Model Whirlpool CA1300XKW1 ROOM AIR CONDITIONER – Common Parts &amp; Diagrams

1

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51

1

Miscellaneous Parts Bag WPL 375976 Contact Us For Availability

2

Cover, Gearcase WPL 367552 Contact Us For Availability

2

Panel, Rear WPL 94216 Contact Us For Availability

2

Cover, Gusset (L.R. & L.F.) WPL 352143 Contact Us For Availability

2

COVER, GUSSET (R.R.) WPL 94114 Contact Us For Availability

3

Gasket, Gearcase WPL 95089 Contact Us For Availability

3

Box, Control WPL 356922 Contact Us For Availability

3

Ball, Suspension (6) WPL 91073 Contact Us For Availability

4

Shaft, Agitator WPL 362642 Contact Us For Availability

4

Rod, Suspension (3) WPL 82584 Contact Us For Availability

5

Ring, Retainer WPL 352430 Contact Us For Availability

5

Strap, Ground WPL 22965 Contact Us For Availability

5

Baseplate & Centerpost WPL 359430 Contact Us For Availability

6

WP3400516 Whirlpool Screw In Stock WPL WP3400516 $2.51

6

Seal, Agitator Shaft WPL 92814 Contact Us For Availability

6

Motor, Timer (60 Hz.) WPL 369253 Contact Us For Availability

7

WP96743 Whirlpool Hose Backorder WPL WP96743 $25.33

7

Shield, Agitator Spring WPL 94276 Contact Us For Availability

7

Screw, Ground (10-24 x 1) WPL 132848 Contact Us For Availability

7

Escapement WPL 369257 Contact Us For Availability

7

Brace, Baseplate WPL 353301 Contact Us For Availability

8

WP356138 Whirlpool Hose Clamp In Stock WPL WP356138 $3.70

8

Spring, Agitator Shaft WPL 92815 Contact Us For Availability

8

Timer Assembly, 60 Hz. WPL 359750 Contact Us For Availability

8

Nut, 5/16-24 WPL 96101 Contact Us For Availability

9

WP89503 Whirlpool Washer Fill Hose In Stock WPL WP89503 $4.47

9

Connector, Hose WPL 95440 Contact Us For Availability

9

Gear, Agitator Shaft WPL 355469 Contact Us For Availability

9

Magnet WPL 365998 Contact Us For Availability

10

WP16123 Whirlpool Washer In Stock WPL WP16123 $2.51

10

Shaft, Agitator WPL 362098 Contact Us For Availability

10

Screw, Taper End WPL 16135 Contact Us For Availability

285205 Whirlpool Bearing Backorder WPL 285205 $3.70

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.12

350938 Whirlpool Spray Gun Backorder WPL 350938 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.51

72109 Whirlpool Dacor Avocado Touch-Up Paint Backorder WPL 72109 $10.07

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $10.07

WP3351614 Whirlpool Screw Backorder WPL WP3351614 $2.51

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

Block, Drive WPL 96384 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability

New Avocado WPL 261888 Contact Us For Availability

New Avocado (Uncut) WPL 261889 Contact Us For Availability

Golden Harvest WPL 261890 Contact Us For Availability

Golden Harvest (Uncut) WPL 261891 Contact Us For Availability

Leveler (Thinner) WPL 350941 Contact Us For Availability

Instructions, Installation WPL 372065 Contact Us For Availability

List, Repair Parts WPL 385284 Contact Us For Availability

Thinner (1 Gal.) WPL 799351 Contact Us For Availability

Almond (Uncut) WPL 978883 Contact Us For Availability

Guide, Cam Bar WPL 95462 Contact Us For Availability

WP356418 Whirlpool Screw In Stock WPL WP356418 $2.51

WPW10083200 Whirlpool Wire Ring In Stock WPL WPW10083200 $4.96

Panel, Rear WPL 85279 Contact Us For Availability

Cam, Bar Spin WPL 354838 Contact Us For Availability

13

WP95405 Whirlpool Belt In Stock WPL WP95405 $9.26

13

Washer, Thrust (2) WPL 353320 Contact Us For Availability

13

Gear, Sector WPL 75073 Contact Us For Availability

WP96160 Whirlpool Washer Inlet Valve Screen In Stock WPL WP96160 $4.76

Pulley, Basket Drive WPL 364032 Contact Us For Availability

Ring, Retainer WPL 52083 Contact Us For Availability

Cover, Front WPL 356831 Contact Us For Availability

Screw, 1/4-28 x 1/2 WPL 98001 Contact Us For Availability

Spring, Brake WPL 94726 Contact Us For Availability

Bearing, Drive Pulley WPL 16033 Contact Us For Availability

Hose, Pump Discharge WPL 21114 Contact Us For Availability

Pin, Dowel WPL 5018 Contact Us For Availability

WP285655 Whirlpool Hose Clamp In Stock WPL WP285655 $3.70

WP359231 Whirlpool Shield In Stock WPL WP359231 $3.70

WP91939 Whirlpool Shaft Seal In Stock WPL WP91939 $4.07

Bolt, 5/16-24 x 3/4 (4) WPL 356599 Contact Us For Availability

Cam, Agitator & Pump WPL 18642 Contact Us For Availability

WP18776 Whirlpool Lock In Stock WPL WP18776 $11.20

Drive Tube & Bearing, Basket WPL 357965 Contact Us For Availability

Bearing, Gear Fork WPL 96853 Contact Us For Availability

Hinge, R.H. WPL 95530 Contact Us For Availability

Plunger WPL 84866 Contact Us For Availability

WP21366 Whirlpool Spanner Nut In Stock WPL WP21366 $3.70

WP356427 Whirlpool Shaft Seal In Stock WPL WP356427 $3.88

Plate, Gusset (2) WPL 356459 Contact Us For Availability

Support, Brake Shoe Yoke WPL 356445 Contact Us For Availability

Strike, Lid Switch WPL 357633 Contact Us For Availability

Rivet WPL 354959 Contact Us For Availability

Set Screw, 5/16-18X 13/16 WPL 356057 Contact Us For Availability

Spring, Gear Fork Shaft WPL 16015 Contact Us For Availability

Bumper, Lid Hinge WPL 91605 Contact Us For Availability

Spring, Brake Yoke WPL 17261 Contact Us For Availability

Seal WPL 351830 Contact Us For Availability

Spacer, Agitator Shaft WPL 356937 Contact Us For Availability

Fork, Agitator Gear WPL 80398 Contact Us For Availability

Basket Drive & Brake (Refer To Page 7 For Fur WPL 358364 Contact Us For Availability

21

Hinge, L.H. WPL 95531 Contact Us For Availability

21

Support, Spin Tube WPL 358586 Contact Us For Availability

22

WP21097 Whirlpool Pad In Stock WPL WP21097 $3.70

22

Spacer, Clutch Shaft WPL 359332 Contact Us For Availability

23

WP21258 Whirlpool Washer Lid Hinge Bearing In Stock WPL WP21258 $6.91

23

Pin, Roll WPL 90532 Contact Us For Availability

23

Rod, Connecting WPL 76577 Contact Us For Availability

24

WPW10119828 Whirlpool Screw In Stock WPL WPW10119828 $2.64

24

Roller, Basket Clutch Shaft WPL 92119 Contact Us For Availability

24

Ring, Retaining WPL 95082 Contact Us For Availability

Cabinet (White) WPL 384793 Contact Us For Availability

Cabinet (Almond) WPL 384794 Contact Us For Availability

Cabinet (New Avocado) WPL 384796 Contact Us For Availability

Cabinet (Golden Harvest) WPL 384797 Contact Us For Availability

Washer, Retainer WPL 95083 Contact Us For Availability

Handle, Lid WPL 356478 Contact Us For Availability

Shaft, Basket Clutch WPL 383723 Contact Us For Availability

WP359364 Whirlpool Clip In Stock WPL WP359364 $3.88

Gearcase (Refer To Page 6 For Further Breakdo WPL 358483 Contact Us For Availability

Gear, Main Drive WPL 353397 Contact Us For Availability

Lid (White) WPL 373115 Contact Us For Availability

Lid (New Avocado) WPL 373210 Contact Us For Availability

Lid (Golden Harvest) WPL 373211 Contact Us For Availability

Lid (Almond) WPL 378802 Contact Us For Availability

BUMPER WPL 356908 Contact Us For Availability

Wire, Ground WPL 364089 Contact Us For Availability

Washer, Thrust WPL 363362 Contact Us For Availability

Pad, Gusset Cover (4) WPL 352434 Contact Us For Availability

WP356907 Whirlpool Rivet Backorder WPL WP356907 $3.70

WP8577376 Whirlpool Seal In Stock WPL WP8577376 $3.88

Leveling Link Assembly WPL 359059 Contact Us For Availability

Gearcase WPL 362906 Contact Us For Availability

WP355214 Whirlpool Screw In Stock WPL WP355214 $2.51

WP358594 Whirlpool Leveling Feet In Stock WPL WP358594 $7.27

Bolt, 5/16-24 x 1-1/8 (3) WPL 356512 Contact Us For Availability

Bolt, 5/16 x 5/8 (2) WPL 126211 Contact Us For Availability

Bolt, 5/16 x 1 (3) WPL 126358 Contact Us For Availability

Bolt, Snubber (1) WPL 353770 Contact Us For Availability

30

18849 Whirlpool Pad Backorder WPL 18849 $9.13

30

Bearing, Drive Pinion WPL 354513 Contact Us For Availability

30

Bolt, 5/16-24 WPL 98048 Contact Us For Availability

Hinge, R.H. WPL 18775 Contact Us For Availability

Hinge, L.H. WPL 92657 Contact Us For Availability

Pinion, Drive WPL 84467 Contact Us For Availability

Gasket, Tub (7) WPL 17235 Contact Us For Availability

32

WP8546455 Whirlpool Bearing In Stock WPL WP8546455 $9.46

32

Cord, Power (120 Volt) WPL 354837 Contact Us For Availability

32

Washer, Drive Pinion WPL 16024 Contact Us For Availability

350572 Whirlpool Oil Transmission 15 Oz In Stock WPL 350572 $32.56

W11095997 Whirlpool Seal In Stock WPL W11095997 $10.76

Valve, Mixing (Serviced Only As Complete Valv WPL 358277 Contact Us For Availability

