Model Whirlpool KGLC500TWH0 WASHER-DRYER LAUNDRY SYSTEM – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350938 Whirlpool Spray Gun In Stock WPL 350938 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $10.07

72113 Whirlpool Touch-Up Paint Backorder WPL 72113 $10.07

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

Harvest Wheat WPL 261890 Contact Us For Availability

Harvest Wheat (Uncut) WPL 261891 Contact Us For Availability

LUBRICANT (USE ONLY IN BRAKE SHOE ASSEMBLY ON WPL 285208 Contact Us For Availability

Toast WPL 285365 Contact Us For Availability

Paint, Spray (13 Oz.) (Platinum) WPL 285366 Contact Us For Availability

Enamal, Toast (1 Qt. Uncut) WPL 285367 Contact Us For Availability

Platinum (Uncut) WPL 285368 Contact Us For Availability

Leveler (Thinner) WPL 350941 Contact Us For Availability

Paint, (Touch-Up 1/2 Oz.) (Toast) WPL 72112 Contact Us For Availability

Almond (Uncut) WPL 978883 Contact Us For Availability

Hang Tag (Energy Guide) WPL LIT3350594 Contact Us For Availability

List, Repair Parts WPL LIT3387298 Contact Us For Availability

Guide, Use And Care WPL LIT3387331 Contact Us For Availability

Guide, Laundry WPL LIT3387380 Contact Us For Availability

Instructions, Installation WPL LIT3387487 Contact Us For Availability

Wiring Diagram WPL LIT697546 Contact Us For Availability

1

285203 Whirlpool CP Bearing In Stock WPL 285203 $71.60

1

356746 Whirlpool Clip Backorder WPL 356746 $10.76

1

W10820043 Whirlpool Washer Drive and Brake Ba In Stock WPL W10820043 $88.94

1

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51

1

WPW10112403 Whirlpool Miscellaneous Parts Backorder WPL WPW10112403 $29.04

1

Harness, Door Switch (Includes Illus. 1A) WPL 692728 Contact Us For Availability

1

Exhaust Deflector Kit (Complete) WPL 694609 Contact Us For Availability

1A

WP717253 Whirlpool Dishwasher Connector Backorder WPL WP717253 $3.51

1B

696073 Whirlpool Connector Backorder WPL 696073 $28.80

2

285202 Whirlpool Cover Assembly Backorder WPL 285202 $78.48

2

345396 Whirlpool Clip Backorder WPL 345396 $26.21

2

WP16123 Whirlpool Washer In Stock WPL WP16123 $2.51

2

WP358237 Whirlpool Agitator Bolt In Stock WPL WP358237 $2.29

2

WP62658 Whirlpool Seal Ring Backorder WPL WP62658 $5.27

2

WP63292 Whirlpool Washer In Stock WPL WP63292 $3.70

2

Handle, Lid (White) WPL 389008 Contact Us For Availability

2

Handle, Lid (Almond) WPL 389009 Contact Us For Availability

2

Handle, Lid (Harvest Wheat) WPL 389010 Contact Us For Availability

2

Handle, Lid (Toast) WPL 389011 Contact Us For Availability

2

Handle, Lid (Platinum) WPL 389012 Contact Us For Availability

3

696529 Whirlpool Air Duct Backorder WPL 696529 $45.93

3

