Model Whirlpool GX2FHDXVB02 REFRIGERATOR – Common Parts &amp; Diagrams

1

12977869WQ Whirlpool Refrigerator DOR-FIP WH Backorder WPL 12977869WQ $482.63

1

12992301 Whirlpool Refrigerator Screw Backorder WPL 12992301 $13.89

1

DOOR, LEFT (WHITE) WPL 12978044WQ Contact Us For Availability

1

Use & Care Guide WPL W10200283 Contact Us For Availability

1

ENERGY GUIDE WPL W10260546 Contact Us For Availability

1

TECH SHEET WPL W10279337 Contact Us For Availability

1

LINER (NOT A SERVICEABLE PART) WPL NP Contact Us For Availability

1

DOOR, FREEZER (BISCUIT) WPL 12977821QQ Contact Us For Availability

1

DOOR, FREEZER (MONO SATINA) WPL 12977822LQ Contact Us For Availability

1

DOOR, FREEZER (STAINLESS) WPL 12977826SQ Contact Us For Availability

2

W10856123 Whirlpool Refrigerator Gasket Backorder WPL W10856123 $3.70

2

W11120581 Whirlpool Refrigerator Water Tube Backorder WPL W11120581 $45.71

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $52.96

2

WPW10231482 Whirlpool Refrigerator Shelf Trim Backorder WPL WPW10231482 $42.88

2

Handle, Door (White) WPL W10189639 Contact Us For Availability

2

Handle, Door (Black) WPL W10189640 Contact Us For Availability

2

HANDLE, DOOR (BISCUIT) WPL W10189641 Contact Us For Availability

2

Handle, Door (Stainless) WPL W10189642 Contact Us For Availability

2

Module, Light WPL 12806303 Contact Us For Availability

3

W10337647 Whirlpool Refrigerator Cover Backorder WPL W10337647 $13.74

3

W10443315 Whirlpool Door Gasket In Stock WPL W10443315 $119.64

3

W10443316 Whirlpool Refrigerator Door Gasket In Stock WPL W10443316 $122.64

3

W11448709 Whirlpool Refrigerator Bracket Backorder WPL W11448709 $11.69

3

WPW10337634 Whirlpool Refrigerator Cover Backorder WPL WPW10337634 $13.74

3

WPW10337648 Whirlpool Refrigerator Cover Backorder WPL WPW10337648 $12.22

3

WPW10436250 Whirlpool Refrigerator Freezer Do In Stock WPL WPW10436250 $131.01

3

Overlay WPL W10180451 Contact Us For Availability

3

Bucket, Can Dispenser WPL W10169347 Contact Us For Availability

3

COVER, LEFT HINGE (BISCUIT) WPL W10217490 Contact Us For Availability

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $7.69

4

WP13005401SP Whirlpool Can Rack In Stock WPL WP13005401SP $46.20

4

Module, Control WPL 12806407 Contact Us For Availability

5

WPW10128551 Whirlpool Evaporator Fan Motor In Stock WPL WPW10128551 $44.47

5

WPW10503183 Whirlpool Refrigerator Basket Backorder WPL WPW10503183 $136.97

5

WPW10503278 Whirlpool Refrigerator Electronic In Stock WPL WPW10503278 $125.44

5

WPW10515762 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10515762 $42.21

5

WPW10515763 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10515763 $49.66

6

W11285509 Whirlpool Refrigerator Shut-Off Arm Backorder WPL W11285509 $52.56

6

W11291138 Whirlpool Refrigerator Door Switch In Stock WPL W11291138 $14.97

6

W11402523 Whirlpool Refrigerator Glass Shelf Backorder WPL W11402523 $124.05

6

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $4.70

7

W11284721 Whirlpool Refrigerator Cover Backorder WPL W11284721 $38.12

7

W11592375 Whirlpool Door Hinge Backorder WPL W11592375 $10.07

8

12806601 Whirlpool Refrigerator Light Housing Backorder WPL 12806601 $45.48

8

WP67003924 Whirlpool Refrigerator Cover Backorder WPL WP67003924 $3.70

9

W10241046 Whirlpool Refrigerator Divider Backorder WPL W10241046 $12.44

9

W10829281 Whirlpool Refrigerator Screw In Stock WPL W10829281 $5.01

9

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $3.71

9

WP8281196 Whirlpool Screw In Stock WPL WP8281196 $4.52

67005958 Whirlpool Refrigerator Top Hinge Cov In Stock WPL 67005958 $12.02

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $5.40

W11469652 Whirlpool Refrigerator Shield Backorder WPL W11469652 $10.76

WP12729128 Whirlpool Defrost Heater In Stock WPL WP12729128 $67.69

WP67005956 Whirlpool Refrigerator Cover Backorder WPL WP67005956 $12.06

WPW10191117 Whirlpool Refrigerator Cover Backorder WPL WPW10191117 $11.03

COVER, RIGHT HINGE (BISCUIT) WPL 12962302Q Contact Us For Availability

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $29.10

67003900 Whirlpool Refrigerator Insert Damper In Stock WPL 67003900 $4.52

W10308415 Whirlpool Refrigerator Evaporator C Backorder WPL W10308415 $109.42

WP489349 Whirlpool Refrigerator Screw In Stock WPL WP489349 $3.33

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $30.25

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $3.33

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $28.15

WP400021-1 Whirlpool Screw In Stock WPL WP400021-1 $5.38

WP67003405 Whirlpool Pivot Block In Stock WPL WP67003405 $4.70

WPW10197428 Whirlpool Start Device In Stock WPL WPW10197428 $41.28

Nameplate WPL 2220214 Contact Us For Availability

12726003 Whirlpool Refrigerator Water Cover Backorder WPL 12726003 $7.16

W10121318 Whirlpool Refrigerator Grommet In Stock WPL W10121318 $28.66

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $39.73

WP12992902 Whirlpool Refrigerator Screw Backorder WPL WP12992902 $4.58

Backorder WPL W11750607 $19.22

WP12028505AP Whirlpool Closing Cam In Stock WPL WP12028505AP $43.13

WP67001314 Whirlpool Snack Pan Backorder WPL WP67001314 $87.33

WPW10277025 Whirlpool Refrigerator Housing Backorder WPL WPW10277025 $54.90

W10917988 Whirlpool Refrigerator Door Hinge Backorder WPL W10917988 $37.30

W10918113 Whirlpool Refrigerator Door Hinge Backorder WPL W10918113 $41.43

W10918164 Whirlpool Refrigerator Door Hinge Backorder WPL W10918164 $49.19

W11233072 Whirlpool Screw In Stock WPL W11233072 $10.41

WPW10196393 Whirlpool Control Damper In Stock WPL WPW10196393 $93.06

CLIP, EVAP. MOTOR WPL 13058002 Contact Us For Availability

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $10.41

W11396033 Whirlpool Refrigerator Rocker Switc In Stock WPL W11396033 $15.68

W11592374 Whirlpool Refrigerator Top Door Hin In Stock WPL W11592374 $10.89

WP67002633 Whirlpool Crisper Pan In Stock WPL WP67002633 $95.97

12587703W Whirlpool Refrigerator Cover Backorder WPL 12587703W $10.76

67003485 Whirlpool Refrigerator Corner Cover Backorder WPL 67003485 $10.76

W11478401 Whirlpool Refrigerator Housing Backorder WPL W11478401 $88.31

WP12227303WD Whirlpool Refrigerator Crisper B Backorder WPL WP12227303WD $44.45

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $3.70

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $4.52

COVER, CORNER (BISCUIT) WPL 12587703C Contact Us For Availability

18

A3076901 Whirlpool Refrigerator Plug Backorder WPL A3076901 $5.53

18

W10815413 Whirlpool Refrigerator Funnel Backorder WPL W10815413 $29.08

18

WPW10568041 Whirlpool Refrigerator Crisper Sh In Stock WPL WPW10568041 $80.04

19

WP67006878 Whirlpool Refrigerator Crisper Gla In Stock WPL WP67006878 $127.63

19

WPM0500703 Whirlpool Refrigerator O-Ring Seal Backorder WPL WPM0500703 $4.72

20

67006564 Whirlpool Refrigerator Screw Backorder WPL 67006564 $3.33

20

W10273463 Whirlpool Refrigerator Ladder Backorder WPL W10273463 $11.38

20

W11451451 Whirlpool Refrigerator Gasket Backorder WPL W11451451 $4.85

21

W10251969 Whirlpool Refrigerator Ladder Backorder WPL W10251969 $11.51

21

WPB8381501 Whirlpool Refrigerator Door Gasket In Stock WPL WPB8381501 $4.52

21

WPW10210979 Whirlpool Refrigerator Back Cover In Stock WPL WPW10210979 $79.97

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

W10311695 Whirlpool Refrigerator Divider Backorder WPL W10311695 $14.37

WPW10175909 Whirlpool Grille Assembly In Stock WPL WPW10175909 $40.86

WPW10534160 Whirlpool Refrigerator Front Gril In Stock WPL WPW10534160 $41.16

WPW10534161 Whirlpool Refrigerator Front Gril Backorder WPL WPW10534161 $50.05

WPW10534162 Whirlpool Refrigerator Front Gril In Stock WPL WPW10534162 $39.08

GRILLE, TOE (BISCUIT) WPL W10236197 Contact Us For Availability

WP67001721 Whirlpool Refrigerator Support In Stock WPL WP67001721 $4.52

WP67001722 Whirlpool Refrigerator Support Backorder WPL WP67001722 $3.70

WPM0114003 Whirlpool Microwave Speed Clip Cla Backorder WPL WPM0114003 $4.59

WPW10167023 Whirlpool Refrigerator Shroud Backorder WPL WPW10167023 $35.83

Dam (Left Side) WPL 12225602 Contact Us For Availability

12918001 Whirlpool Refrigerator Funnel Backorder WPL 12918001 $7.69

W10619951 Whirlpool Drain Tube with Grommet In Stock WPL W10619951 $25.33

W11613295 Whirlpool Condenser Motor In Stock WPL W11613295 $50.82

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $27.11

WP67001719 Whirlpool Refrigerator Track Backorder WPL WP67001719 $2.51

W11673433 Whirlpool Clip Backorder WPL W11673433 $62.75

WPW10330991 Whirlpool Refrigerator Bracket In Stock WPL WPW10330991 $42.30

WPW10330993 Whirlpool Refrigerator Bracket In Stock WPL WPW10330993 $59.75

Drawer, Pantry WPL 12645027 Contact Us For Availability

26

W10656986 Whirlpool Refrigerator Shelf Trim Backorder WPL W10656986 $44.96

26

WPW10234024 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10234024 $176.20

26

Fiber, Acoustic WPL 12820505 Contact Us For Availability

W10208592 Whirlpool Refrigerator Valve Cover Backorder WPL W10208592 $33.53

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $15.50

WPW10280608 Whirlpool Refrigerator Bracket Backorder WPL WPW10280608 $36.87

WPW10280613 Whirlpool Refrigerator Bracket Backorder WPL WPW10280613 $36.87

28

W10833902 Whirlpool Refrigerator Clamp In Stock WPL W10833902 $4.45

28

W11658402 Whirlpool Drawer Slide Rail In Stock WPL W11658402 $75.69

28

WPW10474715 Whirlpool Refrigerator Gear Backorder WPL WPW10474715 $10.96

W10348260 Whirlpool Refrigerator Bracket Backorder WPL W10348260 $31.90

W11176463 Whirlpool Refrigerator Water Tube In Stock WPL W11176463 $44.76

WPW10284684 Whirlpool Refrigerator Bracket In Stock WPL WPW10284684 $15.24

WPW10284685 Whirlpool Refrigerator Bracket In Stock WPL WPW10284685 $15.34

30

W10348259 Whirlpool Refrigerator Bracket Asse Backorder WPL W10348259 $31.90

30

WP489474 Whirlpool Refrigerator Screw Backorder WPL WP489474 $2.75

30

WP98165 Whirlpool Screw In Stock WPL WP98165 $2.51

12999501 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999501 $35.59

12999502 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999502 $36.00

W10149389 Whirlpool Refrigerator Handle Backorder WPL W10149389 $30.25

W11556315 Whirlpool Shroud In Stock WPL W11556315 $30.01

32

WP7101P126-60 Whirlpool Screw Backorder WPL WP7101P126-60 $2.51

32

WPW10474716 Whirlpool Refrigerator Gear Backorder WPL WPW10474716 $10.87

13000002WD Whirlpool Refrigerator Door Hinge Backorder WPL 13000002WD $55.95

W10918168 Whirlpool Refrigerator Door Hinge Backorder WPL W10918168 $28.99

W11489993 Whirlpool Refrigerator Rail In Stock WPL W11489993 $8.97

W11489994 Whirlpool Refrigerator Rail In Stock WPL W11489994 $8.97

WP67001716 Whirlpool Refrigerator Shelf Suppo In Stock WPL WP67001716 $8.60

34

W10157765 Whirlpool Refrigerator Deflector Backorder WPL W10157765 $30.25

34

DIVIDER-PANTRY WPL 12707601 Contact Us For Availability

34

SWEEP, WATER WPL W10216614 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $29.35

285006 Whirlpool Spray In Stock WPL 285006 $29.65

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.94

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $28.40

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $34.75

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.99

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.02

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (BLACK (UNCUT)) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

CLEANER, 10 OZ. STAINLESS STEEL WPL 31462 Contact Us For Availability

PAINT, BULK (1 QT.) (BISCUIT (UNCUT)) WPL 4392900 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability
