Model Whirlpool LA4000XKW0 AUTOMATIC WASHER – Common Parts &amp; Diagrams

1

Panel, Rear Console WPL 358470 Contact Us For Availability

1

Miscellaneous Parts Bag WPL 357962 Contact Us For Availability

2

Screw, 8-18 x 1 WPL 358225 Contact Us For Availability

2

Cover, Gearcase WPL 367552 Contact Us For Availability

2

Cover, Gusset (L.R.) WPL 352143 Contact Us For Availability

2

Cover, Gusset (L.F.) WPL 353230 Contact Us For Availability

2

COVER, GUSSET (R.R.) WPL 94114 Contact Us For Availability

3

285452A Whirlpool Hose Seal and Screen In Stock WPL 285452A $2.64

3

Gasket, Gearcase WPL 95089 Contact Us For Availability

3

Screw, 13-16 x 5/8 WPL 355326 Contact Us For Availability

3

Ball, Suspension (6) WPL 91073 Contact Us For Availability

4

Cap, End (L.H) (White Cap, End (R.H)) WPL 377314 Contact Us For Availability

4

Cap, End (L.H) (White) WPL 377315 Contact Us For Availability

4

Shaft, Agitator WPL 362642 Contact Us For Availability

4

Rod, Suspension (3) WPL 82584 Contact Us For Availability

4

Wire, Ground WPL 364089 Contact Us For Availability

5

WP9724509 Whirlpool Bumper In Stock WPL WP9724509 $2.64

5

Ring, Retainer WPL 352430 Contact Us For Availability

5

Baseplate & Centerpost WPL 358949 Contact Us For Availability

5

Strap, Ground WPL 22965 Contact Us For Availability

6

WP3400516 Whirlpool Screw In Stock WPL WP3400516 $2.51

6

Seal, Agitator Shaft WPL 92814 Contact Us For Availability

7

WP686711 Whirlpool Door Handle In Stock WPL WP686711 $3.88

7

Shield, Agitator Spring WPL 94276 Contact Us For Availability

7

Brace, Baseplate WPL 353301 Contact Us For Availability

7

Screw, Ground (10-24 x 1) WPL 132848 Contact Us For Availability

8

WP356138 Whirlpool Hose Clamp In Stock WPL WP356138 $3.70

8

Nut, Push-In (1) WPL 358472 Contact Us For Availability

8

Spring, Agitator Shaft WPL 92815 Contact Us For Availability

8

Nut, 5/16-24 WPL 96101 Contact Us For Availability

9

Nut, Snap In (2) WPL 358473 Contact Us For Availability

9

Gear, Agitator Shaft WPL 355469 Contact Us For Availability

9

Magnet WPL 365998 Contact Us For Availability

10

Shaft, Agitator WPL 362098 Contact Us For Availability

10

Screw, Taper End WPL 16135 Contact Us For Availability

285205 Whirlpool Bearing Backorder WPL 285205 $3.70

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350938 Whirlpool Spray Gun Backorder WPL 350938 $32.57