WP16272 Whirlpool Hose Coupling Backorder WPL WP16272 $2.51

3

WP3349985 Whirlpool Shaft Seal In Stock WPL WP3349985 $9.35

3

WP64137 Whirlpool Shield Assembly Backorder WPL WP64137 $12.96

3

WP691581 Whirlpool Actuator In Stock WPL WP691581 $3.70

3

WP91939 Whirlpool Shaft Seal In Stock WPL WP91939 $3.70

3

WPW10080230 Whirlpool Ring In Stock WPL WPW10080230 $4.98

3

Lid (White) WPL 3348069 Contact Us For Availability

3

Lid (Almond) WPL 3348070 Contact Us For Availability

3

Lid (Harvest Wheat) WPL 3348071 Contact Us For Availability

3

Lid (Toast) WPL 3348072 Contact Us For Availability

3

Lid (Platinum) WPL 3348073 Contact Us For Availability

4

285314 Whirlpool O/S1 Panel In Stock WPL 285314 $194.20

4

285320 Whirlpool Washer Siphon Break Kit In Stock WPL 285320 $29.80

4

285353 Whirlpool Ring Backorder WPL 285353 $3.70

4

80011 Whirlpool Washer Lid Bumper Kit of 2 Backorder WPL 80011 $2.73

4

WP285195 Whirlpool Sealer Assembly Backorder WPL WP285195 $44.98

4

WP367594 Whirlpool Leveling Feet In Stock WPL WP367594 $10.89

4

WPW10250667 Whirlpool Washer Suspension Sprin In Stock WPL WPW10250667 $2.29

4

Panel, Front (Almond) WPL 692620 Contact Us For Availability

4

Panel, Front (Toast) WPL 692621 Contact Us For Availability

4

Panel, Front (Platinum) WPL 692622 Contact Us For Availability

4

Panel, Front (Harvest Wheat) WPL 692623 Contact Us For Availability

4

Shield, Rear WPL 3390408 Contact Us For Availability

5

285664 Whirlpool Drain Hose In Stock WPL 285664 $18.32

5

285666 Whirlpool Drain Hose 10' In Stock WPL 285666 $28.37

5

285785 Whirlpool Washer Direct Drive Clutch In Stock WPL 285785 $18.42

5

285805 Whirlpool Washer Water Inlet Valve In Stock WPL 285805 $13.91

5

384458 Whirlpool Hinge Assembly Backorder WPL 384458 $29.43

5

696541 Whirlpool Base Backorder WPL 696541 $29.43

5

W10831641 Whirlpool Tub Ring Backorder WPL W10831641 $127.70

5

W11613302 Whirlpool Door Seal In Stock WPL W11613302 $19.71

5

WP358594 Whirlpool Leveling Feet In Stock WPL WP358594 $7.27

5

WP694674 Whirlpool Cycling Thermostat In Stock WPL WP694674 $27.10

5

Suspension Assembly (3) WPL 63731 Contact Us For Availability

5

Spacer, Drive Tube WPL 356937 Contact Us For Availability

6

280077 Whirlpool Door Backorder WPL 280077 $116.57

6

285790 Whirlpool Washer Clutch Band and Linin In Stock WPL 285790 $28.49

6

WP21097 Whirlpool Pad In Stock WPL WP21097 $3.70

6

WP21366 Whirlpool Spanner Nut In Stock WPL WP21366 $3.70

6

WP356427 Whirlpool Shaft Seal In Stock WPL WP356427 $3.70

6

WP596669 Whirlpool Hose Clamp In Stock WPL WP596669 $2.51

6

WP64208 Whirlpool Spin Tube Backorder WPL WP64208 $127.32

6

WP8577373 Whirlpool Base Assembly Backorder WPL WP8577373 $127.73

