Model Whirlpool RS630PXV1 – Common Parts &amp; Diagrams

WPL LIT313358 WPL LIT313358 Contact Us For Availability

WPL LIT3148323 WPL LIT3148323 Contact Us For Availability

WPL LIT3148556 WPL LIT3148556 Contact Us For Availability

WPL LIT884467 WPL LIT884467 Contact Us For Availability

1

screw (6) WPL 3148443 Contact Us For Availability

1

Liner, Door WPL 3170710 Contact Us For Availability

1

Harness, Wire (Oven) WPL 310909 Contact Us For Availability

1

End Cap (Screw (2)) WPL 308504 Contact Us For Availability

1

End Cap (R.H.) WPL 3148444 Contact Us For Availability

1

End Cap (L.H.) WPL 3148445 Contact Us For Availability

1

Support, Burner Box (2) WPL 310718 Contact Us For Availability

2

Seal, Glass WPL 3148183 Contact Us For Availability

2

Harness, Wire (Surface Unit) WPL 3147828 Contact Us For Availability

2

Control Panel, Glass WPL 3148633 Contact Us For Availability

2

Burner Box WPL 311019 Contact Us For Availability

3

Glass, Inner WPL 3148179 Contact Us For Availability

3

Harness, Wire (Infinite Switch) WPL 313464 Contact Us For Availability

3

Rail, Top WPL 3148616 Contact Us For Availability

3

Shield, Switch WPL 310716 Contact Us For Availability

4

Baffle, Insulation WPL 3148287 Contact Us For Availability

4

Trim, Center WPL 3148626 Contact Us For Availability

4

screw (2) WPL 342043 Contact Us For Availability

4

Support, Cooktop WPL 310717 Contact Us For Availability

5

16515 Whirlpool Clip Backorder WPL 16515 $11.62

5

Clip, Handle Mtg. (2) WPL 3148282 Contact Us For Availability

5

Rail, Bottom WPL 3148630 Contact Us For Availability

6

Bushing WPL 258109 Contact Us For Availability

7

Retainer, Glass (4) WPL 3149882 Contact Us For Availability

7

Cover, Top Rear WPL 3147565 Contact Us For Availability

8

814103 Whirlpool Clip In Stock WPL 814103 $3.95

8

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.51

8

screw (3) WPL 307748 Contact Us For Availability

8

Frame, Door WPL 3148235 Contact Us For Availability

8

Screw (4) WPL 98520 Contact Us For Availability

8

Bracket, Control Panel (2) WPL 3148634 Contact Us For Availability

8

Cooktop, Chrome WPL 3148039 Contact Us For Availability

9

330031 Whirlpool Range Surface Element Recept In Stock WPL 330031 $5.40

9

WP313808 Whirlpool Screw In Stock WPL WP313808 $2.51

9

Glass, Outer Pano WPL 3148185 Contact Us For Availability

9

Bracket, Control WPL 313314 Contact Us For Availability

9

Clip (2) WPL 313381 Contact Us For Availability

10

Timer WPL 3148053 Contact Us For Availability

10

Panel, Control WPL 3148704 Contact Us For Availability

Heat Seal WPL 309107 Contact Us For Availability

Screw (5) WPL 3149333 Contact Us For Availability

Top, Door Frame WPL 3148223 Contact Us For Availability

Motor, Timer WPL 309822 Contact Us For Availability

Seal, Switch WPL 309839 Contact Us For Availability

W10900107 Whirlpool Oven Surface Element Swit In Stock WPL W10900107 $28.79

WP486579 Whirlpool Air Conditioner Screw Backorder WPL WP486579 $3.11

Switch, Infinite (Use W/8`` Surface Unit (2)) WPL 3148947 Contact Us For Availability

Cover, Side (Right Hand) WPL 3149027 Contact Us For Availability

Cover, Side (Left Hand) WPL 3149028 Contact Us For Availability

13

Seal, Backguard WPL 313316 Contact Us For Availability

13

Indicator Light WPL 313461 Contact Us For Availability

98005642 Whirlpool Clip Backorder WPL 98005642 $28.80

Thermostat, Oven (Alt.) WPL 310861 Contact Us For Availability

Thermostat, Oven (Alt.) WPL 311495 Contact Us For Availability

Thermostat, Oven WPL 660564 Contact Us For Availability

15

Switch, Selector (4 Position) WPL 310866 Contact Us For Availability

16

WP308544 Whirlpool Screw Backorder WPL WP308544 $2.51

16

Light, Indicator (250 V) WPL 311802 Contact Us For Availability

17

Switch, Oven Light WPL 312581 Contact Us For Availability

17

Lockwasher WPL 312796 Contact Us For Availability

242831 Whirlpool Oven Wire Backorder WPL 242831 $261.62

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72109 Whirlpool Dacor Avocado Touch-Up Paint Backorder WPL 72109 $10.07

