Model Whirlpool 4KSRS25QAW01 REFRIGERATOR – Common Parts & Diagrams

WPL  1117510
WPL 1117510 WPL 1117510 Contact Us For Availability
View on Model
WPL  LIT2167323
WPL LIT2167323 WPL LIT2167323 Contact Us For Availability
View on Model
WPL  LIT2167460
WPL LIT2167460 WPL LIT2167460 Contact Us For Availability
View on Model
WPL  LIT628371
WPL LIT628371 WPL LIT628371 Contact Us For Availability
View on Model
1
Shelf Assembly, Cantilever (2)
Shelf Assembly, Cantilever (2) WPL 1125597 Contact Us For Availability
View on Model
1
Liner (Not A Serviceable Part)
Liner (Not A Serviceable Part) WPL ARI14307A7 Contact Us For Availability
View on Model
1
Freezer Door (Includes No.8 And Dispenser Fro
Freezer Door (Includes No.8 And Dispenser Fro WPL 2167430 Contact Us For Availability
View on Model
1
Freezer Door (Includes No.8 And Dispenser Fro
Freezer Door (Includes No.8 And Dispenser Fro WPL 2167431 Contact Us For Availability
View on Model
1
Bracket, Motor
Bracket, Motor WPL 1118386 Contact Us For Availability
View on Model
1
Refrigerator Door (Includes No.7) (White)
Refrigerator Door (Includes No.7) (White) WPL 2159404 Contact Us For Availability
View on Model
1
Refrigerator Door (Includes No.7) (Almond)
Refrigerator Door (Includes No.7) (Almond) WPL 2159405 Contact Us For Availability
View on Model
1
Control Box
Control Box WPL 2169147 Contact Us For Availability
View on Model
2
Fan, Blade
Fan, Blade WPL 1108179 Contact Us For Availability
View on Model
2
Mounting Bracket
Mounting Bracket WPL 1110629 Contact Us For Availability
View on Model
2
Glass, Shelf
Glass, Shelf WPL 1125593 Contact Us For Availability
View on Model
2
Shelf, Top Compartment
Shelf, Top Compartment WPL 2167276 Contact Us For Availability
View on Model
2
Motor, Dispenser
Motor, Dispenser WPL 2165401 Contact Us For Availability
View on Model
2
Load Lock (4)
Load Lock (4) WPL 1117999 Contact Us For Availability
View on Model
3
Retainer, Glass
Retainer, Glass WPL 1125594 Contact Us For Availability
View on Model
3
Air Scoop
Air Scoop WPL 2161231 Contact Us For Availability
View on Model
3
Door, Ice Compartment
Door, Ice Compartment WPL 2167277 Contact Us For Availability
View on Model
3
Door, Compartment
Door, Compartment WPL 2167317 Contact Us For Availability
View on Model
3
Screw (2)
Screw (2) WPL 489397 Contact Us For Availability
View on Model
4
Gasket, Front
Gasket, Front WPL 1125786 Contact Us For Availability
View on Model
4
Housing, Dispenser (Not a Serviceable Part)
Housing, Dispenser (Not a Serviceable Part) WPL ARI14308A1 Contact Us For Availability
View on Model
4
Holder, Beverage
Holder, Beverage WPL 1125981 Contact Us For Availability
View on Model
5
Air Duct Freezer
Air Duct Freezer WPL 2155575 Contact Us For Availability
View on Model
5
Stud, R.S. Front
Stud, R.S. Front WPL 946356 Contact Us For Availability
View on Model
5
Butter, Tray
Butter, Tray WPL 1125936 Contact Us For Availability
View on Model
6
Tube, Water (See Item No.22)
Tube, Water (See Item No.22) WPL ARI14309A2 Contact Us For Availability
View on Model
6
Insert, Handle (White)
Insert, Handle (White) WPL 1117948 Contact Us For Availability
View on Model
6
Insert, Handle (Almond)
Insert, Handle (Almond) WPL 1117949 Contact Us For Availability
View on Model
7
Gasket, Cover (Rear)
Gasket, Cover (Rear) WPL 1125706 Contact Us For Availability
View on Model
7
Frame, Slides (White)
Frame, Slides (White) WPL 2152717 Contact Us For Availability
View on Model
7
Frame, Slides (Almond)
Frame, Slides (Almond) WPL 2152718 Contact Us For Availability
View on Model
7
Fan Motor
Fan Motor WPL 2154986 Contact Us For Availability
View on Model
7
Shelf Bin (4)
Shelf Bin (4) WPL 2156016 Contact Us For Availability
View on Model
7
Wiring Assembly, Ice Dispenser
Wiring Assembly, Ice Dispenser WPL 2149192 Contact Us For Availability
View on Model
8
Glass, Cover (2)
Glass, Cover (2) WPL 1125822 Contact Us For Availability
View on Model
8
Slide, Cube/Crush Switch (White)
Slide, Cube/Crush Switch (White) WPL 2152720 Contact Us For Availability
View on Model
8
Slide, Cube/Crush Switch (Almond)
Slide, Cube/Crush Switch (Almond) WPL 2152721 Contact Us For Availability
View on Model
8
Support, Stud (2)
Support, Stud (2) WPL 946355 Contact Us For Availability
View on Model
8
End Cap, Handle
End Cap, Handle WPL 1107341 Contact Us For Availability
View on Model
9
Pan Shelf & Slide Assembly
Pan Shelf & Slide Assembly WPL 2161760 Contact Us For Availability
View on Model
9
Grommet (2)
Grommet (2) WPL 1110779 Contact Us For Availability
View on Model
9
Screw
Screw WPL 489075 Contact Us For Availability
View on Model
10
Glass, Shelf
Glass, Shelf WPL 1125595 Contact Us For Availability
View on Model
10
Door Mechanism Assembly
Door Mechanism Assembly WPL 2157650 Contact Us For Availability
View on Model
10
Grommet, Fan (2)
Grommet, Fan (2) WPL 2155589 Contact Us For Availability
View on Model
10
Handle Assembly
Handle Assembly WPL 1107215 Contact Us For Availability
View on Model
10
Valve, Solenoid
Valve, Solenoid WPL 2167100 Contact Us For Availability
View on Model
11
Gasket (Front)
Gasket (Front) WPL 1125814 Contact Us For Availability
View on Model
11
Shelf
Shelf WPL 2155683 Contact Us For Availability
View on Model
11
Trim, Door Shelf
Trim, Door Shelf WPL 2157603 Contact Us For Availability
View on Model
11
Cam Assembly
Cam Assembly WPL 2161250 Contact Us For Availability
View on Model
12
Gasket (Rear)
Gasket (Rear) WPL 1125817 Contact Us For Availability
View on Model
12
Harness, Fan Evaporator, And Heater, Bi-Metal
Harness, Fan Evaporator, And Heater, Bi-Metal WPL 2158782 Contact Us For Availability
View on Model
12
Spacer, Handle
Spacer, Handle WPL 1107651 Contact Us For Availability
View on Model
12
Cover, Motor
Cover, Motor WPL 1115339 Contact Us For Availability
View on Model
13
Shim, Hinge Top
Shim, Hinge Top WPL 1123515 Contact Us For Availability
View on Model
13
Eyelet, Roller
Eyelet, Roller WPL 1112308 Contact Us For Availability
View on Model
13
Grille, Overflow (White)
Grille, Overflow (White) WPL 1126120 Contact Us For Availability
View on Model
13
Grille, Overflow (Almond)
Grille, Overflow (Almond) WPL 1126121 Contact Us For Availability
View on Model
13
Chute, Ice
Chute, Ice WPL 2156146 Contact Us For Availability
View on Model
13
Tube, Water Inlet
Tube, Water Inlet WPL 2155247 Contact Us For Availability
View on Model
14
Roller
Roller WPL 2161749 Contact Us For Availability
View on Model
14
Clip, Bearing (2)
Clip, Bearing (2) WPL 987917 Contact Us For Availability
View on Model
14
Cover, Wiring
Cover, Wiring WPL 2155572 Contact Us For Availability
View on Model
14
Bracket, Door Stop
Bracket, Door Stop WPL 2155332 Contact Us For Availability
View on Model
14
Washer
Washer WPL 628337 Contact Us For Availability
View on Model
14
Retainer, Damper
Retainer, Damper WPL 938439 Contact Us For Availability
View on Model
15
Pivot Arm
Pivot Arm WPL 1110559 Contact Us For Availability
View on Model
15
Bearing, Lever (3)
Bearing, Lever (3) WPL 983697 Contact Us For Availability
View on Model
15
Retainer, Insert (Bottom)
Retainer, Insert (Bottom) WPL 1117952 Contact Us For Availability
View on Model
15
Tube, Inlet Valve
Tube, Inlet Valve WPL 627860 Contact Us For Availability
View on Model
16
Spring, Lever (2)
Spring, Lever (2) WPL 983696 Contact Us For Availability
View on Model
16
Crisper Pan (2)
Crisper Pan (2) WPL 2167284 Contact Us For Availability
View on Model
16
Drain Fitting
Drain Fitting WPL 2155556 Contact Us For Availability
View on Model
16
Retainer, Insert
Retainer, Insert WPL 1107243 Contact Us For Availability
View on Model
16
Clamp
Clamp WPL 510716 Contact Us For Availability
View on Model
16
Stop, Cone
Stop, Cone WPL 1118480 Contact Us For Availability
View on Model
17
Utility Pan
Utility Pan WPL 2167282 Contact Us For Availability
View on Model
17
Shield, Wiring
Shield, Wiring WPL 2147165 Contact Us For Availability
View on Model
17
Cover, Evaporator
Cover, Evaporator WPL 2155612 Contact Us For Availability
View on Model
17
Shelf Track (Right Side (3))
Shelf Track (Right Side (3)) WPL 1126354 Contact Us For Availability
View on Model
17
Shelf Track (Left Side (3))
Shelf Track (Left Side (3)) WPL 1126355 Contact Us For Availability
View on Model
17
Trim, Door
Trim, Door WPL 1119062 Contact Us For Availability
View on Model
17
Nut, Valve
Nut, Valve WPL 537588 Contact Us For Availability
View on Model
17
Feeder Cone
Feeder Cone WPL 1119074 Contact Us For Availability
View on Model
18
Cover
Cover WPL 628329 Contact Us For Availability
View on Model
18
Shelf Bin (4)
Shelf Bin (4) WPL 1125555 Contact Us For Availability
View on Model
18
Trim Kit Panels (Black)
Trim Kit Panels (Black) WPL 4210348 Contact Us For Availability
View on Model
18
Almond Handle Inserts
Almond Handle Inserts WPL 4211147 Contact Us For Availability
View on Model
18
White
White WPL 4211148 Contact Us For Availability
View on Model
18
Trim Kit Acrylic Panel Kit
Trim Kit Acrylic Panel Kit WPL 4318336 Contact Us For Availability
View on Model
18
Handle Inserts (Black)
Handle Inserts (Black) WPL 4318339 Contact Us For Availability
View on Model
18
Woodgrain
Woodgrain WPL 4318340 Contact Us For Availability
View on Model
18
Black Grille Kit
Black Grille Kit WPL 4318417 Contact Us For Availability
View on Model
19
Spacer
Spacer WPL 625834 Contact Us For Availability
View on Model
20
Spacer, Hinge
Spacer, Hinge WPL 1129868 Contact Us For Availability
View on Model
20
Control Box Harness
Control Box Harness WPL 2149186 Contact Us For Availability
View on Model
21
Filler, Wrapper (White)
Filler, Wrapper (White) WPL 1110708 Contact Us For Availability
View on Model
21
Filler, Wrapper (Almond)
Filler, Wrapper (Almond) WPL 1110709 Contact Us For Availability
View on Model
21
Basket, Middle
Basket, Middle WPL 2155685 Contact Us For Availability
View on Model
22
Grille (White)
Grille (White) WPL 2155486 Contact Us For Availability
View on Model
22
Grille (Almond)
Grille (Almond) WPL 2155487 Contact Us For Availability
View on Model
22
Glass, Shelf
Glass, Shelf WPL 2161683 Contact Us For Availability
View on Model
22
Front, Basket
Front, Basket WPL 2167281 Contact Us For Availability
View on Model
22
CLIP, WIRING
CLIP, WIRING WPL 1115375 Contact Us For Availability
View on Model
23
Clamp
Clamp WPL 2161324 Contact Us For Availability
View on Model
23
Reflector
Reflector WPL 2161809 Contact Us For Availability
View on Model
23
Basket, Upper
Basket, Upper WPL 2152093 Contact Us For Availability
View on Model
23
Connecting Rod
Connecting Rod WPL 1123960 Contact Us For Availability
View on Model
24
Fastener, Push-On
Fastener, Push-On WPL 489285 Contact Us For Availability
View on Model
24
Wiring Assembly
Wiring Assembly WPL 2165297 Contact Us For Availability
View on Model
24
Gasket, Front
Gasket, Front WPL 2161686 Contact Us For Availability
View on Model
24
Lever Assembly, Ice Dispenser (Almond)
Lever Assembly, Ice Dispenser (Almond) WPL 1125972 Contact Us For Availability
View on Model
24
Lever Assembly, Ice Dispenser (White)
Lever Assembly, Ice Dispenser (White) WPL 2155815 Contact Us For Availability
View on Model
24
Front, Basket
Front, Basket WPL 2167279 Contact Us For Availability
View on Model
24
Blade, Fixed (2)
Blade, Fixed (2) WPL 1119009 Contact Us For Availability
View on Model
25
Guide, Ice (White)
Guide, Ice (White) WPL 1124730 Contact Us For Availability
View on Model
25
Frame & Roller
Frame & Roller WPL 2161706 Contact Us For Availability
View on Model
25
Guide, Ice (Almond)
Guide, Ice (Almond) WPL 1126026 Contact Us For Availability
View on Model
25
Basket, Lower
Basket, Lower WPL 2152102 Contact Us For Availability
View on Model
25
Escutcheon, Control Box
Escutcheon, Control Box WPL 2167184 Contact Us For Availability
View on Model
26
Frame And Roller Asm. (Cantilever)
Frame And Roller Asm. (Cantilever) WPL 2161806 Contact Us For Availability
View on Model
26
Screw
Screw WPL 488892 Contact Us For Availability
View on Model
27
Slide, Light Switch (White)
Slide, Light Switch (White) WPL 2152726 Contact Us For Availability
View on Model
27
Slide, Light Switch (Almond)
Slide, Light Switch (Almond) WPL 2152727 Contact Us For Availability
View on Model
27
Stud, Shelf (4) Compartment
Stud, Shelf (4) Compartment WPL 1115386 Contact Us For Availability
View on Model
27
Cement Alumilastic)
Cement Alumilastic) WPL 542369 Contact Us For Availability
View on Model
27
Knob, Air Control
Knob, Air Control WPL 1116853 Contact Us For Availability
View on Model
28
Knob, Retainer
Knob, Retainer WPL 837444 Contact Us For Availability
View on Model
29
Lamp Holder
Lamp Holder WPL 2147131 Contact Us For Availability
View on Model
29
Light Lens
Light Lens WPL 1115389 Contact Us For Availability
View on Model
30
Stud, R.S. Rear
Stud, R.S. Rear WPL 1106982 Contact Us For Availability
View on Model
31
Tap Plate (2)
