Model Whirlpool KTRS20KHBT00 REFRIGERATOR – Common Parts &amp; Diagrams

1

W11023687 Whirlpool Refrigerator Door Assembl Backorder WPL W11023687 $471.91

1

W11023688 Whirlpool Refrigerator Door Assembl Backorder WPL W11023688 $471.91

1

Service & Wiring Sheet WPL LIT2195481 Contact Us For Availability

1

Use & Care Guide WPL LIT2200941 Contact Us For Availability

1

Energy Label WPL LIT2204720 Contact Us For Availability

1

Refrigerator Door (Includes No.8) (White) WPL 2183935 Contact Us For Availability

1

Refrigerator Door (Includes No.8) (Black) WPL 2200713 Contact Us For Availability

1

Refrigerator Door (Includes No.8) (Biscuit) WPL 2204687 Contact Us For Availability

2

WP2195916K Whirlpool End Cap In Stock WPL WP2195916K $6.75

2

WP2261963 Whirlpool Refrigerator Door Hinge In Stock WPL WP2261963 $41.10

3

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $13.54

3

WP8281206 Whirlpool Refrigerator Screw In Stock WPL WP8281206 $2.51

3

Divider, Door Shelf WPL 1123293 Contact Us For Availability

4

W11745278 Whirlpool Bracket In Stock WPL W11745278 $5.18

5

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

6

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $3.70

7

WP2212648 Whirlpool Refrigerator Hinge Sleeve Backorder WPL WP2212648 $3.70

7

WP2212649 Whirlpool Refrigerator Button Plug Backorder WPL WP2212649 $3.70

7

WP2212651 Whirlpool Refrigerator Button Plug Backorder WPL WP2212651 $10.27

8

2159060 Whirlpool Refrigerator Gasket In Stock WPL 2159060 $143.90

8

2159061 Whirlpool Refrigerator Door Gasket In Stock WPL 2159061 $94.28

8

2177310 Whirlpool Refrigerator Door Gasket In Stock WPL 2177310 $106.14

8

2177311 Whirlpool Refrigerator Magnetic Door In Stock WPL 2177311 $151.83

9

Screw WPL 489462 Contact Us For Availability

WP489467 Whirlpool Hinge Shim In Stock WPL WP489467 $4.59

Eyelet, Roller WPL 2174478 Contact Us For Availability

Retainer, Insert (Black) WPL 2188222B Contact Us For Availability

Retainer, Insert (Biscuit) WPL 2188222T Contact Us For Availability

Retainer, Insert (White) WPL 2188222W Contact Us For Availability

WP2163777 Whirlpool Refrigerator Fan Blade In Stock WPL WP2163777 $30.29

WP488921 Whirlpool Refrigerator Screw Backorder WPL WP488921 $2.51

Glass, Crisper Cover WPL 2174141 Contact Us For Availability

Screw WPL 2174650 Contact Us For Availability

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94

Endcap, Handle (White) WPL 2195995W Contact Us For Availability

Cover (Service Only) WPL 1105055 Contact Us For Availability

Endcap, Handle (Black) WPL 2195995B Contact Us For Availability

Endcap, Handle (Biscuit) WPL 2195995T Contact Us For Availability

13

2183408 Whirlpool Refrigerator Overload Backorder WPL 2183408 $47.31

13

4387913 Whirlpool Refrigerator Primary Overlo In Stock WPL 4387913 $33.47

13

W11594405 Whirlpool Axle In Stock WPL W11594405 $6.90

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

WP4387558 Whirlpool Refrigerator Compressor G Backorder WPL WP4387558 $3.70

Insert, Handle (Black) WPL 2188155 Contact Us For Availability

Insert, Handle (White) WPL 2195986 Contact Us For Availability

Insert, Handle (Biscuit) WPL 2200932 Contact Us For Availability

WP489497 Whirlpool Screw In Stock WPL WP489497 $4.58

Endcap (White) WPL 2195994W Contact Us For Availability

Retaining Clip, Capacitor WPL 2166683 Contact Us For Availability

Endcap, Handle (Black) WPL 2188132 Contact Us For Availability

Endcap, Handle (White) WPL 2195990 Contact Us For Availability

Endcap, Handle (Biscuit) WPL 2200930 Contact Us For Availability

End Cap (Black) WPL 2195994B Contact Us For Availability

Endcap (Biscuit) WPL 2195994T Contact Us For Availability

16

WP2254618 Whirlpool Center Door Hinge In Stock WPL WP2254618 $25.07

16

WP489357 Whirlpool Recessed Screw In Stock WPL WP489357 $2.51

4388239 Whirlpool Refrigerator Primary Cabine In Stock WPL 4388239 $39.33

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $4.54

Trim, Door Shelf (2) WPL 2195947 Contact Us For Availability

Screw WPL 3400873 Contact Us For Availability

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $4.56

Spacer, Handle WPL 2188146 Contact Us For Availability

Nameplate (White) WPL 2188149 Contact Us For Availability

Nameplate (Black) WPL 2188151 Contact Us For Availability

Nameplate (Biscuit) WPL 2200935 Contact Us For Availability

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

Clip, Heater WPL 2182338 Contact Us For Availability

Insert, Retainer (Black) WPL 2195992B Contact Us For Availability

Insert, Retainer (Biscuit) WPL 2195992T Contact Us For Availability

Insert, Retainer (White) WPL 2195992W Contact Us For Availability

20

WP2254473 Whirlpool Refrigerator Door Hinge In Stock WPL WP2254473 $3.70

20

Bin, Door Shelf (2) WPL 2171066 Contact Us For Availability

WPW10421486 Whirlpool Refrigerator Door Trim In Stock WPL WPW10421486 $39.75

Cover, Air Diffuser WPL 2176281 Contact Us For Availability

Nut (Not Serviced) WPL ARI111910A Contact Us For Availability

Insert, Handle (Black) WPL 2188154 Contact Us For Availability

Insert, Handle (White) WPL 2195984 Contact Us For Availability

Insert, Handle (Biscuit) WPL 2200933 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

WP2313637 Whirlpool Cutting Grid Assembly Backorder WPL WP2313637 $145.59

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WPL 876029 WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

Support Block WPL 2189906 Contact Us For Availability

Featurepak (Includes 2, 17) See also Shelf Pa WPL 2204676 Contact Us For Availability

PAINT, BULK (1 QT.) (BISCUIT (UNCUT)) WPL 4392900 Contact Us For Availability

WPL 542639 WPL 542639 Contact Us For Availability

WPL 799340 WPL 799340 Contact Us For Availability

WPL 799832 WPL 799832 Contact Us For Availability

WPL 799833 WPL 799833 Contact Us For Availability

23

Shim, Bottom Hinge WPL 2172743 Contact Us For Availability

23

Air Tower WPL 2182340 Contact Us For Availability

23

Cover, Unit WPL 2198740 Contact Us For Availability

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $4.32

WP2189000 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189000 $3.70

WP2189009 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189009 $3.51

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $42.62

WP2200936 Whirlpool Refrigerator Handle Plug Backorder WPL WP2200936 $2.51

Fitting, Water Tube (Not Serviced) WPL ARI111907A Contact Us For Availability

25

Tray, Butter WPL 2165792 Contact Us For Availability

26

Air Diffuser, Top WPL 2204690 Contact Us For Availability

27

WP2151652 Whirlpool Refrigerator Button Plug Backorder WPL WP2151652 $8.20

27

WP2183998 Whirlpool Refrigerator Button Plug Backorder WPL WP2183998 $6.68

27

Hole Plug (6) (Biscuit) WPL 2200924 Contact Us For Availability

876765 Whirlpool Primary Mounting Kit Refrige In Stock WPL 876765 $24.72

W10309988 Whirlpool Refrigerator Compressor In Stock WPL W10309988 $284.26

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

Installation Kit WPL 482801 Contact Us For Availability

Gasket, Door Compartment WPL 2159124 Contact Us For Availability

29

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

29

Bin, Door Shelf WPL 2171063 Contact Us For Availability

30

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $4.10

30

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

31

Relay (Production (Service - See Overload)) WPL 2176805 Contact Us For Availability

31

Cover, Water Valve WPL 2166251 Contact Us For Availability

31

Beverage Holder WPL 2193409 Contact Us For Availability

32

WP4387764 Whirlpool Run Capacitor Backorder WPL WP4387764 $81.03

32

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $28.24

33

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

35

W10283958 Whirlpool Refrigerator Filler Backorder WPL W10283958 $14.60

35

W11252732 Whirlpool Refrigerator Filler Backorder WPL W11252732 $7.16

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $3.70

36

Grille (White) WPL 2201006 Contact Us For Availability

36

Grille (Black) WPL 2201008 Contact Us For Availability

36

Grille (Biscuit) WPL 2201020 Contact Us For Availability

37

CLIP, GRILLE WPL 2189356 Contact Us For Availability

38

WP2172890 Whirlpool Refrigerator Wire Backorder WPL WP2172890 $2.51

38

WP487576 Whirlpool Washer In Stock WPL WP487576 $4.58

39

Air Baffle WPL 2198921 Contact Us For Availability

2213364 Whirlpool Refrigerator Cover Backorder WPL 2213364 $9.48

833697 Whirlpool Condenser Fan Motor In Stock WPL 833697 $41.18

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $11.95

WP2213363 Whirlpool Refrigerator Cover Backorder WPL WP2213363 $11.29

41

Rail Center (Not Serviced) WPL ARI111908A Contact Us For Availability

42

Wire Assy. Unit WPL 2200798 Contact Us For Availability

43

Blade, Fan WPL 2190685 Contact Us For Availability

44

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

44

Cover, Unit WPL 2200508 Contact Us For Availability

46

Tube, Discharge WPL 2184451 Contact Us For Availability

47

Tube, Suction WPL 2189173 Contact Us For Availability

48

2154109 Whirlpool Refrigerator Tube Backorder WPL 2154109 $33.89

49

Tube, Condenser To Heat Loop WPL 2174670 Contact Us For Availability

50

REAR FENCE PULL-OUT FREEZER FLOOR WPL 2198768 Contact Us For Availability

56

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Tray, Evaporator WPL 2189433 Contact Us For Availability

Start Kit WPL 482278 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability
