Model Whirlpool KFIS25XVBL4 REFRIGERATOR – Common Parts &amp; Diagrams

1

W11033333 Whirlpool Glass Shelf Backorder WPL W11033333 $127.18

1

WPW10300025 Whirlpool Refrigerator Ice Mold Backorder WPL WPW10300025 $90.86

1

WPW10324090 Whirlpool Refrigerator Ice Bin In Stock WPL WPW10324090 $212.66

2

W10121282 Whirlpool Refrigerator Insert Backorder WPL W10121282 $10.16

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $35.43

2

WPW10175514 Whirlpool Refrigerator Shut-Off A Backorder WPL WPW10175514 $42.71

2

TRIM, CRISPER WPL W10231484 Contact Us For Availability

3

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $8.86

3

W10121281 Whirlpool Refrigerator Shroud Backorder WPL W10121281 $26.21

3

W10327050 Whirlpool Refrigerator Cup Fill Backorder WPL W10327050 $33.65

3

WP67003405 Whirlpool Pivot Block In Stock WPL WP67003405 $3.70

3

Board, L.V. WPL 13053103SP Contact Us For Availability

3

FRONT, CRISPER WPL 12909404SP Contact Us For Availability

4

12921801 Whirlpool Refrigerator Light Cover Backorder WPL 12921801 $10.76

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $7.69

4

W10318914 Whirlpool Refrigerator Ejector Arm Backorder WPL W10318914 $13.89

4

WP67006010 Whirlpool Refrigerator Shelf Trim Backorder WPL WP67006010 $87.59

4

WPW10162697 Whirlpool Refrigerator Motor Backorder WPL WPW10162697 $113.74

5

67005958 Whirlpool Refrigerator Top Hinge Cov Backorder WPL 67005958 $12.02

5

W11028221 Whirlpool Refrigerator Shaft In Stock WPL W11028221 $11.31

5

WP13005703B Whirlpool Refrigerator Chute Backorder WPL WP13005703B $182.90

5

WP13005703W Whirlpool Refrigerator Chute Backorder WPL WP13005703W $182.53

5

WP67005956 Whirlpool Refrigerator Cover Backorder WPL WP67005956 $12.06

5

WPW10119841 Whirlpool Cantilever Bin In Stock WPL WPW10119841 $44.91

5

WPW10122563 Whirlpool Refrigerator Stripper A Backorder WPL WPW10122563 $32.68

6

12981401B Whirlpool Refrigerator Filtration C Backorder WPL 12981401B $7.78

6

12981401W Whirlpool Refrigerator Cover Filter Backorder WPL 12981401W $7.78

6

W10390735 Whirlpool Refrigerator Tube Backorder WPL W10390735 $49.57

6

WP67001719 Whirlpool Refrigerator Track Backorder WPL WP67001719 $2.51

7

12961602 Whirlpool Refrigerator Wire Cover Backorder WPL 12961602 $39.14

7

67002329 Whirlpool Refrigerator Pantry Gasket Backorder WPL 67002329 $10.76

7

Grommet, Fan Motor WPL W10151687 Contact Us For Availability

7

SCREW-HANDLE WPL W10290759 Contact Us For Availability

8

12656202 Whirlpool Refrigerator Housing Backorder WPL 12656202 $52.78

8

628532 Whirlpool Refrigerator Thermostat Backorder WPL 628532 $40.53

8

W10356556 Whirlpool Refrigerator Divider Backorder WPL W10356556 $48.35

8

W11456069 Whirlpool Refrigerator Clamp In Stock WPL W11456069 $10.76

8

WP12924903 Whirlpool Refrigerator Freezer Bin Backorder WPL WP12924903 $67.98

8

Facade, Dispenser (Black) WPL W10184486 Contact Us For Availability

9

W10001240 Whirlpool Refrigerator Screw Backorder WPL W10001240 $5.65

9

W10829281 Whirlpool Refrigerator Screw Backorder WPL W10829281 $5.01

9

W11402525 Whirlpool Glass Shelf Backorder WPL W11402525 $118.14

9

WP8281196 Whirlpool Screw In Stock WPL WP8281196 $3.70

9

WPW10314515 Whirlpool Refrigerator Handle Backorder WPL WPW10314515 $122.50

12925404SP Whirlpool Refrigerator Bracket Backorder WPL 12925404SP $20.64

W11469652 Whirlpool Refrigerator Shield Backorder WPL W11469652 $10.76

W11592374 Whirlpool Refrigerator Top Door Hin Backorder WPL W11592374 $10.07

W11671282 Whirlpool Refrigerator Ice Auger Mo In Stock WPL W11671282 $65.49

WP12729123 Whirlpool Refrigerator Heater In Stock WPL WP12729123 $75.66

WP67003793 Whirlpool Refrigerator Temperature Backorder WPL WP67003793 $26.96

WPW10121440 Whirlpool Refrigerator Extension Backorder WPL WPW10121440 $28.80

Grille, Sump WPL W10187370 Contact Us For Availability

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

W10170831 Whirlpool Refrigerator Pad Backorder WPL W10170831 $34.28

W10170832 Whirlpool Refrigerator Pad Backorder WPL W10170832 $34.95

W10275942 Whirlpool Refrigerator Water Tube Backorder WPL W10275942 $43.13

W10308421 Whirlpool Refrigerator Evaporator C Backorder WPL W10308421 $102.86

WP67006380 Whirlpool Screw Backorder WPL WP67006380 $2.51

WPW10127427 Whirlpool Refrigerator Control In Stock WPL WPW10127427 $65.37

WPW10235357 Whirlpool Refrigerator Glide Asse Backorder WPL WPW10235357 $144.39

WPW10235370 Whirlpool Refrigerator Glide In Stock WPL WPW10235370 $108.35

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $2.51

WPW10119846 Whirlpool Refrigerator Door Bin S In Stock WPL WPW10119846 $46.57

WPW10194431 Whirlpool Start Device In Stock WPL WPW10194431 $58.28

WPW10197428 Whirlpool Start Device In Stock WPL WPW10197428 $40.46

WPW10235367 Whirlpool Refrigerator Glide Backorder WPL WPW10235367 $131.97

W10337647 Whirlpool Refrigerator Cover Backorder WPL W10337647 $13.74

W10874836 Whirlpool Endcap Assembly Left Hand In Stock WPL W10874836 $16.87

W11676504 Whirlpool Insert Assembly Backorder WPL W11676504 $12.77

WP2313326 Whirlpool Refrigerator Switch Backorder WPL WP2313326 $7.94

WPW10337634 Whirlpool Refrigerator Cover Backorder WPL WPW10337634 $13.74

W11434460 Whirlpool Refrigerator Housing Backorder WPL W11434460 $12.39

WP12722813W Whirlpool Refrigerator Mullion Ra Backorder WPL WP12722813W $111.55

WP489349 Whirlpool Refrigerator Screw In Stock WPL WP489349 $2.51

WP67004515 Whirlpool Crisper Drawer In Stock WPL WP67004515 $87.12

WPW10312691 Whirlpool Refrigerator Air Baffle In Stock WPL WPW10312691 $116.63

13000002WD Whirlpool Refrigerator Door Hinge Backorder WPL 13000002WD $53.88

W10884713 Whirlpool Refrigerator Wire Harness In Stock WPL W10884713 $70.43

W10918168 Whirlpool Refrigerator Door Hinge Backorder WPL W10918168 $27.61

WP12227305WD Whirlpool Drawer Support Backorder WPL WP12227305WD $42.82

16

W10251965 Whirlpool Refrigerator Ladder Backorder WPL W10251965 $11.38

16

WP67006390 Whirlpool Refrigerator High Voltag In Stock WPL WP67006390 $88.47

12587703W Whirlpool Refrigerator Cover Backorder WPL 12587703W $10.76

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $27.71

67003485 Whirlpool Refrigerator Corner Cover Backorder WPL 67003485 $10.76

WPW10329866 Whirlpool Frame In Stock WPL WPW10329866 $112.59

18

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

18

W11592375 Whirlpool Door Hinge Backorder WPL W11592375 $10.07

18

WP67006704 Whirlpool Glass Crisper Cover In Stock WPL WP67006704 $119.56

12996601 Whirlpool Refrigerator Bushing Clip Backorder WPL 12996601 $6.92

W10273464 Whirlpool Refrigerator Ladder Backorder WPL W10273464 $11.03

W11395888 Whirlpool Refrigerator Bypass Filte In Stock WPL W11395888 $24.32

W11658402 Whirlpool Drawer Slide Rail In Stock WPL W11658402 $74.88

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

WPW10515762 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10515762 $37.39

WPW10515763 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10515763 $37.73

67006564 Whirlpool Refrigerator Screw Backorder WPL 67006564 $2.51

W10251966 Whirlpool Refrigerator Ladder Backorder WPL W10251966 $28.80

W11547653 Whirlpool Refrigerator Drip Tray Backorder WPL W11547653 $29.39

WPW10121434 Whirlpool Refrigerator Insert Backorder WPL WPW10121434 $9.86

WPW10312696 Whirlpool Water Inlet Valve In Stock WPL WPW10312696 $113.26

12999501 Whirlpool Refrigerator Hinge Shim In Stock WPL 12999501 $33.89

12999502 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999502 $34.28

WPW10284682 Whirlpool Refrigerator Bracket Backorder WPL WPW10284682 $47.84

WPW10284683 Whirlpool Refrigerator Bracket In Stock WPL WPW10284683 $72.92

WPW10309869 Whirlpool Refrigerator Cover Backorder WPL WPW10309869 $39.13

W10709795 Whirlpool Refrigerator Screw Backorder WPL W10709795 $7.81

W11536253 Whirlpool Refrigerator Evaporator Backorder WPL W11536253 $105.14

WPW10243392 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243392 $33.09

WPW10243393 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243393 $35.74

WPW10534153 Whirlpool Refrigerator Black Kick In Stock WPL WPW10534153 $55.37

WPW10534154 Whirlpool Refrigerator Front Gril Backorder WPL WPW10534154 $55.04

23

12987301 Whirlpool Refrigerator Cover Backorder WPL 12987301 $7.91

23

67006428 Whirlpool Refrigerator Lid, High Vol Backorder WPL 67006428 $26.21

23

WP67006415 Whirlpool Refrigerator Screw Backorder WPL WP67006415 $3.70

W10918113 Whirlpool Refrigerator Door Hinge Backorder WPL W10918113 $39.45

W10918164 Whirlpool Refrigerator Door Hinge Backorder WPL W10918164 $46.85

W11613295 Whirlpool Condenser Motor In Stock WPL W11613295 $50.00

WP67005864 Whirlpool Humidity Control In Stock WPL WP67005864 $3.70

W10118193 Whirlpool Refrigerator Cover Backorder WPL W10118193 $28.80

W11673433 Whirlpool Clip Backorder WPL W11673433 $59.77

W11686675 Whirlpool Screw Backorder WPL W11686675 $8.11

WP67003795 Whirlpool Refrigerator Temperature Backorder WPL WP67003795 $3.70

26

W10850438 Whirlpool Refrigerator Evaporator M Backorder WPL W10850438 $160.43

26

WP67003531 Whirlpool Drawer Assembly In Stock WPL WP67003531 $91.17

26

CABINET (NOT A SERVICABLE PART) WPL NP Contact Us For Availability

27

W11498983 Whirlpool Refrigerator Knob Backorder WPL W11498983 $11.14

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $13.98

28

W10854958 Whirlpool Refrigerator Screw Backorder WPL W10854958 $2.71

28

WP67005930 Whirlpool Refrigerator Pantry Draw In Stock WPL WP67005930 $46.10

29

WPW10326469 Whirlpool Drawer Slide Rail In Stock WPL WPW10326469 $11.36

29

GASKET, HV CONTROL WPL 12957801 Contact Us For Availability

30

WP13062602 Whirlpool Refrigerator Support Backorder WPL WP13062602 $28.80

30

WPW10270394 Whirlpool Refrigerator Back Cover Backorder WPL WPW10270394 $77.72

31

W10619951 Whirlpool Drain Tube with Grommet In Stock WPL W10619951 $24.50

31

W11556315 Whirlpool Shroud Backorder WPL W11556315 $27.80

31

WP12642303WD Whirlpool Refrigerator Drawer Su Backorder WPL WP12642303WD $43.11

32

WP98165 Whirlpool Screw Backorder WPL WP98165 $2.51

33

WP67002759 Whirlpool Refrigerator Divider In Stock WPL WP67002759 $27.10

33

Fiber, Acoustic WPL 12820505 Contact Us For Availability

34

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $3.70

34

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $3.70

35

WPW10312695-includeCORE Whirlpool WPW10312695 Backorder WPL WPW10312695-includeCORE $197.16

35

WPW10334458 Whirlpool Refrigerator Connector Backorder WPL WPW10334458 $8.62

100

WPW10300024 Whirlpool Ice Maker In Stock WPL WPW10300024 $122.14

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability
