Model Whirlpool ED5LHAXWT02 REFRIGERATOR – Common Parts &amp; Diagrams

1

WP2182120 Whirlpool Refrigerator Scroll Fan Backorder WPL WP2182120 $34.61

1

WP2198573 Whirlpool Refrigerator Ice Bin Backorder WPL WP2198573 $138.23

1

WPW10334458 Whirlpool Refrigerator Connector Backorder WPL WPW10334458 $8.62

2

2172931 Whirlpool Refrigerator Shield Backorder WPL 2172931 $32.39

2

WP2174267 Whirlpool Refrigerator Wire Shelf Backorder WPL WP2174267 $49.56

2

WP2256101 Whirlpool Dairy Door In Stock WPL WP2256101 $69.06

2

WP2309517 Whirlpool Crisper Snack Pan In Stock WPL WP2309517 $84.79

2

RETAINER, FAN MOTOR WPL 2155590 Contact Us For Availability

2

Fitting, Water Tube WPL 2303216 Contact Us For Availability

3

W10508993 Whirlpool Refrigerator Cover Pan In Stock WPL W10508993 $120.22

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

3

WP2198641 Whirlpool Refrigerator Ice Maker Co Backorder WPL WP2198641 $3.33

3

WP2309718 Whirlpool Refrigerator Door Trim In Stock WPL WP2309718 $40.33

3

WP2317240 Whirlpool Refrigerator Ice Auger In Stock WPL WP2317240 $61.42

3

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

3

SLIDE MEAT PAN CONTROL WPL 2182757 Contact Us For Availability

4

2303234 Whirlpool Refrigerator Shield Backorder WPL 2303234 $30.25

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $24.28

4

WP3-24004-109 Whirlpool Refrigerator Screw Backorder WPL WP3-24004-109 $2.51

4

WPW10224328 Whirlpool Refrigerator Spring In Stock WPL WPW10224328 $33.21

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

4

Washer WPL 2258220 Contact Us For Availability

5

2198619 Whirlpool Refrigerator Wire Harness Backorder WPL 2198619 $55.13

5

W11239891 Whirlpool Refrigerator Light Lens Backorder WPL W11239891 $38.12

5

W11527119 Whirlpool Refrigerator Shelf Stud Backorder WPL W11527119 $4.12

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $8.51

5

WP2255411 Whirlpool Refrigerator Clip In Stock WPL WP2255411 $13.05

5

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $20.33

5

SHELF, WIRE (3) WPL 2174268 Contact Us For Availability

5

COVER, LIGHT LENS WPL 2200096 Contact Us For Availability

6

WP2154473 Whirlpool Refrigerator Connector Backorder WPL WP2154473 $10.76

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $4.52

6

WP2179243 Whirlpool Refrigerator Pan Trim Backorder WPL WP2179243 $34.18

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $8.03

6

WP2182971 Whirlpool Refrigerator Freezer Bin Backorder WPL WP2182971 $75.48

6

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

6

Cover, Crusher WPL 2317248 Contact Us For Availability

7

W10278731 Whirlpool Refrigerator Blade Backorder WPL W10278731 $31.81

7

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $123.54

7

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $27.11

7

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.64

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

8

WPW10127762 Whirlpool Refrigerator Handle Backorder WPL WPW10127762 $98.05

8

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

8

CUP, SHELF WPL 2176134 Contact Us For Availability

9

W10242649 Whirlpool Refrigerator Door Hinge Backorder WPL W10242649 $35.25

9

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $4.52

9

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $4.70

9

WP2315562 Whirlpool Refrigerator Thermostat In Stock WPL WP2315562 $57.79

9

Blade, Fixed WPL 2257020 Contact Us For Availability

9

Screw WPL W10191952 Contact Us For Availability

2181741 Whirlpool Refrigerator Slide Backorder WPL 2181741 $39.71

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $31.82

W11084324 Whirlpool Refrigerator Wire Harness Backorder WPL W11084324 $42.66

WP2188656 Whirlpool Refrigerator Crisper Clea In Stock WPL WP2188656 $81.31

WPW10272168 Whirlpool Refrigerator Water Fill Backorder WPL WPW10272168 $32.15

2317239 Whirlpool Refrigerator Blade Block Backorder WPL 2317239 $4.78

W10152855 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152855 $35.56

WP2179343 Whirlpool Refrigerator Control Body Backorder WPL WP2179343 $13.98

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $30.25

WP8281227 Whirlpool Screw In Stock WPL WP8281227 $4.58

WPW10152853 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152853 $36.65

WPW10152854 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152854 $26.52

2161466 Whirlpool Refrigerator Slide Backorder WPL 2161466 $10.76

2203407T Whirlpool Refrigerator Cover Backorder WPL 2203407T $13.83

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $28.47

W11661170 Whirlpool Clip Backorder WPL W11661170 $4.39

WP2179342 Whirlpool Refrigerator Slide Backorder WPL WP2179342 $10.08

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $7.78

WP2182179 Whirlpool Cam Closer In Stock WPL WP2182179 $4.21

WP2198587 Whirlpool Refrigerator Cover Backorder WPL WP2198587 $32.34

WP2203407B Whirlpool Refrigerator Cover Backorder WPL WP2203407B $12.81

WP2203407W Whirlpool Refrigerator Cover Backorder WPL WP2203407W $11.51

WPW10151374 Whirlpool Refrigerator Diffuser In Stock WPL WPW10151374 $50.99

WPW10272161 Whirlpool Refrigerator Stripper A Backorder WPL WPW10272161 $31.09

BRACKET, DOOR STOP (SILVER) WPL W10219801 Contact Us For Availability

BRACKET, DOOR STOP (BLACK) WPL W10219802 Contact Us For Availability

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $34.62

2180200 Whirlpool Refrigerator Socket Backorder WPL 2180200 $32.98

W10138965 Whirlpool Refrigerator Door Hinge Backorder WPL W10138965 $31.29

