Model Whirlpool ED20TQXFT01 SIDE BY SIDE REFRIGERATOR – Common Parts &amp; Diagrams

1

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

1

Liner (Not A Serviceable Part) WPL ARI25978A4 Contact Us For Availability

1

Bracket, Motor WPL 2183728 Contact Us For Availability

1

Refrigerator Door Panel (Almond) WPL 2194612N Contact Us For Availability

1

Refrigerator Door Panel (Biscuit) WPL 2194612T Contact Us For Availability

1

Refrigerator Door Panel (White) WPL 2194612W Contact Us For Availability

1

Housing, Dispenser (White) WPL 2180220 Contact Us For Availability

1

Housing, Dispenser (Almond) WPL 2180221 Contact Us For Availability

1

Housing, Dispenser (Biscuit) WPL 2186849 Contact Us For Availability

2

2194744 Whirlpool Refrigerator Escutcheon Backorder WPL 2194744 $28.80

2

WP2155590 Whirlpool Refrigerator Retainer Backorder WPL WP2155590 $2.51

2

WP2188242 Whirlpool Refrigerator Motor In Stock WPL WP2188242 $153.53

2

WP2196157 Whirlpool Fill Tube In Stock WPL WP2196157 $4.59

2

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

2

Blade, Fan WPL 2190685 Contact Us For Availability

2

Mounting Bracket WPL 1110629 Contact Us For Availability

2

Tap, Plate WPL 2196135 Contact Us For Availability

3

2171712 Whirlpool Refrigerator Ice Door Backorder WPL 2171712 $42.79

3

2182757 Whirlpool Refrigerator Slide Backorder WPL 2182757 $31.55

3

WP2152713 Whirlpool Refrigerator Solenoid In Stock WPL WP2152713 $95.64

3

WP2182179 Whirlpool Cam Closer In Stock WPL WP2182179 $3.39

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $4.13

3

Handle (White) WPL 2186649W Contact Us For Availability

4

W10850503 Whirlpool Refrigerator Guide Backorder WPL W10850503 $4.63

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $22.34

4

WP2256126 Whirlpool Refrigerator Reservoir In Stock WPL WP2256126 $77.94

4

WP489483 Whirlpool Screw In Stock WPL WP489483 $4.58

4

WPW10224328 Whirlpool Refrigerator Spring Backorder WPL WPW10224328 $30.85

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

5

2171846 Whirlpool Refrigerator Release Valve Backorder WPL 2171846 $10.76

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $7.69

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

6

WP1115374 Whirlpool Refrigerator Clip Backorder WPL WP1115374 $2.51

6

Shelf Ladder (2) WPL 2181796 Contact Us For Availability

6

Door, Ice WPL 2180205 Contact Us For Availability

7

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.51

7

Wiring Assembly, Ice Dispenser WPL 2186815 Contact Us For Availability

7

Door Mechanism Assembly WPL 2180208 Contact Us For Availability

8

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

8

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

8

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

8

Endcap, Handle (2) (Almond) WPL 2193353N Contact Us For Availability

8

Endcap, Handle (2) (Biscuit) WPL 2193353T Contact Us For Availability

8

Delay Mechanism WPL 2180223 Contact Us For Availability

9

W11223328 Whirlpool Refrigerator Shelf Stud Backorder WPL W11223328 $9.59

9

WP2196046 Whirlpool Refrigerator Door Hinge Backorder WPL WP2196046 $33.95

9

WPW10169511 Whirlpool Refrigerator Coupling In Stock WPL WPW10169511 $9.70

9

Grille, Overflow (White) WPL 2183787W Contact Us For Availability

9

Stud, Rear WPL 2196207 Contact Us For Availability

9

Cover, Unit Compartment WPL 2182057 Contact Us For Availability

9

Grille, Overflow (Almond) WPL 2183787N Contact Us For Availability

9

Grille, Overflow (Biscuit) WPL 2183787T Contact Us For Availability

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $3.70

WP4388152 Whirlpool Refrigerator Fitting In Stock WPL WP4388152 $83.91

Louver WPL 2182147 Contact Us For Availability

Gasket Retainer, Side (2) WPL 1117766 Contact Us For Availability

2182146 Whirlpool Refrigerator Duct Backorder WPL 2182146 $32.79

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $30.80

WP1129262 Whirlpool Refrigerator Cover Backorder WPL WP1129262 $10.38

WP2182195 Whirlpool Refrigerator Cam Backorder WPL WP2182195 $5.14

WP488488 Whirlpool Refrigerator Screw Backorder WPL WP488488 $3.70

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $4.59

Lever, Ice Dispenser (Biscuit) WPL 2195089T Contact Us For Availability

Gasket Retainer, Top & Bottom WPL 1118301 Contact Us For Availability

Lever, Ice Dispenser (Almond) WPL 2195089N Contact Us For Availability

Lever, Ice Dispenser (White) WPL 2195089W Contact Us For Availability

1110560 Whirlpool Refrigerator Bearing Backorder WPL 1110560 $4.72

2188404A Whirlpool Refrigerator Door Gasket In Stock WPL 2188404A $119.63

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $6.95

WP939101 Whirlpool Refrigerator Plate Backorder WPL WP939101 $3.70

Screw WPL 489284 Contact Us For Availability

Extension WPL 2179561 Contact Us For Availability

2180200 Whirlpool Refrigerator Socket Backorder WPL 2180200 $31.40

8201707 Whirlpool Door Hinge Backorder WPL 8201707 $28.26

W10845585 Whirlpool Refrigerator Track Backorder WPL W10845585 $50.98

Grommet (4) WPL 2176134 Contact Us For Availability

Shelf, Cantilever WPL 2173178 Contact Us For Availability

Cap, Hinge Sleeve WPL 509929 Contact Us For Availability

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $8.38

WP2196090 Whirlpool Refrigerator Container Backorder WPL WP2196090 $71.88

WP489497 Whirlpool Screw In Stock WPL WP489497 $4.58

Handle, Center (Almond) WPL 2186649N Contact Us For Availability

Handle, Center (Biscuit) WPL 2186649T Contact Us For Availability

W10749708 Whirlpool Refrigerator Coupling Backorder WPL W10749708 $13.85

WP2180226 Whirlpool Ice Dispenser Control Swi In Stock WPL WP2180226 $6.38

WP2181911 Whirlpool Refrigerator Shim Backorder WPL WP2181911 $11.97

Pivot Arm WPL 1110559 Contact Us For Availability

Reinforcement, Shelf WPL 2152266 Contact Us For Availability

2179350 Whirlpool Refrigerator Deflector Backorder WPL 2179350 $27.14

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $3.70

WP22002263 Whirlpool Dryer 10W Light Bulb In Stock WPL WP22002263 $7.83

Filler, Wrapper (White) WPL 2196094 Contact Us For Availability

Filler, Wrapper (Almond) WPL 2196095 Contact Us For Availability

Filler, Wrapper (Biscuit) WPL 2196150 Contact Us For Availability

W10804014 Whirlpool Refrigerator Grille Backorder WPL W10804014 $73.81

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $108.46

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $34.73

Lever, Water Dispenser (Biscuit) WPL 2195090T Contact Us For Availability

Grille (Almond) WPL 2198469N Contact Us For Availability

Grille (Biscuit) WPL 2198469T Contact Us For Availability

Screw Anchor WPL 941242 Contact Us For Availability

W10508993 Whirlpool Refrigerator Cover Pan In Stock WPL W10508993 $110.82

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $4.67

WP2180279 Whirlpool Refrigerator Switch Backorder WPL WP2180279 $87.10

Clip, Defrost Heater WPL 2161324 Contact Us For Availability

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $4.87

WP2188661 Whirlpool Crisper Pan In Stock WPL WP2188661 $90.28

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

Plaque, Front Cover (White) WPL 2180355 Contact Us For Availability

Plaque, Front Cover (Almond) WPL 2180356 Contact Us For Availability

Plaque, Front Cover (Biscuit) WPL 2205768 Contact Us For Availability

W10278731 Whirlpool Refrigerator Blade Backorder WPL W10278731 $30.29

WP2188664 Whirlpool Dishwasher Meat Crisper P In Stock WPL WP2188664 $45.77

WP2196483 Whirlpool Refrigerator Shelf Stud Backorder WPL WP2196483 $4.34

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

Wire Assembly WPL 2196198 Contact Us For Availability

W10136387A Whirlpool Refrigerator Egg Contain In Stock WPL W10136387A $5.98

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $30.30

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

Front Cover, Housing (Not Available, Order No WPL ARI25980A9 Contact Us For Availability

W10278733 Whirlpool Refrigerator Blade Backorder WPL W10278733 $30.30

W11566763 Whirlpool Fitting In Stock WPL W11566763 $18.87

WP2256085 Whirlpool Refrigerator Retainer Backorder WPL WP2256085 $13.73

WP3400906 Whirlpool Refrigerator Screw Backorder WPL WP3400906 $2.51

WP628356 Whirlpool Refrigerator Fill Cup In Stock WPL WP628356 $15.77

WP1108438 Whirlpool Refrigerator Extension Backorder WPL WP1108438 $10.07

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $4.59

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

Front Cover Assembly (Includes Items 18, 19, WPL 2194569N Contact Us For Availability

Front Cover Assembly (Includes Items 18, 19, WPL 2194569T Contact Us For Availability

Front Cover Assembly (Includes Items 18, 19, WPL 2194569W Contact Us For Availability

WP1108439 Whirlpool Refrigerator Clip Backorder WPL WP1108439 $4.63

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $26.81

WP2182189 Whirlpool Door Shelf Bar In Stock WPL WP2182189 $53.69

WPW10151374 Whirlpool Refrigerator Diffuser In Stock WPL WPW10151374 $33.42

Spacer, Switch (2) WPL 625834 Contact Us For Availability

Fastener, Push-On WPL 489285 Contact Us For Availability

Blade, Fixed (2) WPL 1119009 Contact Us For Availability

1119787 Whirlpool Refrigerator Hinge Cover Backorder WPL 1119787 $12.24

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $32.98

2157405 Whirlpool Refrigerator Blade Block Backorder WPL 2157405 $10.76

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $4.81

2182111 Whirlpool Refrigerator Thermal Knob Backorder WPL 2182111 $9.53

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $27.12

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94

WP2154473 Whirlpool Refrigerator Connector Backorder WPL WP2154473 $10.76

WP3400012 Whirlpool Refrigerator Screw Backorder WPL WP3400012 $2.51

Cover, Conduit WPL 2150330 Contact Us For Availability

Heater, Dispenser WPL 2198094 Contact Us For Availability

W10759522 Whirlpool Screw Backorder WPL W10759522 $2.51

WP2188756 Whirlpool Refrigerator Unit Cover Backorder WPL WP2188756 $65.32

Knob, Air Control WPL 2197871 Contact Us For Availability

Conveyor WPL 2181957 Contact Us For Availability

Interior Door Panel (Also Order Item No.15) WPL 2196137 Contact Us For Availability

4388736 Whirlpool Refrigerator Ice Dispenser In Stock WPL 4388736 $30.73

W10845583 Whirlpool Refrigerator Track Backorder WPL W10845583 $46.34

WP2256010 Whirlpool Door Shelf Trim Backorder WPL WP2256010 $34.66

Bracket, Door Stop WPL 2195950 Contact Us For Availability

Glass, Shelf WPL 2177978 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $10.07

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

WP2196189 Whirlpool Shelf Retainer Bar Backorder WPL WP2196189 $4.48

WP2196190 Whirlpool Shelf Retainer Bar Suppor Backorder WPL WP2196190 $4.48

WP3400912 Whirlpool Refrigerator Washer Backorder WPL WP3400912 $2.51

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WPL 876029 WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

Retainer WPL 1125594 Contact Us For Availability

30

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $4.61

30

W10852691 Whirlpool Refrigerator Baffle Backorder WPL W10852691 $13.16

30

WP489491 Whirlpool Refrigerator Screw In Stock WPL WP489491 $2.51

31

WP1119018 Whirlpool Refrigerator Bearing Backorder WPL WP1119018 $3.70

31

WP2193353W Whirlpool Refrigerator Trim Handle In Stock WPL WP2193353W $3.70

31

Screw WPL 488280 Contact Us For Availability

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $5.67

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

Control Arm WPL 2169938 Contact Us For Availability

Compartment Door WPL 2148289 Contact Us For Availability

1119020 Whirlpool Refrigerator Spring Backorder WPL 1119020 $6.09

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $12.32

WP3400806 Whirlpool Screw In Stock WPL WP3400806 $2.51

Trim, Door Compartment WPL 2188148 Contact Us For Availability

34

1119021 Whirlpool Refrigerator Clip Backorder WPL 1119021 $4.63

34

WP3-24004-109 Whirlpool Refrigerator Screw Backorder WPL WP3-24004-109 $2.51

34

WP4387764 Whirlpool Run Capacitor Backorder WPL WP4387764 $81.03

35

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $4.56

37

WPW10185018 Whirlpool Refrigerator Housing Backorder WPL WPW10185018 $52.10

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

38

WP1119017 Whirlpool Refrigerator Deflector Backorder WPL WP1119017 $3.70

39

489234 Whirlpool Refrigerator Washer Backorder WPL 489234 $9.59

40

WP489236 Whirlpool Refrigerator Ring Backorder WPL WP489236 $5.09

41

4317870 Whirlpool Refrigerator Auger Sleeve Backorder WPL 4317870 $82.48

44

Front Cover, Ice Container WPL 2171709 Contact Us For Availability

45

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.56

46

WP2171706 Whirlpool Refrigerator Light Lens Backorder WPL WP2171706 $30.21

53

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

NI

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $88.85