Tap Plate (2) WPL 2147310 Contact Us For Availability
View on Model
31
Shroud, Bracket
Shroud, Bracket WPL 1129333 Contact Us For Availability
View on Model
32
Insulator, Control Bracket
Insulator, Control Bracket WPL 2147164 Contact Us For Availability
View on Model
33
Bracket, Control
Bracket, Control WPL 2147163 Contact Us For Availability
View on Model
34
Bulb, Light
Bulb, Light WPL 989331 Contact Us For Availability
View on Model
35
Screw (2)
Screw (2) WPL 488361 Contact Us For Availability
View on Model
36
Screw,
Screw, WPL 489155 Contact Us For Availability
View on Model
38
Lever Assembly, Water Dispenser (Almond)
Lever Assembly, Water Dispenser (Almond) WPL 2159198 Contact Us For Availability
View on Model
38
Lever Assembly, Water Dispenser (White)
Lever Assembly, Water Dispenser (White) WPL 2159199 Contact Us For Availability
View on Model
39
Insert, Cover (White)
Insert, Cover (White) WPL 2167292 Contact Us For Availability
View on Model
39
Insert, Cover (Almond)
Insert, Cover (Almond) WPL 2167293 Contact Us For Availability
View on Model
40
Service Cord
Service Cord WPL 1129332 Contact Us For Availability
View on Model
40
Cover, Housing (Includes Item 39) (White)
Cover, Housing (Includes Item 39) (White) WPL 2167290 Contact Us For Availability
View on Model
40
Cover, Housing (Includes Item 39) (Almond)
Cover, Housing (Includes Item 39) (Almond) WPL 2167291 Contact Us For Availability
View on Model
40
Nut, Compression
Nut, Compression WPL 1129179 Contact Us For Availability
View on Model
41
Heat Shield, Frame
Heat Shield, Frame WPL 2147172 Contact Us For Availability
View on Model
41
Housing Filler
Housing Filler WPL 2152700 Contact Us For Availability
View on Model
42
Bracket, Water
Bracket, Water WPL 987049 Contact Us For Availability
View on Model
43
WPL  876029
WPL 876029 WPL 876029 Contact Us For Availability
View on Model
43
TAPE, VINYL (3/4 X 108``)
TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability
View on Model
43
Insert
Insert WPL 1129177 Contact Us For Availability
View on Model
43
Leveler, Enamel (13 Oz. Spray Can)
Leveler, Enamel (13 Oz. Spray Can) WPL 350941 Contact Us For Availability
View on Model
43
Transformer (115-230 Volt)
Transformer (115-230 Volt) WPL 515393 Contact Us For Availability
View on Model
43
CEMENT, ALUMILASTIC (1 1/4 OZ.)
CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability
View on Model
43
Enamel, B
Enamel, B WPL 799340 Contact Us For Availability
View on Model
43
WPL  799833
WPL 799833 WPL 799833 Contact Us For Availability
View on Model
43
WPL  978883
WPL 978883 WPL 978883 Contact Us For Availability
View on Model
43
Ice Deflector
Ice Deflector WPL 1119043 Contact Us For Availability
View on Model
44
Front Cover, Ice Container
Front Cover, Ice Container WPL 1126036 Contact Us For Availability
View on Model
46
Light Lens, Dispenser
Light Lens, Dispenser WPL 983359 Contact Us For Availability
View on Model
47
Cover, Unit
Cover, Unit WPL 2167191 Contact Us For Availability
View on Model
48
Cabinet (Not A Serviceable Part)
Cabinet (Not A Serviceable Part) WPL ARI14305A6 Contact Us For Availability
View on Model
63
VALVE, ACCESS (5/8``)
VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability
View on Model
