Model Whirlpool ID3CHEXVQ00 REFRIGERATOR – Common Parts &amp; Diagrams

1

BIN, UPPER CRUSHER WPL 2223317 Contact Us For Availability

1

LINER (NOT A SERVICEABLE PART) WPL NP Contact Us For Availability

1

DOOR, FREEZER (WHITE) WPL W10201420W Contact Us For Availability

1A

DOOR, FREEZER (STAINLESS) WPL W10201420S Contact Us For Availability

2

2223524 Whirlpool Escutcheon Backorder WPL 2223524 $28.80

2

WP2179343 Whirlpool Refrigerator Control Body In Stock WPL WP2179343 $13.98

2

WP2223506 Whirlpool Refrigerator Light Lens Backorder WPL WP2223506 $52.72

2

WPW10130497 Whirlpool Refrigerator Crush Bin Backorder WPL WPW10130497 $86.34

2

WPW10139483 Whirlpool Refrigerator Condenser In Stock WPL WPW10139483 $28.58

3

2223339 Whirlpool Slide Backorder WPL 2223339 $35.30

3

WP2179342 Whirlpool Refrigerator Slide Backorder WPL WP2179342 $10.08

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

3

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $3.70

3

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

3

DOOR, DAIRY WPL 2255421 Contact Us For Availability

3

ASSEMBLY, CONDENSER WPL W10131059 Contact Us For Availability

3

SCOOP, AIR WPL 2223298 Contact Us For Availability

4

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

4

WPA3073101 Whirlpool Light Bulb In Stock WPL WPA3073101 $5.97

4

WASHER, AUGER WPL 2258220 Contact Us For Availability

5

3400524 Whirlpool Refrigerator Screw Backorder WPL 3400524 $7.80

5

W11497323 Whirlpool Snack Pan In Stock WPL W11497323 $109.31

5

W11545866 Whirlpool Refrigerator Clip Backorder WPL W11545866 $4.39

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

5

WP2188820 Whirlpool Refrigerator Thermistor In Stock WPL WP2188820 $18.70

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $7.69

5

WPW10170540 Whirlpool Screw In Stock WPL WPW10170540 $4.58

5

WPW10202821 Whirlpool Refrigerator Handle Backorder WPL WPW10202821 $165.66

5

WPW10210603 Whirlpool Refrigerator Inlet Valv Backorder WPL WPW10210603 $106.74

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

6

WP2171157 Whirlpool Shelf Trim Backorder WPL WP2171157 $31.93

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $7.21

6

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $19.51

6

COVER, CRUSHER WPL 2317248 Contact Us For Availability

6

LADDER, SHELF WPL 2319866 Contact Us For Availability

7

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $108.46

7

GASKET, DOOR (MIST BEIGE) WPL 2223850 Contact Us For Availability

7A

GASKET, DOOR (BLACK) WPL 2223912 Contact Us For Availability

8

2171846 Whirlpool Refrigerator Release Valve Backorder WPL 2171846 $10.76

8

2223545 Whirlpool Refrigerator Shim Backorder WPL 2223545 $31.71

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

8

WPW10307490 Whirlpool Door Trim Assembly In Stock WPL WPW10307490 $8.60

8

EYELET, ROLLER WPL 2174478 Contact Us For Availability

9

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $3.70

9

WP2206670W Whirlpool Dispenser Tray In Stock WPL WP2206670W $30.46

9

WP2224173 Whirlpool Refrigerator Cantilever B In Stock WPL WP2224173 $45.64

9

WP2317844 Whirlpool Refrigerator Cover Backorder WPL WP2317844 $5.20

9

BLADE, FIXED WPL 2257020 Contact Us For Availability

9A

2307008B Whirlpool Refrigerator Butt Hinge Backorder WPL 2307008B $15.96

9A

WP2206670B Whirlpool Dispenser Tray In Stock WPL WP2206670B $20.18

W10132977 Whirlpool Refrigerator Door Cam Backorder WPL W10132977 $8.31

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $30.30

WP2223879 Whirlpool Refrigerator Compressor D Backorder WPL WP2223879 $54.88

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $4.56

2317239 Whirlpool Refrigerator Blade Block Backorder WPL 2317239 $4.78

WP489483 Whirlpool Screw In Stock WPL WP489483 $4.58

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

WPW10152853 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152853 $34.13

GASKET, AIR BAFFLE WPL 2304597 Contact Us For Availability

11A

WPW10152854 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152854 $26.38

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $27.12

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $6.95

HINGE, BOTTOM RIGHT WPL 2307179 Contact Us For Availability

COVER, AIR DIFFUSER WPL 2223403 Contact Us For Availability

BRACKET, DOOR STOP (SILVER) WPL W10215319 Contact Us For Availability

12A

W10215323 Whirlpool Bracket Backorder WPL W10215323 $26.21

13

COVER, EMITTER WPL 2259487 Contact Us For Availability

13

ASSEMBLY, AIR DIFFUSER WPL 2224076 Contact Us For Availability

13

WIRE ASSEMBLY, DOOR WPL W10193334 Contact Us For Availability

14

WP2220377 Whirlpool Refrigerator Air Baffle In Stock WPL WP2220377 $173.69

14

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

14

SPACER, HOLDING SWITCH WPL 625834 Contact Us For Availability

2306940 Whirlpool Refrigerator Bracket Backorder WPL 2306940 $32.79

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $30.80

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $27.27

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $4.61

15A

2306940B Whirlpool Refrigerator Bracket Backorder WPL 2306940B $13.10

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

W11629923 Whirlpool Coupling In Stock WPL W11629923 $12.72

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.38

WP2179243 Whirlpool Refrigerator Pan Trim Backorder WPL WP2179243 $32.56

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $5.44

WP3400012 Whirlpool Refrigerator Screw Backorder WPL WP3400012 $2.51

WPW10276792 Whirlpool Refrigerator Water Rese In Stock WPL WPW10276792 $59.78

16A

2307007B Whirlpool Refrigerator Butt Hinge Backorder WPL 2307007B $44.38

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $4.56

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $34.73

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

HANDLE, MEAT PAN WPL 2203029 Contact Us For Availability

17A

WPW10152859 Whirlpool Refrigerator Dispenser Backorder WPL WPW10152859 $32.50

18

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.56

18

W11566763 Whirlpool Fitting In Stock WPL W11566763 $18.87

18

WP2187467 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187467 $46.19

W10136850 Whirlpool Refrigerator Front Cover Backorder WPL W10136850 $72.33

WP2315559 Whirlpool Motor Coupling In Stock WPL WP2315559 $26.70

EXTENSION, DRAIN FITTING WPL 2254566 Contact Us For Availability

LENS, LIGHT WPL 2223663 Contact Us For Availability

BRACKET, ICEMAKER MOUNTING WPL 2303583 Contact Us For Availability

WP2304673 Whirlpool Refrigerator Bracket Backorder WPL WP2304673 $6.35

WPW10185438 Whirlpool Ice Maker Cover In Stock WPL WPW10185438 $42.16

LATCH, BIN WPL 2317277 Contact Us For Availability

COVER, UNIT WPL 2223409 Contact Us For Availability

SCREW, GAS INLET WPL W10080380 Contact Us For Availability

21

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $192.85

21

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

21

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $3.70

21A

SLIDE, ICE MAKER MOUNTING (RIGHT HAND) WPL 2212321 Contact Us For Availability

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $2.51

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

CLIP, DEFROST HEATER WPL 2161324 Contact Us For Availability

23

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $59.32

23

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

24

WP2188919 Whirlpool Refrigerator Holder In Stock WPL WP2188919 $3.70

24

HINGE, BOTTOM LEFT WPL 2307152 Contact Us For Availability

25

2260503W Whirlpool Refrigerator Button Backorder WPL 2260503W $13.30

25

2317243 Whirlpool Refrigerator Wiper Backorder WPL 2317243 $28.80

26

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.01

26

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $4.56

27

2317250 Whirlpool Refrigerator Divider Backorder WPL 2317250 $11.09

27

everydrop® Filter 3 EDR3RXD1 Whirlpool Refri In Stock WPL EDR3RXD1 $55.44

27

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $14.42

28

COVER, RECEIVER WPL W10173569 Contact Us For Availability

28

CLOSER, DOOR (FREEZER) WPL 2307051 Contact Us For Availability

29

2315398 Whirlpool Refrigerator Slide Backorder WPL 2315398 $4.78

29

WP2260518W Whirlpool Refrigerator Filter Cap In Stock WPL WP2260518W $16.27

29

ENCLOSURE, MOTOR WPL 2322488 Contact Us For Availability

29A

WP2260518B Whirlpool Water Filter Cap In Stock WPL WP2260518B $12.93

31

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $2.51

31

HEATER, DEFROST WPL 2323199 Contact Us For Availability

32

CLOSER, DOOR (REFRIGERATOR) WPL 2307049 Contact Us For Availability

33

W10853301 Whirlpool Refrigerator Screw Backorder WPL W10853301 $4.48

34

W11496481 Whirlpool Refrigerator Water Tube In Stock WPL W11496481 $12.61

34

WP2198641 Whirlpool Refrigerator Ice Maker Co In Stock WPL WP2198641 $2.51

35

WPW10121140 Whirlpool Refrigerator Housing In Stock WPL WPW10121140 $106.14

38

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $3.70

39

2187737 Whirlpool Refrigerator Wire Harness Backorder WPL 2187737 $54.34

40

FITTING, WATER WPL 2303216 Contact Us For Availability

100

ICE CONTAINER (COMPLETE) WPL W10130500 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS WPL 978029 Contact Us For Availability

MISCELLANEOUS, KIT, FOAM SLAB (30" X 32 1/2" WPL 876029 Contact Us For Availability

MISCELLANEOUS, TAPE, VINYL (3/4 X 108") WPL 479502 Contact Us For Availability

TORX SCREW WRENCH, TORX KEY WPL 1117510 Contact Us For Availability

MISCELLANEOUS, CLEANER, STAINLESS STEEL WPL 20000008 Contact Us For Availability

MISCELLANEOUS, CEMENT, ALUMILASTIC (1 1/4 OZ. WPL 542639 Contact Us For Availability