Ring, Retainer WPL 90094 Contact Us For Availability

Nut, Push-In (2) WPL 98219 Contact Us For Availability

34

16515 Whirlpool Clip Backorder WPL 16515 $11.62

34

Spring, Snubber WPL 357977 Contact Us For Availability

35

Snubber WPL 358336 Contact Us For Availability

35

Retainer, Brake Yoke WPL 356444 Contact Us For Availability

36

Locator, Top (2) WPL 98669 Contact Us For Availability

36

Ball WPL 358585 Contact Us For Availability

37

Setscrew, 5/16-18 x 1/2 WPL 355345 Contact Us For Availability

WP367594 Whirlpool Leveling Feet In Stock WPL WP367594 $10.89

Top (Almond) WPL 359510 Contact Us For Availability

Top (White) WPL 373677 Contact Us For Availability

Top (New Avocado) WPL 377893 Contact Us For Availability

Top (Golden Harvest) WPL 377894 Contact Us For Availability

Pulley, Main Drive WPL 360840 Contact Us For Availability

39

WP358160 Whirlpool Nut Backorder WPL WP358160 $2.51

40

Switch, Water Level WPL 359361 Contact Us For Availability

40

Spring, L.H. WPL 92398 Contact Us For Availability

40

Bracket, Motor Mounting WPL 85286 Contact Us For Availability

41

WP90767 Whirlpool Screw In Stock WPL WP90767 $3.08

41

Nut (4) WPL 98023 Contact Us For Availability

42

Grommet, Motor Bracket (4) WPL 19138 Contact Us For Availability

42

Barrier, Splash WPL 353885 Contact Us For Availability

43

Cap, Terminal (12-Way) (Use W/97452 Terminal) WPL 370148 Contact Us For Availability

43

Pulley, Motor (60 Hz.) WPL 92216 Contact Us For Availability

44

Plug, Terminal (12-Way) (Use W/96413 Terminal WPL 370147 Contact Us For Availability

44

Shield, Motor (Upper) WPL 356217 Contact Us For Availability

45

WP94614 Whirlpool Terminal Backorder WPL WP94614 $2.51

Plug, Terminal (15 Way) WPL 96894 Contact Us For Availability

Motor, 60 Hz. (Alt.) (Emerson) WPL 358589 Contact Us For Availability

Motor, 60 Hz. (Alt.) (General Electric) WPL 362857 Contact Us For Availability

WPL 660303 WPL 660303 Contact Us For Availability

47

8528351 Whirlpool Clip Backorder WPL 8528351 $27.52

47

WPL 359190 WPL 359190 Contact Us For Availability

48

Plug, Cabinet (2) WPL 354179 Contact Us For Availability

48

Screw, 8-32 x 5/16 WPL 155028 Contact Us For Availability

48

WPL 358804 WPL 358804 Contact Us For Availability

49

WP3390631 Whirlpool Screw In Stock WPL WP3390631 $2.51

49

WP90016 Whirlpool Clip Backorder WPL WP90016 $4.78

50

Cap, Terminal (15 Way) WPL 96895 Contact Us For Availability

50

WPL 354195 WPL 354195 Contact Us For Availability

51

Terminal WPL 96413 Contact Us For Availability

51

WPL 98537 WPL 98537 Contact Us For Availability

52

Terminal WPL 97452 Contact Us For Availability

52

WPL 93549 WPL 93549 Contact Us For Availability

53

Cap, Terminal (12-Way) (Use W/97454 Plug & 96 WPL 97455 Contact Us For Availability

53

WPL 95721 WPL 95721 Contact Us For Availability

54

Plug, Terminal (12-Way) (Use W/97455 Cap WPL 97454 Contact Us For Availability

55

WPL 357695 WPL 357695 Contact Us For Availability

55

WPL 357571 WPL 357571 Contact Us For Availability

56

WPL 359642 WPL 359642 Contact Us For Availability

56

WPL 362738 WPL 362738 Contact Us For Availability

58

WPL 351499 WPL 351499 Contact Us For Availability

58

WPL 351500 WPL 351500 Contact Us For Availability

59

WPL 16062 WPL 16062 Contact Us For Availability

60

WPL 90877 WPL 90877 Contact Us For Availability

65

WPL 285134 WPL 285134 Contact Us For Availability

85

Switch Actuator Assembly WPL 370959 Contact Us For Availability

87

Screw & Washer WPL 354975 Contact Us For Availability

89

W10820036 Whirlpool Door Switch Kit In Stock WPL W10820036 $20.22

91

Screw & Washer WPL 354764 Contact Us For Availability
