Model Whirlpool KFCS22EVWH1 REFRIGERATOR – Common Parts &amp; Diagrams

1

DOOR, REFRIGERATOR (BLACK, LH) WPL 13094713BQ Contact Us For Availability

1

DOOR, REFRIGERATOR (WHITE, LH) WPL 13094713WQ Contact Us For Availability

1

DOOR, REFRIGERATOR (STAINLESS, LH) WPL 13094715SQ Contact Us For Availability

2

67006901 Whirlpool Refrigerator Screw Backorder WPL 67006901 $2.51

2

W11120581 Whirlpool Refrigerator Water Tube Backorder WPL W11120581 $43.54

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $35.43

3

W11024160 Whirlpool Refrigerator Breaker Trim Backorder WPL W11024160 $7.03

3

WP12656822 Whirlpool Refrigerator Pantry Draw In Stock WPL WP12656822 $56.74

3

WP12744905 Whirlpool Refrigerator Compressor Backorder WPL WP12744905 $53.64

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $7.69

4

W10119222 Whirlpool Refrigerator Control Knob Backorder WPL W10119222 $8.00

4

WP67001279 Whirlpool Refrigerator Dairy Tray Backorder WPL WP67001279 $46.65

5

W11028221 Whirlpool Refrigerator Shaft In Stock WPL W11028221 $11.31

5

WP12227305WD Whirlpool Drawer Support Backorder WPL WP12227305WD $42.82

5

WP12544124 Whirlpool Refrigerator Valve In Stock WPL WP12544124 $109.42

5

WPW10451453 Whirlpool Refrigerator Cantilever Backorder WPL WPW10451453 $46.46

6

W11214482 Whirlpool Refrigerator Roller Backorder WPL W11214482 $34.97

6

W11510593 Whirlpool Refrigerator Mat Backorder WPL W11510593 $7.80

6

W11510594 Whirlpool Refrigerator Mat Backorder WPL W11510594 $10.43

6

WPW10233569 Whirlpool Refrigerator Tube Backorder WPL WPW10233569 $43.19

7

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $8.86

8

W10144706 Whirlpool Refrigerator Freezer Bin Backorder WPL W10144706 $118.57

8

W10830046 Whirlpool Refrigerator Door Gasket In Stock WPL W10830046 $118.49

8

W10830047 Whirlpool Refrigerator Door Gasket In Stock WPL W10830047 $112.05

8

W11403914 Whirlpool Door Gasket In Stock WPL W11403914 $101.79

9

12992603 Whirlpool Refrigerator Screw Backorder WPL 12992603 $4.56

9

W10829281 Whirlpool Refrigerator Screw Backorder WPL W10829281 $5.01

9

WPW10314515 Whirlpool Refrigerator Handle Backorder WPL WPW10314515 $122.50

9

WPW10314517K Whirlpool Refrigerator Handle Backorder WPL WPW10314517K $120.76

9

Handle, Door (Black) WPL W10119643 Contact Us For Availability

12656202 Whirlpool Refrigerator Housing Backorder WPL 12656202 $52.78

W10210891 Whirlpool Refrigerator Door Hinge Backorder WPL W10210891 $27.29

W10825088 Whirlpool Refrigerator Defrost Heat In Stock WPL W10825088 $76.49

W11712699 Whirlpool Housing Backorder WPL W11712699 $32.28

WP67006113 Whirlpool Stud Bolt In Stock WPL WP67006113 $5.00

W11661170 Whirlpool Clip Backorder WPL W11661170 $4.39

WP12028505AP Whirlpool Closing Cam In Stock WPL WP12028505AP $29.12

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

WP67003638 Whirlpool Closing Cam In Stock WPL WP67003638 $3.70

WP67003639 Whirlpool Refrigerator Closer In Stock WPL WP67003639 $27.82

Shelf, Stationary WPL W10156631 Contact Us For Availability

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $26.81

WPW10194431 Whirlpool Start Device In Stock WPL WPW10194431 $58.28

WPW10243392 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243392 $33.09

WPW10243393 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243393 $35.74

Nameplate (Grey) WPL W10046610 Contact Us For Availability

2207415 Whirlpool Refrigerator Nut Backorder WPL 2207415 $9.59

W10892762 Whirlpool Refrigerator Cover Backorder WPL W10892762 $11.11

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $37.84

WPW10120102 Whirlpool Refrigerator Cover Backorder WPL WPW10120102 $3.51

W10132652 Whirlpool Refrigerator Glide Backorder WPL W10132652 $88.53

Backorder WPL W11750607 $18.30

WP489349 Whirlpool Refrigerator Screw In Stock WPL WP489349 $2.51

WPW10132653 Whirlpool Refrigerator Glide Backorder WPL WPW10132653 $121.88

W10162695 Whirlpool Refrigerator Door Hinge Backorder WPL W10162695 $26.75

W10210883 Whirlpool Refrigerator Door Hinge Backorder WPL W10210883 $26.94

Backorder WPL W11747629 $22.36

WP98165 Whirlpool Screw Backorder WPL WP98165 $2.51

WPW10594329 Whirlpool Control Damper In Stock WPL WPW10594329 $91.80

CLIP, EVAP. MOTOR WPL 13058002 Contact Us For Availability

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

WP12777701 Whirlpool Refrigerator Filler Bloc Backorder WPL WP12777701 $4.15

WPW10121977 Whirlpool End Cap In Stock WPL WPW10121977 $31.75

WPW10122078 Whirlpool Endcap Assembly In Stock WPL WPW10122078 $32.34

12587703W Whirlpool Refrigerator Cover Backorder WPL 12587703W $10.76

67003485 Whirlpool Refrigerator Corner Cover Backorder WPL 67003485 $10.76

W10119219 Whirlpool Refrigerator Crisper Pan In Stock WPL W10119219 $64.54

W10153126 Whirlpool Refrigerator Door Stop Backorder WPL W10153126 $8.53

W10163249 Whirlpool Refrigerator Door Stop Backorder WPL W10163249 $9.61

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $3.70

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

WPW10120097 Whirlpool Refrigerator Door Stop Backorder WPL WPW10120097 $2.93

W10119848 Whirlpool Refrigerator Bracket Backorder WPL W10119848 $13.29

W10119849 Whirlpool Refrigerator Bracket Asse Backorder WPL W10119849 $45.51

W10892768 Whirlpool Refrigerator Door Hinge Backorder WPL W10892768 $26.55

W11346623 Whirlpool Refrigerator Water Filter In Stock WPL W11346623 $55.58

WPW10451454 Whirlpool Refrigerator Cantilever Backorder WPL WPW10451454 $48.51

EDR4RXD1 Whirlpool EveryDrop„¢ Filter 4 Re In Stock WPL EDR4RXD1 $55.44

W11177230 Whirlpool Refrigerator Mullion Rail Backorder WPL W11177230 $120.04

W11177238 Whirlpool Refrigerator Mullion Rail In Stock WPL W11177238 $120.04

W11177241 Whirlpool Refrigerator Mullion Rail Backorder WPL W11177241 $120.04

WPW10170836 Whirlpool Refrigerator Glide Backorder WPL WPW10170836 $117.53

WPW10515762 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10515762 $37.39

WPW10515763 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10515763 $37.73

67006564 Whirlpool Refrigerator Screw Backorder WPL 67006564 $2.51

W11159728 Whirlpool Refrigerator Gasket In Stock WPL W11159728 $10.10

W11311945 Whirlpool Refrigerator Screw Backorder WPL W11311945 $9.59

WPW10119215 Whirlpool Refrigerator Frame Backorder WPL WPW10119215 $174.10

12999501 Whirlpool Refrigerator Hinge Shim In Stock WPL 12999501 $33.89

12999502 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999502 $34.28

13094739BQ Whirlpool Refrigerator Black Foam Backorder WPL 13094739BQ $464.13

13094739WQ Whirlpool Refrigerator Foam Assemb Backorder WPL 13094739WQ $464.13

WP12204827 Whirlpool Refrigerator Glass Shelf Backorder WPL WP12204827 $140.58

WPW10544403 Whirlpool Refrigerator Bracket Backorder WPL WPW10544403 $45.29

WPW10544404 Whirlpool Refrigerator Bracket Backorder WPL WPW10544404 $45.31

DOOR, RIGHT (STAINLESS) WPL 13094716SQ Contact Us For Availability