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.51

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

WP96743 Whirlpool Hose In Stock WPL WP96743 $23.59

Guide, Cam Bar WPL 95462 Contact Us For Availability

Leveler (Thinner) WPL 350941 Contact Us For Availability

Guide, Laundry WPL 358770 Contact Us For Availability

Instructions, Installation WPL 372845 Contact Us For Availability

List, Repair Parts WPL 381815 Contact Us For Availability

Label, Energy Guide WPL 382263 Contact Us For Availability

Instructions, Operating WPL 382595 Contact Us For Availability

Thinner (1 Gal.) WPL 799351 Contact Us For Availability

12

Block, Drive WPL 96384 Contact Us For Availability

12

Cam, Bar Spin WPL 354838 Contact Us For Availability

WP89503 Whirlpool Washer Fill Hose In Stock WPL WP89503 $4.47

WP91770 Whirlpool Hinge In Stock WPL WP91770 $8.80

WP95405 Whirlpool Belt In Stock WPL WP95405 $9.26

Gear, Sector WPL 75073 Contact Us For Availability

WP16123 Whirlpool Washer In Stock WPL WP16123 $2.51

Spring, Hinge WPL 92398 Contact Us For Availability

Ring, Retainer WPL 52083 Contact Us For Availability

Screw, 1/4-28 x 1/2 WPL 98001 Contact Us For Availability

WP3351614 Whirlpool Screw Backorder WPL WP3351614 $2.51

Spring, Brake WPL 94726 Contact Us For Availability

Bumper, Lid Hinge WPL 91605 Contact Us For Availability

Pin, Dowel WPL 5018 Contact Us For Availability

WP91939 Whirlpool Shaft Seal In Stock WPL WP91939 $3.88

Panel, Rear WPL 85279 Contact Us For Availability

Bolt, 5/16-24 x 3/4 (4) WPL 356599 Contact Us For Availability

Cam, Agitator & Pump WPL 18642 Contact Us For Availability

17

Hinge, L.H. WPL 91099 Contact Us For Availability

17

Bearing, Gear Fork WPL 96853 Contact Us For Availability

17

Plunger WPL 84866 Contact Us For Availability

WP21097 Whirlpool Pad In Stock WPL WP21097 $3.70

WP356427 Whirlpool Shaft Seal In Stock WPL WP356427 $3.88

Support, Brake Shoe Yoke WPL 356445 Contact Us For Availability

Rivet WPL 354959 Contact Us For Availability

19

WP21258 Whirlpool Washer Lid Hinge Bearing In Stock WPL WP21258 $3.88

19

Spring, Gear Fork Shaft WPL 16015 Contact Us For Availability

19

Spring, Brake Yoke WPL 17261 Contact Us For Availability

WPW10119828 Whirlpool Screw In Stock WPL WPW10119828 $2.64

Plate, Gusset WPL 356459 Contact Us For Availability

Fork, Agitator Gear WPL 80398 Contact Us For Availability

Basket Drive & Brake WPL 358364 Contact Us For Availability

21

Cabinet WPL 379101 Contact Us For Availability

21

Lid (White) WPL 373491 Contact Us For Availability

21

Support, Spin Tube WPL 358586 Contact Us For Availability

WP120393 Whirlpool Washer Assembly Backorder WPL WP120393 $2.38

WP359364 Whirlpool Clip In Stock WPL WP359364 $3.88

Plate, Snubber WPL 355852 Contact Us For Availability

Top (White) WPL 373374 Contact Us For Availability

WP90767 Whirlpool Screw In Stock WPL WP90767 $2.51

Cap, Agitator WPL 358431 Contact Us For Availability

Pin, Roll WPL 90532 Contact Us For Availability

Rod, Connecting WPL 76577 Contact Us For Availability

24

Link, Leveling WPL 359059 Contact Us For Availability

24

Roller, Basket Clutch Shaft WPL 92119 Contact Us For Availability

24

Ring, Retaining WPL 95082 Contact Us For Availability

WP358594 Whirlpool Leveling Feet In Stock WPL WP358594 $7.27

Agitator & Insert WPL 357200 Contact Us For Availability

Screw, 10 x 3/8 WPL 90834 Contact Us For Availability

Washer, Retainer WPL 95083 Contact Us For Availability

Shaft, Basket Clutch WPL 359460 Contact Us For Availability

Stud, Agitator Shaft WPL 358440 Contact Us For Availability

Harness, Console WPL 359368 Contact Us For Availability

Gearcase WPL 362901 Contact Us For Availability

Gear, Main Drive WPL 353397 Contact Us For Availability

WP21366 Whirlpool Spanner Nut In Stock WPL WP21366 $3.70

Hinge, R.H. WPL 18775 Contact Us For Availability

Hinge, L.H. WPL 92657 Contact Us For Availability

Harness, Base WPL 358115 Contact Us For Availability

Washer, Thrust WPL 363362 Contact Us For Availability

Pad, Gusset Cover WPL 352434 Contact Us For Availability

WP8577376 Whirlpool Seal In Stock WPL WP8577376 $3.88

Seal WPL 351830 Contact Us For Availability

Cord, Power (60 Hz.) WPL 92667 Contact Us For Availability

Gearcase WPL 362906 Contact Us For Availability

Air Dome Assembly WPL 360804 Contact Us For Availability

Switch, Water Level WPL 366509 Contact Us For Availability

Bolt, 5/16-24 x 1-1/8 (2) WPL 356512 Contact Us For Availability

Bolt, 5/16 x 5/8 (2) WPL 126211 Contact Us For Availability

Bolt, 5/16 x 1 (3) WPL 126358 Contact Us For Availability

Bolt, Snubber (1) WPL 353770 Contact Us For Availability

WP353244 Whirlpool Hose In Stock WPL WP353244 $32.17

Valve, Mixing (Alternate) WPL 358277 Contact Us For Availability

Valve, Mixing (Alternate) (Serviced Only as C WPL 358971 Contact Us For Availability

Bearing, Drive Pinion WPL 354513 Contact Us For Availability

Bolt, 5/16-24 WPL 98048 Contact Us For Availability

Switch, Water Temperature (Alternate) WPL 358934 Contact Us For Availability

Switch, Water Temperature (Alternate) WPL 358935 Contact Us For Availability

Pinion, Drive WPL 84467 Contact Us For Availability

Gasket, Tub WPL 17235 Contact Us For Availability

WP8546455 Whirlpool Bearing In Stock WPL WP8546455 $9.46

Spring, Snubber WPL 357977 Contact Us For Availability

Bracket, Control WPL 359708 Contact Us For Availability

Washer, Drive Pinion WPL 16024 Contact Us For Availability

33

W11095997 Whirlpool Seal In Stock WPL W11095997 $10.76

33

Pad, Snubber WPL 358336 Contact Us For Availability

33

Ring, Retainer WPL 90094 Contact Us For Availability

16515 Whirlpool Clip Backorder WPL 16515 $11.62

350572 Whirlpool Oil Transmission 15 Oz In Stock WPL 350572 $32.56

Locator, Top WPL 98669 Contact Us For Availability

Screw, 5/16-24 x 1-3/4 (1) WPL 355613 Contact Us For Availability

35

Clip, Tub Ring (4) WPL 359763 Contact Us For Availability

35

Retainer, Brake Yoke WPL 356444 Contact Us For Availability

36

Ball WPL 358585 Contact Us For Availability

37

WP367594 Whirlpool Leveling Feet In Stock WPL WP367594 $10.89

37

Setscrew, 5/16-18 x 1/2 WPL 355345 Contact Us For Availability

38

WP18776 Whirlpool Lock In Stock WPL WP18776 $5.01

38

Pulley, Main Drive WPL 360840 Contact Us For Availability

39

WP358160 Whirlpool Nut Backorder WPL WP358160 $2.51

40

Latch WPL 357249 Contact Us For Availability

40

Timer, 60 Hz. WPL 380288 Contact Us For Availability

40

Bracket, Motor Mounting WPL 85286 Contact Us For Availability

41

Filter Assembly WPL 359785 Contact Us For Availability

41

Motor, Timer 60 Hz. WPL 365941 Contact Us For Availability

41

Nut (4) WPL 98023 Contact Us For Availability

42

Grommet, Motor Bracket (4) WPL 19138 Contact Us For Availability

42

Screw (2) WPL 176360 Contact Us For Availability

Retainer WPL 357250 Contact Us For Availability

Hose, Pump Discharge WPL 21114 Contact Us For Availability

Knob Assembly, W.T. WPL 690309 Contact Us For Availability

Pulley, Motor (60 Hz.) WPL 357514 Contact Us For Availability

44

Spring WPL 94403 Contact Us For Availability

44

Shield, Motor (Upper) WPL 356217 Contact Us For Availability

45

WP285655 Whirlpool Hose Clamp In Stock WPL WP285655 $3.70

45

WP356418 Whirlpool Screw In Stock WPL WP356418 $2.51

Connector, Hose WPL 95440 Contact Us For Availability

Hose, Pump To Filter WPL 357346 Contact Us For Availability

Motor (Emerson) (Alternate) 60 Hz. WPL 357875 Contact Us For Availability

Motor (General Electric) (Alternate) 60 Hz. WPL 362856 Contact Us For Availability

47

W10876590 Whirlpool Connector In Stock WPL W10876590 $4.94

47

W11573574 Whirlpool Screw In Stock WPL W11573574 $9.59

48

Bracket, Hose WPL 358339 Contact Us For Availability

49

WP3390631 Whirlpool Screw In Stock WPL WP3390631 $2.51

49

Terminal, Female WPL 352088 Contact Us For Availability

50

Bearing, Lower WPL 354195 Contact Us For Availability

51

Bolt, 3/8-16 x 3/4 WPL 98537 Contact Us For Availability

52

Bracket, Motor Mounti WPL 93549 Contact Us For Availability

53

WPL 95721 WPL 95721 Contact Us For Availability

54

Panel, Control WPL 378652 Contact Us For Availability

55

WPL 357571 WPL 357571 Contact Us For Availability

56

WPL 359642 WPL 359642 Contact Us For Availability

56

WPL 362738 WPL 362738 Contact Us For Availability

57

Dial, Timer WPL 359826 Contact Us For Availability

58

Knob, Timer WPL 359822 Contact Us For Availability

58

WPL 351499 WPL 351499 Contact Us For Availability

58

WPL 351500 WPL 351500 Contact Us For Availability

59

Plug, Cabinet WPL 354179 Contact Us For Availability

59

WPL 16062 WPL 16062 Contact Us For Availability

60

WPL 90877 WPL 90877 Contact Us For Availability

61

WP96160 Whirlpool Washer Inlet Valve Screen In Stock WPL WP96160 $4.76

61

WPL 285134 WPL 285134 Contact Us For Availability

62

WP688805 Whirlpool Spring Clip In Stock WPL WP688805 $3.88

67

WP689559 Whirlpool Nut Backorder WPL WP689559 $3.70

75

Cap, Terminal (Console Harness) WPL 94612 Contact Us For Availability

76

Plug, Terminal (Cabinet Harness) WPL 94611 Contact Us For Availability

78

WP596797 Whirlpool Terminal Backorder WPL WP596797 $2.51

79

WP94614 Whirlpool Terminal Backorder WPL WP94614 $2.51

81

Wire, Ground WPL 357535 Contact Us For Availability

83

8528351 Whirlpool Clip Backorder WPL 8528351 $27.52

84

WP90016 Whirlpool Clip Backorder WPL WP90016 $4.78

85

WP359231 Whirlpool Shield In Stock WPL WP359231 $3.70

86

Screw & Washer WPL 354975 Contact Us For Availability

88

Switch Actuator Assembly WPL 370959 Contact Us For Availability

89

W10820036 Whirlpool Door Switch Kit In Stock WPL W10820036 $9.94

94

W10113937 Whirlpool Clamp Backorder WPL W10113937 $4.78

95

Strike, Lid Switch WPL 357633 Contact Us For Availability

97

Screw & Washer WPL 354764 Contact Us For Availability

98

Rack, Literature WPL 357645 Contact Us For Availability

100

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51
