Model Whirlpool 106.58153800 Side-By-Side Refrigerator (Kenmore 10658153800) – Common Parts &amp; Diagrams

1

W11254898 Whirlpool Refrigerator Scroll Fan Backorder WPL W11254898 $122.77

1

Refrigerator Ice Container WPL 2317246 Contact Us For Availability

1

FOR FIELD INSTALLABLE ICEMAKER REPAIR PARTS L WPL N/P Contact Us For Availability

1

Refrigerator Deli Drawer Trim WPL W10153774 Contact Us For Availability

1A

Refrigerator Door Assembly (Biscuit) WPL 2263189T Contact Us For Availability

1B

L2263189B Whirlpool Refrigerator Black Foam I Backorder WPL L2263189B $912.36

1C

Refrigerator Door Assembly (Monochromatic Sta WPL 2219033LA Contact Us For Availability

1D

Refrigerator Door Panel WPL 2219033SA Contact Us For Availability

2

2172931 Whirlpool Refrigerator Shield Backorder WPL 2172931 $34.33

2

2324712 Whirlpool Refrigerator Condenser Backorder WPL 2324712 $168.99

2

WP2198641 Whirlpool Refrigerator Ice Maker Co In Stock WPL WP2198641 $2.51

2

WP2256101 Whirlpool Dairy Door In Stock WPL WP2256101 $44.17

2

Refrigerator Evaporator Fan Motor Retainer WPL 2155590 Contact Us For Availability

3

2313359 Whirlpool Refrigerator Air Duct Backorder WPL 2313359 $45.80

3

W10180062 Whirlpool Refrigerator Ice Door Backorder WPL W10180062 $42.49

3

W10508993 Whirlpool Refrigerator Cover Pan In Stock WPL W10508993 $123.34

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

3

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

3

WPW10321304 Whirlpool Refrigerator Door Shelf In Stock WPL WPW10321304 $26.50

4

2159073 Whirlpool Refrigerator Door Gasket In Stock WPL 2159073 $87.85

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $20.89

4

WP2179234 Whirlpool Refrigerator Pan Trim Backorder WPL WP2179234 $30.18

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

4

WPW10318960 Whirlpool Wire Shelf In Stock WPL WPW10318960 $54.81

4

Refrigerator Ice Dispenser Auger Washer WPL 2258220 Contact Us For Availability

4A

2159081 Whirlpool Refrigerator Door Gasket Backorder WPL 2159081 $164.67

4B

W10136732 Whirlpool Refrigerator FIP Gasket Backorder WPL W10136732 $130.62

5

2195904K Whirlpool Refrigerator Basket Trim Backorder WPL 2195904K $32.06

5

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $93.38

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $7.69

5

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

5

Refrigerator Door Handle (White) WPL 2323143 Contact Us For Availability

5A

Refrigerator Handle WPL 2323145 Contact Us For Availability

5B

Refrigerator Handle (Black) WPL 2323144 Contact Us For Availability

5C

Refrigerator Door Handle WPL W10155176 Contact Us For Availability

6

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $4.61

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $7.65

6

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $3.88

6

WP2315549 Whirlpool Refrigerator Evaporator M In Stock WPL WP2315549 $150.07

6

Refrigerator Ice Crusher Blade Cover WPL 2317248 Contact Us For Availability

6

Refrigerator Crisper Drawer Humidity Control WPL W10159682 Contact Us For Availability

7

W11751592 Whirlpool Sleeve In Stock WPL W11751592 $12.17

7

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

7

WP2304249 Whirlpool Refrigerator Plate Backorder WPL WP2304249 $8.11

7

WPW10318953 Whirlpool Wire Shelf Backorder WPL WPW10318953 $50.40

7

Refrigerator Crisper Drawer Humidity Control WPL W10159683 Contact Us For Availability

8

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $36.71

8

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

8

WP2182179 Whirlpool Cam Closer In Stock WPL WP2182179 $3.59

8

WP2309517 Whirlpool Crisper Snack Pan In Stock WPL WP2309517 $70.33

8

WPW10130299 Whirlpool Refrigerator Cup In Stock WPL WPW10130299 $9.50

9

2150331 Whirlpool Refrigerator Wire Cover Backorder WPL 2150331 $11.11

9

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $3.70

9

WP2179243 Whirlpool Refrigerator Pan Trim Backorder WPL WP2179243 $36.23

9

WP2206671W Whirlpool Refrigerator Grille In Stock WPL WP2206671W $36.00

9

WP2312034 Whirlpool Refrigerator Freezer Bin Backorder WPL WP2312034 $93.54

9

WP2315562 Whirlpool Refrigerator Thermostat In Stock WPL WP2315562 $56.04

9

WP489483 Whirlpool Screw In Stock WPL WP489483 $4.58

9

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

9

Refrigerator Ice Crusher Fixed Blade WPL 2257020 Contact Us For Availability

9

Refrigerator Shim WPL 2209697 Contact Us For Availability

9

Box Cover WPL 2255624 Contact Us For Availability

9B

WP2206671B Whirlpool Refrigerator Grille In Stock WPL WP2206671B $39.97

2181741 Whirlpool Refrigerator Slide Backorder WPL 2181741 $42.09

2310237 Whirlpool Refrigerator Wire Harness Backorder WPL 2310237 $87.17

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $33.73

W11457217 Whirlpool Refrigerator Rocker Switc In Stock WPL W11457217 $15.76

WP2188656 Whirlpool Refrigerator Crisper Clea In Stock WPL WP2188656 $60.28

WP2206629B Whirlpool Refrigerator Bracket Backorder WPL WP2206629B $13.80

WPW10122550 Whirlpool Refrigerator Ice Mold Backorder WPL WPW10122550 $103.97

Refrigerator Electronic Control WPL 2322572 Contact Us For Availability

10B

Refrigerator Bracket WPL 2321218AP Contact Us For Availability

2317239 Whirlpool Refrigerator Blade Block Backorder WPL 2317239 $4.78

WP2188664 Whirlpool Refrigerator Meat Crisper In Stock WPL WP2188664 $38.32

WPW10152853 Whirlpool Refrigerator Dispenser Backorder WPL WPW10152853 $37.97

WPW10197428 Whirlpool Start Device In Stock WPL WPW10197428 $42.90

WPW10318952 Whirlpool Wire Shelf Backorder WPL WPW10318952 $52.08

Nameplate-ke WPL 13056602 Contact Us For Availability

11A

W10152855 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152855 $37.70

11A

WPW10197426 Whirlpool Refrigerator Start Devi Backorder WPL WPW10197426 $63.69

11B

WPW10152854 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152854 $28.31

11C

W10155161 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10155161 $62.70

2161466 Whirlpool Refrigerator Slide Backorder WPL 2161466 $10.76

2205764 Whirlpool Refrigerator Tube Backorder WPL 2205764 $29.77

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $30.18

W11223328 Whirlpool Refrigerator Shelf Stud Backorder WPL W11223328 $9.59

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $7.37

WP2203770 Whirlpool Refrigerator Door Hinge Backorder WPL WP2203770 $33.56

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $4.56

WPW10288153 Whirlpool Refrigerator Screw In Stock WPL WPW10288153 $3.02

W10683556 Whirlpool Refrigerator Clip Backorder WPL W10683556 $7.05

WP2156022 Whirlpool Refrigerator Door Trim In Stock WPL WP2156022 $39.73

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

WP2198587 Whirlpool Refrigerator Cover Backorder WPL WP2198587 $34.28

WP2203771 Whirlpool Refrigerator Door Hinge In Stock WPL WP2203771 $35.78

WP3-24004-109 Whirlpool Refrigerator Screw Backorder WPL WP3-24004-109 $2.51

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.80

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $30.36

WP3400012 Whirlpool Refrigerator Screw Backorder WPL WP3400012 $2.51

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

WPW10276341 Whirlpool Refrigerator Glass Shel In Stock WPL WPW10276341 $143.17

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $25.41

Refrigerator Fresh-Food Control Light Pipe WPL 2179920 Contact Us For Availability

2161306 Whirlpool Refrigerator Arm Pivot Backorder WPL 2161306 $4.72

WP2196483 Whirlpool Refrigerator Shelf Stud In Stock WPL WP2196483 $4.34

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $5.44

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $4.61

Refrigerator Refrigerant Process Tube WPL 2325479 Contact Us For Availability

2326982 Whirlpool Refrigerator Control Box Backorder WPL 2326982 $32.74

W11629923 Whirlpool Coupling In Stock WPL W11629923 $12.72

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $16.05

WP2304673 Whirlpool Refrigerator Bracket Backorder WPL WP2304673 $6.35

WP3400806 Whirlpool Screw In Stock WPL WP3400806 $2.51

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

W10777924 Whirlpool Refrigerator Wine Rack Backorder WPL W10777924 $8.47

W11629974-includeCORE Whirlpool W11629974 Ref Backorder WPL W11629974-includeCORE $237.68

