Model Whirlpool KBFS25EVMS00 REFRIGERATOR – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.94

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $27.52

67005417 Whirlpool Refrigerator Harness F Backorder WPL 67005417 $42.38

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $34.75

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.99

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.02

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

KIT, FOAM SLAB (30`` X WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

Following Parts Not Illustrated and Optional WPL ARI78383A3 Contact Us For Availability

REFRIGERANT CHARGE 5.0 Ozs. (R-134A) WPL ARI78384A6 Contact Us For Availability

Harness, Lights (Freezer) WPL 67006095 Contact Us For Availability

Following Parts Not Illustrated WPL ARI78380A7 Contact Us For Availability

1

12992301 Whirlpool Refrigerator Screw Backorder WPL 12992301 $13.89

1

Door, Left (Stainless Steel) WPL 13024050SQ Contact Us For Availability

1

Door, Left (White) WPL 13024048WQ Contact Us For Availability

1

Door, Left (Mono Stainless) WPL 13024052SQ Contact Us For Availability

1

Freezer Door (Includes Insulation) (Black) WPL 13092233BQ Contact Us For Availability

1

Freezer Door (Includes Insulation) (White) WPL 13092233WQ Contact Us For Availability

1

Freezer Door (Includes Insulation) (Mono Stai WPL 13092234SQ Contact Us For Availability

