GE JB860EJ4ES Electric Range Parts List

3

BACKGUARD SHIELD HEAT GEN WB34X28565 Contact Us For Availability

View on Model

19

WB24X25013 GE Range Control Infinite Switch In Stock GEN WB24X25013 $39.52

View on Model

22

CONTROL INFINITE SWITCH GEN WB24T10029 Contact Us For Availability

View on Model

23

SWITCH ROTARY GEN WB24X25302 Contact Us For Availability

View on Model

29

WB03X24965 GE Range Infinite Control Knob In Stock GEN WB03X24965 $14.64

View on Model

32

WB27T10668 GE Range Light Indicator In Stock GEN WB27T10668 $7.12

View on Model

33

WB25X20005 GE Range Light Indicator Pilot In Stock GEN WB25X20005 $5.20

View on Model

34

WB25X24023 GE Range Indicator Light Lens In Stock GEN WB25X24023 $4.11

View on Model

43

HUB BLADE ASM GEN WB02X26501 Contact Us For Availability

View on Model

51

WB62X25972 GE Cooktop Glass Maintop Assembly Backorder GEN WB62X25972 $787.30

View on Model

53

WB30X20871 GE Range Radiant 6" Warmer Element Backorder GEN WB30X20871 $86.66

View on Model

55

BADGE ASM GEN WB02X29479 Contact Us For Availability

View on Model

56

WB30T10145 GE Oven Radiant Surface Element In Stock GEN WB30T10145 $94.08

View on Model

57

WB30X24111 GE Oven Dual Radiant Element In Stock GEN WB30X24111 $82.14

View on Model

58

WB30T10130 GE Oven Radiant Surface Element In Stock GEN WB30T10130 $119.38

View on Model

61

GASKET OVEN LIGHT GEN WB04T10021 Contact Us For Availability

View on Model

62

WB02X20940 GE Range Radiant Element Bracket Backorder GEN WB02X20940 $5.20

View on Model

64

BRACKET RADIANT ELEMENT GEN WB02X20902 Contact Us For Availability

View on Model

91

PIN RANGETOP HINGE GEN WB10T10116 Contact Us For Availability

View on Model

102

WB35K10025 GE Oven Side Door Insulation Backorder GEN WB35K10025 $5.20

View on Model

111

WB04T10076 GE Oven Door Gasket Backorder GEN WB04T10076 $31.02

View on Model

113

WB02T10371 GE Oven Retainer Insulation Backorder GEN WB02T10371 $45.16

View on Model

133

DOOR BUMPER GEN WB01T10022 Contact Us For Availability

View on Model

136

HANDLE AND END CAP ASM GEN WB15X24967 Contact Us For Availability

View on Model

140

FRAME DOOR SIDE GEN WB56X21397 Contact Us For Availability

View on Model

143

BRACKET DOOR HANDLE (BK) GEN WB34X25638 Contact Us For Availability

View on Model

150

LATCH ASM GEN WB10X25238 Contact Us For Availability

View on Model

218

COVER TERMINAL BLOCK GEN WB02T10564 Contact Us For Availability

View on Model

221

SIDE PANEL GY GEN WB56X28883 Contact Us For Availability

View on Model

231

WB35T10170 GE Range Insulation Wrapper Backorder GEN WB35T10170 $53.44

View on Model

237

HIDDEN BAKE INSULATION GEN WB35T10022 Contact Us For Availability

View on Model

241

WB48T10076 GE Oven Rack Backorder GEN WB48T10076 $53.78

View on Model

253

WB21X22134 GE Oven Sensor Assembly In Stock GEN WB21X22134 $14.04

View on Model

254

WB08T10045 GE Oven G9 Halogen Lamp In Stock GEN WB08T10045 $7.69

View on Model

255

WB17T10011 GE Oven Terminal Block In Stock GEN WB17T10011 $44.65

View on Model

256

OVEN LAMP HOLDER ASM GEN WB08T10002 Contact Us For Availability

View on Model

258

LAMP HALOGEN ASM GEN WB25X24909 Contact Us For Availability

View on Model

259

OVEN BULB LENS GEN WB25T10002 Contact Us For Availability

View on Model

260

OV LAMP LENS GEN WB25T10013 Contact Us For Availability

View on Model

261

WB24T10147 GE Oven SPDT Light Switch In Stock GEN WB24T10147 $11.73

View on Model

266

BASE RAIL GEN WB02T10353 Contact Us For Availability

View on Model

267

BASE RAIL GEN WB02T10352 Contact Us For Availability

View on Model

268

WB02T10578 GE Oven Anti-Tip Bracket Assembly In Stock GEN WB02T10578 $21.72

View on Model

269

BRACKET STRAIN RELIEF GEN WB02T10542 Contact Us For Availability

View on Model

270

WB27X25594 GE Oven Relay Board In Stock GEN WB27X25594 $63.40

View on Model

272

SIDE PANEL SUPPORT GEN WB02T10034 Contact Us For Availability

View on Model

277

RECEIVER HINGE GEN WB10T10083 Contact Us For Availability

View on Model

281

WB10X25243 GE Range Left Door Hinge Backorder GEN WB10X25243 $21.96

View on Model

296

LEG LEVELER GEN WB02X10521 Contact Us For Availability

View on Model

338

WB56X22160 GE Stove Inner Door Glass Assembly Backorder GEN WB56X22160 $312.68

View on Model

411

GASKET OVN DOOR GEN WB04T10077 Contact Us For Availability

View on Model

438

WB56T10244 GE Oven Upper Window Pack Assembly Backorder GEN WB56T10244 $79.82

View on Model

441

WB48T10072 GE Range Rack Backorder GEN WB48T10072 $66.50

View on Model

453

SENSOR ASM GEN WB23T10015 Contact Us For Availability

View on Model

477

WB10T10104 GE Range Hinge Assembly Backorder GEN WB10T10104 $73.74

View on Model

477

WB10T10105 GE Range Hinge Assembly Backorder GEN WB10T10105 $73.74

View on Model

481

WB10T10100 GE Oven Right-Hand Hinge Receiver Backorder GEN WB10T10100 $34.40

View on Model

481

WB10T10101 GE Oven Upper Receiver Hinge Backorder GEN WB10T10101 $26.72

View on Model

511

MOTOR CONVX GEN WB26X26500 Contact Us For Availability

View on Model

578

WB27T10662 GE Oven Capacitor Backorder GEN WB27T10662 $5.20

View on Model

602

HARNESS WIRE UI COM GEN WB18X25225 Contact Us For Availability

View on Model

604

LEAD WIRE 14 GA GN GEN WB18T10470 Contact Us For Availability

View on Model

696

SCR 10-32 TR3 PNT 1.41 S GEN WB01T10137 Contact Us For Availability

View on Model

919

SPACER DOOR GEN WB02X25272 Contact Us For Availability

View on Model

929

WB02T10026 GE Oven Strike Maintop Backorder GEN WB02T10026 $5.20

View on Model

962

CLIP CABLE GEN WB02X25982 Contact Us For Availability

View on Model

1003

SCREW 10-32 TR T GEN WB01T10008 Contact Us For Availability

View on Model

1005

SCR 8-18 AB TRT20NBS 5/8 GEN WB01X21650 Contact Us For Availability

View on Model
