Model Whirlpool GX2FHDXVA02 REFRIGERATOR – Common Parts &amp; Diagrams

1

WP2256087 Whirlpool Refrigerator Bracket Backorder WPL WP2256087 $30.25

1

DOOR, LEFT (WHITE) WPL 12978044WQ Contact Us For Availability

1

DOOR, LEFT (BISCUIT) WPL 12978044QQ Contact Us For Availability

1

DOOR, LEFT (MONO SATINA) WPL 12978046LQ Contact Us For Availability

1

DOOR, LEFT (STAINLESS) WPL 12978049SQ Contact Us For Availability

1

DOOR, LEFT (BLACK) WPL 12978073BQ Contact Us For Availability

2

W11120581 Whirlpool Refrigerator Water Tube Backorder WPL W11120581 $45.71

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $52.96

2

WPW10231482 Whirlpool Refrigerator Shelf Trim Backorder WPL WPW10231482 $42.88

2

Handle, Door (White) WPL W10189639 Contact Us For Availability

2

DOOR, RIGHT (BISCUIT) WPL 12978043QQ Contact Us For Availability

2

DOOR, RIGHT (WHITE) WPL 12978043WQ Contact Us For Availability

2

DOOR, RIGHT (MONO SATINA) WPL 12978045LQ Contact Us For Availability

2

DOOR, RIGHT (STAINLESS) WPL 12978053SQ Contact Us For Availability

2

DOOR, RIGHT (BLACK) WPL 12978076BQ Contact Us For Availability

2

Module, Light WPL 12806303 Contact Us For Availability

3

W10480110 Whirlpool Refrigerator Plate Backorder WPL W10480110 $67.60

3

Overlay WPL W10180451 Contact Us For Availability

3

Bucket, Can Dispenser WPL W10169347 Contact Us For Availability

3

Clamp WPL 10526702 Contact Us For Availability

4

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $3.33

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $7.69

4

WP13005401SP Whirlpool Can Rack In Stock WPL WP13005401SP $46.20

4

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.33

4

Module, Control WPL 12806407 Contact Us For Availability

5

WP2315576 Whirlpool Water Inlet Valve In Stock WPL WP2315576 $42.95

5

WPW10128551 Whirlpool Evaporator Fan Motor In Stock WPL WPW10128551 $44.47

5

WPW10351081 Whirlpool Refrigerator Cantilever Backorder WPL WPW10351081 $46.23

5

WPW10371194 Whirlpool Refrigerator Door Shelf In Stock WPL WPW10371194 $44.12

5

WPW10503183 Whirlpool Refrigerator Basket Backorder WPL WPW10503183 $136.97

5

WPW10503278 Whirlpool Refrigerator Electronic In Stock WPL WPW10503278 $125.44

5

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $29.06

6

W11285509 Whirlpool Refrigerator Shut-Off Arm Backorder WPL W11285509 $52.56

6

W11291138 Whirlpool Refrigerator Door Switch In Stock WPL W11291138 $14.97

6

W11402523 Whirlpool Refrigerator Glass Shelf Backorder WPL W11402523 $124.05

6

WP12722803AP Whirlpool Refrigerator Mullion R In Stock WPL WP12722803AP $101.54

6

WP12722803B Whirlpool Door Guide In Stock WPL WP12722803B $143.65

6

WP12722803W Whirlpool Door Support In Stock WPL WP12722803W $141.12

6

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $4.70

6

TUBE, DISCHARGE WPL W10217748 Contact Us For Availability

7

W11260592 Whirlpool Refrigerator Wire Harness Backorder WPL W11260592 $43.99

7

W11284721 Whirlpool Refrigerator Cover Backorder WPL W11284721 $38.12

7

W11311945 Whirlpool Refrigerator Screw Backorder WPL W11311945 $9.59

7

W11592375 Whirlpool Door Hinge Backorder WPL W11592375 $10.07

7

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.64

8

12806601 Whirlpool Refrigerator Light Housing Backorder WPL 12806601 $45.48

8

W10830162 Whirlpool Refrigerator Right Hand D In Stock WPL W10830162 $132.01

8

W10830189 Whirlpool Refrigerator Door Gasket In Stock WPL W10830189 $137.01

8

W10830283 Whirlpool Refrigerator Left Hand Do In Stock WPL W10830283 $118.46

8

W10830287 Whirlpool Refrigerator FIP Gasket Backorder WPL W10830287 $113.94

8

W10830289 Whirlpool Refrigerator Gasket FIP Backorder WPL W10830289 $117.66

8

W11368721 Whirlpool Refrigerator French Door In Stock WPL W11368721 $116.56

8

WPA3223101 Whirlpool Refrigerator Insert PL Backorder WPL WPA3223101 $3.70

8

WPW10655367 Whirlpool Refrigerator Drip Pan In Stock WPL WPW10655367 $69.53

9

W10241046 Whirlpool Refrigerator Divider Backorder WPL W10241046 $12.44

9

W10829281 Whirlpool Refrigerator Screw In Stock WPL W10829281 $5.01

9

W11351146 Whirlpool Refrigerator Handle Backorder WPL W11351146 $105.70

9

W11351147 Whirlpool Refrigerator Handle Backorder WPL W11351147 $105.70

9

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $3.71

9

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $145.60

9

WPW10222984K Whirlpool Refrigerator Handle As Backorder WPL WPW10222984K $101.43

9

HANDLE, DOOR (BISCUIT) WPL W10222986N Contact Us For Availability

W10122561 Whirlpool Refrigerator Cup Fill In Stock WPL W10122561 $10.21

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $5.40

W11469652 Whirlpool Refrigerator Shield Backorder WPL W11469652 $10.76

WP12729128 Whirlpool Defrost Heater In Stock WPL WP12729128 $67.69

WP98165 Whirlpool Screw In Stock WPL WP98165 $2.51

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $29.10

67003900 Whirlpool Refrigerator Insert Damper In Stock WPL 67003900 $4.52

W10204187 Whirlpool Refrigerator Retainer Backorder WPL W10204187 $5.71

W11703060 Whirlpool Door Stop Backorder WPL W11703060 $6.20

W11708403 Whirlpool Door Stop Backorder WPL W11708403 $5.07

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $30.25

Stop, Door (Biscuit) WPL 12968202Q Contact Us For Availability

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $28.15

WP400021-1 Whirlpool Screw In Stock WPL WP400021-1 $5.38

WPW10197428 Whirlpool Start Device In Stock WPL WPW10197428 $41.28

Nameplate WPL 2220214 Contact Us For Availability

12726003 Whirlpool Refrigerator Water Cover Backorder WPL 12726003 $7.16

W10121318 Whirlpool Refrigerator Grommet In Stock WPL W10121318 $28.66

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $39.73

WP12992902 Whirlpool Refrigerator Screw Backorder WPL WP12992902 $4.58

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $38.96

WPW10137529 Whirlpool Refrigerator Grommet Backorder WPL WPW10137529 $3.70

Backorder WPL W11750607 $19.22

WP12028505AP Whirlpool Closing Cam In Stock WPL WP12028505AP $43.13

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

WP67003638 Whirlpool Closing Cam In Stock WPL WP67003638 $4.52

WP67003639 Whirlpool Refrigerator Closer In Stock WPL WP67003639 $42.09

WPW10165425 Whirlpool Bimetal Defrost Thermos In Stock WPL WPW10165425 $32.98

WPW10277025 Whirlpool Refrigerator Housing Backorder WPL WPW10277025 $54.90

W10917988 Whirlpool Refrigerator Door Hinge Backorder WPL W10917988 $37.30

W10918113 Whirlpool Refrigerator Door Hinge Backorder WPL W10918113 $41.43

W10918164 Whirlpool Refrigerator Door Hinge Backorder WPL W10918164 $49.19

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $44.85

WP67003637 Whirlpool Dairy Door In Stock WPL WP67003637 $44.73

WP67005149 Whirlpool Roller In Stock WPL WP67005149 $10.76

WPW10196393 Whirlpool Control Damper In Stock WPL WPW10196393 $93.06

CLIP, EVAP. MOTOR WPL 13058002 Contact Us For Availability

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $10.41

W11592374 Whirlpool Refrigerator Top Door Hin In Stock WPL W11592374 $10.89

WP67001279 Whirlpool Refrigerator Dairy Tray Backorder WPL WP67001279 $48.97

Screw WPL 12992101 Contact Us For Availability

12587703W Whirlpool Refrigerator Cover Backorder WPL 12587703W $10.76

W11478401 Whirlpool Refrigerator Housing Backorder WPL W11478401 $88.31

WP12227303WD Whirlpool Refrigerator Crisper B Backorder WPL WP12227303WD $44.45

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $3.70

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $4.52

WPW10169124 Whirlpool Refrigerator Grommet In Stock WPL WPW10169124 $4.52

COVER, CORNER (BISCUIT) WPL 12587703C Contact Us For Availability

18

A3076901 Whirlpool Refrigerator Plug Backorder WPL A3076901 $5.53

18

WPD7813010 Whirlpool Refrigerator Wire Harnes In Stock WPL WPD7813010 $23.36

18

WPW10346420 Whirlpool Refrigerator Condenser In Stock WPL WPW10346420 $115.08

19

10547003 Whirlpool Refrigerator Dryer Clip Backorder WPL 10547003 $4.59

19

WPM0114003 Whirlpool Microwave Speed Clip Cla Backorder WPL WPM0114003 $4.59

20

8201515 Whirlpool Refrigerator Motor and Gear In Stock WPL 8201515 $67.68

20

W10273463 Whirlpool Refrigerator Ladder Backorder WPL W10273463 $11.38

20

WPW10292802 Whirlpool Refrigerator Drip Tray In Stock WPL WPW10292802 $69.65

21

W10251969 Whirlpool Refrigerator Ladder Backorder WPL W10251969 $11.51

21

WP33001882 Whirlpool Screw In Stock WPL WP33001882 $27.52

22

12001919 Whirlpool Refrigerator Evaporator Re Backorder WPL 12001919 $194.96

22

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

23

W11176463 Whirlpool Refrigerator Water Tube In Stock WPL W11176463 $44.76

23

Dam (Left Side) WPL 12225602 Contact Us For Availability

23

Dam (Right Side) WPL 12225702 Contact Us For Availability

24

12918001 Whirlpool Refrigerator Funnel Backorder WPL 12918001 $7.69

24

W11613295 Whirlpool Condenser Motor In Stock WPL W11613295 $50.82

24

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $27.11

25

W11673433 Whirlpool Clip Backorder WPL W11673433 $62.75

25

WPW10171529 Whirlpool Refrigerator Ice Pan In Stock WPL WPW10171529 $63.96

25

WPW10330993 Whirlpool Refrigerator Bracket In Stock WPL WPW10330993 $59.75

26

WPW10234024 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10234024 $176.20

26

Fiber, Acoustic WPL 12820505 Contact Us For Availability

W10208592 Whirlpool Refrigerator Valve Cover Backorder WPL W10208592 $33.53

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $15.50

WPW10280608 Whirlpool Refrigerator Bracket Backorder WPL WPW10280608 $36.87

WPW10280613 Whirlpool Refrigerator Bracket Backorder WPL WPW10280613 $36.87

28

W10160407 Whirlpool Refrigerator Compressor In Stock WPL W10160407 $328.61

28

W11658402 Whirlpool Drawer Slide Rail In Stock WPL W11658402 $75.69

29

WPW10284684 Whirlpool Refrigerator Bracket In Stock WPL WPW10284684 $15.24

29

WPW10284685 Whirlpool Refrigerator Bracket In Stock WPL WPW10284685 $15.34

29

Clip, Evaporator WPL 10623002 Contact Us For Availability

30

67006434 Whirlpool Axle Pin In Stock WPL 67006434 $3.70

30

WP489474 Whirlpool Refrigerator Screw Backorder WPL WP489474 $2.75

31

12999501 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999501 $35.59

31

12999502 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999502 $36.00

31

W11556315 Whirlpool Shroud In Stock WPL W11556315 $30.01

32

EXTENSION, BASEPAN WPL W10206337 Contact Us For Availability

13000002WD Whirlpool Refrigerator Door Hinge Backorder WPL 13000002WD $55.95

W10206339 Whirlpool Fastener Backorder WPL W10206339 $4.70

W10918168 Whirlpool Refrigerator Door Hinge Backorder WPL W10918168 $28.99

W11489993 Whirlpool Refrigerator Rail In Stock WPL W11489993 $8.97

W11489994 Whirlpool Refrigerator Rail In Stock WPL W11489994 $8.97

34

67005680 Whirlpool Refrigerator Condenser Gro Backorder WPL 67005680 $10.76

34

W10157765 Whirlpool Refrigerator Deflector Backorder WPL W10157765 $30.25

100

D7824706Q Whirlpool Refrigerator Ice Maker As In Stock WPL D7824706Q $78.49

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $29.35

285006 Whirlpool Spray In Stock WPL 285006 $29.65

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.94

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $28.40

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $34.75

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.99

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.02

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (BLACK (UNCUT)) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

REFRIGERANT CHARGE (5.25 OZS. (R-134A)) WPL NP Contact Us For Availability

CLEANER, 10 OZ. STAINLESS STEEL WPL 31462 Contact Us For Availability

PAINT, BULK (1 QT.) (BISCUIT (UNCUT)) WPL 4392900 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability
