Model Whirlpool LA5000XMW0 AUTOMATIC WASHER – Common Parts &amp; Diagrams

1

90984 Whirlpool Nut Backorder WPL 90984 $9.13

1

Miscellaneous Parts Bag WPL 375976 Contact Us For Availability

1

Panel, Rear Console WPL 358470 Contact Us For Availability

1

Basket Drive & Brake WPL 358364 Contact Us For Availability

1

Wire, Ground WPL 364089 Contact Us For Availability

2

WP273556 Whirlpool Screw In Stock WPL WP273556 $2.51

2

Screw, 8-18 x 1 (2) WPL 358225 Contact Us For Availability

2

Cover, Gusset (L.R.) WPL 352143 Contact Us For Availability

2

Cover, Gusset (L.F.) WPL 353230 Contact Us For Availability

2

COVER, GUSSET (R.R.) WPL 94114 Contact Us For Availability

2

Drum, Brake (Upper) WPL 350522 Contact Us For Availability

3

Gasket, Gearcase WPL 95089 Contact Us For Availability

3

Screw, 13-16 x 5/8 WPL 355326 Contact Us For Availability

3

Sleeve WPL 96175 Contact Us For Availability

3

Ball, Suspension (6) WPL 91073 Contact Us For Availability

3

Lining, Basket Brake (Upper) WPL 354550 Contact Us For Availability

4

Cap, End (L.H.) (White Cap, End (R.H.)) WPL 375333 Contact Us For Availability

4

Cap, End (L.H.) (White) WPL 375337 Contact Us For Availability

4

Spring, Toggle WPL 96266 Contact Us For Availability

4

Rod, Suspension (3) WPL 82584 Contact Us For Availability

4

Spring, Basket Drive (Orange) (4) WPL 381046 Contact Us For Availability

5

WP9724509 Whirlpool Bumper In Stock WPL WP9724509 $2.64

5

Strap, Ground WPL 22965 Contact Us For Availability

5

Pulley WPL 359630 Contact Us For Availability

5

Baseplate & Centerpost WPL 358949 Contact Us For Availability

5

Drum, Brake (Lower) WPL 97664 Contact Us For Availability

6

WP3400516 Whirlpool Screw In Stock WPL WP3400516 $2.51

6

Lever, Valve WPL 355538 Contact Us For Availability

6

Lining, Basket Brake (Lower) WPL 354244 Contact Us For Availability

7

WP686711 Whirlpool Door Handle In Stock WPL WP686711 $3.88

7

Screw, Ground (10-24 x 1) WPL 132848 Contact Us For Availability

7

Rod, Connecting WPL 96264 Contact Us For Availability

7

Brace, Baseplate WPL 353301 Contact Us For Availability

7

Yoke, Brake WPL 92903 Contact Us For Availability

8

WP356138 Whirlpool Hose Clamp In Stock WPL WP356138 $3.70

8

Nut, Push-In (1) WPL 358472 Contact Us For Availability

8

Bearing Block Assembly WPL 383750 Contact Us For Availability

8

Nut, 5/16-24 WPL 96101 Contact Us For Availability

8

Ring, Snap WPL 16049 Contact Us For Availability

9

Connector, Hose WPL 95440 Contact Us For Availability

9

Nut, Snap In (2) WPL 358473 Contact Us For Availability

9

Wick, Oil WPL 96265 Contact Us For Availability

9

Magnet WPL 365998 Contact Us For Availability

9

Plate & Lining, Basket Drive WPL 357155 Contact Us For Availability

10

386011 Whirlpool Screw Backorder WPL 386011 $27.74

10

Screw, Taper End WPL 16135 Contact Us For Availability

10

Lining, Basket Drive (Set of 3) WPL 354243 Contact Us For Availability

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350938 Whirlpool Spray Gun Backorder WPL 350938 $32.57

