Model Whirlpool ED5LHAXWS01 REFRIGERATOR – Common Parts &amp; Diagrams

1

WP2182120 Whirlpool Refrigerator Scroll Fan Backorder WPL WP2182120 $34.61

1

WPW10334458 Whirlpool Refrigerator Connector Backorder WPL WPW10334458 $8.62

2

WP2198573 Whirlpool Refrigerator Ice Bin Backorder WPL WP2198573 $138.23

2

WP2256101 Whirlpool Dairy Door In Stock WPL WP2256101 $69.06

2

WPW10304660 Whirlpool Wheel Assembly In Stock WPL WPW10304660 $29.99

2

WPW10318961 Whirlpool Refrigerator Wire Shelf In Stock WPL WPW10318961 $55.33

2

RETAINER, FAN MOTOR WPL 2155590 Contact Us For Availability

2

Fitting, Water Tube WPL 2303216 Contact Us For Availability

3

W10803534 Whirlpool Screw In Stock WPL W10803534 $5.01

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

3

WP2198641 Whirlpool Refrigerator Ice Maker Co Backorder WPL WP2198641 $3.33

3

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

3

WPW10321304 Whirlpool Refrigerator Door Shelf In Stock WPL WPW10321304 $27.32

3

Latch, Bin WPL 2317277 Contact Us For Availability

3

SLIDE MEAT PAN CONTROL WPL 2182757 Contact Us For Availability

4

2303234 Whirlpool Refrigerator Shield Backorder WPL 2303234 $30.25

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $24.28

4

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $3.70

5

2198619 Whirlpool Refrigerator Wire Harness Backorder WPL 2198619 $55.13

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $8.51

5

WP2255411 Whirlpool Refrigerator Clip In Stock WPL WP2255411 $13.05

5

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

5

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $20.33

5

WPW10318948 Whirlpool Wire Shelf Backorder WPL WPW10318948 $117.48

5

COVER, LIGHT LENS WPL 2200096 Contact Us For Availability

6

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

6

WP2154473 Whirlpool Refrigerator Connector Backorder WPL WP2154473 $10.76

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $4.52

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $8.03

6

WP2188919 Whirlpool Refrigerator Holder In Stock WPL WP2188919 $4.52

6

TUBE, SUCTION WPL 2205765 Contact Us For Availability

7

W10194475 Whirlpool Refrigerator Shield Backorder WPL W10194475 $55.78

7

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $123.54

7

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $27.11

7

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.63

7

WP2309941 Whirlpool Refrigerator Door Bar Tri In Stock WPL WP2309941 $54.65

7

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.64

8

WP2174706 Whirlpool Refrigerator Pin Hitch Backorder WPL WP2174706 $4.63

8

WPW10127762 Whirlpool Refrigerator Handle Backorder WPL WPW10127762 $98.05

8

WPW10130299 Whirlpool Refrigerator Cup In Stock WPL WPW10130299 $9.50

8

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

9

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $4.52

9

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $4.70

9

WP2206670B Whirlpool Dispenser Tray In Stock WPL WP2206670B $21.01

9

WP2206670T Whirlpool Refrigerator Grille Backorder WPL WP2206670T $38.10

9

WP2206670W Whirlpool Dispenser Tray In Stock WPL WP2206670W $30.46

9

WP2315562 Whirlpool Refrigerator Thermostat In Stock WPL WP2315562 $57.79

9

WPW10318947 Whirlpool Wire Shelf Backorder WPL WPW10318947 $39.73

9

HINGE TOP (RC) WPL W10287684 Contact Us For Availability

9

Screw WPL W10191952 Contact Us For Availability

2181741 Whirlpool Refrigerator Slide Backorder WPL 2181741 $39.71

W11084324 Whirlpool Refrigerator Wire Harness Backorder WPL W11084324 $42.66

WP2309718 Whirlpool Refrigerator Door Trim In Stock WPL WP2309718 $40.33

WPW10272168 Whirlpool Refrigerator Water Fill Backorder WPL WPW10272168 $32.15

W10152855 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152855 $35.56

WP2179343 Whirlpool Refrigerator Control Body Backorder WPL WP2179343 $13.98

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $30.25

WP8281227 Whirlpool Screw In Stock WPL WP8281227 $4.58

WPW10152853 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152853 $36.65

WPW10152854 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152854 $26.52

2161466 Whirlpool Refrigerator Slide Backorder WPL 2161466 $10.76

2203407T Whirlpool Refrigerator Cover Backorder WPL 2203407T $13.83

WP2179342 Whirlpool Refrigerator Slide Backorder WPL WP2179342 $10.08

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $7.78

WP2182179 Whirlpool Cam Closer In Stock WPL WP2182179 $4.21

WP2198587 Whirlpool Refrigerator Cover Backorder WPL WP2198587 $32.34

WP2203407B Whirlpool Refrigerator Cover Backorder WPL WP2203407B $12.81

WP2203407W Whirlpool Refrigerator Cover Backorder WPL WP2203407W $11.51

WPW10151375 Whirlpool Refrigerator Diffuser Backorder WPL WPW10151375 $44.36

WPW10272161 Whirlpool Refrigerator Stripper A Backorder WPL WPW10272161 $31.09

BRACKET, DOOR STOP (SILVER) WPL W10185570 Contact Us For Availability

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $34.62

2180200 Whirlpool Refrigerator Socket Backorder WPL 2180200 $32.98

W10896198 Whirlpool Refrigerator Start Device Backorder WPL W10896198 $70.92

