Model Whirlpool GI0FSAXVB00 REFRIGERATOR, FRENCH DOOR, BOTTOM MOUNT – Common Parts &amp; Diagrams

1

WPW10324088 Whirlpool Refrigerator Ice Bin Backorder WPL WPW10324088 $218.52

1

DOOR, REFRIGERATOR LEFT HAND (WHITE) WPL W10174213 Contact Us For Availability

1

HOUSING, DISPENSER (NOT SERVICED) WPL NP Contact Us For Availability

1A

DOOR, FREEZER (BLACK) WPL W10173929 Contact Us For Availability

1A

DOOR, REFRIGERATOR LEFT HAND (BLACK) WPL W10173928 Contact Us For Availability

1B

DOOR, REFRIGERATOR LEFT HAND (SATINA) WPL W10191136 Contact Us For Availability

1B

DOOR, FREEZER (SATINA) WPL 12977816LQ Contact Us For Availability

1C

DOOR, REFRIGERATOR LEFT HAND (STAINLESS) WPL W10191138 Contact Us For Availability

1C

DOOR, FREEZER (STAINLESS) WPL 12977816SQ Contact Us For Availability

1D

DOOR, REFRIGERATOR RIGHT HAND (WHITE) WPL W10160132 Contact Us For Availability

1E

DOOR, REFRIGERATOR RIGHT HAND (BLACK) WPL W10160123 Contact Us For Availability

1F

DOOR, REFRIGERATOR RIGHT HAND (SATINA) WPL W10191132 Contact Us For Availability

1G

DOOR, REFRIGERATOR RIGHT HAND (STAINLESS) WPL W10191134 Contact Us For Availability