1

Owners Manual WPL W10187309 Contact Us For Availability

1

Tag, Energy WPL W10187812 Contact Us For Availability

1

Tech Sheet WPL W10198858 Contact Us For Availability

1

Liner (Not A Seviceable Part) WPL ARI78379A7 Contact Us For Availability

2

67002722 Whirlpool Refrigerator White Door Bu Backorder WPL 67002722 $10.76

2

W10156818 Whirlpool Refrigerator Fan Blade In Stock WPL W10156818 $50.17

2

W10205737 Whirlpool Refrigerator Glass Shelf Backorder WPL W10205737 $153.45

2

W10856123 Whirlpool Refrigerator Gasket Backorder WPL W10856123 $3.70

2

W11176463 Whirlpool Refrigerator Water Tube In Stock WPL W11176463 $44.76

2

WP67002721 Whirlpool Refrigerator Door Bushin Backorder WPL WP67002721 $3.70

2

WPW10314515 Whirlpool Refrigerator Handle Backorder WPL WPW10314515 $122.50

2

WPW10314517K Whirlpool Refrigerator Handle Backorder WPL WPW10314517K $120.76

2

Handle (Black) WPL W10119643 Contact Us For Availability

3

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $9.68

3

WP12744905 Whirlpool Refrigerator Compressor Backorder WPL WP12744905 $55.71

3

WP628356 Whirlpool Refrigerator Fill Cup In Stock WPL WP628356 $17.39

3

WP67003405 Whirlpool Pivot Block In Stock WPL WP67003405 $4.70

3

WP67006113 Whirlpool Stud Bolt In Stock WPL WP67006113 $5.82

3

Overlay WPL W10175936 Contact Us For Availability

3

Base WPL 67005889 Contact Us For Availability

4

W10436252 Whirlpool Door Gasket In Stock WPL W10436252 $129.24

4

W10443319 Whirlpool Door Gasket In Stock WPL W10443319 $192.65

4

W11416469 Whirlpool Refrigerator Housing Backorder WPL W11416469 $87.50

4

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $30.25

4

WP67001279 Whirlpool Refrigerator Dairy Tray Backorder WPL WP67001279 $48.97

4

GASKET WPL 8170924 Contact Us For Availability

4

Cover, Light WPL 67003905 Contact Us For Availability

5

W11028221 Whirlpool Refrigerator Shaft In Stock WPL W11028221 $12.13

5

WP10450603 Whirlpool Refrigerator Roller In Stock WPL WP10450603 $3.04

5

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $28.15

5

WP67004954 Whirlpool Refrigerator Screw Backorder WPL WP67004954 $2.51

5

WPW10371195 Whirlpool Refrigerator Cantilever Backorder WPL WPW10371195 $48.00

5

Electronic Control WPL W10207861 Contact Us For Availability

6

M0286708 Whirlpool Refrigerator Holder Nut As Backorder WPL M0286708 $28.09

6

W10160407 Whirlpool Refrigerator Compressor In Stock WPL W10160407 $328.61

6

W11311945 Whirlpool Refrigerator Screw Backorder WPL W11311945 $9.59

6

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $5.40

6

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $38.96

7

10712401 Whirlpool Refrigerator Vent Plug (Wh Backorder WPL 10712401 $4.50

7

67004838 Whirlpool Refrigerator Button Vent P Backorder WPL 67004838 $4.72

7

67006901 Whirlpool Refrigerator Screw Backorder WPL 67006901 $2.51

7

Harness, Evap Heater WPL W10171661 Contact Us For Availability

7

Roller Assembly WPL 67006118 Contact Us For Availability

8

W10830162 Whirlpool Refrigerator Right Hand D In Stock WPL W10830162 $132.01

8

W10830189 Whirlpool Refrigerator Door Gasket In Stock WPL W10830189 $137.01

8

W11368721 Whirlpool Refrigerator French Door In Stock WPL W11368721 $116.56

8

WP12579803 Whirlpool Refrigerator Drain Pan Backorder WPL WP12579803 $160.93

8

WP98165 Whirlpool Screw In Stock WPL WP98165 $2.51

9

67002329 Whirlpool Refrigerator Pantry Gasket Backorder WPL 67002329 $10.76

9

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $3.71

9

WP67006132 Whirlpool Refrigerator Condenser Backorder WPL WP67006132 $138.54

9

WP8281196 Whirlpool Screw In Stock WPL WP8281196 $4.52

10

12456801V Whirlpool Refrigerator Bracket Backorder WPL 12456801V $31.38

10

