Model Whirlpool GC3SHAXVT01 REFRIGERATOR – Common Parts &amp; Diagrams

1

WP2223288 Whirlpool Refrigerator Cantilever S Backorder WPL WP2223288 $271.15

1

Ice Bin WPL W10174541 Contact Us For Availability

2

WP2223506 Whirlpool Refrigerator Light Lens Backorder WPL WP2223506 $52.72

2

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $2.51

2

WPW10139483 Whirlpool Refrigerator Condenser In Stock WPL WPW10139483 $28.58

2

FRONT ROLLER ASM (LEFT SIDE) WPL W10199222 Contact Us For Availability

2

FRONT ROLLER ASM (RIGHT SIDE) WPL W10199223 Contact Us For Availability

2

FITTING, WATER TUBE WPL W10271542 Contact Us For Availability

2

TRIM, SHELF WPL 2203087 Contact Us For Availability

3

W10193018 Whirlpool Refrigerator Condenser Backorder WPL W10193018 $180.89

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

3

WP2317240 Whirlpool Refrigerator Ice Auger In Stock WPL WP2317240 $57.58

3

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

3

Dairy Door WPL 2255421 Contact Us For Availability

4

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

4

WPA3073101 Whirlpool Light Bulb In Stock WPL WPA3073101 $5.97

4

WPW10224328 Whirlpool Refrigerator Spring Backorder WPL WPW10224328 $30.85

4

WPW10270150 Whirlpool Crisper Drawer Cover Backorder WPL WPW10270150 $211.76

4

Washer WPL 2258220 Contact Us For Availability

5

3400524 Whirlpool Refrigerator Screw Backorder WPL 3400524 $7.80

5

W11545866 Whirlpool Refrigerator Clip Backorder WPL W11545866 $4.39

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

5

WP2188820 Whirlpool Refrigerator Thermistor In Stock WPL WP2188820 $18.70

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $7.69

5

WPW10210603 Whirlpool Refrigerator Inlet Valv Backorder WPL WPW10210603 $106.74

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $7.21

6

WP2255411 Whirlpool Refrigerator Clip In Stock WPL WP2255411 $12.22

6

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $19.51

6

Cover, Crisper (Includes 2 & 3) WPL 2223307 Contact Us For Availability

6

Cover, Crusher WPL 2317248 Contact Us For Availability

6

Ladder, Shelf (2) WPL 2319866 Contact Us For Availability

7

W10278733 Whirlpool Refrigerator Blade Backorder WPL W10278733 $30.30

7

WP2223591 Whirlpool Refrigerator Glass Shelf Backorder WPL WP2223591 $124.94

7

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.51

7

Door Mechanism Assembly WPL 2304355 Contact Us For Availability

8

2223545 Whirlpool Refrigerator Shim Backorder WPL 2223545 $31.71

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

8

WPW10257120 Whirlpool Refrigerator Handle Backorder WPL WPW10257120 $26.10

8

Eyelet, Roller WPL 2174478 Contact Us For Availability

8

Mechanism Delay WPL 2205686 Contact Us For Availability

9

2307008B Whirlpool Refrigerator Butt Hinge Backorder WPL 2307008B $15.96

9

2307008T Whirlpool Refrigerator Butt Hinge Backorder WPL 2307008T $44.38

9

WP2206670B Whirlpool Dispenser Tray In Stock WPL WP2206670B $20.18

9

WP2206670T Whirlpool Refrigerator Grille Backorder WPL WP2206670T $36.29

9

WP2206670W Whirlpool Dispenser Tray In Stock WPL WP2206670W $30.46

9

Blade, Fixed WPL 2257020 Contact Us For Availability

8201537 Whirlpool Water Tubing Assembly In Stock WPL 8201537 $52.10

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $30.30

WP2223879 Whirlpool Refrigerator Compressor D Backorder WPL WP2223879 $54.88

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

WPW10272168 Whirlpool Refrigerator Water Fill Backorder WPL WPW10272168 $30.62

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $4.56

2317239 Whirlpool Refrigerator Blade Block Backorder WPL 2317239 $4.78

W10152855 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152855 $33.86

W10155161 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10155161 $56.33

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

WPW10152853 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152853 $34.13

WPW10152854 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152854 $26.38

Gasket, Air Baffle WPL 2304597 Contact Us For Availability

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $27.12

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $6.95

WPW10272161 Whirlpool Refrigerator Stripper A Backorder WPL WPW10272161 $29.61

HARNESS, FAN EVAPORATOR (INCLUDES No.6) WPL W10297478 Contact Us For Availability

Hinge Assembly, Bottom-RC WPL 2307179 Contact Us For Availability

2305571 Whirlpool Gasket Assembly Backorder WPL 2305571 $9.11

W10235943 Whirlpool Refrigerator CANT Shelf Backorder WPL W10235943 $143.49

W10278731 Whirlpool Refrigerator Blade Backorder WPL W10278731 $30.29

Cover, Emitter WPL 2259487 Contact Us For Availability

Air Diffuser Assembly WPL 2224076 Contact Us For Availability

W10132977 Whirlpool Refrigerator Door Cam Backorder WPL W10132977 $8.31

WP2220377 Whirlpool Refrigerator Air Baffle In Stock WPL WP2220377 $173.69

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

Spacer, Switch WPL 625834 Contact Us For Availability

Grille (Midnight Grey) WPL W10194061 Contact Us For Availability

Grille (Biscuit) WPL W10194058 Contact Us For Availability

2306940 Whirlpool Refrigerator Bracket Backorder WPL 2306940 $32.79

2306940B Whirlpool Refrigerator Bracket Backorder WPL 2306940B $13.10

W10728484 Whirlpool Refrigerator Dispenser Co In Stock WPL W10728484 $30.65

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $27.27

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $4.61

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

2307007B Whirlpool Refrigerator Butt Hinge Backorder WPL 2307007B $44.38

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

W11629923 Whirlpool Coupling In Stock WPL W11629923 $12.72

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.38

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $5.44

WP3400012 Whirlpool Refrigerator Screw Backorder WPL WP3400012 $2.51

Handle WPL 2203029 Contact Us For Availability

W10152860 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152860 $32.68

WP2224173 Whirlpool Refrigerator Cantilever B In Stock WPL WP2224173 $45.64

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $4.56

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $34.73

WPW10152859 Whirlpool Refrigerator Dispenser Backorder WPL WPW10152859 $32.50

Lever, Water Dispenser (Apollo Grey) WPL W10155162 Contact Us For Availability

W11566763 Whirlpool Fitting In Stock WPL W11566763 $18.87

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

WP2187467 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187467 $46.19

WP3400906 Whirlpool Refrigerator Screw Backorder WPL WP3400906 $2.51

W10136850 Whirlpool Refrigerator Front Cover Backorder WPL W10136850 $72.33

W10136852 Whirlpool Front Cover Backorder WPL W10136852 $128.41

W10171988 Whirlpool Refrigerator Front Cover Backorder WPL W10171988 $151.44

Tube, Extension WPL 2254566 Contact Us For Availability

Nameplate WPL 2220214 Contact Us For Availability

Light Lens WPL 2223663 Contact Us For Availability

BRACKET, ICEMAKER MOUNTING WPL 2303583 Contact Us For Availability

Bezel, Disp (Mono Satina) WPL W10139842 Contact Us For Availability

Bezel, Disp (Black, Stainless) WPL W10136851 Contact Us For Availability

WP2304673 Whirlpool Refrigerator Bracket Backorder WPL WP2304673 $6.35

WPW10185438 Whirlpool Ice Maker Cover In Stock WPL WPW10185438 $42.16

WPW10191952 Whirlpool Refrigerator Screw Backorder WPL WPW10191952 $3.70

Latch, Bin WPL 2317277 Contact Us For Availability

Cover, Unit WPL 2223409 Contact Us For Availability

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $192.85

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $3.70

WP2223320 Whirlpool Slide Track Pan In Stock WPL WP2223320 $12.22

Slide, Ice Maker Mounting (Right Side) WPL 2212321 Contact Us For Availability

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $2.51

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

Clamp WPL 2161324 Contact Us For Availability

23

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $59.32

23

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

23

LED Assy WPL W10245284 Contact Us For Availability

W10139748 Whirlpool Escutcheon Backorder WPL W10139748 $70.95

WP2188919 Whirlpool Refrigerator Holder In Stock WPL WP2188919 $3.70

Hinge Assembly, Bottom-FC WPL 2307152 Contact Us For Availability

Fascia Assy, Disp (Mono Stainless) WPL W10171982 Contact Us For Availability

Fascia Assy, Disp (White) WPL W10136808 Contact Us For Availability

Fascia Assy, Disp (Black, Stainless) WPL W10139747 Contact Us For Availability

Fascia Assy, Disp (Mono Satina) WPL W10144809 Contact Us For Availability

2260503MG Whirlpool Refrigerator Button Backorder WPL 2260503MG $12.11

2260503W Whirlpool Refrigerator Button Backorder WPL 2260503W $13.30

2317243 Whirlpool Refrigerator Wiper Backorder WPL 2317243 $28.80

Gasket (2) WPL W10194025 Contact Us For Availability

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.01

WPW10121140 Whirlpool Refrigerator Housing In Stock WPL WPW10121140 $106.14

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $4.56

Support, Window WPL W10170412 Contact Us For Availability

27

2317250 Whirlpool Refrigerator Divider Backorder WPL 2317250 $11.09

27

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $14.42

28

Cover, Receiver WPL W10173569 Contact Us For Availability

28

Door Closer, FC WPL 2307051 Contact Us For Availability

29

2315398 Whirlpool Refrigerator Slide Backorder WPL 2315398 $4.78

29

WP2260518MG Whirlpool Water Filter Cap Backorder WPL WP2260518MG $27.21

29

Enclosure, Motor WPL 2322488 Contact Us For Availability

31

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $2.51

31

WP489483 Whirlpool Screw In Stock WPL WP489483 $4.58

31

Heater, Defrost WPL 2323199 Contact Us For Availability

32

WP2315559 Whirlpool Motor Coupling In Stock WPL WP2315559 $26.70

32

WPL 2307049 WPL 2307049 Contact Us For Availability

34

WP2198641 Whirlpool Refrigerator Ice Maker Co In Stock WPL WP2198641 $2.51

38

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $3.70

39

2187737 Whirlpool Refrigerator Wire Harness Backorder WPL 2187737 $54.34

40

Connector, Water Tube WPL 2303216 Contact Us For Availability

100

W11512149 Whirlpool Ice Maker Assembly In Stock WPL W11512149 $78.53

100

WP2317251 Whirlpool Refrigerator Ice Containe In Stock WPL WP2317251 $196.63

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

8171357 Whirlpool Spray Nozzle Backorder WPL 8171357 $30.47

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

W10134625 Whirlpool Refrigerator Touch-Up Pai In Stock WPL W10134625 $7.48

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

PAINT, TOUCH-UP (1/2oz.) (Graphite) WPL 80051 Contact Us For Availability

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

Refinishing Material (Biscuit) WPL 4392900 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

Refinishing Material (Black) WPL 799340 Contact Us For Availability

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability

Refinishing Material (Graphite) WPL 8171358 Contact Us For Availability