6

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

6

Retainer, Drain Hose WPL 357247 Contact Us For Availability

6B

WP62889 Whirlpool Washer Lid Switch Receptacl Backorder WPL WP62889 $3.70

6C

WP62505 Whirlpool Connector Backorder WPL WP62505 $10.76

7

W10083190 Whirlpool Ring-E Backorder WPL W10083190 $4.94

7

WP348205 Whirlpool Door Backorder WPL WP348205 $55.84

7

WP389387 Whirlpool Agitator Shaft In Stock WPL WP389387 $103.30

7

WP692699 Whirlpool Hose In Stock WPL WP692699 $15.77

7

WPW10119828 Whirlpool Screw In Stock WPL WPW10119828 $2.51

7

End Cap, Console (L.H. & R.H.) WPL 692993 Contact Us For Availability

7

Door, Front (Almond) WPL 689314 Contact Us For Availability

7

Door, Front (Harvest Wheat) WPL 689319 Contact Us For Availability

7

Door, Front (Toast) WPL 695214 Contact Us For Availability

7

Door, Front (Platinum) WPL 695215 Contact Us For Availability

7

Retainer, Wire WPL 3350222 Contact Us For Availability

8

285438 Whirlpool Brake Shoe In Stock WPL 285438 $75.04

8

WP384496 Whirlpool Hose Coupling Backorder WPL WP384496 $30.85

8

WP62646 Whirlpool Cap In Stock WPL WP62646 $2.51

8

WP694424 Whirlpool Limiter In Stock WPL WP694424 $12.57

8

Thermostat, Heater Box (Alt.) WPL 341196 Contact Us For Availability

8

Cabinet (White) WPL 696013 Contact Us For Availability

8

Cabinet (Almond) WPL 696014 Contact Us For Availability

8

Cabinet (Harvest Wheat) WPL 696015 Contact Us For Availability

8

Cabinet (Toast) WPL 696016 Contact Us For Availability

8

Cabinet (Platinum) WPL 696017 Contact Us For Availability

8

Ring, Retaining (2) WPL 90369 Contact Us For Availability

8

Thermostat, Heater Box WPL 660036 Contact Us For Availability

8

Thermostat, Heater Box (Alt.) WPL 696707 Contact Us For Availability

9

279264 Whirlpool Bearing and Seal Kit In Stock WPL 279264 $46.61

9

3360629 Whirlpool Washer Gearcase Transmissio In Stock WPL 3360629 $177.07

9

62677 Whirlpool Retainer Backorder WPL 62677 $7.58

9

WP692985 Whirlpool Clip Assembly Backorder WPL WP692985 $3.70

9

WP8546462 Whirlpool Bearing In Stock WPL WP8546462 $3.70

9

Tub WPL 63782 Contact Us For Availability

279220 Whirlpool Clip Backorder WPL 279220 $11.93

279771 Whirlpool Clip Backorder WPL 279771 $6.20

285658 Whirlpool Sleeve Kit Backorder WPL 285658 $6.44

WP389140 Whirlpool Drive Block or Bell In Stock WPL WP389140 $8.44

WP696710 Whirlpool Hose In Stock WPL WP696710 $24.25

WP8577376 Whirlpool Seal In Stock WPL WP8577376 $3.70

Spring, Agitator WPL 62676 Contact Us For Availability

Plug, Button (2) WPL 54690 Contact Us For Availability

Screw, 5/16-24 x 3/16 (3) (Gearcase To Tub Su WPL 62735 Contact Us For Availability

279570 Whirlpool Dryer Door Latch Kit In Stock WPL 279570 $1.66

280007 Whirlpool Heater Box Backorder WPL 280007 $110.08

692790 Whirlpool Plug Backorder WPL 692790 $26.75

WP62611 Whirlpool Plate Backorder WPL WP62611 $37.28

WP63748 Whirlpool Spring Backorder WPL WP63748 $2.51

WP694422 Whirlpool Spring Backorder WPL WP694422 $9.42

WP8546455 Whirlpool Bearing In Stock WPL WP8546455 $9.46

WP89503 Whirlpool Washer Fill Hose In Stock WPL WP89503 $3.62

Spring, Lid (L.H.) (Includes Illus 10) WPL 384460 Contact Us For Availability

62619 Whirlpool Washer Backorder WPL 62619 $9.59

W11095997 Whirlpool Seal In Stock WPL W11095997 $10.76

WP3400516 Whirlpool Screw Backorder WPL WP3400516 $2.51

WP371502 Whirlpool Clamp Backorder WPL WP371502 $4.78

WP384693 Whirlpool Top Backorder WPL WP384693 $149.36

WP660975 Whirlpool Button Plug Backorder WPL WP660975 $3.70

WP98129 Whirlpool Screw Backorder WPL WP98129 $2.51

Top (Almond) WPL 697272 Contact Us For Availability

Top (Harvest Wheat) WPL 697273 Contact Us For Availability

Top (Toast) WPL 697274 Contact Us For Availability

Top (Platinum) WPL 697275 Contact Us For Availability

285753A Whirlpool Washer Direct Drive Motor C In Stock WPL 285753A $9.63

693711 Whirlpool Sleeve Backorder WPL 693711 $4.59

W11213338 Whirlpool Connector Backorder WPL W11213338 $26.90

WP339956 Whirlpool Foam Seal In Stock WPL WP339956 $3.70

WP63134 Whirlpool Ring Backorder WPL WP63134 $3.70

WP694423 Whirlpool Regulator Backorder WPL WP694423 $3.70

WP8546461 Whirlpool Brake Cam Assembly Backorder WPL WP8546461 $2.51

Bumper, Lid Hinge (2) WPL 19119 Contact Us For Availability

8577411 Whirlpool Pad Backorder WPL 8577411 $4.54

WP21258 Whirlpool Washer Lid Hinge Bearing In Stock WPL WP21258 $3.70

WP273556 Whirlpool Screw In Stock WPL WP273556 $2.51

WP3389441 Whirlpool Door Catch In Stock WPL WP3389441 $3.70

WP63022 Whirlpool Sleeve Backorder WPL WP63022 $13.67

WP661600 Whirlpool Drive Motor In Stock WPL WP661600 $138.84

WP693151 Whirlpool Lock Spring Backorder WPL WP693151 $3.70

WP696426 Whirlpool Wheel In Stock WPL WP696426 $39.36

Clamp, Hose WPL 272855 Contact Us For Availability

356398 Whirlpool Tube Backorder WPL 356398 $28.80

63636 Whirlpool Bracket Backorder WPL 63636 $26.74

WP308685 Whirlpool Microwave Screw In Stock WPL WP308685 $2.51

WP356471 Whirlpool Cap In Stock WPL WP356471 $3.70

WP686711 Whirlpool Door Handle In Stock WPL WP686711 $3.70

Handle, Door (Almond) WPL 689306 Contact Us For Availability

Handle, Door (Harvest Wheat) WPL 689584 Contact Us For Availability

Handle, Door (Platinum) WPL 695286 Contact Us For Availability

Shaft, Agitator WPL 389231 Contact Us For Availability

Screw & Washer, Lid Switch Shield (2) WPL 354764 Contact Us For Availability

Clip WPL 3349322 Contact Us For Availability

WP3388255 Whirlpool Timer Backorder WPL WP3388255 $179.40

WP356363 Whirlpool Siphon Break In Stock WPL WP356363 $3.70

WP358684 Whirlpool Strike Assembly In Stock WPL WP358684 $3.19

WP3946532 Whirlpool Shield Backorder WPL WP3946532 $11.77

WPW10083200 Whirlpool Wire Ring In Stock WPL WPW10083200 $4.96

Support Protector WPL 692846 Contact Us For Availability

Washer, Cam Thrust WPL 62618 Contact Us For Availability

Seal, Fan Scroll WPL 696658 Contact Us For Availability

238614 Whirlpool Bumper Hinge Backorder WPL 238614 $68.16

285205 Whirlpool Bearing Backorder WPL 285205 $3.70

384459 Whirlpool Hinge Backorder WPL 384459 $29.43

63637 Whirlpool Shield Backorder WPL 63637 $12.96

W10814296 Whirlpool Washer Center Post Seal G In Stock WPL W10814296 $2.58

WP616099 Whirlpool Clamp Backorder WPL WP616099 $3.24

WP696418 Whirlpool Fan Scroll Backorder WPL WP696418 $41.30

Fastener, Push (2) WPL 693739 Contact Us For Availability

279710 Whirlpool Nut In Stock WPL 279710 $26.21

WP308544 Whirlpool Screw Backorder WPL WP308544 $2.51

WP3363394 Whirlpool Washer Drain Pump In Stock WPL WP3363394 $20.87

WP3390631 Whirlpool Screw Backorder WPL WP3390631 $2.51

WP696394 Whirlpool Hose In Stock WPL WP696394 $34.64

693152 Whirlpool Bumper In Stock WPL 693152 $4.87

W10863713 Whirlpool Support Backorder WPL W10863713 $233.75

WP694091 Whirlpool Screw Backorder WPL WP694091 $2.51

WP8546127 Whirlpool Retainer Clip In Stock WPL WP8546127 $3.70

Bottom and Pinion, Gearcase WPL 389229 Contact Us For Availability

Actuator, Lid Switch WPL 357347 Contact Us For Availability

W10080180 Whirlpool Nut Backorder WPL W10080180 $9.59

WP348023 Whirlpool Hinge Backorder WPL WP348023 $3.70

Gear, Main Drive WPL 62528 Contact Us For Availability

Harness, Thermostat & Heater (Includes Illus. WPL 697440 Contact Us For Availability

