Model Whirlpool KBRO36FTX06 36`` BOTTOM MOUNT BUILT IN REFRIGERATOR – Common Parts &amp; Diagrams

1

Door, Refrigerator (Includes Item 2) WPL W10192039 Contact Us For Availability

1

Tube, Transition (Condenser) WPL 2309072 Contact Us For Availability

2

2302709 Whirlpool Refrigerator Door Gasket In Stock WPL 2302709 $163.30

2

W10388653 Whirlpool Refrigerator Tube Backorder WPL W10388653 $13.93

2

WP2221240 Whirlpool Refrigerator Heater In Stock WPL WP2221240 $67.89

3

2256384 Whirlpool Refrigerator Door Hinge Backorder WPL 2256384 $29.81

3

2307584 Whirlpool Refrigerator Grommet Backorder WPL 2307584 $12.70

3

W10468945 Whirlpool Refrigerator Control Box Backorder WPL W10468945 $506.44

3

W11624204 Whirlpool Screw Backorder WPL W11624204 $9.59

3

WPW10281342 Whirlpool Refrigerator Motor Modu Backorder WPL WPW10281342 $108.63

4

2307944 Whirlpool Clip Backorder WPL 2307944 $7.61

4

W10135775 Whirlpool Refrigerator Screw Backorder WPL W10135775 $8.73

4

W11673500 Whirlpool Door Hinge In Stock WPL W11673500 $61.63

4

WPW10138054 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10138054 $15.79

4

FRONT, UNIT COVER WPL W10185625 Contact Us For Availability

5

W11474472 Whirlpool Screw In Stock WPL W11474472 $2.51

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

5

Screw WPL W10061370 Contact Us For Availability

5

Bracket, Mounting WPL 2307945 Contact Us For Availability

6

2006324 Whirlpool Refrigerator Cover Trim Backorder WPL 2006324 $19.00

6

2209084S Whirlpool Refrigerator Trim Cover Backorder WPL 2209084S $49.03

6

W11565275 Whirlpool Refrigerator Water Tube Backorder WPL W11565275 $23.42

6

WP1163283 Whirlpool Air Conditioner Screw Backorder WPL WP1163283 $2.51

6

TUBE, SUCTION WPL W10431124 Contact Us For Availability

7

2317847 Whirlpool Refrigerator Water Tube Backorder WPL 2317847 $29.43

7

WP2268393 Whirlpool Refrigerator Heater Backorder WPL WP2268393 $56.40

7

WPW10121451 Whirlpool Refrigerator Insert Backorder WPL WPW10121451 $3.70

7

HINGE ASSY, BOTTOM WPL 2256280 Contact Us For Availability

8

WP1106508 Whirlpool Refrigerator Gasket Backorder WPL WP1106508 $4.14

8

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $4.56

8

SCROLL ASSEMBLY WPL W10321092 Contact Us For Availability

8

Transformer WPL 2303033 Contact Us For Availability

9

2215676 Whirlpool Refrigerator Terminal Cover Backorder WPL 2215676 $28.80

9

2309475 Whirlpool Refrigerator Door Trim Backorder WPL 2309475 $118.49

9

W11533506 Whirlpool Refrigerator Water Tube Backorder WPL W11533506 $11.29

9

W11624996 Whirlpool Refrigerator FIP Gasket In Stock WPL W11624996 $83.88

9

WPW10191429 Whirlpool Refrigerator Socket In Stock WPL WPW10191429 $2.51

9

SEAL TRIM, SIDE WPL 2005925 Contact Us For Availability

9

ICE PAN ASSEMBLY WPL 2306174 Contact Us For Availability

9

GROMMET, MOTOR WPL W10321090 Contact Us For Availability

2006329 Whirlpool Refrigerator Cover Trim Backorder WPL 2006329 $28.80

W11671461 Whirlpool Evaporator Motor In Stock WPL W11671461 $102.39

