Model Whirlpool 106.59082892 Side-By-Side Refrigerator (Kenmore 10659082892) – Common Parts &amp; Diagrams

1

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

1

Refrigerator Energy Guide WPL LIT2206431 Contact Us For Availability

1

Refrigerator Control Box WPL 2200137 Contact Us For Availability

1A

Refrigerator Energy Guide WPL LIT2203824 Contact Us For Availability

1B

Refrigerator Owner's Manual WPL LIT2200128 Contact Us For Availability

1C

Refrigerator Technical Sheet WPL LIT2200280 Contact Us For Availability

1D

Service Sheet WPL LIT628370 Contact Us For Availability

1E

Refrigerator Parts List WPL LIT2211630 Contact Us For Availability

1F

Owner's Manual WPL LIT787808 Contact Us For Availability

1G

Ice Maker Repair Manual WPL LIT787316 Contact Us For Availability

2

2194744 Whirlpool Refrigerator Escutcheon Backorder WPL 2194744 $32.06

2

WP2196157 Whirlpool Fill Tube In Stock WPL WP2196157 $4.83

2

Refrigerator Condenser Fan WPL 2190685 Contact Us For Availability

2

Refrigerator Evaporator Fan Motor Retainer WPL 2155590 Contact Us For Availability

2

Refrigerator Thermistor Bracket WPL 1110629 Contact Us For Availability

2

Refrigerator Cabinet Roller WPL 2174748 Contact Us For Availability

3

2171712 Whirlpool Refrigerator Ice Door Backorder WPL 2171712 $47.62

3

W10850698 Whirlpool Refrigerator Screw Backorder WPL W10850698 $4.72

3

WP2152713 Whirlpool Refrigerator Solenoid In Stock WPL WP2152713 $106.45

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

3

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $2.51

3

Refrigerator Deli Drawer Temperature Control WPL 2182757 Contact Us For Availability

3

Refrigerator Air Scoop WPL 2161231 Contact Us For Availability

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $20.89

4

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $3.88

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

5

WP2196003 Whirlpool Refrigerator Bar Riser Backorder WPL WP2196003 $3.70

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $7.69

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

5

Inglis Refrigerator Pressure Relief Valve WPL 2171846 Contact Us For Availability

5

Refrigerator Door Bin Support WPL 2196166 Contact Us For Availability

6

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $3.70

6

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

6

Refrigerator Door Bin Support WPL 2196165 Contact Us For Availability

6

Refrigerator Air Duct Diffuser WPL 2149544 Contact Us For Availability

6

Refrigerator Defrost Timer WPL 2176648 Contact Us For Availability

7

4389144 Whirlpool Refrigerator Evaporator Fan In Stock WPL 4389144 $38.95

7

489392 Whirlpool Refrigerator Screw Backorder WPL 489392 $9.59

7

W10823511 Whirlpool Refrigerator Water Tube In Stock WPL W10823511 $13.36

7

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $93.38

7

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

7

WP3400852 Whirlpool Refrigerator Screw Backorder WPL WP3400852 $6.70

8

2188404A Whirlpool Refrigerator Door Gasket In Stock WPL 2188404A $133.14

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

8

WP2196046 Whirlpool Refrigerator Door Hinge Backorder WPL WP2196046 $37.79

8

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

8

Refrigerator Control Panel Hole Plug WPL 940014 Contact Us For Availability

8A

Refrigerator Door Gasket (Black) WPL 2156852 Contact Us For Availability

9

WP2198202 Whirlpool Refrigerator Temperature In Stock WPL WP2198202 $51.64

9

Refrigerator Dispenser Overflow Grille WPL 2183787W Contact Us For Availability

9

Cap WPL 509929 Contact Us For Availability

9

Refrigerator Shim WPL 2196048 Contact Us For Availability

9B

Refrigerator Dispenser Drip Tray WPL 2183787B Contact Us For Availability

W10408179 Whirlpool Ice Maker Water Inlet Fil In Stock WPL W10408179 $54.96

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $3.70

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

Refrigerator Door Handle WPL 2194265W Contact Us For Availability

Refrigerator Door Hinge Cover Mounting Screw WPL 489284 Contact Us For Availability

10A

Refrigerator Door Handle WPL 2194265N Contact Us For Availability

10B

Refrigerator Door Handle WPL 2194265B Contact Us For Availability

2182146 Whirlpool Refrigerator Duct Backorder WPL 2182146 $36.51

WP2179343 Whirlpool Refrigerator Control Body Backorder WPL WP2179343 $13.98

WP2182195 Whirlpool Refrigerator Cam Backorder WPL WP2182195 $5.14

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $4.59

Refrigerator Freezer Door Upper Hinge Cover WPL 1129262 Contact Us For Availability

11A

Refrigerator Hinge Cover (Almond) WPL 2150343 Contact Us For Availability

11B

Refrigerator Hinge Cover (Black) WPL 2151694 Contact Us For Availability

1110560 Whirlpool Refrigerator Bearing Backorder WPL 1110560 $4.72

8201707 Whirlpool Door Hinge In Stock WPL 8201707 $31.44

WP2179342 Whirlpool Refrigerator Slide Backorder WPL WP2179342 $10.08

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $7.37

WP939101 Whirlpool Refrigerator Plate Backorder WPL WP939101 $3.70

Plate WPL 941242 Contact Us For Availability

Refrigerator Nut WPL 2200083 Contact Us For Availability

Refrigerator Wire Harness WPL 2186800 Contact Us For Availability

2180200 Whirlpool Refrigerator Socket Backorder WPL 2180200 $34.95

W11496481 Whirlpool Refrigerator Water Tube In Stock WPL W11496481 $12.61

WP2155789 Whirlpool Refrigerator Gasket Backorder WPL WP2155789 $3.70

WP2181911 Whirlpool Refrigerator Shim Backorder WPL WP2181911 $11.97

WP3400012 Whirlpool Refrigerator Screw Backorder WPL WP3400012 $2.51

Refrigerator Freezer Shelf Support Grommet WPL 2176134 Contact Us For Availability

13A

W10845585 Whirlpool Refrigerator Track Backorder WPL W10845585 $56.13

8201597 Whirlpool Inlet Water Fill Tube Kit F In Stock WPL 8201597 $26.85

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.80

WP2196062 Whirlpool Refrigerator Clip Backorder WPL WP2196062 $4.59

WP2196090 Whirlpool Refrigerator Container Backorder WPL WP2196090 $80.00

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

Refrigerator Defrost Clip WPL 2161324 Contact Us For Availability

Refrigerator Trim Cap WPL 2196094 Contact Us For Availability

Interior Panel WPL 2196138 Contact Us For Availability

14A

Refrigerator Filler WPL 2196095 Contact Us For Availability

14B

Refrigerator Filler WPL 2196097 Contact Us For Availability

15

W10749708 Whirlpool Refrigerator Coupling Backorder WPL W10749708 $13.85

15

Refrigerator Damper Control Pivot Arm WPL 1110559 Contact Us For Availability

15

Suport-pnl WPL 1115379 Contact Us For Availability

15B

W10802713 Whirlpool Refrigerator Grille Backorder WPL W10802713 $61.63

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $36.71

4388500 Whirlpool Refrigerator Gasket Backorder WPL 4388500 $29.77

627068 Whirlpool Refrigerator Screw Backorder WPL 627068 $7.52

WP3400912 Whirlpool Refrigerator Washer Backorder WPL WP3400912 $2.51

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

WP489497 Whirlpool Screw In Stock WPL WP489497 $4.58

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $34.28

W11566763 Whirlpool Fitting In Stock WPL W11566763 $21.01

WP4387764 Whirlpool Run Capacitor Backorder WPL WP4387764 $90.19

Refrigerator Plate WPL 2196135 Contact Us For Availability

2179350 Whirlpool Refrigerator Deflector Backorder WPL 2179350 $30.20

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

WP1108438 Whirlpool Refrigerator Extension Backorder WPL WP1108438 $10.07

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

WP2180236 Whirlpool Refrigerator Switch Backorder WPL WP2180236 $126.70

WP2182179 Whirlpool Cam Closer In Stock WPL WP2182179 $3.59

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.64

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $8.24

WP1108439 Whirlpool Refrigerator Clip Backorder WPL WP1108439 $4.63

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

Suport-pnl WPL 1119055 Contact Us For Availability

W11223328 Whirlpool Refrigerator Shelf Stud Backorder WPL W11223328 $9.59

WP489483 Whirlpool Screw In Stock WPL WP489483 $4.58

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $153.49

Refrigerator Compressor Access Panel WPL 2182057 Contact Us For Availability

Refrigerator Wire Harness WPL 2203634 Contact Us For Availability

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

WP1115374 Whirlpool Refrigerator Clip Backorder WPL WP1115374 $2.51

WP2188756 Whirlpool Refrigerator Unit Cover Backorder WPL WP2188756 $72.69

WP2196483 Whirlpool Refrigerator Shelf Stud In Stock WPL WP2196483 $4.34

Refrigerator Door Bracket (Black) WPL 2195950 Contact Us For Availability

21A

Refrigerator Door Bracket (Black) WPL 2195952 Contact Us For Availability

4388358 Whirlpool Refrigerator Support Bracke Backorder WPL 4388358 $12.65

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $17.55

Refrigerator Shelf Stud WPL 2196207 Contact Us For Availability

Refrigerator Door Trim WPL 2188148 Contact Us For Availability

FOR FIELD INSTALLABLE ICEMAKER REPAIR PARTS L WPL N/P Contact Us For Availability

Refrigerator Retainer Clip WPL 1115375 Contact Us For Availability

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

WP489491 Whirlpool Refrigerator Screw Backorder WPL WP489491 $2.51

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $32.06

Inglis Refrigerator Door Hinge Cover WPL 1119787 Contact Us For Availability

Refrigerator Rod WPL 1123959 Contact Us For Availability

23A

Refrigerator Hinge Cover (Almond) WPL 1119789 Contact Us For Availability

23B

Refrigerator Door Hinge Cover WPL 2155938 Contact Us For Availability

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $29.83

Refrigerator Air Damper Control Clip WPL 489285 Contact Us For Availability

Refrigerator Cantilever Bin WPL 2182788 Contact Us For Availability

2157405 Whirlpool Refrigerator Blade Block Backorder WPL 2157405 $10.76

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $41.30

NLA:SCREW Backorder WPL WPW10141645 $3.70

Refrigerator Extension WPL 2194706W Contact Us For Availability

Refrigerator Escutcheon WPL 2200101 Contact Us For Availability

25A

Refrigerator Extension WPL 2194706N Contact Us For Availability

25B

Refrigerator Extension WPL 2194706B Contact Us For Availability

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $30.18

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

WPW10329686 Whirlpool Door Cam Black In Stock WPL WPW10329686 $3.59

Refrigerator Temperature Control Knob WPL 2182111 Contact Us For Availability

Refrigerator Door Handle Trim WPL 2194705W Contact Us For Availability

26A

Refrigerator Door Handle Trim WPL 2194705N Contact Us For Availability

26B

Refrigerator Door Trim (Black) WPL 2194705B Contact Us For Availability

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $46.67

Spacer WPL 625834 Contact Us For Availability

Refrigerator Temperature Control Knob WPL 2197871 Contact Us For Availability

Refrigerator Door Gasket Retainer WPL 1118301 Contact Us For Availability

28

2006254 Whirlpool Refrigerator Screw Backorder WPL 2006254 $8.09

28

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

28

Refrigerator Door Gasket Retainer WPL 1117766 Contact Us For Availability

28A

W10845583 Whirlpool Refrigerator Track Backorder WPL W10845583 $51.59

29

489203 Whirlpool Refrigerator Washer Backorder WPL 489203 $4.36

29

WP2186443 Whirlpool Water Filter Housing In Stock WPL WP2186443 $38.23

29

WP2195327 Whirlpool Refrigerator Clip Backorder WPL WP2195327 $3.70

W10852691 Whirlpool Refrigerator Baffle Backorder WPL W10852691 $13.16

WP2154473 Whirlpool Refrigerator Connector Backorder WPL WP2154473 $10.76

WP2186494W Whirlpool Water Filter Cap Backorder WPL WP2186494W $33.10

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $2.51

Refrigerator Light Cover WPL 2200096 Contact Us For Availability

30A

Refrigerator Filter Cap WPL 2186494N Contact Us For Availability

30B

WP2186494B Whirlpool Refrigerator Filter Cap In Stock WPL WP2186494B $21.50

W11342242 Whirlpool Refrigerator Ice Level Ar In Stock WPL W11342242 $28.40

WP1119018 Whirlpool Refrigerator Bearing Backorder WPL WP1119018 $3.70

Refrigerator Water Filter WPL 2203980 Contact Us For Availability

Refrigerator Clip WPL 2200097 Contact Us For Availability

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $5.67

WP2187464 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187464 $48.79

WP489500 Whirlpool Refrigerator Screw Backorder WPL WP489500 $2.51

Refrigerator Microcomputer WPL 2203385 Contact Us For Availability

33

1119020 Whirlpool Refrigerator Spring Backorder WPL 1119020 $6.09

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $12.32

34

1119021 Whirlpool Refrigerator Clip Backorder WPL 1119021 $4.63

37

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $49.38

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

38

WP1119017 Whirlpool Refrigerator Deflector Backorder WPL WP1119017 $3.70

38

WP2172890 Whirlpool Refrigerator Wire Backorder WPL WP2172890 $2.51

39

489234 Whirlpool Refrigerator Washer Backorder WPL 489234 $9.59

40

WP489236 Whirlpool Refrigerator Ring Backorder WPL WP489236 $5.09

40

Refrigerator Nut WPL 1129179 Contact Us For Availability

44

Refrigerator Ice Bin Cover, Front WPL 2171709 Contact Us For Availability

46

WP2171706 Whirlpool Refrigerator Light Lens Backorder WPL WP2171706 $33.64

53

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

55

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $30.25

285006 Whirlpool Spray In Stock WPL 285006 $44.38

350930 Whirlpool White Spray Paint In Stock WPL 350930 $21.41

350942 Whirlpool Spray Paint Backorder WPL 350942 $50.33

350956 Whirlpool Spray Assembly In Stock WPL 350956 $28.82

4210463RW Whirlpool Refrigerator Coil Brush In Stock WPL 4210463RW $14.22

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $107.21

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $29.17

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.92

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $7.21

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $106.84

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $35.96

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $37.79

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $39.53

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $43.61

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $64.36

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $24.56

WP72107 Whirlpool Touchup In Stock WPL WP72107 $6.13

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.82

Refrigerator Service Valve WPL 978029 Contact Us For Availability

Foam Slab WPL 876029 Contact Us For Availability

Refrigerator Vinyl Tape WPL 479502 Contact Us For Availability

Appliance Porcelain Touch-Up Paint, 1-qt (Whi WPL 799344 Contact Us For Availability

Refrigerator Ice Maker Torx Key Wrench WPL 1117510 Contact Us For Availability

Crushr-mec WPL 2169939 Contact Us For Availability

Refrigerator Ice Container WPL 2182098 Contact Us For Availability

Adhesive WPL 542639 Contact Us For Availability

Pnt-blk-qrt WPL 799340 Contact Us For Availability

Epoxy WPL 799833 Contact Us For Availability

Refrigerator Service Valve WPL 978028 Contact Us For Availability

Touch-Up Paint (Almond) WPL 978883 Contact Us For Availability
