Model Whirlpool KSSS36QHX00 BUILT IN REFRIGERATOR – Common Parts &amp; Diagrams

1

WP4389155 Whirlpool Refrigerator Evaporator M In Stock WPL WP4389155 $102.45

1

Refrigerator Door Panel (Includes Insulation) WPL 2003870 Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI106744A Contact Us For Availability

1

Bracket, Motor WPL 2003939 Contact Us For Availability

1

Control Panel WPL 1112640 Contact Us For Availability

1

Frame, Shelf WPL 2174402 Contact Us For Availability

1

LITERATURE PARTS (Service & Wiring Sheet) WPL LIT2005930 Contact Us For Availability

1

LITERATURE PARTS (Use & Care Guide) WPL LIT2006136 Contact Us For Availability

1

LITERATURE PARTS (Installation Instructions) WPL LIT2006137 Contact Us For Availability

1

LITERATURE PARTS (Energy Label) WPL LIT2006651 Contact Us For Availability

1

Modular Icemaker Service Sheet WPL LIT628370 Contact Us For Availability

1

Solid Shelf WPL 2003142 Contact Us For Availability

1

Freezer Door Panel (Includes Insulation) WPL 2202546B Contact Us For Availability

1

Cabinet, Trim (2) WPL 2004553 Contact Us For Availability

2

WP2188242 Whirlpool Refrigerator Motor In Stock WPL WP2188242 $153.53

2

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

2

WP939101 Whirlpool Refrigerator Plate Backorder WPL WP939101 $3.70

2

Bracket, Light WPL 2005567 Contact Us For Availability

2

Clamp, Bi-Metal WPL 1113043 Contact Us For Availability

2

Cup, Clearance WPL 2002732 Contact Us For Availability

2

Inlay, Control Panel WPL 2003301 Contact Us For Availability

2

Glass, Shelf WPL 2003375 Contact Us For Availability

2

Cabinet (Not A Serviceable Part) WPL ARI106743A Contact Us For Availability

2

Front, Ice Compartment WPL 2003133 Contact Us For Availability

2

Screw WPL 2003857 Contact Us For Availability

3

876765 Whirlpool Primary Mounting Kit Refrige In Stock WPL 876765 $24.72

3

WP1113466 Whirlpool Refrigerator Thermostat Backorder WPL WP1113466 $125.12

3

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

3

Lens WPL 1113650 Contact Us For Availability

3

Soleniod Assembly WPL 2003979 Contact Us For Availability

3

Circuit Board WPL 2004005 Contact Us For Availability

3

Reflector, Shelf WPL 1113546 Contact Us For Availability

3

Grommet, Tube Crossover WPL 2005004 Contact Us For Availability

3

Shelf, Fixed (1) WPL 1113564 Contact Us For Availability

3

Shelf, Deep (2) WPL 1113636 Contact Us For Availability

4

4387491 Whirlpool Refrigerator Insert In Stock WPL 4387491 $3.70

4

W10850503 Whirlpool Refrigerator Guide Backorder WPL W10850503 $4.63

4

WPW10138054 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10138054 $15.79

4

Socket, Light WPL 2005042 Contact Us For Availability

4

Retaining Ring, Door-Closure WPL 2004881 Contact Us For Availability

4

Bracket (Double) WPL 548263 Contact Us For Availability

4

Control Knob WPL 2003842 Contact Us For Availability

4

Gasket, Glass (2) WPL 1113790 Contact Us For Availability

4

Basket WPL 2208192 Contact Us For Availability

4

Cabinet, Trim (Bottom) WPL 2004536 Contact Us For Availability

5

2006518 Whirlpool Refrigerator Track Backorder WPL 2006518 $10.38

5

W10777924 Whirlpool Refrigerator Wine Rack Backorder WPL W10777924 $8.47

5

W10860229 Whirlpool Refrigerator Support Backorder WPL W10860229 $177.18

5