2

W10121282 Whirlpool Refrigerator Insert Backorder WPL W10121282 $10.16

2

W10450032 Whirlpool Refrigerator Mat Backorder WPL W10450032 $36.25

2

W10882877 Whirlpool Refrigerator White Dispen Backorder WPL W10882877 $245.29

2

W11415785 Whirlpool Refrigerator Water Fill T In Stock WPL W11415785 $40.44

2

WPW10175514 Whirlpool Refrigerator Shut-Off A Backorder WPL WPW10175514 $42.71

2

HANDLE, DOOR (WHITE) WPL W10159708 Contact Us For Availability

2A

W10450033 Whirlpool Refrigerator Mat Backorder WPL W10450033 $35.81

2A

W10860143 Whirlpool Refrigerator Electronic C Backorder WPL W10860143 $165.08

2A

HANDLE, DOOR (BLACK) WPL W10159709 Contact Us For Availability

2B

W10882878 Whirlpool Refrigerator Electronic C Backorder WPL W10882878 $188.06

2B

WPW10223025K Whirlpool Refrigerator Handle Backorder WPL WPW10223025K $101.36

2C

W10740218 Whirlpool Refrigerator Electric Con In Stock WPL W10740218 $150.91

3

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $8.86

3

12991101 Whirlpool Refrigerator Screw Backorder WPL 12991101 $9.59

3

W10121281 Whirlpool Refrigerator Shroud Backorder WPL W10121281 $26.21

3

WP98165 Whirlpool Screw Backorder WPL WP98165 $2.51

4

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

4

WPW10162697 Whirlpool Refrigerator Motor Backorder WPL WPW10162697 $113.74

4

WPW10443321 Whirlpool Door Gasket In Stock WPL WPW10443321 $126.50

4

SUMP, DISPENSER (WHITE) WPL W10141657 Contact Us For Availability

4

ENDCAP, HANDLE (WHITE) WPL W10157431 Contact Us For Availability

4A

WPW10436253 Whirlpool Refrigerator Black Free In Stock WPL WPW10436253 $144.09

4A

SUMP, DISPENSER (BLACK) WPL W10168726 Contact Us For Availability

4A

ENDCAP, HANDLE (BLACK) WPL W10157432 Contact Us For Availability

4B

WPW10714545 Whirlpool Refrigerator Freezer Do In Stock WPL WPW10714545 $101.59

4B

SUMP, DISPENSER (APOLLO GREY (LIGHT)) WPL W10168728 Contact Us For Availability

4B

ENDCAP, HANDLE (NICKEL) WPL W10172585 Contact Us For Availability

4C

W11676505 Whirlpool Drip Tray Backorder WPL W11676505 $8.62

5

WP13005704W Whirlpool Refrigerator Chute Backorder WPL WP13005704W $118.67

5

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $26.81

5

WP3387230 Whirlpool Screw In Stock WPL WP3387230 $2.51

5

WPW10123444K Whirlpool Refrigerator Wheel Backorder WPL WPW10123444K $30.40

5

WPW10451500 Whirlpool Cantilever Bin In Stock WPL WPW10451500 $54.75

5A

WP13005704B Whirlpool Ice Chute Backorder WPL WP13005704B $118.30

5B

WP13005706 Whirlpool Refrigerator Chute In Stock WPL WP13005706 $118.57

5C

67005958 Whirlpool Refrigerator Top Hinge Cov Backorder WPL 67005958 $12.02

5E

WPW10191117 Whirlpool Refrigerator Cover Backorder WPL WPW10191117 $11.03

6

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $2.51

6

W10165970 Whirlpool Refrigerator Clip Backorder WPL W10165970 $28.80

6

W11311945 Whirlpool Refrigerator Screw Backorder WPL W11311945 $9.59

6

BIN, LOWER WPL 67006981 Contact Us For Availability

6B

W10191141 Whirlpool Refrigerator Tube Cover Backorder WPL W10191141 $8.88

7

67006295 Whirlpool Refrigerator Target Ring Backorder WPL 67006295 $31.07

7

W10187469 Whirlpool Refrigerator Bracket Backorder WPL W10187469 $28.80

7

W10267047 Whirlpool Screw Backorder WPL W10267047 $9.59

7

GROMMET, FAN MOTOR WPL W10151687 Contact Us For Availability

7

COVER, LIGHT WPL 67006318 Contact Us For Availability

8

W10184227 Whirlpool Refrigerator Freezer Bin Backorder WPL W10184227 $63.40

8

W11396037 Whirlpool Door Gasket In Stock WPL W11396037 $105.32

8

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $41.93

8

FACADE, DISPENSER (WHITE) WPL W10141655 Contact Us For Availability

8

DIVIDER, ICE BOX WPL W10187440 Contact Us For Availability

8A

W11378944 Whirlpool Door Gasket In Stock WPL W11378944 $105.32

8A

FACADE, DISPENSER (BLACK) WPL W10163996 Contact Us For Availability

8B

W10830055 Whirlpool Refrigerator Door Gasket In Stock WPL W10830055 $124.35

8B

WPW10310690 Whirlpool Refrigerator Cover Backorder WPL WPW10310690 $189.78

8C

FACADE, DISPENSER (APOLLO GREY (WITH SATINA I WPL W10168725 Contact Us For Availability

9

67002329 Whirlpool Refrigerator Pantry Gasket Backorder WPL 67002329 $10.76

9

M0108106 Whirlpool Refrigerator Clamp Backorder WPL M0108106 $28.80

9

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $2.75

9

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

9

WP67006341 Whirlpool Refrigerator Gasket In Stock WPL WP67006341 $3.70

9

WPW10222984K Whirlpool Refrigerator Handle As Backorder WPL WPW10222984K $101.43

9A

HANDLE, DOOR (BLACK) WPL W10157428 Contact Us For Availability

9B

W11351147 Whirlpool Refrigerator Handle Backorder WPL W11351147 $100.67

67006342 Whirlpool Refrigerator Auger Motor Backorder WPL 67006342 $148.01

W10184223 Whirlpool Refrigerator Bracket Backorder WPL W10184223 $38.27

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $4.58

W11592375 Whirlpool Door Hinge Backorder WPL W11592375 $10.07

WP12565502 Whirlpool Refrigerator Spring Backorder WPL WP12565502 $3.70

WPW10121440 Whirlpool Refrigerator Extension Backorder WPL WPW10121440 $28.80

CLIP, HANDLE WPL 13067102SP Contact Us For Availability

HEATER, DEFROST WPL W10162932 Contact Us For Availability

10A

W11592374 Whirlpool Refrigerator Top Door Hin Backorder WPL W11592374 $10.07

12962106 Whirlpool Refrigerator Waterline Doo Backorder WPL 12962106 $78.61

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

W10235358 Whirlpool Refrigerator Glide Backorder WPL W10235358 $142.79

WPW10127427 Whirlpool Refrigerator Control In Stock WPL WPW10127427 $65.37

YOKE/PAD ASSEMBLY (WHITE) WPL W10146247 Contact Us For Availability

COVER, WATER TANK (UPPER) WPL 67006330 Contact Us For Availability

11A

WPW10168729 Whirlpool Refrigerator Pad Backorder WPL WPW10168729 $8.78

11B

WPW10185234 Whirlpool Refrigerator Pad Backorder WPL WPW10185234 $3.00

67003796 Whirlpool Refrigerator Fiber Acousti Backorder WPL 67003796 $10.76

67006344 Whirlpool Refrigerator Solenoid Backorder WPL 67006344 $89.07

WP67003793 Whirlpool Refrigerator Temperature Backorder WPL WP67003793 $26.96

WP67006331 Whirlpool Refrigerator Water Filte In Stock WPL WP67006331 $53.03

WPW10197428 Whirlpool Start Device In Stock WPL WPW10197428 $40.46

WPW10235368 Whirlpool Refrigerator Glide Backorder WPL WPW10235368 $134.64

WPW10451501 Whirlpool Refrigerator Cantilever In Stock WPL WPW10451501 $55.01

67006329 Whirlpool Refrigerator Lower Water T Backorder WPL 67006329 $83.31

W10826790 Whirlpool Refrigerator Retainer Backorder WPL W10826790 $28.49

W11676504 Whirlpool Insert Assembly Backorder WPL W11676504 $12.77

WP2313326 Whirlpool Refrigerator Switch Backorder WPL WP2313326 $7.94

WPW10287601 Whirlpool Seal In Stock WPL WPW10287601 $14.38

13A

W10826791 Whirlpool Refrigerator Retainer Backorder WPL W10826791 $28.49

EDR4RXD1 Whirlpool EveryDrop„¢ Filter 4 Re In Stock WPL EDR4RXD1 $55.44

WP67006387 Whirlpool Refrigerator Thermostat In Stock WPL WP67006387 $38.96

WPW10121269 Whirlpool Refrigerator Air Baffle Backorder WPL WPW10121269 $28.80

WPW10235370 Whirlpool Refrigerator Glide In Stock WPL WPW10235370 $108.35

WPW10330994 Whirlpool Refrigerator Bracket Backorder WPL WPW10330994 $54.13

14A

WPW10151713 Whirlpool Refrigerator Mullion Ra Backorder WPL WPW10151713 $117.64

14A

WPW10330991 Whirlpool Refrigerator Bracket In Stock WPL WPW10330991 $42.00

14B

WP12722813W Whirlpool Refrigerator Mullion Ra Backorder WPL WP12722813W $111.55

67005680 Whirlpool Refrigerator Condenser Gro Backorder WPL 67005680 $10.76

67006325 Whirlpool Filter Base Bracket In Stock WPL 67006325 $41.96

67007111 Whirlpool Refrigerator Spring Bracke Backorder WPL 67007111 $10.76

W11712696 Whirlpool Clip Backorder WPL W11712696 $6.62

WP12992902 Whirlpool Refrigerator Screw Backorder WPL WP12992902 $4.58

HARNESS, ICEMAKER WPL W10123395 Contact Us For Availability

15A

W10918164 Whirlpool Refrigerator Door Hinge Backorder WPL W10918164 $46.85

15D

W10918168 Whirlpool Refrigerator Door Hinge Backorder WPL W10918168 $27.61

12002355 Whirlpool Refrigerator Thermistor Ki In Stock WPL 12002355 $22.72

12820504 Whirlpool Refrigerator Insulation Backorder WPL 12820504 $25.22

67006346 Whirlpool Refrigerator Washer Backorder WPL 67006346 $9.24

WP67003638 Whirlpool Closing Cam In Stock WPL WP67003638 $3.70

ENDCAP, HANDLE (WHITE) WPL W10157435 Contact Us For Availability

16A

WP67003639 Whirlpool Refrigerator Closer In Stock WPL WP67003639 $27.82

16A

ENDCAP, HANDLE (BLACK) WPL W10157436 Contact Us For Availability

16B

WP12028505AP Whirlpool Closing Cam In Stock WPL WP12028505AP $29.12

16B

ENDCAP, HANDLE (STAINLESS) WPL W10172586 Contact Us For Availability

17

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $27.71

17

67006324 Whirlpool Refrigerator Bracket Backorder WPL 67006324 $11.29

17

YOKE, ICE DISPENSER WPL 630521 Contact Us For Availability

17A

W11708403 Whirlpool Door Stop Backorder WPL W11708403 $5.07

17B

W11703060 Whirlpool Door Stop Backorder WPL W11703060 $5.38

17B

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $3.70

18

WP12956202 Whirlpool Refrigerator Reservoir In Stock WPL WP12956202 $131.86

18

NAMEPLATE WPL 2220214 Contact Us For Availability

18

YOKE, SOLENOID WPL 67006347 Contact Us For Availability

12996601 Whirlpool Refrigerator Bushing Clip Backorder WPL 12996601 $6.92

67006348 Whirlpool Refrigerator Spring Backorder WPL 67006348 $7.89

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

PLUG, BYPASS WPL 12664501 Contact Us For Availability

67006322 Whirlpool Refrigerator Dual Water Va In Stock WPL 67006322 $90.11

67006564 Whirlpool Refrigerator Screw Backorder WPL 67006564 $2.51

W11451451 Whirlpool Refrigerator Gasket Backorder WPL W11451451 $4.85

WPW10121434 Whirlpool Refrigerator Insert Backorder WPL WPW10121434 $9.86

FOIL, ICE BOX WPL W10142628 Contact Us For Availability

21

13033601 Whirlpool Refrigerator Wire Cover Backorder WPL 13033601 $28.80

21

WPW10169124 Whirlpool Refrigerator Grommet In Stock WPL WPW10169124 $3.70

22A

WPW10131134 Whirlpool Refrigerator Front Gril Backorder WPL WPW10131134 $43.96

23

W10118194 Whirlpool Refrigerator Cover Backorder WPL W10118194 $28.80

23

W10164397 Whirlpool Refrigerator Drain Tube Backorder WPL W10164397 $8.73

23

W11700329 Whirlpool Evaporator Shroud Backorder WPL W11700329 $19.27

24

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $3.70

24

WATERLINE, CABINET (W/NUT) WPL 67006970 Contact Us For Availability

25

W10118193 Whirlpool Refrigerator Cover Backorder WPL W10118193 $28.80

25

W11673433 Whirlpool Clip Backorder WPL W11673433 $59.77

25

W11676465 Whirlpool Grommet Backorder WPL W11676465 $5.38

26

COVER, UNIT WPL 12575101WD Contact Us For Availability

27

WP67005864 Whirlpool Humidity Control In Stock WPL WP67005864 $3.70

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $13.98

28

67003794 Whirlpool Refrigerator Temperature C Backorder WPL 67003794 $8.09

35

12961602 Whirlpool Refrigerator Wire Cover Backorder WPL 12961602 $39.14

40

W11686675 Whirlpool Screw Backorder WPL W11686675 $8.11

100

D7824706Q Whirlpool Refrigerator Ice Maker As In Stock WPL D7824706Q $68.02

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

8003RP Whirlpool Refrigerator 25' 1/4" Copper In Stock WPL 8003RP $21.98

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

F2WC9I1 Whirlpool Refrigerator Ice Maker Wate In Stock WPL F2WC9I1 $46.20

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

WPL W10917540 WPL W10917540 Contact Us For Availability

VALVE, ACCESS (5/8") WPL 978029 Contact Us For Availability

MISCELLANEOUS, KIT, FOAM SLAB (30" X 32 1/2" WPL 876029 Contact Us For Availability

MISCELLANEOUS, TAPE, VINYL (3/4 X 108") WPL 479502 Contact Us For Availability

TORX SCREW WRENCH, TORX KEY WPL 1117510 Contact Us For Availability

MISCELLANEOUS, CLEANER, STAINLESS STEEL WPL 20000008 Contact Us For Availability

MISCELLANEOUS, CEMENT, ALUMILASTIC (1 1/4 OZ. WPL 542639 Contact Us For Availability
