Model Whirlpool LA3800XMW0 AUTOMATIC WASHER – Common Parts &amp; Diagrams

1

90984 Whirlpool Nut Backorder WPL 90984 $9.13

1

Basket Drive & Brake WPL 359699 Contact Us For Availability

1

Gearcase (Complete) WPL 358483 Contact Us For Availability

2

WP273556 Whirlpool Screw In Stock WPL WP273556 $2.51

2

Cover, Gusset (3) WPL 352143 Contact Us For Availability

2

Cover, Gearcase WPL 367552 Contact Us For Availability

2

Drum, Brake (Upper) WPL 350522 Contact Us For Availability

3

Gasket, Gearcase WPL 95089 Contact Us For Availability

3

Sleeve WPL 96175 Contact Us For Availability

3

Ball, Suspension (6) WPL 91073 Contact Us For Availability

3

Lining, Basket Brake (Upper) WPL 354550 Contact Us For Availability

4

Spring, Toggle WPL 96266 Contact Us For Availability

4

Rod, Suspension (3) WPL 359678 Contact Us For Availability

4

Shaft, Agitator WPL 362642 Contact Us For Availability

4

Spring, Basket Drive (Green) (4) WPL 354275 Contact Us For Availability

5

Pulley, Pump WPL 359630 Contact Us For Availability

5

Baseplate & Centerpost WPL 359721 Contact Us For Availability

5

Ring, Retainer WPL 352430 Contact Us For Availability

5

Drum, Brake (Lower) WPL 97664 Contact Us For Availability

6

WP3400516 Whirlpool Screw Backorder WPL WP3400516 $2.51

6

Lever, Valve WPL 355538 Contact Us For Availability

6

Seal, Agitator Shaft WPL 92814 Contact Us For Availability

6

Lining, Basket Brake (Lower) WPL 354244 Contact Us For Availability

7

WP96743 Whirlpool Hose In Stock WPL WP96743 $23.59

7

Rod, Connecting WPL 96264 Contact Us For Availability

7

Brace, Baseplate WPL 353301 Contact Us For Availability

7

Shield, Agitator Spring WPL 94276 Contact Us For Availability

7

Yoke, Brake WPL 92903 Contact Us For Availability

8

WP356138 Whirlpool Hose Clamp In Stock WPL WP356138 $3.70

8

Nut, Push-In (1) WPL 358472 Contact Us For Availability

8

Bearing Block Assembly WPL 383750 Contact Us For Availability

8

Nut, 5/16-24 WPL 96101 Contact Us For Availability

8

Spring, Agitator Shaft WPL 92815 Contact Us For Availability

8

Ring, Snap WPL 16049 Contact Us For Availability

9

WP89503 Whirlpool Washer Fill Hose In Stock WPL WP89503 $3.62

9

Connector, Hose WPL 95440 Contact Us For Availability

9

Nut, Push-In (2) WPL 358473 Contact Us For Availability

9

Wick, Oil WPL 96265 Contact Us For Availability

9

Magnet WPL 365998 Contact Us For Availability

9

Gear, Agitator Shaft WPL 355469 Contact Us For Availability

9

Plate & Lining, Basket Drive WPL 357155 Contact Us For Availability

386011 Whirlpool Screw Backorder WPL 386011 $26.43

WP16123 Whirlpool Washer In Stock WPL WP16123 $2.51

Screw, Taper End WPL 16135 Contact Us For Availability

Shaft, Agitator WPL 362098 Contact Us For Availability

Lining, Basket Drive (Set of 3) WPL 354243 Contact Us For Availability

285205 Whirlpool Bearing Backorder WPL 285205 $3.70

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350938 Whirlpool Spray Gun In Stock WPL 350938 $32.57

