Model Whirlpool KRMF536RBS01 REFRIGERATOR, ALL – Common Parts &amp; Diagrams

1

WPW10737428 Whirlpool Refrigerator Glass Shel Backorder WPL WPW10737428 $239.31

1

HOUSING, DISPENSER (NOT SERVICED) WPL ARI0820F7799426DB23CC858392159B72FE Contact Us For Availability

2

W11728384 Whirlpool Mullion Rail Backorder WPL W11728384 $113.42

2

Backorder WPL W11753082-includeCORE $240.68

2

WP2188935 Whirlpool Refrigerator Fan Blade In Stock WPL WP2188935 $28.77

2

PLATE, ICE CHUTE WPL W11705888 Contact Us For Availability

3

W10734555 Whirlpool Refrigerator Pivot Block In Stock WPL W10734555 $8.22

3

W10819058 Whirlpool Refrigerator Shield Backorder WPL W10819058 $50.18

3

W11400994 Whirlpool Refrigerator Screw Backorder WPL W11400994 $9.13

3

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.01

4

W10277839 Whirlpool Refrigerator Cover Backorder WPL W10277839 $30.29

4

W10847834 Whirlpool Clip Backorder WPL W10847834 $5.42

4

W10853387 Whirlpool Refrigerator Pad Backorder WPL W10853387 $110.79

4

W11728302 Whirlpool Crispr Pan In Stock WPL W11728302 $121.50

4

WPW10503522 Whirlpool Refrigerator Shaft In Stock WPL WPW10503522 $31.90

5

W10904595 Whirlpool Refrigerator Closer Backorder WPL W10904595 $6.39

5

W11499276 Whirlpool Refrigerator Handle In Stock WPL W11499276 $93.50

5

W11509548 Whirlpool Ice Bucket Coupler In Stock WPL W11509548 $10.87

5

WPW10577864 Whirlpool Refrigerator Ice Door In Stock WPL WPW10577864 $60.22

5A

W11212164 Whirlpool Refrigerator Door Closer Backorder WPL W11212164 $6.13

6

W10415341 Whirlpool Refrigerator Gasket Backorder WPL W10415341 $12.92

6

W10634640 Whirlpool Refrigerator Freezer Bin Backorder WPL W10634640 $103.69

6

W10822606 Whirlpool Refrigerator Dispenser Mo In Stock WPL W10822606 $96.04

6

WPW10435760 Whirlpool Refrigerator Ice Guide In Stock WPL WPW10435760 $8.45

6

ASSEMBLY, CRISPER COVER (INCLUDES FRONT SUPPO WPL W11696529 Contact Us For Availability

6B

W11506625 Whirlpool Refrigerator Coupler In Stock WPL W11506625 $10.60

7

W11448765 Whirlpool Drip Tray Backorder WPL W11448765 $7.39

7

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

7

DOOR, PANTRY (INCLUDES DOOR GASKET) (BLACK ST WPL W11699367 Contact Us For Availability

8

W10622445 Whirlpool Refrigerator FIP Gasket Backorder WPL W10622445 $176.06

8

W10754145 Whirlpool Refrigerator Cover Backorder WPL W10754145 $38.83

8

W11129522 Whirlpool Ice Bucket Assembly In Stock WPL W11129522 $174.33

8

W11225840 Whirlpool Refrigerator Evaporator T Backorder WPL W11225840 $54.33

8

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $3.70

8

WPW10402180 Whirlpool Refrigerator Trim Backorder WPL WPW10402180 $33.32

9

W10807832 Whirlpool Refrigerator Glass Shelf Backorder WPL W10807832 $137.68

9

W10852685 Whirlpool Clip Assembly Backorder WPL W10852685 $3.62

9

W11290115 Whirlpool Refrigerator Light In Stock WPL W11290115 $29.59

9

W11658802 Whirlpool Refrigerator Ice Maker In Stock WPL W11658802 $95.30

9

WP2223877 Whirlpool Door Hook In Stock WPL WP2223877 $37.55

W10407187 Whirlpool Refrigerator Door Bumper Backorder WPL W10407187 $26.44

W10754143 Whirlpool Refrigerator Filter Cover Backorder WPL W10754143 $40.74

WPW10291905 Whirlpool Seal In Stock WPL WPW10291905 $9.97

WPW10363507 Whirlpool Refrigerator Shroud Backorder WPL WPW10363507 $26.75

ADAPTER, PANTRY (LEFT HAND) WPL W11695482 Contact Us For Availability

10A

ADAPTER, PANTRY (RIGHT HAND) WPL W11695479 Contact Us For Availability

W10673842 Whirlpool Refrigerator Screw Backorder WPL W10673842 $9.59

W10788795 Whirlpool Refrigerator Roller Backorder WPL W10788795 $12.08

W10876598 Whirlpool Refrigerator Nameplate In Stock WPL W10876598 $32.83

W11677723 Whirlpool Support Backorder WPL W11677723 $56.16

12

W10471617 Whirlpool Refrigerator Cover Backorder WPL W10471617 $13.32

12

COVER, GEAR (LEFT HAND) WPL W11698180 Contact Us For Availability

12A

COVER, GEAR (RIGHT HAND) WPL W11698181 Contact Us For Availability

13

12991702 Whirlpool Screw Backorder WPL 12991702 $5.44

13

COVER, HINGE (RIGHT) (BLACK) WPL W10407157 Contact Us For Availability

W10503218 Whirlpool Refrigerator Funnel Backorder WPL W10503218 $8.36

W11087201 Whirlpool Refrigerator Heater In Stock WPL W11087201 $52.08

W11126052 Whirlpool Screw Assembly In Stock WPL W11126052 $9.26

W11131390 Whirlpool Refrigerator Bracket In Stock WPL W11131390 $53.67

GEAR, SPUR WPL W10277360 Contact Us For Availability

14A

W11161915 Whirlpool Refrigerator Bracket Backorder WPL W11161915 $55.33

15

W10407279 Whirlpool Refrigerator Door Hinge Backorder WPL W10407279 $29.59

15

SHAFT, RACK WPL W11706355 Contact Us For Availability

W10407275 Whirlpool Refrigerator Door Hinge Backorder WPL W10407275 $29.59

W10467460 Whirlpool Refrigerator Ladder Backorder WPL W10467460 $26.28

W10585151 Whirlpool Refrigerator Stop Pan Backorder WPL W10585151 $28.99

W11625019 Whirlpool Refrigerator Gasket Backorder WPL W11625019 $27.43

WPW10598013 Whirlpool Refrigerator Cover In Stock WPL WPW10598013 $51.35

16A

W10585150 Whirlpool Refrigerator Stop Pan Backorder WPL W10585150 $29.04

17

W11661208 Whirlpool Cover Assembly Backorder WPL W11661208 $10.76

17

COLLAR, GEAR WPL W10447530 Contact Us For Availability

18

W11435997 Whirlpool Refrigerator Housing Backorder WPL W11435997 $83.33

18

W11573594 Whirlpool Refrigerator Axle In Stock WPL W11573594 $6.66

18

WPW10530656 Whirlpool Refrigerator Utility Pa Backorder WPL WPW10530656 $113.39

W10467461 Whirlpool Refrigerator Ladder Backorder WPL W10467461 $26.75

W11457241 Whirlpool Burner Drip Bowl In Stock WPL W11457241 $48.95

W11578839 Whirlpool Roller Backorder WPL W11578839 $5.38

WPW10515763 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10515763 $37.73

19A

WPW10515762 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10515762 $37.39

67006692 Whirlpool Refrigerator Screw Backorder WPL 67006692 $4.58

W10785113 Whirlpool Refrigerator Trim Backorder WPL W10785113 $48.29

WP8281136 Whirlpool Screw Backorder WPL WP8281136 $2.51

WPW10499015 Whirlpool Refrigerator Water Tube Backorder WPL WPW10499015 $42.11

20B

W11506620 Whirlpool Refrigerator Coupler In Stock WPL W11506620 $16.85

21

W10423561 Whirlpool Screw Backorder WPL W10423561 $26.21

21

W11504381 Whirlpool Refrigerator Retainer Backorder WPL W11504381 $5.73

21

W11686675 Whirlpool Screw Backorder WPL W11686675 $8.11

22

