Model ZET2PM1SS – Common Parts & Diagrams

Common parts from model ZET2PM1SS

WB36T10930 GE Oven Control Panel Assembly 30

WB36T10930 GE Oven Control Panel Assembly 30 Out of Stock GEN WB36T10930 $535.09

WB27T10820 GE Oven Encoder Assembly Mode

WB27T10820 GE Oven Encoder Assembly Mode Out of Stock GEN WB27T10820 $127.00

BRACKET CAPACITOR

BRACKET CAPACITOR Out of Stock GEN WB02T10194 $5.11

WB03T10253 GE Oven Knob Assembly Metal

WB03T10253 GE Oven Knob Assembly Metal Out of Stock GEN WB03T10253 $78.93

WB26X10264 GE Oven Fan Kit

WB26X10264 GE Oven Fan Kit In Stock GEN WB26X10264 $104.09

WB03T10248 GE Oven Knob Timer (SS)

WB03T10248 GE Oven Knob Timer (SS) Out of Stock GEN WB03T10248 $78.40

WB02T10289 GE Oven Stirrer Fan Blade

WB02T10289 GE Oven Stirrer Fan Blade In Stock GEN WB02T10289 $15.70

WB02X10833 GE Oven Badge Monogram Small

WB02X10833 GE Oven Badge Monogram Small Out of Stock GEN WB02X10833 $53.50

WB35X30052 GE Oven Door Insulation

WB35X30052 GE Oven Door Insulation Out of Stock GEN WB35X30052 $5.11

WB35K10025 GE Oven Insulation Oven Door Side

WB35K10025 GE Oven Insulation Oven Door Side Out of Stock GEN WB35K10025 $5.11

WB55T10148 GE Oven Liner Oven Door Assembly

WB55T10148 GE Oven Liner Oven Door Assembly Out of Stock GEN WB55T10148 $75.34

WB02T10371 GE Oven Retainer Insulation

WB02T10371 GE Oven Retainer Insulation Out of Stock GEN WB02T10371 $43.44

WB57K5230 GE Oven Door GL Inner

WB57K5230 GE Oven Door GL Inner Out of Stock GEN WB57K5230 $133.58

WB04T10050 GE Oven Gasket Oven Door

WB04T10050 GE Oven Gasket Oven Door In Stock GEN WB04T10050 $42.71

WB01T10022 GE Oven Bumper Door

WB01T10022 GE Oven Bumper Door Out of Stock GEN WB01T10022 $5.11

WB24T10081 GE Oven High Limit Thermostat

WB24T10081 GE Oven High Limit Thermostat In Stock GEN WB24T10081 $27.04

WB24T10061 GE Oven Clean TCO

WB24T10061 GE Oven Clean TCO Out of Stock GEN WB24T10061 $8.89

WB24T10127 GE Oven Switch Limit Bimetal

WB24T10127 GE Oven Switch Limit Bimetal In Stock GEN WB24T10127 $7.00

WB24T10118 GE Oven Switch Limit Bimetal

WB24T10118 GE Oven Switch Limit Bimetal Out of Stock GEN WB24T10118 $7.94

WB02T10284 GE Oven Retainer Insulation Side

WB02T10284 GE Oven Retainer Insulation Side Out of Stock GEN WB02T10284 $46.69

RETAINER INSLN BTM

RETAINER INSLN BTM Out of Stock GEN WB02T10372 $77.00

WB02T10309 GE Plate Insulation Mount

WB02T10309 GE Plate Insulation Mount Out of Stock GEN WB02T10309 $21.30

COVER WIRE UPR

COVER WIRE UPR Out of Stock GEN WB02T10373 $28.98

WB35T10127 GE Oven Insulation Back & Bottom

WB35T10127 GE Oven Insulation Back & Bottom Out of Stock GEN WB35T10127 $66.50

WB48T10041 GE Oven Rack Guide Pack Assembly

WB48T10041 GE Oven Rack Guide Pack Assembly Out of Stock GEN WB48T10041 $163.15

WB48T10089 GE Oven Broiler Pan (XL)

WB48T10089 GE Oven Broiler Pan (XL) Out of Stock GEN WB48T10089 $35.28

WB44T10056 GE Oven Element Bake

WB44T10056 GE Oven Element Bake Out of Stock GEN WB44T10056 $107.10

WB44T10057 GE Oven Element Broil

WB44T10057 GE Oven Element Broil Out of Stock GEN WB44T10057 $200.10

WB23T10015 GE Oven Sensor Probe

WB23T10015 GE Oven Sensor Probe In Stock GEN WB23T10015 $18.34

WB01T10107 GE Oven Bolt Retainer

WB01T10107 GE Oven Bolt Retainer Out of Stock GEN WB01T10107 $5.11

WB25T10064 GE Oven Lamp Halogen 20W

WB25T10064 GE Oven Lamp Halogen 20W In Stock GEN WB25T10064 $11.16

WB25T10061 GE Oven Lamp Halogen Assembly

WB25T10061 GE Oven Lamp Halogen Assembly Out of Stock GEN WB25T10061 $152.27

WB25T10062 GE Oven Lamp Halogen Assembly (RT)

WB25T10062 GE Oven Lamp Halogen Assembly (RT) Out of Stock GEN WB25T10062 $163.65

WB25T10063 GE Oven Crystal Lamp

WB25T10063 GE Oven Crystal Lamp Out of Stock GEN WB25T10063 $51.03

RANGE GLASS RETAINER CLIP

RANGE GLASS RETAINER CLIP Out of Stock GEN WB02T10297 $5.11

WB10T10117 GE Oven Receiver Hinge

WB10T10117 GE Oven Receiver Hinge Out of Stock GEN WB10T10117 $25.33

WB20T10023 GE Oven Heat Probe or Gauge

WB20T10023 GE Oven Heat Probe or Gauge In Stock GEN WB20T10023 $60.46

WB10T10094 GE Oven Hinge Right Door

WB10T10094 GE Oven Hinge Right Door Out of Stock GEN WB10T10094 $56.96

WB10T10095 GE Oven Hinge Left Door

WB10T10095 GE Oven Hinge Left Door In Stock GEN WB10T10095 $58.63

WB28T10215 GE Oven Tube Vent Assembly

WB28T10215 GE Oven Tube Vent Assembly Out of Stock GEN WB28T10215 $29.86

WB44T10058 GE Oven Element Convection

WB44T10058 GE Oven Element Convection Out of Stock GEN WB44T10058 $48.01

WB56T10105 GE Oven Inner Window Assembly

WB56T10105 GE Oven Inner Window Assembly In Stock GEN WB56T10105 $118.44

WB27T10821 GE Oven Board Assembly Relay

WB27T10821 GE Oven Board Assembly Relay In Stock GEN WB27T10821 $254.53

WB26T10038 GE Oven Motor Convection Plate Ass

WB26T10038 GE Oven Motor Convection Plate Ass Out of Stock GEN WB26T10038 $409.92

WB27T10662 GE Oven Capacitor

WB27T10662 GE Oven Capacitor Out of Stock GEN WB27T10662 $5.00

WB18T10377 GE Oven Harness Meat Probe

WB18T10377 GE Oven Harness Meat Probe Out of Stock GEN WB18T10377 $66.29

WB1K5162 GE Oven Screw-Black

WB1K5162 GE Oven Screw-Black In Stock GEN WB1K5162 $5.11

WB1K5200 GE Oven SCREW 340531

WB1K5200 GE Oven SCREW 340531 Out of Stock GEN WB1K5200 $5.11

WB1X536 GE Oven Screw

WB1X536 GE Oven Screw Out of Stock GEN WB1X536 $6.25

WB1X1137 GE Oven Screw-10AB

WB1X1137 GE Oven Screw-10AB Out of Stock GEN WB1X1137 $5.00

SCR 8-32 1HW .312 NI

SCR 8-32 1HW .312 NI Out of Stock GEN WB01T10072 $5.11

WH2X930 GE Screw

WH2X930 GE Screw In Stock GEN WH2X930 $5.11

WB1K5173 GE Oven Screw ST 8-18 X 3/4" Black

WB1K5173 GE Oven Screw ST 8-18 X 3/4" Black Out of Stock GEN WB1K5173 $5.11

WB02T10017 GE Oven Nut

WB02T10017 GE Oven Nut Out of Stock GEN WB02T10017 $6.25

WB02T10303 GE Lubricant Cleaner

WB02T10303 GE Lubricant Cleaner Out of Stock GEN WB02T10303 $35.53

WB01T10017 GE Oven Screw 8-18 AB IHW 3/8 S NS

WB01T10017 GE Oven Screw 8-18 AB IHW 3/8 S NS Out of Stock GEN WB01T10017 $5.00

WB01T10008 GE Oven Screw 10-32 TR

WB01T10008 GE Oven Screw 10-32 TR In Stock GEN WB01T10008 $5.11