Switch, Main Drive Motor WPL 62850 Contact Us For Availability

20A

Plug, Multi-Terminal (Connects With Main Drye WPL 692997 Contact Us For Availability

285352 Whirlpool Washer Oil Seal Kit for Gear In Stock WPL 285352 $29.23

694037 Whirlpool Clip Backorder WPL 694037 $28.80

WP285655 Whirlpool Hose Clamp In Stock WPL WP285655 $3.70

WP338906 Whirlpool Dryer Gas Sensor In Stock WPL WP338906 $17.97

WP62691 Whirlpool Grommet In Stock WPL WP62691 $5.31

WPW10359269 Whirlpool Dryer Shaft Support Rol In Stock WPL WPW10359269 $30.76

Barrier, Harness WPL 693303 Contact Us For Availability

Spring, Lid (R.H.) (Includes Illus. 10) WPL 384461 Contact Us For Availability

3391834 Whirlpool Drum Backorder WPL 3391834 $170.42

697441 Whirlpool Valve Backorder WPL 697441 $117.00

W10820036 Whirlpool Door Switch Kit In Stock WPL W10820036 $9.94

WP3351614 Whirlpool Screw Backorder WPL WP3351614 $2.51

WP691366 Whirlpool Dryer Idler Pulley Assembl In Stock WPL WP691366 $5.69

WP90767 Whirlpool Screw In Stock WPL WP90767 $2.51

WPW10086010 Whirlpool Motor Retainer Clip Backorder WPL WPW10086010 $3.70

3350013 Whirlpool Foam Seal Backorder WPL 3350013 $28.80

386011 Whirlpool Screw Backorder WPL 386011 $26.43

WP3394508 Whirlpool Bearing Ring In Stock WPL WP3394508 $40.88

WP358652 Whirlpool Link Backorder WPL WP358652 $28.80

WP90016 Whirlpool Clip Backorder WPL WP90016 $4.78

Ring, Retaining WPL 95082 Contact Us For Availability

685207 Whirlpool Dryer Baffle Backorder WPL 685207 $35.37

696044 Whirlpool Block Backorder WPL 696044 $29.43

W11573574 Whirlpool Screw In Stock WPL W11573574 $9.59

WP359231 Whirlpool Shield In Stock WPL WP359231 $3.70

WP359364 Whirlpool Clip In Stock WPL WP359364 $3.70

Washer Kit, Thrust WPL 285292 Contact Us For Availability

WP692400 Whirlpool Nut In Stock WPL WP692400 $3.70

WP98234 Whirlpool Nut In Stock WPL WP98234 $4.78

Nut, Compression WPL 233076 Contact Us For Availability

Screw, Baffle Mounting (6) (11-16 x 7/8) WPL 690372 Contact Us For Availability

Harness, Lid Switch WPL 697381 Contact Us For Availability

25A

Receptacle, Terminal (3-Way) (Connects With H WPL 62888 Contact Us For Availability

279735 Whirlpool Dryer Rear Drum Seal White S In Stock WPL 279735 $38.59

388253A Whirlpool Neutral Drain Kit In Stock WPL 388253A $29.41

WP297092 Whirlpool Clip In Stock WPL WP297092 $3.70

Lock, Top (2) WPL 697701 Contact Us For Availability

692933 Whirlpool Panel Backorder WPL 692933 $100.78

WP692628 Whirlpool Panel Backorder WPL WP692628 $204.60

Panel, Front (Almond) WPL 692629 Contact Us For Availability

Panel, Front (Toast) WPL 692630 Contact Us For Availability

Panel, Front (Platinum) WPL 692631 Contact Us For Availability

Panel, Front (Harvest Wheat) WPL 692632 Contact Us For Availability

Bulkhead WPL 697540 Contact Us For Availability

28

W10828351 Whirlpool Dryer Filter Lint Screen In Stock WPL W10828351 $33.01

28

Insert, Handle WPL 389043 Contact Us For Availability

29

WP388815 Whirlpool Washer Backorder WPL WP388815 $2.51

29

WP488130 Whirlpool Air Conditioner Nut Backorder WPL WP488130 $3.09

WP688805 Whirlpool Spring Clip In Stock WPL WP688805 $3.70

WP693145 Whirlpool Lid Latch Backorder WPL WP693145 $28.80

WPW10512946 Whirlpool Dryer Tri-Ring Drum Rol In Stock WPL WPW10512946 $4.52

O Ring WPL 3348609 Contact Us For Availability

31

WP692983 Whirlpool Console Lock Backorder WPL WP692983 $28.80

31

WPW10359270 Whirlpool Dryer Drum Roller Shaft In Stock WPL WPW10359270 $30.85

31

Pad, Extruder (2) WPL 694398 Contact Us For Availability

32

349241T Whirlpool Dryer Drum Support Roller K In Stock WPL 349241T $6.97

32

60001022 Whirlpool Oven Screw Backorder WPL 60001022 $30.96

32

WP694419 Whirlpool Buzzer Adjuster Backorder WPL WP694419 $49.52

33

WP348197 Whirlpool Washer Assembly Backorder WPL WP348197 $2.51

33

WP693304 Whirlpool Screw Backorder WPL WP693304 $2.51

34

WP358160 Whirlpool Nut Backorder WPL WP358160 $2.51

36

Harness, Main Dryer Wiring (Includes Illus. 3 WPL 697435 Contact Us For Availability

36A

Receptacle, Terminal (2-Way) (Connects With D WPL 717252 Contact Us For Availability

36B

Receptacle, Multi-Terminal (Connect WPL 692998 Contact Us For Availability

36C

WPL 717315 WPL 717315 Contact Us For Availability

37

357030 Whirlpool Clamp Backorder WPL 357030 $10.76

37

WPL 693141 WPL 693141 Contact Us For Availability

38

WPW10581952 Whirlpool Power Cord Backorder WPL WPW10581952 $71.75

38A

W11712577 Whirlpool Clip Backorder WPL W11712577 $2.43

39

279457 Whirlpool Dryer Heating Element Wide S In Stock WPL 279457 $3.93

40

WP3388703 Whirlpool Washer Backorder WPL WP3388703 $4.36

41

279393 Whirlpool Terminal Block Screw and Nut In Stock WPL 279393 $15.35

42

279318 Whirlpool Terminal In Stock WPL 279318 $39.58

44

WP90296 Whirlpool Clip Backorder WPL WP90296 $2.51

44

WPL 3389665 WPL 3389665 Contact Us For Availability

45

WPL 61894 WPL 61894 Contact Us For Availability

46

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.51

47

WP3392519 Whirlpool Dryer Thermal Fuse In Stock WPL WP3392519 $7.30

48

W10491983 Whirlpool Tine Tip Backorder WPL W10491983 $3.81

49

488946 Whirlpool Air Conditioner Clamp Backorder WPL 488946 $10.25

50

WP3400935 Whirlpool Dishwasher Clip Backorder WPL WP3400935 $4.65

51

WPL 312147 WPL 312147 Contact Us For Availability

52

345335 Whirlpool Cover Backorder WPL 345335 $56.91

53

347455 Whirlpool Support Assembly Backorder WPL 347455 $8.31

54

WPL 3387208 WPL 3387208 Contact Us For Availability

55

WPL 697571 WPL 697571 Contact Us For Availability

56

WPL 697436 WPL 697436 Contact Us For Availability

A1

279823 Whirlpool Exhaust Pipe Backorder WPL 279823 $97.29

NI

WPL 696818 WPL 696818 Contact Us For Availability

NI

WPL ARI154639A WPL ARI154639A Contact Us For Availability

NI

Screw WPL 359243 Contact Us For Availability