WP67002493 Whirlpool Refrigerator Defrost Hea In Stock WPL WP67002493 $72.92

10

Housing, Light WPL 67001035 Contact Us For Availability

67003900 Whirlpool Refrigerator Insert Damper In Stock WPL 67003900 $4.52

W11727809 Whirlpool Evaporator Cover Backorder WPL W11727809 $34.44

WP67006380 Whirlpool Screw Backorder WPL WP67006380 $3.33

WPW10243392 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243392 $34.73

WPW10243393 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243393 $37.53

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $29.06

Nameplate (Apollo Grey) WPL W10046610 Contact Us For Availability

71003131 Whirlpool Oven Screw Backorder WPL 71003131 $4.85

WP67003793 Whirlpool Refrigerator Temperature Backorder WPL WP67003793 $28.31

WPW10197428 Whirlpool Start Device In Stock WPL WPW10197428 $41.28

WPW10289498 Whirlpool Refrigerator Cantilever Backorder WPL WPW10289498 $69.25

W10217485 Whirlpool Refrigerator Cover Backorder WPL W10217485 $11.16

WP854334 Whirlpool Air Conditioner Sealing St Backorder WPL WP854334 $5.71

Door, Right (Stainless) WPL 13024049SQ Contact Us For Availability

Door, Right (Black) WPL 13024047BQ Contact Us For Availability

Door, Right (White) WPL 13024047WQ Contact Us For Availability

Door, Right (Mono Stainless) WPL 13024051SQ Contact Us For Availability

Cover, Left Hinge (White) WPL 67007156 Contact Us For Availability

67003906 Whirlpool Refrigerator Control Modul Backorder WPL 67003906 $51.55

WP12722803AP Whirlpool Refrigerator Mullion R In Stock WPL WP12722803AP $101.54

WP12722803B Whirlpool Door Guide In Stock WPL WP12722803B $143.65

WP12722803W Whirlpool Door Support In Stock WPL WP12722803W $141.12

WP489349 Whirlpool Refrigerator Screw In Stock WPL WP489349 $3.33

WPW10165425 Whirlpool Bimetal Defrost Thermos In Stock WPL WPW10165425 $32.98

WPW10235370 Whirlpool Refrigerator Glide Backorder WPL WPW10235370 $114.56

12655102AP Whirlpool Refrigerator Door Hinge Backorder WPL 12655102AP $50.34

12655103ED Whirlpool Door Hinge Backorder WPL 12655103ED $29.13

WP67005626 Whirlpool Refrigerator Can Caddy Backorder WPL WP67005626 $45.48

WPW10137529 Whirlpool Refrigerator Grommet Backorder WPL WPW10137529 $3.70

W11396033 Whirlpool Refrigerator Rocker Switc In Stock WPL W11396033 $15.68

WP12028505AP Whirlpool Closing Cam In Stock WPL WP12028505AP $43.13

WP12777701 Whirlpool Refrigerator Filler Bloc Backorder WPL WP12777701 $4.15

WP67003638 Whirlpool Closing Cam In Stock WPL WP67003638 $4.52

WP67003639 Whirlpool Refrigerator Closer In Stock WPL WP67003639 $42.09

Shroud, Condenser WPL 12575309SP Contact Us For Availability

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $29.10

67003484 Whirlpool Refrigerator White Corner Backorder WPL 67003484 $10.25

67003485 Whirlpool Refrigerator Corner Cover Backorder WPL 67003485 $10.76

W11401472 Whirlpool Refrigerator Door Stop Backorder WPL W11401472 $10.76

W11708403 Whirlpool Door Stop Backorder WPL W11708403 $5.07

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $3.70

Pan, Crisper (2) WPL 67005929 Contact Us For Availability

Clip, Capacitor WPL 2255199 Contact Us For Availability

12626911ED Whirlpool Refrigerator Door Hinge Backorder WPL 12626911ED $30.25

W11714300 Whirlpool Insulation In Stock WPL W11714300 $22.22

WPW10280608 Whirlpool Refrigerator Bracket Backorder WPL WPW10280608 $36.87

WPW10280613 Whirlpool Refrigerator Bracket Backorder WPL WPW10280613 $36.87

WPW10346415 Whirlpool Refrigerator Condenser Backorder WPL WPW10346415 $152.87

W11658402 Whirlpool Drawer Slide Rail In Stock WPL W11658402 $75.69

WP12866903 Whirlpool Refrigerator Discharge T Backorder WPL WP12866903 $75.40

BUSHING, DOOR UPPER LEFT (APOLLO GREY) WPL 12395501AP Contact Us For Availability