W11504378 Whirlpool Refrigerator Gasket Backorder WPL W11504378 $12.21

22

WPW10637669 Whirlpool Refrigerator Front Gril Backorder WPL WPW10637669 $43.66

22

GUIDE, CRISPER WPL W10638123 Contact Us For Availability

22B

W11506619 Whirlpool Refrigerator Coupler In Stock WPL W11506619 $13.58

23

W11684620 Whirlpool Vent Backorder WPL W11684620 $12.77

23

DIVIDER, LARGE PANTRY WPL W10772797 Contact Us For Availability

W10854958 Whirlpool Refrigerator Screw Backorder WPL W10854958 $2.71

W11087438 Whirlpool Refrigerator Evaporator M In Stock WPL W11087438 $80.45

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $27.27

ASSEMBLY, FLOOR (INCLUDES HEATER) WPL W11696535 Contact Us For Availability

25

W11109499 Whirlpool Refrigerator Tube In Stock WPL W11109499 $20.17

25

W11123941 Whirlpool Refrigerator Switch In Stock WPL W11123941 $14.15

25A

W11504445 Whirlpool Refrigerator Coupler In Stock WPL W11504445 $15.56

25B

W11506623 Whirlpool Refrigerator Coupler In Stock WPL W11506623 $11.51

26

W11170612 Whirlpool Refrigerator Wire Harness In Stock WPL W11170612 $51.86

26A

W11504431 Whirlpool Microwave Coupler In Stock WPL W11504431 $14.24

26B

W11504415 Whirlpool Refrigerator Coupler In Stock WPL W11504415 $13.69

26C

W11506621 Whirlpool Refrigerator Coupler In Stock WPL W11506621 $11.51

26D

W11506635 Whirlpool Refrigerator Valve Couple In Stock WPL W11506635 $20.70

27

W11449276 Whirlpool Handle Support In Stock WPL W11449276 $9.59

28

W10754591 Whirlpool Refrigerator Cover Backorder WPL W10754591 $42.00

28

W11168403 Whirlpool Refrigerator Thermistor In Stock WPL W11168403 $42.62

28

WPW10280983 Whirlpool Refrigerator Insulation In Stock WPL WPW10280983 $29.50

29

WPW10389152 Whirlpool Support In Stock WPL WPW10389152 $8.09

29

WPW10406719 Whirlpool Refrigerator Shroud Backorder WPL WPW10406719 $24.94

29

COVER, CONNECTOR WPL W11695471 Contact Us For Availability

30

W11126056 Whirlpool Refrigerator Adapter In Stock WPL W11126056 $38.47

30

W11728344-includeCORE Whirlpool W11728344 Dis Backorder WPL W11728344-includeCORE $182.31

31

W11038526 Whirlpool Shelf Glass Backorder WPL W11038526 $127.18

31

W11225849 Whirlpool Refrigerator Retainer Backorder WPL W11225849 $10.76

32

12702901 Whirlpool Refrigerator Pad Backorder WPL 12702901 $6.59

32

W10141518 Whirlpool Refrigerator Screw Backorder WPL W10141518 $5.65

32

W11230117 Whirlpool Refrigerator Support Backorder WPL W11230117 $107.51

33

W10858273 Whirlpool Refrigerator Bin Backorder WPL W10858273 $150.62

33

WPW10248595 Whirlpool Damper Control Assembly In Stock WPL WPW10248595 $84.83

33

COUPLER, DOOR WPL W10505294 Contact Us For Availability

34

W10212137 Whirlpool Refrigerator Grommet Backorder WPL W10212137 $7.78

34

W10826105 Whirlpool Refrigerator Pro Service Backorder WPL W10826105 $60.18

34

W11238397 Whirlpool Refrigerator Cover Backorder WPL W11238397 $10.76

35

W11256332 Whirlpool Refrigerator Evaporator C In Stock WPL W11256332 $80.55

35

W11483116 Whirlpool Refrigerator Module In Stock WPL W11483116 $7.06

36

W10731491 Whirlpool Refrigerator Cover Backorder WPL W10731491 $42.00

36

W11435996 Whirlpool Gasket Backorder WPL W11435996 $9.63

37

W11568592 Whirlpool Refrigerator Gasket Backorder WPL W11568592 $7.12

37

SPACER, CRISPER HANDLE WPL W11694798 Contact Us For Availability

38

WPW10001160 Whirlpool Refrigerator Screw Backorder WPL WPW10001160 $4.56

38

WPW10320706 Whirlpool Refrigerator Gasket In Stock WPL WPW10320706 $9.75

39

WPW10280988 Whirlpool Refrigerator Gasket In Stock WPL WPW10280988 $3.70

40

WPW10392172 Whirlpool Refrigerator Gasket Backorder WPL WPW10392172 $9.70

41

W10860238 Whirlpool Refrigerator Air Tower Backorder WPL W10860238 $158.05

42

W10470981 Whirlpool Refrigerator Gasket Backorder WPL W10470981 $9.66

44

W11678575 Whirlpool Ring In Stock WPL W11678575 $8.11

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $6.86

8003RP Whirlpool Refrigerator 25' 1/4" Copper In Stock WPL 8003RP $21.98

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WPL ARI5CEE166A87037E457C58EA881531C0AA WPL ARI5CEE166A87037E457C58EA881531C0AA Contact Us For Availability