W10860448 Whirlpool Refrigerator Support Backorder WPL W10860448 $137.10

5

WP2002171 Whirlpool Refrigerator Sleeve Backorder WPL WP2002171 $10.19

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

5

Slide, Container (Right Side) WPL 2002720 Contact Us For Availability

5

Bracket (Single) WPL 938224 Contact Us For Availability

5

Retainer, Knob WPL 2003841 Contact Us For Availability

5

Trim, Basket WPL 2003112 Contact Us For Availability

6

520965 Whirlpool Refrigerator Support Backorder WPL 520965 $10.14

6

W10136387A Whirlpool Refrigerator Egg Contain In Stock WPL W10136387A $5.98

6

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

6

WP2004523 Whirlpool Refrigerator Door Hinge Backorder WPL WP2004523 $28.51

6

Condenser Inlet Tube WPL 2002999 Contact Us For Availability

6

Decortive Panel Assembly WPL 2003722 Contact Us For Availability

6

Support Clip, Icemaker (2) WPL 538533 Contact Us For Availability

6

Grommet WPL 548268 Contact Us For Availability

6

Grommet, Wiring WPL 2005006 Contact Us For Availability

6

Slide, Basket (Left Side) WPL 2208197 Contact Us For Availability

6

Slide, Basket (Right Side) WPL 2208198 Contact Us For Availability

6

Hinge, Bottom WPL 2004524 Contact Us For Availability

6

Cabinet, Trim Top WPL 2003645 Contact Us For Availability

7

W10823511 Whirlpool Refrigerator Water Tube In Stock WPL W10823511 $12.61

7

W11474472 Whirlpool Screw In Stock WPL W11474472 $2.51

7

Guard, Compressor Wiring WPL 2005534 Contact Us For Availability

7

Grommet, Screw (2) WPL 2000193 Contact Us For Availability

7

Wiring Assembly, Ice Dispenser WPL 2004006 Contact Us For Availability

7

Seal, Control Panel WPL 1113133 Contact Us For Availability

7

Frame, Assembly Meat Pan WPL 2006523 Contact Us For Availability

7

Grommet, Flexible WPL 2005007 Contact Us For Availability

8

W10903204 Whirlpool Refrigerator Washer Backorder WPL W10903204 $4.03

8

WP1106508 Whirlpool Refrigerator Gasket Backorder WPL WP1106508 $4.14

8

WP2177817 Whirlpool Refrigerator Egg Containe Backorder WPL WP2177817 $7.39

8

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

8

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51

8

Tube, Connect (Drier) WPL 2003015 Contact Us For Availability

8

Hinge, Top WPL 2005329 Contact Us For Availability

8

Gasket Retainer, Top & Bottom WPL 1112539 Contact Us For Availability

8

Deflector, Air Duct WPL 2003924 Contact Us For Availability

8

Screw (3) WPL 489260 Contact Us For Availability

9

2188319A Whirlpool Refrigerator Door Gasket In Stock WPL 2188319A $140.01

9

WP2004545 Whirlpool Refrigerator Heater Pan In Stock WPL WP2004545 $177.02

9

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $4.56

9

WPW10169511 Whirlpool Refrigerator Coupling In Stock WPL WPW10169511 $9.70

9

Seal, Side Trim WPL 2005925 Contact Us For Availability

9

Spacer-Door, Top WPL 2004520 Contact Us For Availability

9

Hole Plug (3) WPL 2000153 Contact Us For Availability

9

Cover, Crisper WPL 1113893 Contact Us For Availability

9

Mounting Stud, Grill WPL 2006442 Contact Us For Availability

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

Trim, Grille Bottom WPL 2003611 Contact Us For Availability

Valve, Solenoid WPL 2003791 Contact Us For Availability

Hanger, Heater WPL 1113062 Contact Us For Availability

