Model Whirlpool 3ED22DQXDW03 REFRIGERATOR – Common Parts &amp; Diagrams

WPL 1117510 WPL 1117510 Contact Us For Availability

WPL LIT2165605 WPL LIT2165605 Contact Us For Availability

WPL LIT2182955 WPL LIT2182955 Contact Us For Availability

WPL LIT628371 WPL LIT628371 Contact Us For Availability

1

W11254898 Whirlpool Refrigerator Scroll Fan Backorder WPL W11254898 $115.82

1

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

1

WPW10141748 Whirlpool Refrigerator Glass Shel Backorder WPL WPW10141748 $165.08

1

Control Box WPL 2169147 Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI11789A3 Contact Us For Availability

1

Refrigerator Door (Includes Item No.8) (White WPL 2171082 Contact Us For Availability

1

Refrigerator Door (Includes Item No.8) (Almon WPL 2171083 Contact Us For Availability

2

2194744 Whirlpool Refrigerator Escutcheon Backorder WPL 2194744 $28.80

2

W11497323 Whirlpool Snack Pan In Stock WPL W11497323 $109.31

2

WP2155590 Whirlpool Refrigerator Retainer Backorder WPL WP2155590 $2.51

2

Fan, Blade WPL 1108179 Contact Us For Availability

2

Mounting Bracket WPL 1110629 Contact Us For Availability

2

Motor, Dispenser WPL 2165167 Contact Us For Availability

2

Retainer, Bottle WPL 2173643 Contact Us For Availability

3

2171712 Whirlpool Refrigerator Ice Door Backorder WPL 2171712 $42.79

3

2182757 Whirlpool Refrigerator Slide Backorder WPL 2182757 $31.55

3

W10508993 Whirlpool Refrigerator Cover Pan In Stock WPL W10508993 $110.82

3

WP2256101 Whirlpool Dairy Door In Stock WPL WP2256101 $51.86

3

WP488878 Whirlpool Refrigerator Tube Clamp Backorder WPL WP488878 $4.81

3

WPW10129867 Whirlpool Refrigerator Solenoid Backorder WPL WPW10129867 $78.81

3

Condenser Assembly WPL 2164513 Contact Us For Availability

3

Screw (2) WPL 489397 Contact Us For Availability

3

Air Scoop WPL 2161231 Contact Us For Availability

4

4387491 Whirlpool Refrigerator Insert In Stock WPL 4387491 $3.70

4

W10850503 Whirlpool Refrigerator Guide Backorder WPL W10850503 $4.63

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $22.34

4

WP2156022 Whirlpool Refrigerator Door Trim In Stock WPL WP2156022 $35.69

4

WP2175210 Whirlpool Refrigerator Shroud Backorder WPL WP2175210 $26.21

4

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

4

Gasket, Cover (Front) WPL 2174442 Contact Us For Availability

5

2171846 Whirlpool Refrigerator Release Valve Backorder WPL 2171846 $10.76

5

WP2196003 Whirlpool Refrigerator Bar Riser Backorder WPL WP2196003 $3.70

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

6

681390 Whirlpool Refrigerator Screw Backorder WPL 681390 $9.13

6

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $108.46

6

WP1115374 Whirlpool Refrigerator Clip Backorder WPL WP1115374 $2.51

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

6

WP2166867 Whirlpool Refrigerator Defrost Time Backorder WPL WP2166867 $84.73

6

WP489115 Whirlpool Refrigerator Rivet Backorder WPL WP489115 $3.70

6

WPW10321304 Whirlpool Refrigerator Door Shelf In Stock WPL WPW10321304 $25.24

6

Louver WPL 1127161 Contact Us For Availability

6

Diffuser, Air Duct WPL 2149544 Contact Us For Availability

7

489392 Whirlpool Refrigerator Screw Backorder WPL 489392 $9.59

7

W10823511 Whirlpool Refrigerator Water Tube In Stock WPL W10823511 $12.61

7

Heat Shield And Drain Pan WPL 2149293 Contact Us For Availability

7

Wiring Assembly, Ice Dispenser WPL 2169490 Contact Us For Availability

7

Fan, Motor WPL 2154976 Contact Us For Availability

7

Extension, Bottom (White) WPL 2174282 Contact Us For Availability

7

Extension, Bottom (Almond) WPL 2174283 Contact Us For Availability

8

2159072 Whirlpool Refrigerator FIP Gasket Backorder WPL 2159072 $87.71

8

2159073 Whirlpool Refrigerator Door Gasket Backorder WPL 2159073 $87.71

8

940014 Whirlpool Refrigerator Primary Button Backorder WPL 940014 $10.25

8

WP1106508 Whirlpool Refrigerator Gasket Backorder WPL WP1106508 $4.14

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

8

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

9

WP2158826 Whirlpool Refrigerator Dampener Backorder WPL WP2158826 $0.90

9

WP2181911 Whirlpool Refrigerator Shim Backorder WPL WP2181911 $11.97

9

WP2198202 Whirlpool Refrigerator Temperature In Stock WPL WP2198202 $45.43

9

WPW10169511 Whirlpool Refrigerator Coupling In Stock WPL WPW10169511 $9.70

9

Shelf Ladder WPL 2181796 Contact Us For Availability

9

Frame, Shelf (2) WPL 2174042 Contact Us For Availability

9

Handle, Center (White) WPL 2189789 Contact Us For Availability

9

Handle, Center (Almond) WPL 2189790 Contact Us For Availability

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $3.70

WP2188656 Whirlpool Refrigerator Crisper Clea In Stock WPL WP2188656 $70.03

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.51

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

Valve, Solenoid WPL 2167100 Contact Us For Availability

2182146 Whirlpool Refrigerator Duct Backorder WPL 2182146 $32.79

W10759522 Whirlpool Screw Backorder WPL W10759522 $2.51

WP2179343 Whirlpool Refrigerator Control Body In Stock WPL WP2179343 $13.98

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $4.59

Cam Assembly WPL 2161250 Contact Us For Availability

Shim WPL 2179399 Contact Us For Availability

1110560 Whirlpool Refrigerator Bearing Backorder WPL 1110560 $4.72

2256178 Whirlpool Shield Assembly Backorder WPL 2256178 $69.97

W10777924 Whirlpool Refrigerator Wine Rack Backorder WPL W10777924 $8.47

WP1120581 Whirlpool Refrigerator Mechanism Backorder WPL WP1120581 $80.45

WP2162358 Whirlpool Refrigerator Terminal Cov Backorder WPL WP2162358 $30.03

WP2179342 Whirlpool Refrigerator Slide Backorder WPL WP2179342 $10.08

WPW10284487 Whirlpool Refrigerator Bracket Backorder WPL WPW10284487 $42.13

Harness, Fan Evaporator, And Heater, Bi-Metal WPL 2189564 Contact Us For Availability

Divider, Bin WPL 2171284 Contact Us For Availability

WP2155789 Whirlpool Refrigerator Gasket Backorder WPL WP2155789 $3.70

WP2169412 Whirlpool Overload Relay Backorder WPL WP2169412 $50.33

WP2256085 Whirlpool Refrigerator Retainer Backorder WPL WP2256085 $13.73

Tube, Water Inlet WPL 2171943 Contact Us For Availability

Grommet (4) WPL 2176134 Contact Us For Availability

Extension, Top (White) WPL 2174276 Contact Us For Availability

Extension, Top (Almond) WPL 2174277 Contact Us For Availability

4318165 Whirlpool Refrigerator Door Closure C In Stock WPL 4318165 $9.42

WP2188664 Whirlpool Dishwasher Meat Crisper P In Stock WPL WP2188664 $45.77

WP2196089 Whirlpool Refrigerator Container In Stock WPL WP2196089 $74.70

WP488488 Whirlpool Refrigerator Screw Backorder WPL WP488488 $3.70

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

Clip, Defrost Heater WPL 2161324 Contact Us For Availability

Washer WPL 628337 Contact Us For Availability

Retainer, Damper WPL 938439 Contact Us For Availability

W10136387A Whirlpool Refrigerator Egg Contain In Stock WPL W10136387A $5.98

W10749708 Whirlpool Refrigerator Coupling Backorder WPL W10749708 $13.85

WP1129262 Whirlpool Refrigerator Cover Backorder WPL WP1129262 $10.38

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

WP2262184 Whirlpool Refrigerator Start Relay Backorder WPL WP2262184 $41.23

WP999367 Whirlpool Refrigerator Screw Backorder WPL WP999367 $2.51

WPW10151374 Whirlpool Refrigerator Diffuser In Stock WPL WPW10151374 $33.42

Pivot Arm WPL 1110559 Contact Us For Availability

Tube, Inlet Valve WPL 627860 Contact Us For Availability

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $32.98

627068 Whirlpool Refrigerator Screw Backorder WPL 627068 $7.52

WP2177817 Whirlpool Refrigerator Egg Containe Backorder WPL WP2177817 $7.39

WP2304241 Whirlpool Refrigerator Gasket Backorder WPL WP2304241 $26.21

Spring, Lever (2) WPL 983696 Contact Us For Availability

Clamp Tube WPL 510716 Contact Us For Availability

Stop, Cone WPL 1118480 Contact Us For Availability

Bracket, Door Stop WPL 2155332 Contact Us For Availability

2150331 Whirlpool Refrigerator Wire Cover Backorder WPL 2150331 $11.11

4388357 Whirlpool Refrigerator Evaporator Cov Backorder WPL 4388357 $93.63

WP2201147 Whirlpool Refrigerator Capacitor Backorder WPL WP2201147 $48.06

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $4.56

Nut WPL 537588 Contact Us For Availability

Feeder Cone WPL 1119074 Contact Us For Availability

Cover WPL 2169935 Contact Us For Availability

2179350 Whirlpool Refrigerator Deflector Backorder WPL 2179350 $27.14

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $30.80

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.51

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

WP2179234 Whirlpool Refrigerator Pan Trim Backorder WPL WP2179234 $27.12

WP2256126 Whirlpool Refrigerator Reservoir In Stock WPL WP2256126 $77.94

Screw Grommet WPL 509812 Contact Us For Availability

4388539 Whirlpool Refrigerator Shelf Stud In Stock WPL 4388539 $9.30

W10278731 Whirlpool Refrigerator Blade Backorder WPL W10278731 $30.29

WP67002552 Whirlpool Refrigerator Light Bulb In Stock WPL WP67002552 $2.56

WPW10122523 Whirlpool Refrigerator Ice Mold Backorder WPL WPW10122523 $85.43

Unit Cover, Bottom WPL 2160505 Contact Us For Availability

Control Box Harness WPL 2189566 Contact Us For Availability

4388538 Whirlpool Refrigerator Shelf Stud Kit In Stock WPL 4388538 $11.05

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $30.30

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

Light Lens WPL 2174436 Contact Us For Availability

Cover, Endcap (White) WPL 2174006 Contact Us For Availability

Cover, End Cap (Almond) WPL 2174007 Contact Us For Availability

W10278733 Whirlpool Refrigerator Blade Backorder WPL W10278733 $30.30

WP2188822 Whirlpool Refrigerator Evaporator In Stock WPL WP2188822 $194.99

WP628356 Whirlpool Refrigerator Fill Cup In Stock WPL WP628356 $15.77

CLIP, WIRING WPL 1115375 Contact Us For Availability

Screw (2) WPL 488280 Contact Us For Availability

Shelf, Snack Bin WPL 2174045 Contact Us For Availability

4388358 Whirlpool Refrigerator Support Bracke Backorder WPL 4388358 $12.65

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

Connecting Rod WPL 1123960 Contact Us For Availability

Shelf, Slide (Side To Side) WPL 2174392 Contact Us For Availability

8201703 Whirlpool Refrigerator Condenser Moto Backorder WPL 8201703 $132.02

WP2179243 Whirlpool Refrigerator Pan Trim Backorder WPL WP2179243 $32.56

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $26.81

Lever, Ice Dispenser (White) WPL 2177144 Contact Us For Availability

Fastener, Push-On WPL 489285 Contact Us For Availability

Blade, Fixed (2) WPL 1119009 Contact Us For Availability

2157405 Whirlpool Refrigerator Blade Block Backorder WPL 2157405 $10.76

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $37.11

Guide, Ice (White) WPL 1124730 Contact Us For Availability

Tray, Evaporator WPL 2154114 Contact Us For Availability

Escutcheon, Control Box WPL 2179361 Contact Us For Availability

Hook, Shelf WPL 2169608 Contact Us For Availability

2182111 Whirlpool Refrigerator Thermal Knob Backorder WPL 2182111 $9.53

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $27.12

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

WP489463 Whirlpool Refrigerator Screw In Stock WPL WP489463 $2.51

Harness, Intermediate WPL 2167065 Contact Us For Availability

Screw WPL 489419 Contact Us For Availability

W10422851 Whirlpool Ice Maker Bucket Auger Backorder WPL W10422851 $97.41

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $41.93

Cement Alumilastic) WPL 542369 Contact Us For Availability

Knob, Air Control WPL 1116853 Contact Us For Availability

Track, Shelf WPL 2174422 Contact Us For Availability

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

876765 Whirlpool Primary Mounting Kit Refrige In Stock WPL 876765 $24.72

W10183407 Whirlpool Refrigerator Compressor Backorder WPL W10183407 $361.52

W10845583 Whirlpool Refrigerator Track Backorder WPL W10845583 $46.34

W10845585 Whirlpool Refrigerator Track Backorder WPL W10845585 $50.98

Knob, Retainer WPL 837444 Contact Us For Availability

29

4388736 Whirlpool Refrigerator Ice Dispenser In Stock WPL 4388736 $30.73

29

489203 Whirlpool Refrigerator Washer Backorder WPL 489203 $4.36

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

2304903 Whirlpool Refrigerator Frame Backorder WPL 2304903 $95.80

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

W10852691 Whirlpool Refrigerator Baffle Backorder WPL W10852691 $13.16

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $2.51

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WPL 876029 WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Leveler, Enamel (13 Oz. Spray Can) WPL 350941 Contact Us For Availability

Washer WPL 486632 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

Enamel, Black (1 Qt. Uncut) WPL 799340 Contact Us For Availability

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

31

W11342242 Whirlpool Refrigerator Ice Level Ar In Stock WPL W11342242 $25.51

31

WP1119018 Whirlpool Refrigerator Bearing Backorder WPL WP1119018 $3.70

31

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.38

32

W11596045 Whirlpool Refrigerator Control Arm In Stock WPL W11596045 $12.11

32

WP2187464 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187464 $43.83

32

Bracket, Fan Motor WPL 548695 Contact Us For Availability

33

1119020 Whirlpool Refrigerator Spring Backorder WPL 1119020 $6.09

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $12.32

33

WP2313330 Whirlpool Refrigerator Heater Backorder WPL WP2313330 $62.86

34

1119021 Whirlpool Refrigerator Clip Backorder WPL 1119021 $4.63

34

Clip WPL 2161330 Contact Us For Availability

35

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $4.56

35

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $19.51

36

1129563 Whirlpool Shield Backorder WPL 1129563 $26.21

36

Clip, Support (2) WPL 2155021 Contact Us For Availability

37

W10190933 Whirlpool Refrigerator Motor Assemb Backorder WPL W10190933 $191.63

37

WPW10185018 Whirlpool Refrigerator Housing Backorder WPL WPW10185018 $52.10

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

WP1119017 Whirlpool Refrigerator Deflector Backorder WPL WP1119017 $3.70

WP2172890 Whirlpool Refrigerator Wire Backorder WPL WP2172890 $2.51

Lever, Water Dispenser (White) WPL 2177149 Contact Us For Availability

39

489234 Whirlpool Refrigerator Washer Backorder WPL 489234 $9.59

39

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

40

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $4.56

40

WP489236 Whirlpool Refrigerator Ring Backorder WPL WP489236 $5.09

40

Nut, Compression WPL 1129179 Contact Us For Availability

41

4317870 Whirlpool Refrigerator Auger Sleeve Backorder WPL 4317870 $82.48

41

W10896764 Whirlpool Refrigerator Air Baffle Backorder WPL W10896764 $36.11

42

Housing Filler WPL 2152700 Contact Us For Availability

44

Front Cover, Ice Container WPL 2171709 Contact Us For Availability

46

WP2171706 Whirlpool Refrigerator Light Lens Backorder WPL WP2171706 $30.21

48

Spacer WPL 625834 Contact Us For Availability

48

Unit Mounting Rail WPL 2149717 Contact Us For Availability

49

Screw WPL 488624 Contact Us For Availability

50

1105612 Whirlpool Fan Guard Backorder WPL 1105612 $24.10

51

W11751592 Whirlpool Sleeve In Stock WPL W11751592 $12.17

52

489348 Whirlpool Refrigerator Tube Clamp Backorder WPL 489348 $5.38

52

Wire Tie WPL 851095 Contact Us For Availability

53

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

54

Wire Connector WPL 850145 Contact Us For Availability

59

Clip, Wire & Tube WPL 2155658 Contact Us For Availability

61

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

62

Clip, Tube (3) WPL 934011 Contact Us For Availability

63

WP4211117 Whirlpool Refrigerator Connector In Stock WPL WP4211117 $5.34

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

Tube, Spring Following WPL 983659 Contact Us For Availability
