Model Whirlpool GR2SHTXMS00 REFRIGERATOR – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

1

WP488878 Whirlpool Refrigerator Tube Clamp Backorder WPL WP488878 $4.81

1

Housing, Dispenser WPL 2210500 Contact Us For Availability

1

Refrigerator Door (Includes 8 & 12) (White) WPL 2202519 Contact Us For Availability

1

Refrigerator Door (Includes 8 & 12) (Biscuit) WPL 2204865 Contact Us For Availability

1

Refrigerator Door (Includes 8 & 12) (Black) WPL 2204867 Contact Us For Availability

1

Refrigerator Door (Includes 8 & 12) (Stainles WPL 2218278 Contact Us For Availability

1

Refrigerator Door (Includes 8 & 12) (Stainles WPL 2218505 Contact Us For Availability

1

Freezer Door (Includes 8 & 12) (White) WPL 2202520 Contact Us For Availability

1

Freezer Door (Includes 8 & 12) (Biscuit) WPL 2204854 Contact Us For Availability

1

Freezer Door (Includes 8 & 12) (Black) WPL 2204856 Contact Us For Availability

1

Freezer Door (Includes 8 & 12) (Stainless, Br WPL 2212419 Contact Us For Availability

1

Freezer Door (Includes 8 & 12) (Stainless-VCM WPL 2218508 Contact Us For Availability

3

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $4.32

3

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $13.54

3

WP2214960 Whirlpool Refrigerator Condenser Backorder WPL WP2214960 $134.98

3

WP2254360 Whirlpool Refrigerator Gasket In Stock WPL WP2254360 $8.67

4

4387491 Whirlpool Refrigerator Insert In Stock WPL 4387491 $3.70

4

W11745278 Whirlpool Bracket In Stock WPL W11745278 $5.18

4

Flange, Tube WPL 2210523 Contact Us For Availability

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

5

EVAPORATOR ASSY. WPL 2254249 Contact Us For Availability

5

HOLE PLUG, ENDCAP (WHITE) WPL 2204837 Contact Us For Availability

5

Hole-Plug Endcap (Biscuit) WPL 2204838 Contact Us For Availability

5

HOLE PLUG, ENDCAP (BLACK) WPL 2204840 Contact Us For Availability

6

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.38

6

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $2.51

6

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

7

W10823511 Whirlpool Refrigerator Water Tube In Stock WPL W10823511 $12.61

7

WP2186494B Whirlpool Refrigerator Filter Cap In Stock WPL WP2186494B $25.25

7

WP2186494T Whirlpool Water Filter Cap In Stock WPL WP2186494T $6.15

7

WP2186494W Whirlpool Water Filter Cap Backorder WPL WP2186494W $29.76

7

WP2212648 Whirlpool Refrigerator Hinge Sleeve Backorder WPL WP2212648 $3.70

7

WP2212649 Whirlpool Refrigerator Button Plug Backorder WPL WP2212649 $3.70

7

WP2212651 Whirlpool Refrigerator Button Plug Backorder WPL WP2212651 $10.27

7

Drain Pan WPL 2254295 Contact Us For Availability

8

2159060 Whirlpool Refrigerator Gasket In Stock WPL 2159060 $143.90

8

2159061 Whirlpool Refrigerator Door Gasket In Stock WPL 2159061 $94.28

8

2177310 Whirlpool Refrigerator Door Gasket In Stock WPL 2177310 $106.14

8

2177311 Whirlpool Refrigerator Magnetic Door In Stock WPL 2177311 $151.83

9

WP2225521 Whirlpool Water Filter Housing In Stock WPL WP2225521 $92.74

9

Damper, Air WPL 2179858 Contact Us For Availability

10

WPW10189703 Whirlpool Refrigerator Evaporator In Stock WPL WPW10189703 $35.77

WP2163777 Whirlpool Refrigerator Fan Blade In Stock WPL WP2163777 $30.29

WP2176225 Whirlpool Glass Shelf Backorder WPL WP2176225 $120.79

WP3400504 Whirlpool Refrigerator Screw Backorder WPL WP3400504 $3.70

Housing Compartment WPL 2210566 Contact Us For Availability

12

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $3.70

12

Control Box WPL 2218304 Contact Us For Availability

W11594405 Whirlpool Axle In Stock WPL W11594405 $6.90

WP2188808 Whirlpool Refrigerator Inlet Valve In Stock WPL WP2188808 $96.47

Thermostat Assembly (Includes Items 5, 18, & WPL 2210491 Contact Us For Availability

Tray, Door WPL 2195388 Contact Us For Availability

14

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $4.56

14

Insulation, Water Tube WPL 2301622 Contact Us For Availability

15

WP489497 Whirlpool Screw In Stock WPL WP489497 $4.58

16

Cover, Evaporator WPL 2254262 Contact Us For Availability

17

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.56

17

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $4.54

17

Trim, Door Shelf (2) WPL 2195947 Contact Us For Availability

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.51

Nameplate WPL 2220214 Contact Us For Availability

Weight, Thermal WPL 2200831 Contact Us For Availability

EDR6D1 Whirlpool EveryDrop® Ice and Water Re In Stock WPL EDR6D1 $43.40

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

Clip, Heater WPL 2182338 Contact Us For Availability

Endcap, Handle (White) WPL 2212624 Contact Us For Availability

Endcap, Handle (Biscuit) WPL 2212645 Contact Us For Availability

Endcap, Handle (Black) WPL 2221644 Contact Us For Availability

Endcap, Handle (White) WPL 2225094 Contact Us For Availability

Endcap, Handle (Biscuit) WPL 2225095 Contact Us For Availability

Endcap, Handle (Black) WPL 2225108 Contact Us For Availability

20

WP2204813 Whirlpool Refrigerator Cantilever B In Stock WPL WP2204813 $48.02

20

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $137.91

20

Wire Assembly, Freezer Compartment WPL 2187690 Contact Us For Availability

21

WPW10421486 Whirlpool Refrigerator Door Trim In Stock WPL WPW10421486 $39.75

21

Cover, Air Diffuser WPL 2176281 Contact Us For Availability

21

Shim, Bottom Hinge WPL 2172743 Contact Us For Availability

W10829461 Whirlpool Refrigerator Thermal Knob Backorder WPL W10829461 $12.08

WP2195916K Whirlpool End Cap In Stock WPL WP2195916K $6.75

WP2218109 Whirlpool Refrigerator Door Compres Backorder WPL WP2218109 $42.64

WP628356 Whirlpool Refrigerator Fill Cup In Stock WPL WP628356 $15.77

Support Block WPL 2201185 Contact Us For Availability

23

WP2254354 Whirlpool Refrigerator Air Tower Backorder WPL WP2254354 $51.48

23

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

23

Trim, Door Shelf WPL 2159306 Contact Us For Availability

24

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $26.81

24

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $42.62

25

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $37.11

25

Retainer, Freezer Floor WPL 2225473 Contact Us For Availability

26

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

26

Air Diffuser, Top WPL 2204690 Contact Us For Availability

27

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $41.93

27

WP98129 Whirlpool Screw Backorder WPL WP98129 $2.51

28

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

29

Bracket, Fan Motor WPL 2218696 Contact Us For Availability

30

Bracket, Evap. Fan, Front WPL 2214979 Contact Us For Availability

31

WP4387503 Whirlpool Refrigerator Bimetal Defr In Stock WPL WP4387503 $16.40

31

WP627792 Whirlpool Refrigerator Shut Off Arm Backorder WPL WP627792 $35.26

32

WP2176222 Whirlpool Refrigerator Slide In Stock WPL WP2176222 $9.97

32

WP2187464 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187464 $43.83

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $12.32

34

Knob, Damper WPL 2176297 Contact Us For Availability

35

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $52.25

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $3.70

35

Bracket, Evap. Fan, Rear WPL 2214976 Contact Us For Availability

WP2205079 Whirlpool Refrigerator Seal Backorder WPL WP2205079 $4.14

WP2212446 Whirlpool Refrigerator Control Body In Stock WPL WP2212446 $30.98

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

Grille (White) WPL 2301618W Contact Us For Availability

37

8281197 Whirlpool Refrigerator Screw Backorder WPL 8281197 $5.38

37

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $28.80

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

38

WP487576 Whirlpool Washer In Stock WPL WP487576 $4.58

38

Endcap, Door Trim WPL 2177340 Contact Us For Availability

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $3.70

CLIP, GRILLE WPL 2189356 Contact Us For Availability

Housing Base WPL 2201153 Contact Us For Availability

40

2213364 Whirlpool Refrigerator Cover Backorder WPL 2213364 $9.48

40

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $11.95

40

WP489442 Whirlpool Refrigerator Screw Backorder WPL WP489442 $4.56

41

Wiring Harness, Freezer Light WPL 2187601 Contact Us For Availability

42

Electrical Shield, Freezer Light WPL 2193491 Contact Us For Availability

43

4396822 Whirlpool Refrigerator Light Bulb In Stock WPL 4396822 $5.98

43

WP2195341 Whirlpool Refrigerator Pan Trim Backorder WPL WP2195341 $27.12

44

940014 Whirlpool Refrigerator Primary Button Backorder WPL 940014 $10.25

44

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

45

Shield, heat WPL 2204639 Contact Us For Availability

46

2205533 Whirlpool Refrigerator Tube Backorder WPL 2205533 $28.80

46

Post, Damper WPL 2179859 Contact Us For Availability

47

Bracket, Damper Knob WPL 2163810 Contact Us For Availability

48

Gasket, Rear WPL 2166284 Contact Us For Availability

49

Pullout, Freezer Floor WPL 2225476 Contact Us For Availability

50

REAR FENCE PULL-OUT FREEZER FLOOR WPL 2198768 Contact Us For Availability

54

W10853646 Whirlpool Indicator Light Backorder WPL W10853646 $46.43

55

8201597 Whirlpool Inlet Water Fill Tube Kit F In Stock WPL 8201597 $25.33

56

Cover, Tubing WPL 2225531 Contact Us For Availability

57

Cover, Light Lens WPL 2213495 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Tube, Water WPL 2301621 Contact Us For Availability

100

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $88.85