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.51

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

WP96743 Whirlpool Hose Backorder WPL WP96743 $25.33

Leveler (Thinner) WPL 350941 Contact Us For Availability

Sheet, Installation Instructions WPL 378953 Contact Us For Availability

Instructions, Operating WPL 383166 Contact Us For Availability

Label, Energy Guide WPL 383363 Contact Us For Availability

List, Repair Parts WPL 384547 Contact Us For Availability

Guide, Laundry WPL 385238 Contact Us For Availability

Thinner (1 Gal.) WPL 799351 Contact Us For Availability

Guide, Cam Bar WPL 95462 Contact Us For Availability

Eyelet (3) WPL 98281 Contact Us For Availability

12

WPW10083200 Whirlpool Wire Ring In Stock WPL WPW10083200 $4.96

12

Block, Drive WPL 96384 Contact Us For Availability

12

Cam, Bar Spin WPL 354838 Contact Us For Availability

W10814296 Whirlpool Washer Center Post Seal G In Stock WPL W10814296 $2.58

WP89503 Whirlpool Washer Fill Hose In Stock WPL WP89503 $4.47

WP91770 Whirlpool Hinge In Stock WPL WP91770 $8.80

WP95405 Whirlpool Belt In Stock WPL WP95405 $9.26

Washer, Thrust (2) WPL 353320 Contact Us For Availability

WP16123 Whirlpool Washer In Stock WPL WP16123 $2.51

Tub WPL 359592 Contact Us For Availability

Spring, Hinge WPL 92398 Contact Us For Availability

Screw, 1/4-28 x 1/2 WPL 98001 Contact Us For Availability

Pulley, Basket Drive WPL 364032 Contact Us For Availability

WP3351614 Whirlpool Screw Backorder WPL WP3351614 $2.51

Spring, Brake WPL 94726 Contact Us For Availability

Screw & Washer, Tub (4) WPL 370571 Contact Us For Availability

Bumper, Lid Hinge WPL 91605 Contact Us For Availability

Bearing, Drive Pulley WPL 16033 Contact Us For Availability

16

WP91939 Whirlpool Shaft Seal In Stock WPL WP91939 $3.88

16

Cam, Agitator & Pump WPL 18642 Contact Us For Availability

16

Panel, Rear WPL 85279 Contact Us For Availability

Hose WPL 92231 Contact Us For Availability

Hinge, L.H. WPL 91099 Contact Us For Availability

Plunger WPL 84866 Contact Us For Availability

Drive Tube & Bearing, Basket WPL 357965 Contact Us For Availability

18

WP21097 Whirlpool Pad In Stock WPL WP21097 $3.70

18

WP356427 Whirlpool Shaft Seal In Stock WPL WP356427 $3.88

18

Rivet WPL 354959 Contact Us For Availability

19

WP21258 Whirlpool Washer Lid Hinge Bearing In Stock WPL WP21258 $3.88

19

Spring, Brake Yoke WPL 17261 Contact Us For Availability

19

Set Screw, 5/16-18X 13/16 WPL 356057 Contact Us For Availability

20

WPW10119828 Whirlpool Screw In Stock WPL WPW10119828 $2.64

20

Plate, Gusset WPL 356459 Contact Us For Availability

20

Spacer, Agitator Shaft WPL 356937 Contact Us For Availability

21

Lid (White) WPL 385360 Contact Us For Availability

21

Support, Spin Tube WPL 358586 Contact Us For Availability

21

Cabinet WPL 384793 Contact Us For Availability

WP359364 Whirlpool Clip In Stock WPL WP359364 $3.88

Plate, Snubber WPL 355852 Contact Us For Availability

Top (White) WPL 384018 Contact Us For Availability

Spacer, Clutch Shaft (1) WPL 359332 Contact Us For Availability

23

WP90767 Whirlpool Screw In Stock WPL WP90767 $2.51

23

Cap, Agitator WPL 358431 Contact Us For Availability

23

Pin, Roll WPL 90532 Contact Us For Availability

24

Knob & Clip, Water Level WPL 690298 Contact Us For Availability

24

Roller, Basket Clutch Shaft WPL 92119 Contact Us For Availability

24

Link, Leveling WPL 359059 Contact Us For Availability

25

WP358594 Whirlpool Leveling Feet In Stock WPL WP358594 $7.27

25

Agitator & Insert WPL 383952 Contact Us For Availability

25

Shaft, Basket Clutch WPL 383723 Contact Us For Availability

26

Stud, Agitator Shaft WPL 358440 Contact Us For Availability

26

Harness, Console WPL 385058 Contact Us For Availability

26

Gearcase (Refer To Page 8 For Further Breakdo WPL 362901 Contact Us For Availability

WP21366 Whirlpool Spanner Nut In Stock WPL WP21366 $3.70

Harness, Base WPL 358115 Contact Us For Availability

Pad, Gusset Cover (4) WPL 352434 Contact Us For Availability

Hinge, R.H. WPL 18775 Contact Us For Availability

Hinge, L.H. WPL 92657 Contact Us For Availability

28

WP8577376 Whirlpool Seal In Stock WPL WP8577376 $3.88

28

Seal WPL 351830 Contact Us For Availability

28

Cord, Power (60 Hz.) WPL 92667 Contact Us For Availability

Air Dome Assembly WPL 360804 Contact Us For Availability

Switch, Water Level (363300) (Alt.) (359648) WPL 660929 Contact Us For Availability

Bolt, 5/16 x 5/8 (2) WPL 126211 Contact Us For Availability

Bolt, 5/16 x 1 (3) WPL 126358 Contact Us For Availability

Bolt, Snubber (1) WPL 353770 Contact Us For Availability

30

WP353244 Whirlpool Hose In Stock WPL WP353244 $32.17

30

Bolt, 5/16-24 WPL 98048 Contact Us For Availability

30

Valve, Mixing (358277) (Alt.) (358971) (Alt.) WPL 660749 Contact Us For Availability

31

Switch, Water Temperature 358934 (Alt.) 35893 WPL 660746 Contact Us For Availability

31

Gasket, Tub (7) WPL 17235 Contact Us For Availability

31

Hose, Pump Discharge WPL 21114 Contact Us For Availability

32

WP8546455 Whirlpool Bearing In Stock WPL WP8546455 $9.46

32

Bracket, Control WPL 359708 Contact Us For Availability

32

Spring, Snubber WPL 357977 Contact Us For Availability

33

W11095997 Whirlpool Seal In Stock WPL W11095997 $10.76

33

Pad, Snubber WPL 358336 Contact Us For Availability

34

16515 Whirlpool Clip Backorder WPL 16515 $11.62

34

350572 Whirlpool Oil Transmission 15 Oz In Stock WPL 350572 $32.56

34

Locator, Top WPL 98669 Contact Us For Availability

35

WP285655 Whirlpool Hose Clamp In Stock WPL WP285655 $3.70

35

Clip, Tub Ring (4) WPL 359763 Contact Us For Availability

35

Retainer, Brake Yoke WPL 356444 Contact Us For Availability

36

Ball WPL 358585 Contact Us For Availability

37

WP367594 Whirlpool Leveling Feet In Stock WPL WP367594 $10.89

37

Setscrew, 5/16-18 x 1/2 WPL 355345 Contact Us For Availability

38

WP18776 Whirlpool Lock In Stock WPL WP18776 $5.01

38

Pulley, Main Drive WPL 360840 Contact Us For Availability

40

Timer, 60 Hz. WPL 380288 Contact Us For Availability

40

Bracket, Motor Mounting WPL 85286 Contact Us For Availability

41

Motor, Timer 60 Hz. WPL 365941 Contact Us For Availability

41

Nut (4) WPL 98023 Contact Us For Availability

42

Grommet, Motor Bracket (4) WPL 19138 Contact Us For Availability

43

Knob & Clip, Water Temperature WPL 690299 Contact Us For Availability

43

Pulley, Motor (60 Hz.) WPL 357514 Contact Us For Availability

44

Shield, Motor (Upper) WPL 356217 Contact Us For Availability

45

WP356418 Whirlpool Screw In Stock WPL WP356418 $2.51

46

Motor (Emerson) (Alternate) 60 Hz. WPL 357875 Contact Us For Availability

46

Motor (General Elect WPL 362856 Contact Us For Availability

47

W10876590 Whirlpool Connector In Stock WPL W10876590 $4.94

49

WP3390631 Whirlpool Screw In Stock WPL WP3390631 $2.51

49

Terminal, Female WPL 352088 Contact Us For Availability

50

WPL 354195 WPL 354195 Contact Us For Availability

51

WPL 98537 WPL 98537 Contact Us For Availability

52

WPL 93549 WPL 93549 Contact Us For Availability

53

WPL 95721 WPL 95721 Contact Us For Availability

54

Panel, Control WPL 384678 Contact Us For Availability

55

WPL 357571 WPL 357571 Contact Us For Availability

56

WPL 359642 WPL 359642 Contact Us For Availability

56

WPL 362738 WPL 362738 Contact Us For Availability

57

Dial, Timer WPL 359817 Contact Us For Availability

58

Knob, Timer WPL 359205 Contact Us For Availability

58

WPL 351499 WPL 351499 Contact Us For Availability

58

WPL 351500 WPL 351500 Contact Us For Availability

59

WPL 16062 WPL 16062 Contact Us For Availability

59

Plug, Cabinet WPL 354179 Contact Us For Availability

60

WPL 90877 WPL 90877 Contact Us For Availability

61

WP96160 Whirlpool Washer Inlet Valve Screen In Stock WPL WP96160 $4.76

61

WPL 285134 WPL 285134 Contact Us For Availability

62

WP688805 Whirlpool Spring Clip In Stock WPL WP688805 $3.88

67

Nut, Push-In (4) WPL 689559 Contact Us For Availability

75

Cap, Terminal (Console Harness) WPL 94612 Contact Us For Availability

76

Plug, Terminal (Cabinet Harness) WPL 94611 Contact Us For Availability

79

WP94614 Whirlpool Terminal Backorder WPL WP94614 $2.51

81

Wire, Ground WPL 357535 Contact Us For Availability

83

8528351 Whirlpool Clip Backorder WPL 8528351 $27.52

84

WP90016 Whirlpool Clip Backorder WPL WP90016 $4.78

85

WP359231 Whirlpool Shield In Stock WPL WP359231 $3.70

86

Screw & Washer WPL 354975 Contact Us For Availability

88

Switch Actuator Assembly WPL 370959 Contact Us For Availability

89

W10820036 Whirlpool Door Switch Kit In Stock WPL W10820036 $9.94

94

W10113937 Whirlpool Clamp Backorder WPL W10113937 $4.78

95

Strike, Lid Switch WPL 357633 Contact Us For Availability

97

Screw & Wa WPL 354764 Contact Us For Availability

98

WPL 357645 WPL 357645 Contact Us For Availability

100

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51
