Model Whirlpool LGR5636PQ0 29``GAS DRYER – Common Parts &amp; Diagrams

2

3400859 Whirlpool Screw Backorder WPL 3400859 $9.13

2

WP489463 Whirlpool Refrigerator Screw In Stock WPL WP489463 $2.51

3

WP3394427 Whirlpool Clip In Stock WPL WP3394427 $3.70

3

WP3404162 Whirlpool Clamp In Stock WPL WP3404162 $3.70

4

279311 Whirlpool Dryer Flat Igniter Assembly In Stock WPL 279311 $15.72

4

W11415783 Whirlpool Seal In Stock WPL W11415783 $6.81

5

W11539855 Whirlpool Refrigerator Pump In Stock WPL W11539855 $338.82

5

WP90767 Whirlpool Screw In Stock WPL WP90767 $2.51

5

WPW10366705 Whirlpool Screw In Stock WPL WPW10366705 $2.51

5

Connector, Timer WPL 3397269 Contact Us For Availability

6

W11398682 Whirlpool Bracket Backorder WPL W11398682 $19.91

6

WP681414 Whirlpool Screw In Stock WPL WP681414 $2.51

7

3395683 Whirlpool Connector Backorder WPL 3395683 $32.06

7

WP3392519 Whirlpool Dryer Thermal Fuse In Stock WPL WP3392519 $7.30

7

Base, Burner WPL 693986 Contact Us For Availability

8

8066086 Whirlpool Plug Backorder WPL 8066086 $4.76

8

8546676 Whirlpool Clip Backorder WPL 8546676 $36.12

8

WP693995 Whirlpool Screw In Stock WPL WP693995 $1.92

9

WP229742 Whirlpool Gas Orifice Backorder WPL WP229742 $12.08

9

WP234826 Whirlpool Gas Orifice In Stock WPL WP234826 $12.08

9

WP234868 Whirlpool Gas Orifice Backorder WPL WP234868 $12.08

9

WP3387134 Whirlpool Dryer Cycling Thermostat In Stock WPL WP3387134 $10.97

9

WP694419 Whirlpool Buzzer Adjuster Backorder WPL WP694419 $49.52

10

WP694089 Whirlpool Dryer Blower Wheel In Stock WPL WP694089 $16.56

10

WP8318277 Whirlpool Gas Valve In Stock WPL WP8318277 $198.88

10

Screen, Lint (Biscuit) WPL 8557858 Contact Us For Availability

11

694421 Whirlpool Screw Assembly Backorder WPL 694421 $7.58

12

694538 Whirlpool Bracket Backorder WPL 694538 $40.00

12

CLIP WPL 8066155 Contact Us For Availability

14

279834 Whirlpool Dryer Gas Valve Solenoid Coi In Stock WPL 279834 $12.01

14

8541401 Whirlpool Door Spring Backorder WPL 8541401 $37.28

15

WP694424 Whirlpool Limiter In Stock WPL WP694424 $12.57

16

49621 Whirlpool Leveling Feet In Stock WPL 49621 $2.29

16

WP694423 Whirlpool Regulator Backorder WPL WP694423 $3.70

17

WP694422 Whirlpool Spring Backorder WPL WP694422 $9.42

19

WP98234 Whirlpool Nut In Stock WPL WP98234 $4.78

20

W10295523 Whirlpool Plug Backorder WPL W10295523 $10.76

21

WP3976584 Whirlpool Timer Assembly In Stock WPL WP3976584 $144.23

21

Seal, Blower WPL 3394196 Contact Us For Availability

24

WP3389441 Whirlpool Door Catch In Stock WPL WP3389441 $3.70

341029 Whirlpool Clamp Backorder WPL 341029 $7.58

49572A Whirlpool Dryer Propane Gas Conversion In Stock WPL 49572A $15.98

W10906683 Whirlpool Door Seal In Stock WPL W10906683 $33.81

FOLLOWING PARTS NOT ILLUSTRATED WPL ARI156963A Contact Us For Availability

26

W11252547 Whirlpool Clip Assembly Backorder WPL W11252547 $10.76

28

WP8066056 Whirlpool Door Hinge In Stock WPL WP8066056 $30.80

28

WP8066057 Whirlpool Door Hinge In Stock WPL WP8066057 $31.07

29

W10854425 Whirlpool Dryer Front Panel Bottom In Stock WPL W10854425 $6.19

30

WP357213 Whirlpool Hinge Stopper Backorder WPL WP357213 $3.70

32

WP8536939 Whirlpool Spring Clip In Stock WPL WP8536939 $3.70

35

WP695737 Whirlpool Door Backorder WPL WP695737 $104.93

36

WP3393549 Whirlpool Door Assembly Backorder WPL WP3393549 $79.93

39

WP3404233 Whirlpool Dryer Starter Switch In Stock WPL WP3404233 $37.17

46

WP348197 Whirlpool Washer Assembly Backorder WPL WP348197 $2.51

47

WP3359452 Whirlpool Nut In Stock WPL WP3359452 $2.51

48

W10756270 Whirlpool Dryer Timer Knob Backorder WPL W10756270 $25.78

48

W11178667 Whirlpool Bulkhead Assembly In Stock WPL W11178667 $118.41

48

Timer Knob Assembly (Biscuit) WPL 8544956 Contact Us For Availability

49

WP338906 Whirlpool Dryer Gas Sensor In Stock WPL WP338906 $17.97

49

Plug, Front Panel (White) WPL 3394975 Contact Us For Availability

49

Knob, Control (White) WPL 8544935 Contact Us For Availability

52

WP94614 Whirlpool Terminal Backorder WPL WP94614 $2.51

53

WP691366 Whirlpool Dryer Idler Pulley Assembl In Stock WPL WP691366 $5.69

55

3936144 Whirlpool Connector Backorder WPL 3936144 $10.76

56

WP388326 Whirlpool Screw Backorder WPL WP388326 $2.51

57

WP348780 Whirlpool Base In Stock WPL WP348780 $36.31

58

3400500 Whirlpool Screw Backorder WPL 3400500 $9.59

63

WP660658 Whirlpool Clamp In Stock WPL WP660658 $3.70

68

WP692490 Whirlpool Drum Baffle In Stock WPL WP692490 $49.76

69

W11684613 Whirlpool Bracket Backorder WPL W11684613 $7.96

70

WP90296 Whirlpool Clip Backorder WPL WP90296 $2.51

71

WP3403636 Whirlpool Drum Baffle Backorder WPL WP3403636 $45.29

73

WP339956 Whirlpool Foam Seal In Stock WPL WP339956 $3.70

3404351 Whirlpool Dryer Rack Backorder WPL 3404351 $20.13

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350938 Whirlpool Spray Gun In Stock WPL 350938 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

W11224254 Whirlpool Test Kit In Stock WPL W11224254 $4.76

W11233063 Whirlpool Shield Assembly Backorder WPL W11233063 $10.76
