Model Whirlpool RF398PXPW1 – Common Parts &amp; Diagrams

WP312309 Whirlpool Bake Element In Stock WPL WP312309 $70.05

WP660533 Whirlpool Oven 8" Surface Element In Stock WPL WP660533 $15.88

Screw, 10-12 x 7/8 (2) WPL 308043 Contact Us For Availability

1

Harness, Wire (Surface Unit) WPL 313148 Contact Us For Availability

1

Main Chassis (White) WPL 330086 Contact Us For Availability

1

Main Chassis (Almond) WPL 330090 Contact Us For Availability

1

Screw 8-18 x 5/8 (4) WPL 312604 Contact Us For Availability

1

End Trim L.H. WPL 313188 Contact Us For Availability

1

End Trim R.H. WPL 313189 Contact Us For Availability

1

Latch Assembly (Pyro) WPL 330191 Contact Us For Availability

1

Screw, 10-24 x 1/2 (2) WPL 247326 Contact Us For Availability

1

Liner, Door WPL 329694 Contact Us For Availability

2

238614 Whirlpool Bumper Hinge Backorder WPL 238614 $68.16

2

Harness, Wire (Electronic) WPL 313904 Contact Us For Availability

2

End Cap L.H. WPL 313181 Contact Us For Availability

2

End Cap R.H. WPL 313182 Contact Us For Availability

2

Safety Switch WPL 313309 Contact Us For Availability

2

Screw (2) WPL 98106 Contact Us For Availability

2

Channel, Latch WPL 308033 Contact Us For Availability

3

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $3.70

3

Harness, Wire (Main) WPL 313208 Contact Us For Availability

3

Insulator, Switch WPL 309245 Contact Us For Availability

3

Seal, Fiberglass WPL 311904 Contact Us For Availability

4

WP308180 Whirlpool Range Bake Element 2600W 2 In Stock WPL WP308180 $24.28

4

Harness, Wire (Lockswitch) WPL 313478 Contact Us For Availability

4

Frame, Front WPL 330168 Contact Us For Availability

4

Screw,6-3/8 (2) WPL 309258 Contact Us For Availability

4

Shield, Latch Terminal WPL 313035 Contact Us For Availability

4

Panel, Inner WPL 327898 Contact Us For Availability

5

Harness, Wire (Oven Light) WPL 313479 Contact Us For Availability

5

Pin, Hinge (2) WPL 307985 Contact Us For Availability

5

Screw (2) WPL 311056 Contact Us For Availability

5

Handle, Latch WPL 307976 Contact Us For Availability

5

Screw, 10-24 x 1/2 (2) WPL 308422 Contact Us For Availability

5

Window Package WPL 330038 Contact Us For Availability

6

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $2.51

6

Harness, Wire (Infinite Switch) WPL 313210 Contact Us For Availability

6

Trim, Top WPL 313199 Contact Us For Availability

6

Knob, Latch WPL 307977 Contact Us For Availability

6

Retainer, Insulation WPL 308021 Contact Us For Availability

7

Harness, Wire (AC Supply) WPL 313903 Contact Us For Availability

7

Pushnut (2) WPL 308306 Contact Us For Availability

7

Burner Box WPL 307929 Contact Us For Availability

7

Glass (6.81`` x 18.31``) WPL 309842 Contact Us For Availability

8

Block, Disconnect WPL 308566 Contact Us For Availability

8

Hinge (R.H.) WPL 327890 Contact Us For Availability

8

Hinge (L.H.) WPL 327891 Contact Us For Availability

8

Shield, Wiring WPL 307973 Contact Us For Availability

8

Retainer, Glass (2) WPL 309843 Contact Us For Availability

9

Terminal WPL 308564 Contact Us For Availability

9

Oven (30`` Pyro) WPL 329003 Contact Us For Availability

9

Rod, Cooktop WPL 307968 Contact Us For Availability

9

Frame, Door WPL 310427 Contact Us For Availability

WP3390631 Whirlpool Screw Backorder WPL WP3390631 $2.51

Block, Disconnect WPL 308990 Contact Us For Availability

Socket, Lamp (Alt.) WPL 307856 Contact Us For Availability

Socket, Lamp (Alt.) WPL 310208 Contact Us For Availability

Socket, Lamp WPL 660556 Contact Us For Availability

Retainer, Cooktop WPL 307967 Contact Us For Availability

Glass, Outer WPL 309069 Contact Us For Availability

11

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.56

11

Bracket, Cooktop (2) WPL 307965 Contact Us For Availability

11

Top, Door Frame WPL 310428 Contact Us For Availability

Housing, Terminal WPL 814025 Contact Us For Availability

Cover, Light WPL 308039 Contact Us For Availability

Pin, Cooktop (2) WPL 307966 Contact Us For Availability

clip, glass (10) WPL 310706 Contact Us For Availability

4396923 Whirlpool Broil Pan Set Gray Porcelai In Stock WPL 4396923 $18.48

Housing, Terminal WPL 814026 Contact Us For Availability

Retainer, Light WPL 308038 Contact Us For Availability

Cooktop (White) WPL 307866 Contact Us For Availability

Cooktop (Almond) WPL 307871 Contact Us For Availability

Clip (2) WPL 314235 Contact Us For Availability

W10113937 Whirlpool Clamp Backorder WPL W10113937 $4.78

WP90296 Whirlpool Clip Backorder WPL WP90296 $2.51

Rack, Oven (Straight) WPL 308173 Contact Us For Availability

Block, Disconnect WPL 311150 Contact Us For Availability

Plug Button WPL 257314 Contact Us For Availability

Screw 8BT x 1/4 (2) WPL 254225 Contact Us For Availability

Trim, Bottom WPL 313423 Contact Us For Availability

Baffle, Heat WPL 309056 Contact Us For Availability

15

WP308605 Whirlpool Refrigerator Clamp Backorder WPL WP308605 $4.81

15

Rack, Oven (Offset) WPL 308172 Contact Us For Availability

15

Bracket, Oven (Mounting) WPL 311220 Contact Us For Availability

330031 Whirlpool Range Surface Element Recept In Stock WPL 330031 $5.40

WP355515 Whirlpool Screw Backorder WPL WP355515 $2.51

Housing, Terminal WPL 351297 Contact Us For Availability

Vent, Oven WPL 307961 Contact Us For Availability

Bracket, Control Mounting WPL 313581 Contact Us For Availability

Handle, Oven Door WPL 313472 Contact Us For Availability

W10854470 Whirlpool Trim Ring Backorder WPL W10854470 $29.99

W10858781 Whirlpool Trim Ring Backorder WPL W10858781 $31.11

W10900107 Whirlpool Oven Surface Element Swit In Stock WPL W10900107 $28.79

WP486579 Whirlpool Air Conditioner Screw Backorder WPL WP486579 $3.11

Coverplate (2) WPL 311982 Contact Us For Availability

W10291024 Whirlpool Range Cooktop Gray Porcel In Stock WPL W10291024 $30.20

Alternate WPL 313215 Contact Us For Availability

Alternate WPL 3147221 Contact Us For Availability

Sensor, Temperature WPL 661177 Contact Us For Availability

Drawer, Utility WPL 327887 Contact Us For Availability

16515 Whirlpool Clip Backorder WPL 16515 $11.62

242831 Whirlpool Oven Wire Backorder WPL 242831 $261.62

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72109 Whirlpool Dacor Avocado Touch-Up Paint Backorder WPL 72109 $10.07