Bushing, Door (Upper Left) (Black) WPL 12395501B Contact Us For Availability

Bushing, Door (Upper Left) (White) WPL 12395501W Contact Us For Availability

Bracket, Foot (2) WPL W10208641 Contact Us For Availability

10961006AP Whirlpool Refrigerator Hinge Bushi Backorder WPL 10961006AP $5.71

67004978 Whirlpool Refrigerator Black Door Bu Backorder WPL 67004978 $10.76

67006564 Whirlpool Refrigerator Screw Backorder WPL 67006564 $3.33

W11451451 Whirlpool Refrigerator Gasket Backorder WPL W11451451 $4.85

W11547653 Whirlpool Refrigerator Drip Tray Backorder WPL W11547653 $30.85

WP67004977 Whirlpool Refrigerator Door Hinge Backorder WPL WP67004977 $3.70

WPW10330991 Whirlpool Refrigerator Bracket In Stock WPL WPW10330991 $42.30

WPW10330993 Whirlpool Refrigerator Bracket In Stock WPL WPW10330993 $59.75

Clip, Evaporator WPL 10623002 Contact Us For Availability

Shim, Hinge WPL 12579702 Contact Us For Availability

12002041 Whirlpool Refrigerator Evaporator Re In Stock WPL 12002041 $201.99

12028601W Whirlpool Refrigerator Hinge Bushin Backorder WPL 12028601W $8.78

W10853652 Whirlpool Refrigerator Hinge Bushin Backorder WPL W10853652 $4.36

WP67002731 Whirlpool Refrigerator Door Bushin Backorder WPL WP67002731 $3.70

WPW10175909 Whirlpool Grille Assembly In Stock WPL WPW10175909 $40.86

WPW10534153 Whirlpool Refrigerator Black Kick In Stock WPL WPW10534153 $69.64

WPW10534154 Whirlpool Refrigerator Front Gril Backorder WPL WPW10534154 $57.79

WPW10534155 Whirlpool Refrigerator Gray Kickp In Stock WPL WPW10534155 $62.25

WPW10167023 Whirlpool Refrigerator Shroud Backorder WPL WPW10167023 $35.83

Dam (Left Side) WPL 67001083 Contact Us For Availability

Dam (Right Side) WPL 67001084 Contact Us For Availability

Pin WPL M1205302 Contact Us For Availability

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $27.11

Cover, Right Hinge (Apollo Grey) WPL 12629801AP Contact Us For Availability

Motor, Fan WPL 67004432 Contact Us For Availability

Cover, Right Hinge (Black) WPL 12629801B Contact Us For Availability

Cover, Right Hinge (White) WPL 12629801W Contact Us For Availability

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $3.33

EDR4RXD1 Whirlpool EveryDrop® Refrigerator W In Stock WPL EDR4RXD1 $56.07

W11673433 Whirlpool Clip Backorder WPL W11673433 $62.75

W11690160 Whirlpool Grommet Backorder WPL W11690160 $3.22

26

12726003 Whirlpool Refrigerator Water Cover Backorder WPL 12726003 $7.16

26

W11024089 Whirlpool Refrigerator Evaporator F In Stock WPL W11024089 $44.33

26

Harness, Unit WPL 13060202 Contact Us For Availability

W10815413 Whirlpool Refrigerator Funnel Backorder WPL W10815413 $29.08

WP67005864 Whirlpool Humidity Control In Stock WPL WP67005864 $4.52

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $15.50

Cover, Water Valve WPL 67004098 Contact Us For Availability

28

10547003 Whirlpool Refrigerator Dryer Clip Backorder WPL 10547003 $4.59

28

WP7101P126-60 Whirlpool Screw Backorder WPL WP7101P126-60 $2.51

28

WPM0500703 Whirlpool Refrigerator O-Ring Seal Backorder WPL WPM0500703 $4.72

29

W11519867 Whirlpool Refrigerator Cover In Stock WPL W11519867 $13.38

29

WP67004953 Whirlpool Refrigerator Bracket Backorder WPL WP67004953 $30.89

29

WPB8381501 Whirlpool Refrigerator Door Gasket In Stock WPL WPB8381501 $4.52

30

12002355 Whirlpool Refrigerator Thermistor Ki In Stock WPL 12002355 $23.46

30

WPW10169124 Whirlpool Refrigerator Grommet In Stock WPL WPW10169124 $4.52

30

Cover, Unit WPL B5759649 Contact Us For Availability

12846902 Whirlpool Refrigerator Screw Backorder WPL 12846902 $9.13

W11181718 Whirlpool Refrigerator Water Tube Backorder WPL W11181718 $45.71

WP67003924 Whirlpool Refrigerator Cover Backorder WPL WP67003924 $3.70

WP67005930 Whirlpool Refrigerator Pantry Draw In Stock WPL WP67005930 $49.23

12626910ED Whirlpool Refrigerator Door Hinge Backorder WPL 12626910ED $40.88

WP489474 Whirlpool Refrigerator Screw Backorder WPL WP489474 $2.75

Basket, Freezer (Lower) WPL W10150039 Contact Us For Availability

Screw (4) WPL 67006573 Contact Us For Availability

33

67003796 Whirlpool Refrigerator Fiber Acousti Backorder WPL 67003796 $10.76

33

W10709797 Whirlpool Refrigerator Screw Backorder WPL W10709797 $9.59

33

Cover, HV WPL 67005421 Contact Us For Availability

34

W11177593 Whirlpool Leveling Feet In Stock WPL W11177593 $7.08

34

Board, HV WPL W10205114 Contact Us For Availability

35

Spacer, HV WPL 67005418 Contact Us For Availability

35

Cabinet, (Not A Serviceable Part) WPL ARI78378A7 Contact Us For Availability

36

WPM0104106 Whirlpool Refrigerator Clip Backorder WPL WPM0104106 $2.51

36

Box, HV WPL 67004969 Contact Us For Availability

37

W10164397 Whirlpool Refrigerator Drain Tube Backorder WPL W10164397 $8.73

37

SCREW WPL 67006550 Contact Us For Availability

38

Harness, HV WPL 12972902 Contact Us For Availability

38

Clip, Drain Tube WPL W10157973 Contact Us For Availability

39

W10709801 Whirlpool Refrigerator Screw Backorder WPL W10709801 $9.13

40

WP33001882 Whirlpool Screw In Stock WPL WP33001882 $27.52

41

67005680 Whirlpool Refrigerator Condenser Gro Backorder WPL 67005680 $10.76

42

Block, Condenser WPL 67005491 Contact Us For Availability

43

WP67005149 Whirlpool Roller In Stock WPL WP67005149 $10.76

44

67006434 Whirlpool Axle Pin In Stock WPL 67006434 $3.70
