw In Stock WPL WP489483 $4.58

33

2317243 Whirlpool Refrigerator Wiper Backorder WPL 2317243 $28.80

33

Heater, Defrost WPL 2323199 Contact Us For Availability

34

2317250 Whirlpool Refrigerator Divider Backorder WPL 2317250 $11.09

34

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $4.56

34

WPL 2307049 WPL 2307049 Contact Us For Availability

35

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $14.42

36

WPW10154805 Whirlpool Refrigerator Inverter B In Stock WPL WPW10154805 $256.64

36

Cover, Receiver WPL W10173569 Contact Us For Availability

37

2315398 Whirlpool Refrigerator Slide Backorder WPL 2315398 $4.78

37

WPL W10281289 WPL W10281289 Contact Us For Availability

39

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $2.51

42

WP2198641 Whirlpool Refrigerator Ice Maker Co In Stock WPL WP2198641 $2.51

100

W11512149 Whirlpool Ice Maker Assembly In Stock WPL W11512149 $78.53

100

Ice Container (Complete) WPL W10140693 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

8171357 Whirlpool Spray Nozzle Backorder WPL 8171357 $30.47

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

W10134625 Whirlpool Refrigerator Touch-Up Pai In Stock WPL W10134625 $7.48

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

PAINT, TOUCH-UP (1/2oz.) (Graphite) WPL 80051 Contact Us For Availability

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability
