Model Whirlpool 106.58034803 Refrigerator (Kenmore 10658034803) – Common Parts &amp; Diagrams

1

WP2198573 Whirlpool Refrigerator Ice Bin Backorder WPL WP2198573 $145.68

1

Freezer Door Assembly (White) WPL W10142247 Contact Us For Availability

1

FOR FIELD INSTALLABLE ICEMAKER REPAIR PARTS L WPL N/P Contact Us For Availability

1A

Freezer Door Assembly (Biscuit) WPL W10142249 Contact Us For Availability

1B

Freezer Door Assembly (Black) WPL W10142248 Contact Us For Availability

1C

Refrigerator Door Panel WPL W10298960 Contact Us For Availability

1D

Door Panel (Stainless) WPL W10173632 Contact Us For Availability

2

W11497323 Whirlpool Snack Pan Backorder WPL W11497323 $129.98

2

W11700295 Whirlpool Refrigerator Retainer Backorder WPL W11700295 $8.42

2

WP2256101 Whirlpool Dairy Door In Stock WPL WP2256101 $44.17

2

Refrigerator Ice Maker Fill Tube WPL 2303216 Contact Us For Availability

2

Refrigerator Door Handle WPL W10127818 Contact Us For Availability

2

Refrigerator Escutcheon Control Meat Pan Asse WPL W10175967 Contact Us For Availability

2A

Refrigerator Handle Assembly (Off-White) WPL W10127820 Contact Us For Availability

2B

Refrigerator Door Handle WPL W10127819 Contact Us For Availability

2C

Refrigerator Handle WPL W10155177 Contact Us For Availability

3

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $20.89

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

3

WP2317240 Whirlpool Refrigerator Ice Auger Backorder WPL WP2317240 $64.07

3

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

3

Refrigerator Deli Drawer Temperature Control WPL 2182757 Contact Us For Availability

4

2313359 Whirlpool Refrigerator Air Duct Backorder WPL 2313359 $45.80

4

WPW10224328 Whirlpool Refrigerator Spring In Stock WPL WPW10224328 $34.33

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

4

Refrigerator Ice Dispenser Auger Washer WPL 2258220 Contact Us For Availability

4

Refrigerator Wire Harness WPL W10209454 Contact Us For Availability

4

Refrigerator Louver WPL 2257741 Contact Us For Availability

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $7.69

5

WP2255411 Whirlpool Refrigerator Clip In Stock WPL WP2255411 $12.22

5

Refrigerator Freezer Air Duct WPL 2198580 Contact Us For Availability

6

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $93.38

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $7.65

6

WP2315562 Whirlpool Refrigerator Thermostat In Stock WPL WP2315562 $56.04

6

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $19.51

6

WPW10288153 Whirlpool Refrigerator Screw In Stock WPL WPW10288153 $3.02

6

Refrigerator Ice Crusher Blade Cover WPL 2317248 Contact Us For Availability

7

2159074 Whirlpool Door Gasket Seal In Stock WPL 2159074 $161.37

7

2181741 Whirlpool Refrigerator Slide Backorder WPL 2181741 $42.09

7

W10278733 Whirlpool Refrigerator Blade Backorder WPL W10278733 $33.73

7

MOTOR-EVAP In Stock WPL W11780227 $76.45

7

WP2156022 Whirlpool Refrigerator Door Trim In Stock WPL WP2156022 $39.73

7

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.64

7

Refrigerator Freezer Drawer Slide Rail, Right WPL 2301289 Contact Us For Availability

7

Refrigerator Ladder WPL 2319866 Contact Us For Availability

7A

2159082 Whirlpool Refrigerator Door Gasket Bl In Stock WPL 2159082 $141.10

7A

Refrigerator Freezer Drawer Slide Rail, Left WPL 2301290 Contact Us For Availability

7B

W10136735 Whirlpool Refrigerator Door Gasket In Stock WPL W10136735 $130.88

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

8

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

8

Refrigerator Suction Line WPL 2205765 Contact Us For Availability

8

Refrigerator Door Hinge Bushing WPL 2301049 Contact Us For Availability

8A

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $3.88

9

2161466 Whirlpool Refrigerator Slide Backorder WPL 2161466 $10.76

9

W10759522 Whirlpool Screw Backorder WPL W10759522 $2.51

9

WP2304241 Whirlpool Refrigerator Gasket Backorder WPL WP2304241 $29.17

9

WPW10307490 Whirlpool Door Trim Assembly In Stock WPL WPW10307490 $8.60

9

Refrigerator Ice Crusher Fixed Blade WPL 2257020 Contact Us For Availability

9

Refrigerator Screw WPL W10191952 Contact Us For Availability

9C

WP2206670B Whirlpool Dispenser Tray In Stock WPL WP2206670B $21.39

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $4.61

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $33.73

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $3.70

WP2256085 Whirlpool Refrigerator Retainer Backorder WPL WP2256085 $13.73

WPW10159659 Whirlpool Refrigerator Crisper Dr Backorder WPL WPW10159659 $176.24

WPW10272168 Whirlpool Refrigerator Water Fill Backorder WPL WPW10272168 $34.07

Refrigerator Door Cam (Silver) WPL 2323535 Contact Us For Availability

2317239 Whirlpool Refrigerator Blade Block Backorder WPL 2317239 $4.78

W11225843 Whirlpool Refrigerator Wire Harness Backorder WPL W11225843 $68.64

WP2198587 Whirlpool Refrigerator Cover Backorder WPL WP2198587 $34.28

WP488488 Whirlpool Refrigerator Screw Backorder WPL WP488488 $3.70

WP489483 Whirlpool Screw In Stock WPL WP489483 $4.58

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $32.06

WP8281227 Whirlpool Screw In Stock WPL WP8281227 $4.58

WPW10152853 Whirlpool Refrigerator Dispenser Backorder WPL WPW10152853 $37.97

Refrigerator Fresh-Food Control Light Pipe WPL 2179920 Contact Us For Availability

11A

W10152855 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152855 $37.70

11B

WPW10152854 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152854 $28.31

11C

W10155161 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10155161 $62.70

2161306 Whirlpool Refrigerator Arm Pivot Backorder WPL 2161306 $4.72

2323534 Whirlpool Refrigerator Bracket Backorder WPL 2323534 $62.75

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $30.18

WP2155789 Whirlpool Refrigerator Gasket Backorder WPL WP2155789 $3.70

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $7.37

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $30.36

WPW10151374 Whirlpool Refrigerator Diffuser In Stock WPL WPW10151374 $37.19

WPW10272161 Whirlpool Refrigerator Stripper A Backorder WPL WPW10272161 $32.96

Refrigerator Bracket WPL W10185570 Contact Us For Availability

Refrigerator Crisper Drawer Humidity Control WPL W10159682 Contact Us For Availability

12A

Refrigerator Freezer Door Stop WPL 2323534B Contact Us For Availability

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $36.71

W10138965 Whirlpool Refrigerator Door Hinge Backorder WPL W10138965 $33.18

W10278731 Whirlpool Refrigerator Blade Backorder WPL W10278731 $33.71

WP2171157 Whirlpool Shelf Trim Backorder WPL WP2171157 $35.54

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $5.44

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

Refrigerator Electronic Control Board WPL W10259855 Contact Us For Availability

Refrigerator Crisper Drawer Cover Trim WPL W10170984 Contact Us For Availability

2150331 Whirlpool Refrigerator Wire Cover Backorder WPL 2150331 $11.11

4388500 Whirlpool Refrigerator Gasket Backorder WPL 4388500 $29.77

W11457217 Whirlpool Refrigerator Rocker Switc In Stock WPL W11457217 $15.76

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.80

WP3400012 Whirlpool Refrigerator Screw Backorder WPL WP3400012 $2.51

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

Refrigerator Filler WPL 2304846 Contact Us For Availability

2161307 Whirlpool Refrigerator Rod Backorder WPL 2161307 $8.13

2179350 Whirlpool Refrigerator Deflector Backorder WPL 2179350 $30.20

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $34.28

W11629974-includeCORE Whirlpool W11629974 Ref Backorder WPL W11629974-includeCORE $237.68

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $4.61

Refrigerator Evaporator Cover WPL 2206314 Contact Us For Availability

4389654 Whirlpool Screw Backorder WPL 4389654 $9.59

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

W11629923 Whirlpool Coupling In Stock WPL W11629923 $12.72

WP2255720 Whirlpool Refrigerator Ice Maker Do Backorder WPL WP2255720 $45.68

WPW10276792 Whirlpool Refrigerator Water Rese In Stock WPL WPW10276792 $66.54

Refrigerator Door Handle End Cap (White) WPL W10127828 Contact Us For Availability

16A

Refrigerator End Cap Handle (Off-White) WPL W10127830 Contact Us For Availability

16B

Refrigerator End Cap Handle WPL W10127829 Contact Us For Availability

16C

Refrigerator End Cap Handle WPL W10162679 Contact Us For Availability

W10267047 Whirlpool Screw Backorder WPL W10267047 $9.59

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $2.89

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $4.56

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $38.67

Refrigerator Ice Maker Cover Bracket, Right WPL 2212321 Contact Us For Availability

Refrigerator Ice Maker Mounting Bracket WPL 2303583 Contact Us For Availability

17A

W10152860 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152860 $36.38

17B

WPW10152859 Whirlpool Refrigerator Dispenser Backorder WPL WPW10152859 $36.18

17C

Refrigerator Dispenser Lever WPL W10155162 Contact Us For Availability

4388358 Whirlpool Refrigerator Support Bracke Backorder WPL 4388358 $12.65

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

W11239891 Whirlpool Refrigerator Light Lens Backorder WPL W11239891 $40.41

W11566763 Whirlpool Fitting In Stock WPL W11566763 $21.01

WP2179243 Whirlpool Refrigerator Pan Trim Backorder WPL WP2179243 $36.23

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $2.51

2006254 Whirlpool Refrigerator Screw Backorder WPL 2006254 $8.09

W10136850 Whirlpool Refrigerator Front Cover Backorder WPL W10136850 $80.51

W11512417 Whirlpool Drain Connector In Stock WPL W11512417 $13.03

WP2187467 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187467 $51.40

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $196.39

WPW10141748 Whirlpool Refrigerator Glass Shel Backorder WPL WPW10141748 $181.67

Refrigerator Ice Bin Release Button WPL 2317267 Contact Us For Availability

Screw WPL 488280 Contact Us For Availability

19C

Refrigerator Dispenser Cover WPL W10139842 Contact Us For Availability

W10777924 Whirlpool Refrigerator Wine Rack Backorder WPL W10777924 $8.47

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $3.70

Spacer WPL 625834 Contact Us For Availability

Refrigerator Defrost Clip WPL 2161324 Contact Us For Availability

21

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $59.32

21

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

21

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

WP2188919 Whirlpool Refrigerator Holder In Stock WPL WP2188919 $3.70

WP2304673 Whirlpool Refrigerator Bracket Backorder WPL WP2304673 $6.35

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $4.56

23

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $16.05

23

Thermador Refrigerator Ice Container Wiper WPL 2317243 Contact Us For Availability

24

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.01

24

Refrigerator Cover WPL W10173569 Contact Us For Availability

25

2315398 Whirlpool Refrigerator Slide Backorder WPL 2315398 $4.78

25

2317250 Whirlpool Refrigerator Divider Backorder WPL 2317250 $11.09

25

WP2321703 Whirlpool Refrigerator Electronic C Backorder WPL WP2321703 $143.50

26A

Refrigerator Door Cam WPL 2223751 Contact Us For Availability

27

2172931 Whirlpool Refrigerator Shield Backorder WPL 2172931 $34.33

27

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $2.51

27

Refrigerator Auger Motor Cover WPL 2322488 Contact Us For Availability

28

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $5.67

28

WPW10121138 Whirlpool Refrigerator Water Filt In Stock WPL WPW10121138 $56.98

28

Refrigerator Light Lens WPL 2198589 Contact Us For Availability

29

WP2323198 Whirlpool Refrigerator Heater In Stock WPL WP2323198 $30.17

29

Refrigerator Light Lens WPL 2212340 Contact Us For Availability

30

WP2198641 Whirlpool Refrigerator Ice Maker Co In Stock WPL WP2198641 $2.51

30

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

30C

WP2260518MG Whirlpool Water Filter Cap In Stock WPL WP2260518MG $30.29

31

WP2315559 Whirlpool Motor Coupling In Stock WPL WP2315559 $29.72

31

WP489500 Whirlpool Refrigerator Screw Backorder WPL WP489500 $2.51

31

WPW10119935 Whirlpool Refrigerator Socket Backorder WPL WPW10119935 $37.61

32

Refrigerator Ladder WPL 2198609 Contact Us For Availability

32A

Refrigerator Shelf Bracket WPL 2198610 Contact Us For Availability

33

2260503W Whirlpool Refrigerator Button Backorder WPL 2260503W $13.30

33

2303234 Whirlpool Refrigerator Shield Backorder WPL 2303234 $32.06

33C

2260503MG Whirlpool Refrigerator Button Backorder WPL 2260503MG $12.11

36

WP2203770 Whirlpool Refrigerator Door Hinge Backorder WPL WP2203770 $33.56

37

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $9.59

41

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

44

Refrigerator Fitting WPL W10271542 Contact Us For Availability

100

W11512149 Whirlpool Ice Maker Assembly In Stock WPL W11512149 $78.53

100

WPW10170986 Whirlpool Refrigerator Ice Contai Backorder WPL WPW10170986 $270.09

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $30.25

350930 Whirlpool White Spray Paint In Stock WPL 350930 $21.41

350942 Whirlpool Spray Paint Backorder WPL 350942 $50.33

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $7.21

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $43.92

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.92

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $7.21

8171357 Whirlpool Spray Nozzle Backorder WPL 8171357 $46.21

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $35.96

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $37.79

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $39.53

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $43.61

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $64.36

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $24.56

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.82

Touch-Up WPL 80051 Contact Us For Availability

Refrigerator Service Valve WPL 978029 Contact Us For Availability

Refrigerator Vinyl Tape WPL 479502 Contact Us For Availability

Appliance Porcelain Touch-Up Paint, 1-qt (Whi WPL 799344 Contact Us For Availability

Refrigerator Ice Maker Torx Key Wrench WPL 1117510 Contact Us For Availability