W10278733 Whirlpool Refrigerator Blade Backorder WPL W10278733 $31.82

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $28.64

WPW10189190 Whirlpool Start Device In Stock WPL WPW10189190 $68.49

W10252495 Whirlpool Refrigerator Wire Cover Backorder WPL W10252495 $28.82

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $9.63

WP2188664 Whirlpool Refrigerator Meat Crisper In Stock WPL WP2188664 $59.81

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $5.44

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

Light Bar (RC) WPL 2179920 Contact Us For Availability

Filler, Wrapper (White) WPL 2304846 Contact Us For Availability

2161306 Whirlpool Refrigerator Arm Pivot Backorder WPL 2161306 $4.72

2179350 Whirlpool Refrigerator Deflector Backorder WPL 2179350 $28.49

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $4.61

WPW10288153 Whirlpool Refrigerator Screw In Stock WPL WPW10288153 $3.84

WPW10311032 Whirlpool Refrigerator Grille Backorder WPL WPW10311032 $61.29

WPW10311033 Whirlpool Refrigerator Grille Backorder WPL WPW10311033 $78.41

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $10.41

W11629923 Whirlpool Coupling In Stock WPL W11629923 $13.54

WP2179234 Whirlpool Refrigerator Pan Trim Backorder WPL WP2179234 $28.47

WP2213265 Whirlpool Refrigerator Nameplate Backorder WPL WP2213265 $39.71

WP489497 Whirlpool Screw In Stock WPL WP489497 $5.40

W10152860 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152860 $34.31

WP2255720 Whirlpool Refrigerator Ice Maker Do Backorder WPL WP2255720 $43.10

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $5.38

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $45.45

WPW10152859 Whirlpool Refrigerator Dispenser Backorder WPL WPW10152859 $34.13

WPW10276341 Whirlpool Refrigerator Glass Shel In Stock WPL WPW10276341 $143.17

BRACKET, ICEMAKER MOUNTING WPL 2303583 Contact Us For Availability

2161307 Whirlpool Refrigerator Rod Backorder WPL 2161307 $8.13

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

W10243997 Whirlpool Refrigerator Switch Backorder WPL W10243997 $81.56

W11566763 Whirlpool Fitting In Stock WPL W11566763 $20.64

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $2.51

WPW10276348 Whirlpool Refrigerator Glass Shel In Stock WPL WPW10276348 $119.79

Slide, Ice Maker Mounting WPL 2212321 Contact Us For Availability

W11512417 Whirlpool Drain Connector In Stock WPL W11512417 $13.85

WP2187467 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187467 $48.50

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $192.85

Latch, Bin WPL 2317277 Contact Us For Availability

W10354806 Whirlpool Refrigerator Wire Harness Backorder WPL W10354806 $174.96

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $3.70

WP2203770 Whirlpool Refrigerator Door Hinge Backorder WPL WP2203770 $31.66

Clip WPL 2161324 Contact Us For Availability

21

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $59.32

21

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

22

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

22

WP2188919 Whirlpool Refrigerator Holder In Stock WPL WP2188919 $4.52

2317243 Whirlpool Refrigerator Wiper Backorder WPL 2317243 $30.25

WP2203408B Whirlpool Refrigerator Cover Backorder WPL WP2203408B $13.47

WP2203408W Whirlpool Refrigerator Cover Backorder WPL WP2203408W $11.66

WPW10309395 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10309395 $139.29

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.63

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $27.27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $15.50

Spacer, Switch (2) WPL 625834 Contact Us For Availability

2317250 Whirlpool Refrigerator Divider Backorder WPL 2317250 $11.09

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

WP2323198 Whirlpool Refrigerator Heater In Stock WPL WP2323198 $30.17

Cover, Receiver WPL W10173569 Contact Us For Availability

26

2315398 Whirlpool Refrigerator Slide Backorder WPL 2315398 $4.78

26

WP2304673 Whirlpool Refrigerator Bracket Backorder WPL WP2304673 $6.35

27

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $5.67

27

WP489483 Whirlpool Screw In Stock WPL WP489483 $5.40

28

W10141518 Whirlpool Refrigerator Screw Backorder WPL W10141518 $5.65

28

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $3.33

28

WPW10121138 Whirlpool Refrigerator Water Filt In Stock WPL WPW10121138 $57.79

29

everydrop® Filter 3 EDR3RXD1 Whirlpool Refri In Stock WPL EDR3RXD1 $56.07

30

W10853646 Whirlpool Indicator Light In Stock WPL W10853646 $48.75

31

WP2315559 Whirlpool Motor Coupling In Stock WPL WP2315559 $37.44

31

WP489500 Whirlpool Refrigerator Screw Backorder WPL WP489500 $2.51

32

WPW10254073 Whirlpool Refrigerator Washer Backorder WPL WPW10254073 $4.15

33

2260503W Whirlpool Refrigerator Button Backorder WPL 2260503W $13.30

35

TUBE, FILTER INLET WPL W10281289 Contact Us For Availability

36

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $9.59

100

W11512149 Whirlpool Ice Maker Assembly In Stock WPL W11512149 $78.53

100

WP2317251 Whirlpool Refrigerator Ice Containe In Stock WPL WP2317251 $196.63

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $29.35

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $8.03

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $34.75

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.99

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.02

PAINT, TOUCH-UP (1/2oz.) (Graphite) WPL 80051 Contact Us For Availability

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability
