Model Whirlpool GD5RVAXVA01 REFRIGERATOR – Common Parts &amp; Diagrams

1

WP2182120 Whirlpool Refrigerator Scroll Fan In Stock WPL WP2182120 $32.96

1

Ice Bin WPL W10174539 Contact Us For Availability

2

2324712 Whirlpool Refrigerator Condenser Backorder WPL 2324712 $159.43

2

WP2155590 Whirlpool Refrigerator Retainer Backorder WPL WP2155590 $2.51

2

DOOR, DAIRY WPL 2255421 Contact Us For Availability

2

Fitting, Water WPL 2303216 Contact Us For Availability

3

2182757 Whirlpool Refrigerator Slide Backorder WPL 2182757 $31.55

3

2313359 Whirlpool Refrigerator Air Duct Backorder WPL 2313359 $41.16

3

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $7.69

3

WP2317240 Whirlpool Refrigerator Ice Auger In Stock WPL WP2317240 $57.58

3

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

3

BIN, DOOR WPL W10158506 Contact Us For Availability

4

W10683556 Whirlpool Refrigerator Clip Backorder WPL W10683556 $7.05

4

W11223328 Whirlpool Refrigerator Shelf Stud Backorder WPL W11223328 $9.59

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

4

Washer, Auger WPL 2258220 Contact Us For Availability

5

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

5

WP2255411 Whirlpool Refrigerator Clip In Stock WPL WP2255411 $12.22

5

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $19.51

5

SHIELD, HEAT WPL 2304289 Contact Us For Availability

6

W10528574 Whirlpool Refrigerator Tube Backorder WPL W10528574 $93.74

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $7.21

6

SHELF TRACK (RIGHT HAND) WPL 2301289 Contact Us For Availability

6

SHELF TRACK (LEFT HAND) WPL 2301290 Contact Us For Availability

6

Cover, Crusher WPL 2317248 Contact Us For Availability

6

Glass, Meat Cover WPL 2223714 Contact Us For Availability

6

Ladder, Shelf WPL 2319866 Contact Us For Availability

7

WP2156022 Whirlpool Refrigerator Door Trim In Stock WPL WP2156022 $35.69

7

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

7

WP2223591 Whirlpool Refrigerator Glass Shelf Backorder WPL WP2223591 $124.94

7

WP8533993 Whirlpool Refrigerator Screw Backorder WPL WP8533993 $4.56

8

2323188 Whirlpool Refrigerator Cover Backorder WPL 2323188 $28.80

8

W10899382 Whirlpool Refrigerator Damper Contr In Stock WPL W10899382 $101.79

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

8

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

9

W11661170 Whirlpool Clip Backorder WPL W11661170 $4.39

9

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $3.70

9

WP2196483 Whirlpool Refrigerator Shelf Stud Backorder WPL WP2196483 $4.34

9

WP2203771 Whirlpool Refrigerator Door Hinge In Stock WPL WP2203771 $32.13

9

WP2206670B Whirlpool Dispenser Tray In Stock WPL WP2206670B $20.18

9

WP2206670W Whirlpool Dispenser Tray In Stock WPL WP2206670W $30.46

9

Blade, Fixed WPL 2257020 Contact Us For Availability

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $30.30

W11234406 Whirlpool Refrigerator Wire Harness Backorder WPL W11234406 $57.59

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

WP8281227 Whirlpool Screw Backorder WPL WP8281227 $4.58

WPW10189190 Whirlpool Start Device In Stock WPL WPW10189190 $64.45

DOOR CLOSER, UPPER CAM (SILVER) WPL 2323535 Contact Us For Availability

2317239 Whirlpool Refrigerator Blade Block Backorder WPL 2317239 $4.78

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $28.24

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $27.12

W10138965 Whirlpool Refrigerator Door Hinge Backorder WPL W10138965 $29.81

WP2198587 Whirlpool Refrigerator Cover In Stock WPL WP2198587 $30.80

WP2206629B Whirlpool Refrigerator Bracket Backorder WPL WP2206629B $13.80

WP2304673 Whirlpool Refrigerator Bracket Backorder WPL WP2304673 $6.35

13

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $27.27

13

WP2223288 Whirlpool Refrigerator Cantilever S Backorder WPL WP2223288 $271.15

13

Filler, Wrapper (White) WPL 2304846 Contact Us For Availability

2323186 Whirlpool Refrigerator Housing Backorder WPL 2323186 $33.96

W10155161 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10155161 $56.33

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $5.44

WP3400012 Whirlpool Refrigerator Screw Backorder WPL WP3400012 $2.51

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

WPW10152853 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152853 $34.13

WPW10152854 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152854 $26.38

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $4.61

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $41.93

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $34.73

WPW10152859 Whirlpool Refrigerator Dispenser Backorder WPL WPW10152859 $32.50

LEVER, WATER (GREY) WPL W10155162 Contact Us For Availability

Unit Cover, Bottom WPL 2304899 Contact Us For Availability

2179350 Whirlpool Refrigerator Deflector Backorder WPL 2179350 $27.14

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

W10128735 Whirlpool Refrigerator Cover Backorder WPL W10128735 $66.55

W11629923 Whirlpool Coupling In Stock WPL W11629923 $12.72

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $6.95

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

2310527 Whirlpool Refrigerator Wire Jumper Backorder WPL 2310527 $66.34

W11566763 Whirlpool Fitting In Stock WPL W11566763 $18.87

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $192.85

WP2255720 Whirlpool Refrigerator Ice Maker Do Backorder WPL WP2255720 $41.05