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

WPW10534153 Whirlpool Refrigerator Black Kick In Stock WPL WPW10534153 $55.37

WPW10534154 Whirlpool Refrigerator Front Gril Backorder WPL WPW10534154 $55.04

WPW10534155 Whirlpool Refrigerator Gray Kickp In Stock WPL WPW10534155 $52.43

23

WPM0104106 Whirlpool Refrigerator Clip Backorder WPL WPM0104106 $2.51

23

Dam (Left Side) WPL 12225602 Contact Us For Availability

12918001 Whirlpool Refrigerator Funnel Backorder WPL 12918001 $7.69

W10162694 Whirlpool Door Hinge Backorder WPL W10162694 $26.75

W10210882 Whirlpool Refrigerator Door Hinge Backorder WPL W10210882 $28.04

W10861742 Whirlpool Refrigerator Door Hinge Backorder WPL W10861742 $29.83

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

25

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $2.51

25

W10121318 Whirlpool Refrigerator Grommet Backorder WPL W10121318 $27.29

25

W11673433 Whirlpool Clip Backorder WPL W11673433 $59.77

12726003 Whirlpool Refrigerator Water Cover Backorder WPL 12726003 $7.16

W10117324 Whirlpool Refrigerator Ice Guide Backorder WPL W10117324 $28.80

W10120003 Whirlpool Refrigerator Freezer Bask Backorder WPL W10120003 $146.26

W10256742 Whirlpool Refrigerator Wire Harness Backorder WPL W10256742 $167.82

WPW10128551 Whirlpool Evaporator Fan Motor In Stock WPL WPW10128551 $43.65

27

W10119217 Whirlpool Refrigerator Slide Backorder WPL W10119217 $9.96

27

W10208593 Whirlpool Refrigerator Valve Cover Backorder WPL W10208593 $9.24

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $13.98

28

W10854958 Whirlpool Refrigerator Screw Backorder WPL W10854958 $2.71

29

12831101 Whirlpool Refrigerator Tube Clamp Backorder WPL 12831101 $7.69

29

W11229977 Whirlpool Refrigerator Reservoir In Stock WPL W11229977 $59.89

29

WP12655703 Whirlpool Refrigerator Utility Pan Backorder WPL WP12655703 $86.25

30

W10182881 Whirlpool Refrigerator Scoop Backorder WPL W10182881 $12.35

30

WPW10211855 Whirlpool Refrigerator Back Cover Backorder WPL WPW10211855 $76.82

31

W10120005 Whirlpool Refrigerator Ice Pan Backorder WPL W10120005 $121.31

31

W11395888 Whirlpool Refrigerator Bypass Filte In Stock WPL W11395888 $24.32

31

W11556315 Whirlpool Shroud Backorder WPL W11556315 $27.80

32

W10833902 Whirlpool Refrigerator Clamp Backorder WPL W10833902 $4.45

32

WPW10120008 Whirlpool Refrigerator Ice Pan Backorder WPL WPW10120008 $82.25

33

W10184030 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10184030 $61.65

33

INSULATION, SOUND WPL 12820505 Contact Us For Availability

34

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $3.70

35

W10157765 Whirlpool Refrigerator Deflector Backorder WPL W10157765 $28.80

35

W10619951 Whirlpool Drain Tube with Grommet In Stock WPL W10619951 $24.50

35

WPW10174720 Whirlpool Refrigerator Front Pan Backorder WPL WPW10174720 $43.39

36

WPW10170835 Whirlpool Refrigerator Glide Backorder WPL WPW10170835 $180.03

36

CABINET (NOT A SERVICABLE PART) WPL NP Contact Us For Availability

39

W10119220 Whirlpool Refrigerator Front Panel Backorder WPL W10119220 $37.70

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

W10196195 Whirlpool Refrigerator Wire Harness Backorder WPL W10196195 $84.29

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

WPW10119821 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10119821 $85.29

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability