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $10.07

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

WP307986 Whirlpool Hinge Pin Backorder WPL WP307986 $5.23

WP355515 Whirlpool Screw Backorder WPL WP355515 $2.51

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

Leveler (Thinner) (2oz.) WPL 206925 Contact Us For Availability

Wire (14 Ga. 150 c Black) WPL 242820 Contact Us For Availability

Wire (14 Ga. 150 c Blue) WPL 242821 Contact Us For Availability

Wire (14 Ga. 150 c Brown) WPL 242822 Contact Us For Availability

Wire (14 Ga. 150 c Green) WPL 242823 Contact Us For Availability

Wire (14 Ga. 150 c Orange) WPL 242824 Contact Us For Availability

Wire (14 Ga. 150 c Red) WPL 242825 Contact Us For Availability

Wire, White 14 Ga. 150~c WPL 242826 Contact Us For Availability

Wire (14 Ga. 150 c Yellow) WPL 242827 Contact Us For Availability

Wire (12 Ga. 150 c Black) WPL 242828 Contact Us For Availability

Wire, Red 12 Ga. 150~c WPL 242829 Contact Us For Availability

Wire (14 Ga. 200 c Brown) WPL 242830 Contact Us For Availability

Wire, Yellow 14 Ga. 200~c WPL 242832 Contact Us For Availability

Grease WPL 261582 Contact Us For Availability

Touch-Up, Oven (1/2 Pt.) WPL 261810 Contact Us For Availability

rotisserie kit WPL 261880 Contact Us For Availability

Coffee WPL 261886 Contact Us For Availability

Coffee (Uncut) WPL 261887 Contact Us For Availability

New Avocado WPL 261888 Contact Us For Availability

New Avocado (Uncut) WPL 261889 Contact Us For Availability

Harvest Gold WPL 261890 Contact Us For Availability

Harvest Gold (Uncut) WPL 261891 Contact Us For Availability

Handle, Oven Door WPL 3148228 Contact Us For Availability

Paint, Touch-Up 1/2 Oz. (Coffee) WPL 72108 Contact Us For Availability

WPL 799832 WPL 799832 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

Bezel Switch WPL 313030 Contact Us For Availability

WP308605 Whirlpool Refrigerator Clamp Backorder WPL WP308605 $4.81

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

WPW10196405 Whirlpool 8" Chrome Drip Bowl In Stock WPL WPW10196405 $3.04

WPW10196406 Whirlpool 6" Chrome Drip Bowl In Stock WPL WPW10196406 $2.12

Screw, 10-32 x 5/16 WPL 166681 Contact Us For Availability

20

WP660532 Whirlpool Oven Surface Element In Stock WPL WP660532 $12.14

20

Escutcheon, Thermostat WPL 311065 Contact Us For Availability

21

WP311069 Whirlpool Oven Dial Backorder WPL WP311069 $26.48

21

Screw, 8 x 1/4 (2) WPL 254225 Contact Us For Availability

21

Medallion, Surface Unit WPL 309195 Contact Us For Availability

22

WP3150371 Whirlpool Control Knob In Stock WPL WP3150371 $10.05

22

Knob, Control (4) WPL 3150373 Contact Us For Availability

22

Spring, Oven Door (2) WPL 308127 Contact Us For Availability

23

WP3169181 Whirlpool Knob In Stock WPL WP3169181 $9.28

23

Spring WPL 313311 Contact Us For Availability

23

Bracket, Sensor WPL 3147830 Contact Us For Availability

24

Thermostat WPL 3147833 Contact Us For Availability

24

Support, WPL 312752 Contact Us For Availability

25

Plate, Cover WPL 310662 Contact Us For Availability

25

Trim, End Cap Top Rail WPL 3149900 Contact Us For Availability

26

WP308180 Whirlpool Range Bake Element 2600W 2 In Stock WPL WP308180 $24.28

27

WP660579 Whirlpool Range Wall Oven Broil Elem In Stock WPL WP660579 $63.02

28

Socket, Oven Light (Alt.) WPL 307856 Contact Us For Availability

28

Socket, Oven Light (Alt.) WPL 310208 Contact Us For Availability

28

Socket, Oven Light WPL 660556 Contact Us For Availability

29

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.56

30

Switch, Door WPL 310345 Contact Us For Availability

32

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $2.51

32

WP8203546 Whirlpool Terminal Block In Stock WPL WP8203546 $10.45

33

Cover, Bottom WPL 310458 Contact Us For Availability

34

Angle, Support (2) WPL 311592 Contact Us For Availability

35

Screw, Black 8-15 x 1/2 (3) WPL 309029 Contact Us For Availability

35

Grill, Bottom WPL 310668 Contact Us For Availability

36

Broiler Pan WPL 3147865 Contact Us For Availability

37

4396923 Whirlpool Broil Pan Set Gray Porcelai In Stock WPL 4396923 $18.48

38

WPL 308173 WPL 308173 Contact Us For Availability

39

WPL 308172 WPL 308172 Contact Us For Availability

40

WPL 3149542 WPL 3149542 Contact Us For Availability

41

WPL 311012 WPL 311012 Contact Us For Availability

NI

WP660533 Whirlpool Oven 8" Surface Element In Stock WPL WP660533 $15.88

NI

screw, 6-32 x 1/4 (2) WPL 487384 Contact Us For Availability