Shield, Control Panel WPL 2005564 Contact Us For Availability

Glass, Crisper WPL 2003378 Contact Us For Availability

Clip, Wire WPL 2005237 Contact Us For Availability

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $7.69

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $4.59

Trim, Grille Top WPL 2003617 Contact Us For Availability

Handle, Door WPL 2005952 Contact Us For Availability

Shield, Drain Pan WPL 2005908 Contact Us For Availability

Socket, Light WPL 2005043 Contact Us For Availability

Meat Pan, Connector WPL 2000742 Contact Us For Availability

Cap, Grommet WPL 1112849 Contact Us For Availability

Trim, Grille Right Side WPL 2003599 Contact Us For Availability

Gasket Retainer, Side (2) WPL 1112533 Contact Us For Availability

Washer WPL 2001230 Contact Us For Availability

Cover, Motor WPL 1113128 Contact Us For Availability

Connector Wire WPL 227991 Contact Us For Availability

Channel, Wiring WPL 2001145 Contact Us For Availability

Cover WPL 2169935 Contact Us For Availability

WP548049 Whirlpool Refrigerator Light Bulb Backorder WPL WP548049 $26.21

Trim, Grille Left Side WPL 2003605 Contact Us For Availability

Spacer, Control Panel (3) WPL 1112591 Contact Us For Availability

Water Valve, Harness WPL 2006738 Contact Us For Availability

Tube, Discharge WPL 2002995 Contact Us For Availability

Fastner WPL 1112871 Contact Us For Availability

Grommet, Wiring WPL 1113122 Contact Us For Availability

Gasket Retainer, Top & Bottom WPL 1112538 Contact Us For Availability

2003347 Whirlpool Screw Backorder WPL 2003347 $9.35

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $4.61

Ice Container WPL 2208906 Contact Us For Availability

Insert, Tube WPL 1129177 Contact Us For Availability

Scroll, Fan WPL 2000783 Contact Us For Availability

Wire, Light WPL 2006223 Contact Us For Availability

Crisper Pan (2) WPL 2006544 Contact Us For Availability

Wiring Harness, Cabinet WPL 2006752 Contact Us For Availability

Door Gasket, Magnetic WPL 2005529 Contact Us For Availability

489348 Whirlpool Refrigerator Tube Clamp Backorder WPL 489348 $5.38

W10749708 Whirlpool Refrigerator Coupling Backorder WPL W10749708 $13.85

W11624204 Whirlpool Screw Backorder WPL W11624204 $9.59

WP2003001 Whirlpool Refrigerator Exchanger Backorder WPL WP2003001 $182.46

WP488130 Whirlpool Air Conditioner Nut Backorder WPL WP488130 $3.09

Roller WPL 2188212 Contact Us For Availability

Deflector, Air Duct WPL 2003927 Contact Us For Availability

Channel, Wiring WPL 2001141 Contact Us For Availability

1112260 Whirlpool EV Support Backorder WPL 1112260 $4.58

488946 Whirlpool Air Conditioner Clamp Backorder WPL 488946 $10.25

WPW10122127 Whirlpool Refrigerator Evaporator Backorder WPL WPW10122127 $200.73

Eyelet, Roller WPL 2174478 Contact Us For Availability

Trim (Top) WPL 2005010 Contact Us For Availability

Clip, Wiring (2) WPL 1115375 Contact Us For Availability

Handle, Door WPL 2005942 Contact Us For Availability

WP2005378 Whirlpool Refrigerator Screw Backorder WPL WP2005378 $4.58

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $4.56

Stud, Shelf (20) WPL 2004068 Contact Us For Availability

Heater, Defrost WPL 2006749 Contact Us For Availability

Assembly, Air Duct (Also Order Items 8 & 15) WPL 2208900 Contact Us For Availability

1113048 Whirlpool Refrigerator Clamp Backorder WPL 1113048 $4.81

2182146 Whirlpool Refrigerator Duct Backorder WPL 2182146 $32.79

2257644 Whirlpool Refrigerator Door Hinge Backorder WPL 2257644 $62.10

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.51

Door, Spacer WPL 2004549 Contact Us For Availability

Trim (Side) WPL 2005967 Contact Us For Availability

Screw WPL 487559 Contact Us For Availability

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

Screw WPL 487522 Contact Us For Availability

Trim (Bottom) WPL 2003663 Contact Us For Availability

Clamp, Heater (2) WPL 1108431 Contact Us For Availability

W10278731 Whirlpool Refrigerator Blade Backorder WPL W10278731 $30.29

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.51

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $137.91

Panel, Interior Door WPL 1113952 Contact Us For Availability

Gasket, Evaporator WPL 1112844 Contact Us For Availability

Meat Pan WPL 2006529 Contact Us For Availability

Guard, Wiring WPL 1112805 Contact Us For Availability

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $52.25

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $30.30

WP2004994 Whirlpool Refrigerator Hinge Bushin Backorder WPL WP2004994 $3.70

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

Ladder, Shelf (2) WPL 1113951 Contact Us For Availability

Trim (Top) WPL 2005019 Contact Us For Availability

W10278733 Whirlpool Refrigerator Blade Backorder WPL W10278733 $30.30

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

WP628356 Whirlpool Refrigerator Fill Cup In Stock WPL WP628356 $15.77

Bushing WPL 2002903 Contact Us For Availability

Retainer, Shelf Ladder (2) WPL 1112530 Contact Us For Availability

Gasket, Air Baffle WPL 1112869 Contact Us For Availability

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

Thermistor WPL 1116959 Contact Us For Availability

Back Up Plate (8) WPL 1112514 Contact Us For Availability

Strap WPL 851095 Contact Us For Availability

Cover, Air Outlet WPL 2003576 Contact Us For Availability

Retainer, Glass WPL 2002181 Contact Us For Availability

Trim (Bottom) WPL 2004560 Contact Us For Availability

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $26.81

Blade, Fan WPL 2190685 Contact Us For Availability

Blade, Fixed (2) WPL 1119009 Contact Us For Availability

Spring, Door Closure WPL 2004567 Contact Us For Availability

Trim (Side) WPL 2005962 Contact Us For Availability

2157405 Whirlpool Refrigerator Blade Block Backorder WPL 2157405 $10.76

WP2001264 Whirlpool Refrigerator Drip Pan In Stock WPL WP2001264 $88.94

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $37.11

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

Bin, Utility WPL 1112720 Contact Us For Availability

Cover, Evaporator WPL 2005035 Contact Us For Availability

Crisper Spacer, Right Side (2) WPL 2003411 Contact Us For Availability

2003577 Whirlpool Refrigerator Guard Backorder WPL 2003577 $8.31

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $27.12

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.38

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

WP489236 Whirlpool Refrigerator Ring Backorder WPL WP489236 $5.09

Door, Utility Bin WPL 2003463 Contact Us For Availability

Bracket, Drain Pan (Left) WPL 1113206 Contact Us For Availability

Bracket, Drain Pan (Right) WPL 1113207 Contact Us For Availability

Connector, Meat Pan Duct WPL 2000797 Contact Us For Availability

Panel, Interior Door WPL 2002838 Contact Us For Availability

WP2158826 Whirlpool Refrigerator Dampener Backorder WPL WP2158826 $0.90

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $41.93

Insulation, Switch WPL 625834 Contact Us For Availability

Stop, Roller WPL 1113169 Contact Us For Availability

Door Shelf (4) WPL 2003130 Contact Us For Availability

Conveyor WPL 2160602 Contact Us For Availability

Cement Alumilastic) WPL 542639 Contact Us For Availability

Fastener (3) WPL 1113227 Contact Us For Availability

4388736 Whirlpool Refrigerator Ice Dispenser In Stock WPL 4388736 $30.73

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

Tray, Butter WPL 2165792 Contact Us For Availability

Baffle, Evaporator WPL 1112840 Contact Us For Availability

Crisper Spacer, Left Side (2) WPL 2003410 Contact Us For Availability

Gap, Cover Assembly (Bottom) WPL 2006342 Contact Us For Availability

Shelf Bin (2) WPL 2003127 Contact Us For Availability

2180200 Whirlpool Refrigerator Socket Backorder WPL 2180200 $31.40

W10527053 Whirlpool Refrigerator Door Hinge Backorder WPL W10527053 $70.12

WP2006780 Whirlpool Refrigerator Door Hinge Backorder WPL WP2006780 $102.66

WP3400912 Whirlpool Refrigerator Washer Backorder WPL WP3400912 $2.51

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

Diffuser, Air Duct WPL 1112851 Contact Us For Availability

W10852691 Whirlpool Refrigerator Baffle Backorder WPL W10852691 $13.16

WP2256126 Whirlpool Refrigerator Reservoir In Stock WPL WP2256126 $77.94

WP2302876 Whirlpool Refrigerator Hinge Bushin Backorder WPL WP2302876 $27.05

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $2.51

Shelf, Gallon Door WPL 2207459 Contact Us For Availability

W11342242 Whirlpool Refrigerator Ice Level Ar In Stock WPL W11342242 $25.51

WP1119018 Whirlpool Refrigerator Bearing Backorder WPL WP1119018 $3.70

Overlay WPL 2207460 Contact Us For Availability

Screw WPL 488280 Contact Us For Availability

32

Control Arm WPL 2002728 Contact Us For Availability

33

1119020 Whirlpool Refrigerator Spring Backorder WPL 1119020 $6.09

33

WP2256087 Whirlpool Refrigerator Bracket Backorder WPL WP2256087 $28.80

33

Linkage, Door Closure WPL 2004516 Contact Us For Availability

1119021 Whirlpool Refrigerator Clip Backorder WPL 1119021 $4.63

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

Grille Base, Front WPL 2004530 Contact Us For Availability

Ice Chute WPL 2208909 Contact Us For Availability

35

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $4.56

35

Screw WPL 489238 Contact Us For Availability

36

Fitting, Water Tube WPL 2185988 Contact Us For Availability

36

Cover, Rear WPL 2004512 Contact Us For Availability

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $6.95

WPW10185018 Whirlpool Refrigerator Housing Backorder WPL WPW10185018 $52.10

Water Valve Mounting Bracket WPL 2004914 Contact Us For Availability

Grommet, Wiring WPL 2207518 Contact Us For Availability

38

WP1119017 Whirlpool Refrigerator Deflector Backorder WPL WP1119017 $3.70

39

489234 Whirlpool Refrigerator Washer Backorder WPL 489234 $9.59

39

WP2006346 Whirlpool Refrigerator Washer In Stock WPL WP2006346 $4.59

40

Bushing, Door Closure WPL 2004565 Contact Us For Availability

41

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

41

WP1163283 Whirlpool Air Conditioner Screw Backorder WPL WP1163283 $2.51

42

WP4211117 Whirlpool Refrigerator Connector In Stock WPL WP4211117 $5.34

42

Evaporator, Cover Rail (Right Side) WPL 2000685 Contact Us For Availability

42

Evaporator, Cover Rail (Left Side) WPL 2000686 Contact Us For Availability

43

WP8204624 Whirlpool Bolt Backorder WPL WP8204624 $8.82

44

Front Cover, Ice Container WPL 2002722 Contact Us For Availability

44

Compresion Nut WPL 1129179 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Gasket (2) Evaporator Cover WPL 2001337 Contact Us For Availability

46

Gasket (2) WPL 2001079 Contact Us For Availability

47

WP2180325 Whirlpool Dispenser Grille In Stock WPL WP2180325 $39.03

47

Gasket WPL 2001080 Contact Us For Availability

48

Gasket WPL 2001081 Contact Us For Availability

54

W10759522 Whirlpool Screw Backorder WPL W10759522 $2.51

99

Complete Ice Crusher Mechanism Assembly WPL 2160606 Contact Us For Availability

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $88.85

Complete Ice Container Assembly WPL 2006541 Contact Us For Availability

Front Panel Kit (White) WPL 4378650 Contact Us For Availability

Front Panel Kit (Black) WPL 4378653 Contact Us For Availability

Front Panel Kit (Almond) WPL 4378656 Contact Us For Availability

Front Panel Kit (Stainless Steel) WPL 4378659 Contact Us For Availability

Front Panel Kit (Biscuit) WPL 4392886 Contact Us For Availability

Black Acrylic Static Cleaner WPL 978849 Contact Us For Availability
