Model Whirlpool KSRT25FWWH00 REFRIGERATOR – Common Parts &amp; Diagrams

1

WP2198573 Whirlpool Refrigerator Ice Bin Backorder WPL WP2198573 $138.23

1

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

1

HOUSING, DISPENSER (NOT SERVICED) WPL NP Contact Us For Availability

1

DOOR, REFRIGERATOR (BLACK) WPL W10168058B Contact Us For Availability

1

DOOR, REFRIGERATOR (STAINLESS) WPL W10168058S Contact Us For Availability

1

DOOR, REFRIGERATOR (WHITE) WPL W10168058W Contact Us For Availability

2

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $3.33

2

RETAINER, FAN MOTOR WPL 2155590 Contact Us For Availability

2

Handle (Stainless) WPL 2319727S Contact Us For Availability

2

Handle (Black) WPL 2319727B Contact Us For Availability

2

ASSEMBLY, COMPARTMENT DOOR WPL 2301486 Contact Us For Availability

3

2223680 Whirlpool Refrigerator Shield Backorder WPL 2223680 $39.09

3

2324712 Whirlpool Refrigerator Condenser Backorder WPL 2324712 $159.43

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

3

WP2317240 Whirlpool Refrigerator Ice Auger In Stock WPL WP2317240 $61.42

3

SLIDE-CONTROL, MEAT PAN WPL 2182757 Contact Us For Availability

3

Fitting, Water WPL 2303216 Contact Us For Availability

3

HOLDER, BEVERAGE WPL 2193409 Contact Us For Availability

4

WPW10224328 Whirlpool Refrigerator Spring In Stock WPL WPW10224328 $33.21

4

Washer, Auger WPL 2258220 Contact Us For Availability

4

Handle (White) WPL 2319727W Contact Us For Availability

5

2159075 Whirlpool Door Gasket Seal In Stock WPL 2159075 $157.17

5

2159083 Whirlpool Gasket Door In Stock WPL 2159083 $142.79

5

2310527 Whirlpool Refrigerator Wire Jumper Backorder WPL 2310527 $69.65

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $8.51

5

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $20.33

5

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $8.03

6

WPW10236142 Whirlpool Refrigerator Evaporator In Stock WPL WPW10236142 $138.30

6

Cover, Crusher WPL 2317248 Contact Us For Availability

7

W11366418 Whirlpool Screw In Stock WPL W11366418 $10.41

7

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $4.52

7

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $27.11

7

WP2223506 Whirlpool Refrigerator Light Lens Backorder WPL WP2223506 $54.75

7

WPW10010150 Whirlpool Refrigerator Screw Backorder WPL WPW10010150 $2.51

7

GLIDE ASSEMBLY (RIGHT HAND) WPL 2301548 Contact Us For Availability

7

TUBE, SUCTION WPL 2205765 Contact Us For Availability

7

Support, Ice Door WPL 2304355 Contact Us For Availability

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

8

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $4.52

8

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

8

WPW10243392 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243392 $34.73

8

WPW10243393 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243393 $37.53

8

ASSEMBLY, FRONT BASKET WPL 2301134 Contact Us For Availability

8

Nameplate (Grey) WPL W10046610 Contact Us For Availability

8

Ladder, Shelf WPL 2319866 Contact Us For Availability

8

DASHPOT, DISPENSER WPL 2205686 Contact Us For Availability

9

WP2203771 Whirlpool Refrigerator Door Hinge In Stock WPL WP2203771 $34.57

9

WP2206670B Whirlpool Dispenser Tray In Stock WPL WP2206670B $21.01

9

WP2206670W Whirlpool Dispenser Tray In Stock WPL WP2206670W $30.46

9

WPW10170540 Whirlpool Screw In Stock WPL WPW10170540 $5.40

9

WPW10210789-includeCORE Whirlpool WPW10210789 Backorder WPL WPW10210789-includeCORE $215.12