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

WP3351614 Whirlpool Screw Backorder WPL WP3351614 $2.51

Guide, Cam Bar WPL 95462 Contact Us For Availability

Eyelet (3) WPL 98281 Contact Us For Availability

12

WPW10083200 Whirlpool Wire Ring In Stock WPL WPW10083200 $4.96

12

Panel, Rear WPL 85279 Contact Us For Availability

12

Cam, Bar Spin WPL 354838 Contact Us For Availability

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51

WP91770 Whirlpool Hinge Backorder WPL WP91770 $8.80

WP95405 Whirlpool Belt In Stock WPL WP95405 $9.26

Gear, Sector WPL 75073 Contact Us For Availability

Washer, Thrust (2) WPL 353320 Contact Us For Availability

WP96160 Whirlpool Washer Inlet Valve Screen In Stock WPL WP96160 $4.76

Spring, Hinge (L.H.) WPL 92398 Contact Us For Availability

Screw, 1/4-28 x 1/2 WPL 98001 Contact Us For Availability

Ring, Retainer WPL 52083 Contact Us For Availability

Pulley, Basket Drive WPL 359697 Contact Us For Availability

Spring, Brake WPL 94726 Contact Us For Availability

Bumper, Lid Hinge WPL 91605 Contact Us For Availability

Hose, Pump Discharge WPL 358560 Contact Us For Availability

Pin, Dowel WPL 5018 Contact Us For Availability

Bearing, Drive Pulley WPL 16033 Contact Us For Availability

WP285655 Whirlpool Hose Clamp In Stock WPL WP285655 $3.70

WP91939 Whirlpool Shaft Seal In Stock WPL WP91939 $3.70

Cam, Agitator & Pump WPL 18642 Contact Us For Availability

Bolt, 5/16-24 x 3/4 (4) WPL 356599 Contact Us For Availability

WP18776 Whirlpool Lock In Stock WPL WP18776 $4.78

Hinge, L.H. WPL 91099 Contact Us For Availability

Plunger WPL 84866 Contact Us For Availability

Bearing, Gear Fork WPL 96853 Contact Us For Availability

Drive Tube & Bearing, Basket WPL 357965 Contact Us For Availability

WP21097 Whirlpool Pad In Stock WPL WP21097 $3.70

WP21366 Whirlpool Spanner Nut In Stock WPL WP21366 $3.70

WP356427 Whirlpool Shaft Seal In Stock WPL WP356427 $3.70

Plate, Gusset (2) WPL 356459 Contact Us For Availability

Rivet WPL 354959 Contact Us For Availability

Support, Brake Shoe Yoke WPL 356445 Contact Us For Availability

WP21258 Whirlpool Washer Lid Hinge Bearing In Stock WPL WP21258 $3.70

Spring, Brake Yoke WPL 17261 Contact Us For Availability

Spring, Gear Fork Shaft WPL 16015 Contact Us For Availability

Set Screw, 5/16-18X 13/16 WPL 356057 Contact Us For Availability

WPW10119828 Whirlpool Screw In Stock WPL WPW10119828 $2.51

Seal WPL 351830 Contact Us For Availability

Fork, Agitator Gear WPL 80398 Contact Us For Availability

Spacer, Agitator Shaft WPL 356937 Contact Us For Availability

21

Lid (White) WPL 385361 Contact Us For Availability

21

Support, Spin Tube WPL 358586 Contact Us For Availability

21

Pin, Gear Fork Shaft WPL 90532 Contact Us For Availability

22

WP120393 Whirlpool Washer Assembly Backorder WPL WP120393 $2.38

22

Top (White) WPL 384018 Contact Us For Availability

22

Roller, Gear Fork Shaft WPL 92119 Contact Us For Availability

23

WP90767 Whirlpool Screw In Stock WPL WP90767 $2.51

23

Rod, Connecting WPL 76577 Contact Us For Availability

24

Ring, Retaining WPL 95082 Contact Us For Availability

25

Cabinet (White) WPL 384793 Contact Us For Availability

25

Shaft, Basket Clutch WPL 359460 Contact Us For Availability

25

Washer, Retainer WPL 95083 Contact Us For Availability

26

WP359364 Whirlpool Clip In Stock WPL WP359364 $3.70

26

Gear, Main Drive WPL 353397 Contact Us For Availability

27

Pad, Gusset Cover (6) WPL 352434 Contact Us For Availability

27

Washer, Thrust WPL 363362 Contact Us For Availability

28

WP8577376 Whirlpool Seal In Stock WPL WP8577376 $3.70

28

Leveling Link Assembly WPL 359059 Contact Us For Availability

28

Gearcase WPL 362906 Contact Us For Availability

WP358594 Whirlpool Leveling Feet In Stock WPL WP358594 $7.27

Switch, Water Level WPL 359858 Contact Us For Availability

Bolt, 5/16 x 5/8 (2) WPL 126211 Contact Us For Availability

Bolt, 5/16 x 1 (3) WPL 126358 Contact Us For Availability

Bolt, Snubber (1) WPL 353770 Contact Us For Availability

Bolt, 5/16-24 x 1-1/8 (3) WPL 356512 Contact Us For Availability

30

Bolt, 5/16-24 WPL 98048 Contact Us For Availability

30

Bearing, Drive Pinion WPL 354513 Contact Us For Availability

Hinge, R.H. WPL 18775 Contact Us For Availability

Hinge, L.H. WPL 92657 Contact Us For Availability

Gasket, Tub (7) WPL 17235 Contact Us For Availability

Pinion, Drive WPL 84467 Contact Us For Availability

WP8546455 Whirlpool Bearing In Stock WPL WP8546455 $9.46

Bracket, Control WPL 359708 Contact Us For Availability

Cord, Power (120 Volt) WPL 92667 Contact Us For Availability

Washer, Drive Pinion WPL 16024 Contact Us For Availability

350572 Whirlpool Oil Transmission 15 Oz In Stock WPL 350572 $31.00

W11095997 Whirlpool Seal In Stock WPL W11095997 $10.76

Valve, Mixing (Alt.) WPL 358277 Contact Us For Availability

Valve, Mixing (Alt.) (Serviced Only As Comple WPL 358971 Contact Us For Availability

Valve, Mixing WPL 660749 Contact Us For Availability

Ring, Retainer WPL 90094 Contact Us For Availability

34

16515 Whirlpool Clip Backorder WPL 16515 $11.62

34

Spring, Snubber WPL 357977 Contact Us For Availability

35

Snubber WPL 358336 Contact Us For Availability

35

Retainer, Brake Yoke WPL 356444 Contact Us For Availability

36

Locator, Top (2) WPL 98669 Contact Us For Availability

36

Ball WPL 358585 Contact Us For Availability

37

Setscrew, 5/16-18 x 1/2 WPL 355345 Contact Us For Availability

38

WP367594 Whirlpool Leveling Feet In Stock WPL WP367594 $10.89

38

Pulley, Main Drive WPL 360840 Contact Us For Availability

39

WP358160 Whirlpool Nut Backorder WPL WP358160 $2.51

40

Timer, 60 Hz. WPL 385321 Contact Us For Availability

40

Wire, Ground WPL 364089 Contact Us For Availability

40

Bracket, Motor Mounting WPL 85286 Contact Us For Availability

41

Motor, Timer 60 Hz. WPL 365941 Contact Us For Availability

41

Nut (4) WPL 98023 Contact Us For Availability

42

Grommet, Motor Bracket (4) WPL 19138 Contact Us For Availability

43

Pulley, Motor WPL 92216 Contact Us For Availability

44

Shield, Motor (Upper) WPL 356217 Contact Us For Availability

45

WP356418 Whirlpool Screw Backorder WPL WP356418 $2.51

46

Motor, 60 Hz. (Alt.) (Emerson) WPL 358589 Contact Us For Availability

46

Motor, 60 Hz. (Alt.) (General Electric) WPL 362857 Contact Us For Availability

46

Motor, 60 Hz. WPL 660303 Contact Us For Availability

47

W10876590 Whirlpool Connector Backorder WPL W10876590 $4.94

49

WP3390631 Whirlpool Screw Backorder WPL WP3390631 $2.51

49

Terminal, Female WPL 352088 Contact Us For Availability

50

Bearing, Lo WPL 354195 Contact Us For Availability

51

WPL 98537 WPL 98537 Contact Us For Availability

52

WPL 93549 WPL 93549 Contact Us For Availability

53

WPL 95721 WPL 95721 Contact Us For Availability

54

Panel, Control WPL 378651 Contact Us For Availability

55

WPL 359719 WPL 359719 Contact Us For Availability

56

WPL 359642 WPL 359642 Contact Us For Availability

56

WPL 362738 WPL 362738 Contact Us For Availability

57

Dial, Timer WPL 359826 Contact Us For Availability

58

Knob, Timer WPL 359822 Contact Us For Availability

58

WPL 351499 WPL 351499 Contact Us For Availability

58

WPL 351500 WPL 351500 Contact Us For Availability

59

WPL 16062 WPL 16062 Contact Us For Availability

60

WPL 90877 WPL 90877 Contact Us For Availability

61

WPL 285134 WPL 285134 Contact Us For Availability

67

WP689559 Whirlpool Nut Backorder WPL WP689559 $3.70

75

Cap, Terminal (Console Harness) WPL 94612 Contact Us For Availability

76

Plug, Terminal (Cabinet Harness) WPL 94611 Contact Us For Availability

78

WP596797 Whirlpool Terminal Backorder WPL WP596797 $2.51

79

WP94614 Whirlpool Terminal Backorder WPL WP94614 $2.51

80

Harness, (Console) Wiring WPL 359366 Contact Us For Availability

81

Wire, Ground WPL 357535 Contact Us For Availability

82

Harness, (Cabinet) Wiring WPL 359365 Contact Us For Availability

83

8528351 Whirlpool Clip Backorder WPL 8528351 $26.21

84

WP90016 Whirlpool Clip Backorder WPL WP90016 $4.78

85

WP359231 Whirlpool Shield In Stock WPL WP359231 $3.70

86

Screw & Washer WPL 354975 Contact Us For Availability

88

Switch Actuator Assembly WPL 370959 Contact Us For Availability

89

W10820036 Whirlpool Door Switch Kit In Stock WPL W10820036 $9.94

94

W10113937 Whirlpool Clamp Backorder WPL W10113937 $4.78

95

Rack, Literature WPL 357645 Contact Us For Availability

96

Strike, Lid Switch WPL 357633 Contact Us For Availability

97

Screw & Washer WPL 354764 Contact Us For Availability