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $4.56

NAMEPLATE, WHIRLPOOL GOLD WPL 2220214 Contact Us For Availability

BRACKET, ICEMAKER MOUNTING WPL 2303583 Contact Us For Availability

Shelf WPL 2255160 Contact Us For Availability

W11512417 Whirlpool Drain Connector In Stock WPL W11512417 $13.03

WP2223320 Whirlpool Slide Track Pan In Stock WPL WP2223320 $12.22

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $2.51

SPACER, SWITCH HARNESS WPL 625834 Contact Us For Availability

SLIDE, ICEMAKER MOUNTING (RIGHT HAND) WPL 2212321 Contact Us For Availability

Clip, Defrost Heater WPL 2161324 Contact Us For Availability

2223680 Whirlpool Refrigerator Shield Backorder WPL 2223680 $37.22

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.38

WP2187467 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187467 $46.19

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $59.32

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

Latch, Bin WPL 2317277 Contact Us For Availability

20

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $3.70

20

WPW10614158 Whirlpool Refrigerator Evaporator In Stock WPL WPW10614158 $53.89

20

CONTROL, ELECTRONIC WPL 2321751 Contact Us For Availability

W10136850 Whirlpool Refrigerator Front Cover Backorder WPL W10136850 $72.33

WPA3073101 Whirlpool Light Bulb In Stock WPL WPA3073101 $5.97

WPW10291106 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10291106 $126.61

BEZEL, DISPENSER (STAINLESS) WPL W10139842 Contact Us For Availability

22

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

22

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $13.98

22

ENCLOSURE, MOTOR ASSEMBLY WPL 2322488 Contact Us For Availability

W10233961 Whirlpool Refrigerator Compressor In Stock WPL W10233961 $307.66

WP2188919 Whirlpool Refrigerator Holder In Stock WPL WP2188919 $3.70

WP2223506 Whirlpool Refrigerator Light Lens Backorder WPL WP2223506 $52.72

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $4.56

FASCIA, DISPENSER (STAINLESS) WPL W10170190 Contact Us For Availability

FASCIA, DISPENSER (WHITE) WPL W10170187 Contact Us For Availability

FASCIA, DISPENSER (BLACK) WPL W10170188 Contact Us For Availability

FASCIA, DISPENSER (NICKEL) WPL W10171983 Contact Us For Availability

2304904 Whirlpool Frame Assembly Backorder WPL 2304904 $105.40

2305571 Whirlpool Gasket Assembly Backorder WPL 2305571 $9.11

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.01

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $14.42

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $5.67

WP489483 Whirlpool Screw In Stock WPL WP489483 $4.58

Cover, Receiver WPL W10173569 Contact Us For Availability

GASKET, FRONT COVER WPL W10194025 Contact Us For Availability

2315398 Whirlpool Refrigerator Slide Backorder WPL 2315398 $4.78

WP2323198 Whirlpool Refrigerator Heater In Stock WPL WP2323198 $30.17

WPW10121138 Whirlpool Refrigerator Water Filt In Stock WPL WPW10121138 $56.98

Support, Window WPL W10170412 Contact Us For Availability

27

everydrop® Filter 3 EDR3RXD1 Whirlpool Refri In Stock WPL EDR3RXD1 $55.44

27

W11623163 Whirlpool Refrigerator Clip Backorder WPL W11623163 $4.39

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $2.51

WP2260518MG Whirlpool Water Filter Cap Backorder WPL WP2260518MG $27.21

WP4387558 Whirlpool Refrigerator Compressor G Backorder WPL WP4387558 $3.70

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

29

WP2315559 Whirlpool Motor Coupling In Stock WPL WP2315559 $26.70

29

WP489500 Whirlpool Refrigerator Screw Backorder WPL WP489500 $2.51

30

2317243 Whirlpool Refrigerator Wiper Backorder WPL 2317243 $28.80

30

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $4.56

31

2317250 Whirlpool Refrigerator Divider Backorder WPL 2317250 $11.09

31

W10896764 Whirlpool Refrigerator Air Baffle Backorder WPL W10896764 $36.11

31

WP2198641 Whirlpool Refrigerator Ice Maker Co In Stock WPL WP2198641 $2.51

32

Clip, Heat Shield WPL 2155547 Contact Us For Availability

33

2305374 Whirlpool Refrigerator Unit Rail Backorder WPL 2305374 $26.21

34

2303234 Whirlpool Refrigerator Shield Backorder WPL 2303234 $28.80

34

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $9.59

34

WP2203770 Whirlpool Refrigerator Door Hinge Backorder WPL WP2203770 $30.16

35

W11751592 Whirlpool Sleeve In Stock WPL W11751592 $12.17

36

2260503MG Whirlpool Refrigerator Button Backorder WPL 2260503MG $12.11

36

2260503W Whirlpool Refrigerator Button Backorder WPL 2260503W $13.30

36

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

37

W10846218 Whirlpool Refrigerator Door Cam Backorder WPL W10846218 $7.80

37

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

39

WPW10334458 Whirlpool Refrigerator Connector Backorder WPL WPW10334458 $8.62

40

WPW10171469 Whirlpool Refrigerator Screw In Stock WPL WPW10171469 $4.58

41

Tube, Process WPL W10221712 Contact Us For Availability

100

Ice Container (Complete) WPL W10174536 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS WPL 978029 Contact Us For Availability

MISCELLANEOUS, KIT, FOAM SLAB (30`` X 32 1/2` WPL 876029 Contact Us For Availability

MISCELLANEOUS, TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

TORX SCREW WRENCH TORX KEY WPL 1117510 Contact Us For Availability

VALVE, ACCESS WPL 978028 Contact Us For Availability

REFRIGERANT CHARGE (5.25 OZS. (R-134A)) WPL NP Contact Us For Availability