9

Blade, Fixed WPL 2257020 Contact Us For Availability

9

SHELF TRACK (RIGHT HAND) WPL 2301289 Contact Us For Availability

9

SHELF TRACK (LEFT HAND) WPL 2301290 Contact Us For Availability

9

ASSEMBLY, PAN COVER WPL 2301567 Contact Us For Availability

2323186 Whirlpool Refrigerator Housing Backorder WPL 2323186 $35.67

8201537 Whirlpool Water Tubing Assembly In Stock WPL 8201537 $54.92

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $31.82

W10853301 Whirlpool Refrigerator Screw Backorder WPL W10853301 $4.48

WP2182179 Whirlpool Cam Closer In Stock WPL WP2182179 $4.21

DOOR CLOSER, UPPER CAM (SILVER) WPL 2323535 Contact Us For Availability

2317239 Whirlpool Refrigerator Blade Block Backorder WPL 2317239 $4.78

W10138965 Whirlpool Refrigerator Door Hinge Backorder WPL W10138965 $31.29

W10155161 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10155161 $59.15

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $30.25

WPW10152853 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152853 $36.65

WPW10152854 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152854 $26.52

Gasket, Door Compartment WPL 2159124 Contact Us For Availability

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $28.47

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $7.78

WPW10142233 Whirlpool Refrigerator Screw Backorder WPL WPW10142233 $2.71

Filler, Wrapper (White) WPL 2304846 Contact Us For Availability

W10728484 Whirlpool Refrigerator Dispenser Co In Stock WPL W10728484 $43.76

W10899382 Whirlpool Refrigerator Damper Contr In Stock WPL W10899382 $116.82

BRACKET, DOOR STOP (CHROME) WPL W10175740 Contact Us For Availability

Bracket, Door Stop (Black) WPL W10175741 Contact Us For Availability

W10128735 Whirlpool Refrigerator Cover Backorder WPL W10128735 $69.88

WP2198587 Whirlpool Refrigerator Cover Backorder WPL WP2198587 $32.34

WP2223434K Whirlpool Refrigerator Door Shelf In Stock WPL WP2223434K $61.75

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

WP489497 Whirlpool Screw In Stock WPL WP489497 $5.40

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $45.45

WPW10152859 Whirlpool Refrigerator Dispenser Backorder WPL WPW10152859 $34.13

LEVER, WATER DISPENSER (GREY) WPL W10155162 Contact Us For Availability

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $28.64

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $4.61

WP2203770 Whirlpool Refrigerator Door Hinge Backorder WPL WP2203770 $31.66

WP3400012 Whirlpool Refrigerator Screw In Stock WPL WP3400012 $2.51

FASCIA ASSEMBLY (WHITE) WPL W10236484 Contact Us For Availability

FASCIA ASSEMBLY (BLACK) WPL W10236485 Contact Us For Availability

FASCIA ASSEMBLY (STAINLESS) WPL W10236486 Contact Us For Availability

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $10.41

W10916292 Whirlpool Refrigerator Crisper Pan In Stock WPL W10916292 $104.18

W11629923 Whirlpool Coupling In Stock WPL W11629923 $13.54

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $4.70

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $5.44

Control Board WPL 2321749 Contact Us For Availability

W11566763 Whirlpool Fitting In Stock WPL W11566763 $20.64

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $5.38

FRONT BEZEL, DISPENSER (BLACK) WPL 2322507B Contact Us For Availability

FRONT BEZEL, DISPENSER (WHITE) WPL 2322507W Contact Us For Availability

FRONT BEZEL, DISPENSER (STAINLESS) WPL W10139840 Contact Us For Availability

W11239891 Whirlpool Refrigerator Light Lens Backorder WPL W11239891 $38.12

W11512417 Whirlpool Drain Connector In Stock WPL W11512417 $13.85

WP2187467 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187467 $48.50

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $192.85

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $2.51

WP3400906 Whirlpool Refrigerator Screw Backorder WPL WP3400906 $2.51

Window, Crisper Pan WPL 2301001 Contact Us For Availability

W10141518 Whirlpool Refrigerator Screw Backorder WPL W10141518 $5.65

WP2255720 Whirlpool Refrigerator Ice Maker Do Backorder WPL WP2255720 $43.10

Latch, Bin WPL 2317277 Contact Us For Availability

BRACKET, ICEMAKER MOUNTING WPL 2303583 Contact Us For Availability

Clip, Defrost Heater WPL 2161324 Contact Us For Availability

Support, Window WPL W10170417 Contact Us For Availability

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $59.32