WP2304697 Whirlpool Refrigerator Water Tube Backorder WPL WP2304697 $53.34

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $4.56

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $38.67

17A

W10152860 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152860 $36.38

17B

WPW10152859 Whirlpool Refrigerator Dispenser Backorder WPL WPW10152859 $36.18

17C

Refrigerator Dispenser Lever WPL W10155162 Contact Us For Availability

2006254 Whirlpool Refrigerator Screw Backorder WPL 2006254 $8.09

2161307 Whirlpool Refrigerator Rod Backorder WPL 2161307 $8.13

WP2188822 Whirlpool Refrigerator Evaporator In Stock WPL WP2188822 $203.37

WP2321703 Whirlpool Refrigerator Electronic C Backorder WPL WP2321703 $143.50

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $2.51

WPW10276348 Whirlpool Refrigerator Glass Shel In Stock WPL WPW10276348 $127.89

19

Thermador Refrigerator Ice Container Wiper WPL 2317243 Contact Us For Availability

19

Refrigerator Cover WPL W10173569 Contact Us For Availability

19

Refrigerator Defrost Clip WPL 2161324 Contact Us For Availability

2310533 Whirlpool Refrigerator Wire Harness Backorder WPL 2310533 $129.19

2315398 Whirlpool Refrigerator Slide Backorder WPL 2315398 $4.78

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $59.32

Refrigerator Ice Container Latch WPL 2317264 Contact Us For Availability

21

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $3.70

21

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $3.70

21

WPW10614158 Whirlpool Refrigerator Evaporator In Stock WPL WPW10614158 $45.89

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $2.51

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

WPW10194474 Whirlpool Refrigerator Shield Backorder WPL WPW10194474 $57.45

Refrigerator Grille WPL W10184869 Contact Us For Availability

22B

Refrigerator Grille WPL W10184880 Contact Us For Availability

23

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $24.91

23

WP2188919 Whirlpool Refrigerator Holder In Stock WPL WP2188919 $3.70

23A

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $14.68

24

2317250 Whirlpool Refrigerator Divider Backorder WPL 2317250 $11.09

24

W10309988 Whirlpool Refrigerator Compressor In Stock WPL W10309988 $284.26

24

Spacer WPL 625834 Contact Us For Availability

2304903 Whirlpool Refrigerator Frame Backorder WPL 2304903 $106.63

W10856122 Whirlpool Refrigerator Screw Backorder WPL W10856122 $2.51

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.01

Refrigerator Dispenser Ice Chute Door Motor S WPL 2252127 Contact Us For Availability

26

2310425 Whirlpool Refrigerator Wire Harness Backorder WPL 2310425 $171.16

27

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $5.67

27

Refrigerator Auger Motor Cover WPL 2322488 Contact Us For Availability

28

WP2323197 Whirlpool Refrigerator Heater Backorder WPL WP2323197 $52.59

30

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

30

WP2315559 Whirlpool Motor Coupling In Stock WPL WP2315559 $29.72

30

WP8281227 Whirlpool Screw In Stock WPL WP8281227 $4.58

31

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $4.56

32

2260503W Whirlpool Refrigerator Button Backorder WPL 2260503W $13.30

32

W10896764 Whirlpool Refrigerator Air Baffle In Stock WPL W10896764 $40.19

32C

2260503MG Whirlpool Refrigerator Button Backorder WPL 2260503MG $12.11

33

Exchange Clip WPL 2155547 Contact Us For Availability

34

W11115203 Whirlpool Control Panel Backorder WPL W11115203 $244.13

34C

WP2260518MG Whirlpool Water Filter Cap In Stock WPL WP2260518MG $30.29

35

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

35

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

36

WP489500 Whirlpool Refrigerator Screw Backorder WPL WP489500 $2.51

36

Rail Unit WPL 2304754 Contact Us For Availability

37

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $9.59

37

W11566763 Whirlpool Fitting In Stock WPL W11566763 $21.01

38

Refrigerator Drain Tube WPL 2304937 Contact Us For Availability

38

Fan Guard WPL 2260516 Contact Us For Availability

39

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

40

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

40

Refrigerator Door Cam WPL 2223751 Contact Us For Availability

41

WPW10334458 Whirlpool Refrigerator Connector Backorder WPL WPW10334458 $8.62

100

WPW10190961 Whirlpool Ice Maker In Stock WPL WPW10190961 $85.90

100

WPW10191430 Whirlpool Refrigerator Ice Contai Backorder WPL WPW10191430 $227.34

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $30.25

350930 Whirlpool White Spray Paint In Stock WPL 350930 $21.41

350942 Whirlpool Spray Paint Backorder WPL 350942 $50.33

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $7.21

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $43.92

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.92

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $7.21

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $35.96

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $37.79

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $39.53

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $43.61

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $64.36

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $24.56

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.82

Refrigerator Service Valve WPL 978029 Contact Us For Availability

Refrigerator Vinyl Tape WPL 479502 Contact Us For Availability

Appliance Porcelain Touch-Up Paint, 1-qt (Whi WPL 799344 Contact Us For Availability

Refrigerator Ice Maker Torx Key Wrench WPL 1117510 Contact Us For Availability

Refrigerator Service Valve WPL 978028 Contact Us For Availability
