Model Whirlpool GB2SHDXTS02 REFRIGERATOR – Common Parts &amp; Diagrams

1

WPW10671238 Whirlpool Drawer Slide Rail In Stock WPL WPW10671238 $39.36

1

DOOR, REFRIGERATOR (WHITE) WPL 12658565WQ Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI147510A Contact Us For Availability

1

DOOR, FREEZER (BLACK) WPL 13092226BQ Contact Us For Availability

1

DOOR, FREEZER (WHITE) WPL 13092226WQ Contact Us For Availability

1

DOOR, FREEZER (STAINLESS STEEL) WPL 13092254SQ Contact Us For Availability

1

DOOR, REFRIGERATOR (BLACK) WPL 12658565BQ Contact Us For Availability

1

DOOR, REFRIGERATOR (STAINLESS STEEL) WPL 13023880SQ Contact Us For Availability

2

W11120581 Whirlpool Refrigerator Water Tube Backorder WPL W11120581 $43.54

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $35.43

2

WPW10010150 Whirlpool Refrigerator Screw Backorder WPL WPW10010150 $2.51

2

WPW10231482 Whirlpool Refrigerator Shelf Trim Backorder WPL WPW10231482 $40.83

2

BRACKET, CONTROL AND LIGHTS WPL 12806301 Contact Us For Availability

3

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $8.86

3

W10443315 Whirlpool Door Gasket In Stock WPL W10443315 $107.66

3

W10480110 Whirlpool Refrigerator Plate Backorder WPL W10480110 $64.38

3

WP67003637 Whirlpool Dairy Door In Stock WPL WP67003637 $41.82

3

WPW10436250 Whirlpool Refrigerator Freezer Do In Stock WPL WPW10436250 $127.04

3

OVERLAY WPL 12816518N Contact Us For Availability

3

SCREW WPL 12990601N Contact Us For Availability

4

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $2.51

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $7.69

4

W11366418 Whirlpool Screw In Stock WPL W11366418 $9.59

4

WP67001279 Whirlpool Refrigerator Dairy Tray Backorder WPL WP67001279 $46.65

4

WPW10464769 Whirlpool Refrigerator Housing Backorder WPL WPW10464769 $37.00

4

BASKET, FREEZER (UPPER) WPL 12896402 Contact Us For Availability

5

W10208592 Whirlpool Refrigerator Valve Cover Backorder WPL W10208592 $31.93

5

W11715937 Whirlpool Shaft Backorder WPL W11715937 $37.90

5

WPW10371194 Whirlpool Refrigerator Door Shelf In Stock WPL WPW10371194 $41.23

5

WPW10503278 Whirlpool Refrigerator Electronic In Stock WPL WPW10503278 $118.83

5

Basket, Freezer (Lower) WPL W10143561 Contact Us For Availability

6

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

6

W11402523 Whirlpool Refrigerator Glass Shelf Backorder WPL W11402523 $118.14

6

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $3.70

6

TUBE, DISCHARGE WPL W10217745 Contact Us For Availability

7

W10224241 Whirlpool Refrigerator Wire Harness Backorder WPL W10224241 $54.46

7

W10709795 Whirlpool Refrigerator Screw Backorder WPL W10709795 $7.81

7

W11284721 Whirlpool Refrigerator Cover Backorder WPL W11284721 $36.31

7

WP67006642 Whirlpool Refrigerator Pin Backorder WPL WP67006642 $3.70

8

12806601 Whirlpool Refrigerator Light Housing Backorder WPL 12806601 $43.32

8

W10443313 Whirlpool Door Gasket In Stock WPL W10443313 $126.29

8

WP67005864 Whirlpool Humidity Control In Stock WPL WP67005864 $3.70

8

WPW10436248 Whirlpool Door Gasket In Stock WPL WPW10436248 $137.86

8

WPW10655367 Whirlpool Refrigerator Drip Pan In Stock WPL WPW10655367 $54.86

9

W10829281 Whirlpool Refrigerator Screw Backorder WPL W10829281 $5.01

9

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $2.75

9

WP2254600B Whirlpool Refrigerator Handle Backorder WPL WP2254600B $108.69

9

WP2254600W Whirlpool Refrigerator Handle Backorder WPL WP2254600W $148.33

9

Handle, Door (Stainless Steel) WPL 2254600S Contact Us For Availability

9

DIVIDER, BASKET (UPPER) WPL 12693802N Contact Us For Availability

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $4.58

WP12729128 Whirlpool Defrost Heater In Stock WPL WP12729128 $66.88

WP98165 Whirlpool Screw Backorder WPL WP98165 $2.51

DIVIDER, BASKET (LOWER) WPL 12659608 Contact Us For Availability

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $27.71

67003900 Whirlpool Refrigerator Insert Damper In Stock WPL 67003900 $3.70

W11661170 Whirlpool Clip Backorder WPL W11661170 $4.39

W11708403 Whirlpool Door Stop Backorder WPL W11708403 $5.07

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $26.81

WP400021-1 Whirlpool Screw In Stock WPL WP400021-1 $4.56

WP67001314 Whirlpool Snack Pan Backorder WPL WP67001314 $83.17

WPW10197426 Whirlpool Refrigerator Start Devi Backorder WPL WPW10197426 $57.23

Nameplate WPL 2220214 Contact Us For Availability

12726003 Whirlpool Refrigerator Water Cover Backorder WPL 12726003 $7.16

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $37.84

WP67001054 Whirlpool Left Glide In Stock WPL WP67001054 $3.70

Retainer, Ref Door WPL 12690502 Contact Us For Availability

67004978 Whirlpool Refrigerator Black Door Bu Backorder WPL 67004978 $10.76

Backorder WPL W11750607 $18.30

WP67001053 Whirlpool Drawer Glide In Stock WPL WP67001053 $3.70

WP67004977 Whirlpool Refrigerator Door Hinge Backorder WPL WP67004977 $3.70

WPW10165425 Whirlpool Bimetal Defrost Thermos In Stock WPL WPW10165425 $32.00

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

WP12607103WD Whirlpool Refrigerator Center Hi Backorder WPL WP12607103WD $57.16

WP12607104ED Whirlpool Refrigerator Door Hing Backorder WPL WP12607104ED $47.49

WP67003638 Whirlpool Closing Cam In Stock WPL WP67003638 $3.70

WP67003639 Whirlpool Refrigerator Closer In Stock WPL WP67003639 $27.82

WPW10196393 Whirlpool Control Damper In Stock WPL WPW10196393 $74.68

CLIP, EVAP. MOTOR WPL 13058002 Contact Us For Availability

EXTENSION, BASEPAN WPL W10206337 Contact Us For Availability

16

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

16

WP67002633 Whirlpool Crisper Pan In Stock WPL WP67002633 $86.30

12587703W Whirlpool Refrigerator Cover Backorder WPL 12587703W $10.76

M0310343 Whirlpool Button Plug Backorder WPL M0310343 $4.72

WP12227303WD Whirlpool Refrigerator Crisper B Backorder WPL WP12227303WD $42.33

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

WPW10169124 Whirlpool Refrigerator Grommet In Stock WPL WPW10169124 $3.70

18

WPW10346420 Whirlpool Refrigerator Condenser Backorder WPL WPW10346420 $115.08

18

WPW10568041 Whirlpool Refrigerator Crisper Sh In Stock WPL WPW10568041 $71.73

19

W10206339 Whirlpool Fastener Backorder WPL W10206339 $4.70

19

W11658402 Whirlpool Drawer Slide Rail In Stock WPL W11658402 $74.88

19

WP67006878 Whirlpool Refrigerator Crisper Gla In Stock WPL WP67006878 $115.43

20

67001073 Whirlpool Refrigerator Center Ladder Backorder WPL 67001073 $28.16

20

W11159742 Whirlpool Refrigerator Gasket Backorder WPL W11159742 $10.10

20

WPW10292802 Whirlpool Refrigerator Drip Tray Backorder WPL WPW10292802 $66.34

21

WP33001882 Whirlpool Screw Backorder WPL WP33001882 $26.21

21

Ladder, Side WPL 12710602 Contact Us For Availability

22

12001919 Whirlpool Refrigerator Evaporator Re Backorder WPL 12001919 $194.96

22

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

23

Dam (Left Side) WPL 12225602 Contact Us For Availability

23

Dam (Right Side) WPL 12225702 Contact Us For Availability

24

12918001 Whirlpool Refrigerator Funnel Backorder WPL 12918001 $7.69

24

W11613295 Whirlpool Condenser Motor In Stock WPL W11613295 $50.00

24

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

25

W10121318 Whirlpool Refrigerator Grommet Backorder WPL W10121318 $27.29

25

W11673433 Whirlpool Clip Backorder WPL W11673433 $59.77

26

WPW10128551 Whirlpool Evaporator Fan Motor In Stock WPL WPW10128551 $43.65

26

WPW10234024 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10234024 $167.82

26

Fiber, Acoustic WPL 12820505 Contact Us For Availability

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $13.98

28

COMPRESSOR KIT (CONTAINS ITEMS 12, 17, 27, & WPL W10130129 Contact Us For Availability

29

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $28.24

30

12002355 Whirlpool Refrigerator Thermistor Ki In Stock WPL 12002355 $22.72

30

67006434 Whirlpool Axle Pin Backorder WPL 67006434 $3.70

31

W11556315 Whirlpool Shroud Backorder WPL W11556315 $27.80

34

10547003 Whirlpool Refrigerator Dryer Clip Backorder WPL 10547003 $4.59

34

W10157765 Whirlpool Refrigerator Deflector Backorder WPL W10157765 $28.80

35

WP67005149 Whirlpool Roller Backorder WPL WP67005149 $10.76

36

CLIP, EVAP (2) WPL 10623002 Contact Us For Availability

37

WPW10137529 Whirlpool Refrigerator Grommet Backorder WPL WPW10137529 $3.70

100

D7824706Q Whirlpool Refrigerator Ice Maker As In Stock WPL D7824706Q $68.02

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

W11619328 Whirlpool Wire Harness In Stock WPL W11619328 $46.83

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

REFRIGERANT CHARGE 5.25 Ozs. (R-134A) WPL ARI147511A Contact Us For Availability

CLEANER, 10 OZ. STAINLESS STEEL WPL 31462 Contact Us For Availability

PAINT, BULK (1 QT.) (BISCUIT (UNCUT)) WPL 4392900 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability