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $3.70

SLIDE, ICEMAKER MOUNTING (RIGHT HAND) WPL 2212321 Contact Us For Availability

GASKET, DISPENSER WPL W10129948 Contact Us For Availability

21

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

21

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

22

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

22

WP2188919 Whirlpool Refrigerator Holder In Stock WPL WP2188919 $4.52

22

WP2304673 Whirlpool Refrigerator Bracket Backorder WPL WP2304673 $6.35

23

2317243 Whirlpool Refrigerator Wiper Backorder WPL 2317243 $30.25

23

LED ASSEMBLY, BRACKET WPL W10245284 Contact Us For Availability

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.63

WP489483 Whirlpool Screw In Stock WPL WP489483 $5.40

WPA3073101 Whirlpool Light Bulb In Stock WPL WPA3073101 $8.43

WPW10141748 Whirlpool Refrigerator Glass Shel Backorder WPL WPW10141748 $173.34

SPACER, SWITCH HARNESS WPL 625834 Contact Us For Availability

25

2317250 Whirlpool Refrigerator Divider Backorder WPL 2317250 $11.09

25

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $9.63

25

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $5.38

26

everydrop® Filter 3 EDR3RXD1 Whirlpool Refri In Stock WPL EDR3RXD1 $56.07

26

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $27.27

2006254 Whirlpool Refrigerator Screw Backorder WPL 2006254 $8.09

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $5.67

WP489500 Whirlpool Refrigerator Screw Backorder WPL WP489500 $2.51

Cover, Receiver WPL W10173569 Contact Us For Availability

ENCLOSURE, MOTOR ASSEMBLY WPL 2322488 Contact Us For Availability

28

2315398 Whirlpool Refrigerator Slide Backorder WPL 2315398 $4.78

28

WP2260518MG Whirlpool Water Filter Cap Backorder WPL WP2260518MG $28.57

28

WP2323198 Whirlpool Refrigerator Heater In Stock WPL WP2323198 $30.17

29

Screw WPL W10191952 Contact Us For Availability

30

WP2179243 Whirlpool Refrigerator Pan Trim Backorder WPL WP2179243 $34.18

30

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $3.33

30

WP8281227 Whirlpool Screw In Stock WPL WP8281227 $4.58

31

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

31

WP2315559 Whirlpool Motor Coupling In Stock WPL WP2315559 $37.44

32

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $4.56

33

W10896764 Whirlpool Refrigerator Air Baffle In Stock WPL W10896764 $37.92

33

WP2198641 Whirlpool Refrigerator Ice Maker Co Backorder WPL WP2198641 $3.33

34

Clip, Heat Shield WPL 2155547 Contact Us For Availability

35

2260503MG Whirlpool Refrigerator Button Backorder WPL 2260503MG $12.11

35

2260503W Whirlpool Refrigerator Button Backorder WPL 2260503W $13.30

35

Unit Cover, Bottom WPL 2304899 Contact Us For Availability

36

2303234 Whirlpool Refrigerator Shield Backorder WPL 2303234 $30.25

36

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

37

2305374 Whirlpool Refrigerator Unit Rail Backorder WPL 2305374 $27.52

38

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $9.59

40

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $3.33

41

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

43

WPW10334458 Whirlpool Refrigerator Connector Backorder WPL WPW10334458 $8.62

100

ASSEMBLY, ICE CONTAINER WPL 2317273 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $29.35

285006 Whirlpool Spray In Stock WPL 285006 $29.65

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.94

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $8.03

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $28.40

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $100.80

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $34.75

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.99

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.02

VALVE, ACCESS WPL 978029 Contact Us For Availability

MISCELLANEOUS, KIT, FOAM SLAB (30`` X 32 1/2` WPL 876029 Contact Us For Availability

MISCELLANEOUS, TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT. WHITE) WPL 799344 Contact Us For Availability

TORX SCREW WRENCH TORX KEY WPL 1117510 Contact Us For Availability

VALVE, ACCESS WPL 978028 Contact Us For Availability

MISCELLANEOUS, CLEANER, STAINLESS STEEL WPL 20000008 Contact Us For Availability

MISCELLANEOUS, CEMENT, ALUMILASTIC (11/4 OZ.) WPL 542639 Contact Us For Availability