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $28.64

WP2315559 Whirlpool Motor Coupling In Stock WPL WP2315559 $37.44

HINGE BOTTOM WPL W10251408 Contact Us For Availability

W10252495 Whirlpool Refrigerator Wire Cover Backorder WPL W10252495 $28.82

W10283958 Whirlpool Refrigerator Filler Backorder WPL W10283958 $14.60

W11252732 Whirlpool Refrigerator Filler Backorder WPL W11252732 $7.16

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $9.63

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $5.44

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $4.52

Light Bar (RC) WPL 2179920 Contact Us For Availability

2161306 Whirlpool Refrigerator Arm Pivot Backorder WPL 2161306 $4.72

2179350 Whirlpool Refrigerator Deflector Backorder WPL 2179350 $28.49

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $44.85

GRILLE (BISCUIT) WPL W10283950 Contact Us For Availability

16

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $10.41

16

WP2213265 Whirlpool Refrigerator Nameplate Backorder WPL WP2213265 $39.71

16

WP3400012 Whirlpool Refrigerator Screw In Stock WPL WP3400012 $2.51

W10152860 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152860 $34.31

WP2255720 Whirlpool Refrigerator Ice Maker Do Backorder WPL WP2255720 $43.10

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $4.52

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $45.45

WPW10152859 Whirlpool Refrigerator Dispenser Backorder WPL WPW10152859 $34.13

WPW10276341 Whirlpool Refrigerator Glass Shel In Stock WPL WPW10276341 $143.17

BRACKET, ICEMAKER MOUNTING WPL 2303583 Contact Us For Availability

2161307 Whirlpool Refrigerator Rod Backorder WPL 2161307 $8.13

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

W10243997 Whirlpool Refrigerator Switch Backorder WPL W10243997 $81.56

W11566763 Whirlpool Fitting In Stock WPL W11566763 $20.64

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.33

WPW10276348 Whirlpool Refrigerator Glass Shel In Stock WPL WPW10276348 $119.79

Slide, Ice Maker Mounting WPL 2212321 Contact Us For Availability

19

W11512417 Whirlpool Drain Connector In Stock WPL W11512417 $13.85

19

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $192.85

19

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

20

8201515 Whirlpool Refrigerator Motor and Gear In Stock WPL 8201515 $67.68

20

HINGE TOP (FC) WPL W10287685 Contact Us For Availability

20

Clip WPL 2161324 Contact Us For Availability

21

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $59.32

WP2203408B Whirlpool Refrigerator Cover Backorder WPL WP2203408B $13.47

WP2203408W Whirlpool Refrigerator Cover Backorder WPL WP2203408W $11.66

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $5.38

WPW10309395 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10309395 $139.29

FRONT COVER ASSEMBLY (INCLUDES ITEMS 18, 19, WPL W10279318 Contact Us For Availability

Front Cover Assembly (Includes Items 18, 19, WPL 2256973W Contact Us For Availability

24

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $27.27

24

Spacer, Switch (2) WPL 625834 Contact Us For Availability

25

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

25

Cover, Receiver WPL W10173569 Contact Us For Availability

26

2315398 Whirlpool Refrigerator Slide Backorder WPL 2315398 $4.78

26

WP2304673 Whirlpool Refrigerator Bracket Backorder WPL WP2304673 $6.35

27

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $5.67

27

WP489483 Whirlpool Screw In Stock WPL WP489483 $5.40

28

W10853646 Whirlpool Indicator Light In Stock WPL W10853646 $48.75

28

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $3.33

28

WPW10121138 Whirlpool Refrigerator Water Filt In Stock WPL WPW10121138 $57.79

29

everydrop® Filter 3 EDR3RXD1 Whirlpool Refri In Stock WPL EDR3RXD1 $56.07

31

WP489500 Whirlpool Refrigerator Screw Backorder WPL WP489500 $2.51

32

WPW10304659 Whirlpool Wheel Assembly In Stock WPL WPW10304659 $38.05

33

2260503W Whirlpool Refrigerator Button Backorder WPL 2260503W $13.30

33

Air Baffle WPL W10163483 Contact Us For Availability

35

W10196313 Whirlpool Refrigerator Rail Unit Backorder WPL W10196313 $52.01

35

TUBE, FILTER INLET WPL W10281289 Contact Us For Availability

36

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $9.59

100

2198597 Whirlpool Refrigerator Ice Maker In Stock WPL 2198597 $119.51

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $29.35

4210463RW Whirlpool Refrigerator Coil Brush In Stock WPL 4210463RW $15.04

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $8.03

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $34.75

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.99

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.02

PAINT, TOUCH-UP (1/2oz.) (Graphite) WPL 80051 Contact Us For Availability

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT. WHITE) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

PAINT, BULK (1 QT.) (BISCUIT) WPL 4392900 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

PAINT, BULK (1 QT.) (GRAPHITE`) WPL 8171358 Contact Us For Availability