WP2307650 Whirlpool Refrigerator Inlet Valve In Stock WPL WP2307650 $91.62

WPA3073101 Whirlpool Light Bulb In Stock WPL WPA3073101 $5.97

SCREW WPL W10004850 Contact Us For Availability

TRIM, DOOR (HINGE SIDE) WPL 2309476 Contact Us For Availability

2207457 Whirlpool Refrigerator Door Trim Backorder WPL 2207457 $42.33

2309473 Whirlpool Door Trim Backorder WPL 2309473 $111.02

W11671527 Whirlpool Retainer Assembly Backorder WPL W11671527 $9.96

SPACER ASSEMBLY, ICEMAKER (INCLUDES EMITTER) WPL W10321131 Contact Us For Availability

2207470 Whirlpool Refrigerator Hinge Shim Backorder WPL 2207470 $29.41

W10109030 Whirlpool Refrigerator Screw Backorder WPL W10109030 $8.73

WP2006346 Whirlpool Refrigerator Washer In Stock WPL WP2006346 $4.59

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

Diffuser Assembly WPL 2320523 Contact Us For Availability

13

2314064 Whirlpool Refrigerator Drain Tube Backorder WPL 2314064 $28.80

13

W10404239 Whirlpool Refrigerator Tube Backorder WPL W10404239 $39.69

13

COVER, TRIM (HINGE SIDE) WPL 2266942S Contact Us For Availability

14

520965 Whirlpool Refrigerator Support Backorder WPL 520965 $10.14

14

W10139165 Whirlpool Refrigerator Wire Harness Backorder WPL W10139165 $50.69

14

WP8281250 Whirlpool Refrigerator Screw In Stock WPL WP8281250 $4.56

15

2317829 Whirlpool Refrigerator Cover Backorder WPL 2317829 $12.35

15

W10323749 Whirlpool Refrigerator Cantilever B Backorder WPL W10323749 $78.23

15

WPW10195923 Whirlpool Refrigerator Evaporator In Stock WPL WPW10195923 $178.15

2005032 Whirlpool Refrigerator Leveler Backorder WPL 2005032 $65.09

2307998 Whirlpool Refrigerator Condenser In Stock WPL 2307998 $261.55

W11590561 Whirlpool Refrigerator Cantilever B Backorder WPL W11590561 $32.28

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.51

WPW10281063 Whirlpool Refrigerator Heater Pan Backorder WPL WPW10281063 $162.35

2306106 Whirlpool Refrigerator Track Backorder WPL 2306106 $11.07

2318189 Whirlpool Refrigerator Drip Pan Backorder WPL 2318189 $50.98

W10188434 Whirlpool Refrigerator Hinge Gap Backorder WPL W10188434 $41.50

WIRE COVER BOTTOM WPL W10316077 Contact Us For Availability

2252292 Whirlpool Refrigerator Door Hinge Backorder WPL 2252292 $28.99

2306116 Whirlpool Refrigerator Slide Backorder WPL 2306116 $122.91

W10323044 Whirlpool Refrigerator Cantilever B Backorder WPL W10323044 $66.95

W10377174 Whirlpool Refrigerator Front Cover Backorder WPL W10377174 $28.26

WP2221296 Whirlpool Air Baffle In Stock WPL WP2221296 $177.39

WIRE BOX COVER WPL W10321048 Contact Us For Availability

2309474 Whirlpool Door Trim Backorder WPL 2309474 $102.65

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $3.70

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

Cam, Door Closer WPL 2005783 Contact Us For Availability

Block, Evaporator WPL 2306180 Contact Us For Availability

20

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

20

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $4.56

20

DIVIDER, FREEZER BINS (INCLUDES ITEM 34) WPL W10290822 Contact Us For Availability

2006617 Whirlpool Refrigerator Bracket Backorder WPL 2006617 $28.80

2302952 Whirlpool Refrigerator Slide Backorder WPL 2302952 $124.83

2302953 Whirlpool Refrigerator Slide Backorder WPL 2302953 $124.94

W10716209 Whirlpool Refrigerator Support Backorder WPL W10716209 $28.04

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

2302956 Whirlpool Refrigerator Slide Backorder WPL 2302956 $118.28

2302957 Whirlpool Refrigerator Slide Backorder WPL 2302957 $87.50

W10169509 Whirlpool Refrigerator Clip Backorder WPL W10169509 $28.80

Bushing WPL 2300082 Contact Us For Availability

SHIELD WPL 2317927 Contact Us For Availability

W10321050 Whirlpool Refrigerator Shield Backorder WPL W10321050 $26.21

W11578915 Whirlpool Condenser Motor In Stock WPL W11578915 $44.36

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

WPW10121140 Whirlpool Refrigerator Housing In Stock WPL WPW10121140 $106.14

SUPPORT, SLIDE LEFT WPL 2306105 Contact Us For Availability

2320554 Whirlpool Bracket Backorder WPL 2320554 $26.21

WPW10122563 Whirlpool Refrigerator Stripper A Backorder WPL WPW10122563 $32.68

WPW10139483 Whirlpool Refrigerator Condenser In Stock WPL WPW10139483 $28.58

EVAP COVER BRACKET (LEFT SIDE) WPL 2320512 Contact Us For Availability

EVAP COVER BRACKET (RIGHT SIDE) WPL 2327339 Contact Us For Availability

25

W11553819 Whirlpool Refrigerator Insulation In Stock WPL W11553819 $9.59

25

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $41.93

25

SLIDE BRACKET SHIM WPL W10123657 Contact Us For Availability

everydrop® Filter 3 EDR3RXD1 Whirlpool Refri In Stock WPL EDR3RXD1 $55.44

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $3.70

W11715935 Whirlpool Dampener Backorder WPL W11715935 $7.61

AIR RETURN BRACKET WPL W10121940 Contact Us For Availability

27

WP2316859 Whirlpool Refrigerator Bushing In Stock WPL WP2316859 $22.56

28

W10674648 Whirlpool Refrigerator Bracket Backorder WPL W10674648 $8.55

28

WP2317844 Whirlpool Refrigerator Cover Backorder WPL WP2317844 $5.20

29

2252299 Whirlpool Refrigerator Bottom Hinge Backorder WPL 2252299 $62.05

29

WP2188820 Whirlpool Refrigerator Thermistor In Stock WPL WP2188820 $18.70

30

2307566 Whirlpool Refrigerator Tube Backorder WPL 2307566 $10.16

30

W10075920 Whirlpool Refrigerator Washer Backorder WPL W10075920 $5.38

31

2306117 Whirlpool Refrigerator Slide Backorder WPL 2306117 $110.88

31

W10528578 Whirlpool Refrigerator Tube Backorder WPL W10528578 $14.62

32

WP2209024B Whirlpool Refrigerator Front Grill Backorder WPL WP2209024B $67.86

32

WP8533928 Whirlpool Refrigerator Screw In Stock WPL WP8533928 $2.51

33

AIR DEFLECTOR ASSY WPL W10135431 Contact Us For Availability

34

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $2.51

34

WP2310251 Whirlpool Refrigerator Power Cord Backorder WPL WP2310251 $51.17

34

WP2325187B Whirlpool Refrigerator Front Grill Backorder WPL WP2325187B $65.72

35

W10321055 Whirlpool Refrigerator Bracket Backorder WPL W10321055 $10.85

36

W11418227 Whirlpool Refrigerator Extension Backorder WPL W11418227 $28.26

37

WP2266802 Whirlpool Refrigerator Switch In Stock WPL WP2266802 $30.80

39

WP2260518B Whirlpool Water Filter Cap In Stock WPL WP2260518B $12.93

40

W11721628 Whirlpool Screw Assembly Backorder WPL W11721628 $8.11

41

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

W10129081 Whirlpool Refrigerator Handle Backorder WPL W10129081 $207.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability