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $10.07

72113 Whirlpool Touch-Up Paint Backorder WPL 72113 $10.07

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

8212471 Whirlpool Oven Paint In Stock WPL 8212471 $35.69

WP660532 Whirlpool Oven Surface Element In Stock WPL WP660532 $12.14

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

Leveler (Thinner) (2oz.) WPL 206925 Contact Us For Availability

Wire (14 Ga. 150 c Black) WPL 242820 Contact Us For Availability

Wire (14 Ga. 150 c Blue) WPL 242821 Contact Us For Availability

Wire (14 Ga. 150 c Brown) WPL 242822 Contact Us For Availability

Wire (14 Ga. 150 c Green) WPL 242823 Contact Us For Availability

Wire (14 Ga. 150 c Orange) WPL 242824 Contact Us For Availability

Wire (14 Ga. 150 c Red) WPL 242825 Contact Us For Availability

Wire, White 14 Ga. 150~c WPL 242826 Contact Us For Availability

Wire (14 Ga. 150 c Yellow) WPL 242827 Contact Us For Availability

Wire (12 Ga. 150 c Black) WPL 242828 Contact Us For Availability

Wire, Red 12 Ga. 150~c WPL 242829 Contact Us For Availability

Wire (14 Ga. WPL 242830 Contact Us For Availability

WPL 242832 WPL 242832 Contact Us For Availability

WPL 261582 WPL 261582 Contact Us For Availability

WPL 261886 WPL 261886 Contact Us For Availability

WPL 261887 WPL 261887 Contact Us For Availability

WPL 261888 WPL 261888 Contact Us For Availability

WPL 261889 WPL 261889 Contact Us For Availability

WPL 261890 WPL 261890 Contact Us For Availability

WPL 261891 WPL 261891 Contact Us For Availability

WPL 285365 WPL 285365 Contact Us For Availability

WPL 285366 WPL 285366 Contact Us For Availability

WPL 285367 WPL 285367 Contact Us For Availability

WPL 285368 WPL 285368 Contact Us For Availability

WPL 72108 WPL 72108 Contact Us For Availability

WPL 72112 WPL 72112 Contact Us For Availability

WPL 799832 WPL 799832 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

Channel, Arm (2) WPL 329710 Contact Us For Availability

Thermostat, Oven WPL 341197 Contact Us For Availability

Protector, Drawer Side (2) WPL 309329 Contact Us For Availability

WP307986 Whirlpool Hinge Pin Backorder WPL WP307986 $5.23

Screw, 10A x 1/2 (2) WPL 307748 Contact Us For Availability

Medallion (4) WPL 309195 Contact Us For Availability

Glide, Rear (2) WPL 307980 Contact Us For Availability

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $4.56

Ring, Retainer (2) WPL 307594 Contact Us For Availability

Light, Indicator (2) (Includes Amber Lens No. WPL 313106 Contact Us For Availability

Panel Drawer (White) WPL 307935 Contact Us For Availability

Panel, Drawer (Almond) WPL 307939 Contact Us For Availability

WP308126 Whirlpool Door Spring In Stock WPL WP308126 $12.59

WP488627 Whirlpool Refrigerator Screw In Stock WPL WP488627 $4.26

Switch, Fluorescent Light WPL 313348 Contact Us For Availability

Shield, Insulation WPL 312320 Contact Us For Availability

Handle, Drawer WPL 313337 Contact Us For Availability

WP308125 Whirlpool Microwave Range/Cooktop An Backorder WPL WP308125 $5.29

nut, 3/8 x 27 WPL 255912 Contact Us For Availability

Lockwasher WPL 312796 Contact Us For Availability

Switch, Oven Light WPL 312581 Contact Us For Availability

24

Support, L.H. Post WPL 313196 Contact Us For Availability

24

Support, R.H. Post WPL 313197 Contact Us For Availability

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51

Switch, Door (2) WPL 310345 Contact Us For Availability

Lamp, Fluorescent WPL 313110 Contact Us For Availability

Shield, Heat (2) WPL 313716 Contact Us For Availability

Rack, Literature WPL 357645 Contact Us For Availability

26

Ballast (Alt.) WPL 346772 Contact Us For Availability

26

Ballast WPL 660001 Contact Us For Availability

26

Ballast (Alt.) WPL 685591 Contact Us For Availability

27

Socket, Fluorescent Light L.H. WPL 313193 Contact Us For Availability

27

Socket, Fluorescent Light R.H. WPL 313194 Contact Us For Availability

28

Screw, 8-32 x 5/16 (2) WPL 307537 Contact Us For Availability

28

Locator, Cooktop (2) WPL 311909 Contact Us For Availability

29

Bezel, Switch (2) WPL 313030 Contact Us For Availability

30

Snubber, Door (2) WPL 309111 Contact Us For Availability

30

Knob, Control (4) WPL 330171 Contact Us For Availability

31

Insulator, Ballast WPL 313790 Contact Us For Availability

32

WP3196548 Whirlpool Thermal Fuse In Stock WPL WP3196548 $16.20

32

Spacer (2) WPL 313582 Contact Us For Availability

39

Rear Cover Control Panel WPL 313195 Contact Us For Availability

41

Board, Power Control WPL 3170266 Contact Us For Availability

41

Clip WPL 61053 Contact Us For Availability

42

Board, Power Supply WPL 3170267 Contact Us For Availability

44

WP313808 Whirlpool Screw In Stock WPL WP313808 $2.51

44

Bracket, Thermostat WPL 313387 Contact Us For Availability

45

Glass, Touch Panel WPL 313206 Contact Us For Availability

47

Backguard, Lamp WPL 313399 Contact Us For Availability

48

Switch WPL 313425 Contact Us For Availability

48

Cover, Slide Switch WPL 313580 Contact Us For Availability

50

Cover, WPL 3147773 Contact Us For Availability

51

WPL 313486 WPL 313486 Contact Us For Availability

52

WPL 246131 WPL 246131 Contact Us For Availability

52

WPL 313482 WPL 313482 Contact Us For Availability

54

WPL 313444 WPL 313444 Contact Us For Availability

55

WPL 313485 WPL 313485 Contact Us For Availability

57

WPL 3147980 WPL 3147980 Contact Us For Availability

58

WP75614 Whirlpool Connector Backorder WPL WP75614 $2.51

59

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

61

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

61

WPL 313609 WPL 313609 Contact Us For Availability

62

WPL 313087 WPL 313087 Contact Us For Availability
