Model Whirlpool KFIS20XVMS5 REFRIGERATOR – Common Parts &amp; Diagrams

1

WPW10300025 Whirlpool Refrigerator Ice Mold Backorder WPL WPW10300025 $90.86

1

LINER (NOT A SERVICEABLE PART) WPL NP Contact Us For Availability

1

FREEZER DOOR (STAINLESS) WPL 12977842S Contact Us For Availability

2

W10121282 Whirlpool Refrigerator Insert Backorder WPL W10121282 $10.16

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $35.43

2

WPW10175514 Whirlpool Refrigerator Shut-Off A Backorder WPL WPW10175514 $42.71

2

WPW10314517K Whirlpool Refrigerator Handle Backorder WPL WPW10314517K $120.76

2

Dispenser Keyboard WPL W10180050 Contact Us For Availability

2

MODULE, LIGHT WPL 12905803 Contact Us For Availability

3

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $8.86

3

W10121281 Whirlpool Refrigerator Shroud Backorder WPL W10121281 $26.21

3

W10327050 Whirlpool Refrigerator Cup Fill Backorder WPL W10327050 $33.65

3

WPW10330991 Whirlpool Refrigerator Bracket In Stock WPL WPW10330991 $42.00

3

WPW10330994 Whirlpool Refrigerator Bracket Backorder WPL WPW10330994 $54.13

3

Board, L.V. WPL 13053103SP Contact Us For Availability

3

FOIL, LIGHT WPL 12691605 Contact Us For Availability

4

12921801 Whirlpool Refrigerator Light Cover Backorder WPL 12921801 $10.76

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $7.69

4

W10318914 Whirlpool Refrigerator Ejector Arm Backorder WPL W10318914 $13.89

4

WPW10162697 Whirlpool Refrigerator Motor Backorder WPL WPW10162697 $113.74

4

WPW10714545 Whirlpool Refrigerator Freezer Do In Stock WPL WPW10714545 $101.59

4

SUMP-DISPENSER WPL W10310692 Contact Us For Availability

5

W10555984 Whirlpool Refrigerator Grille Backorder WPL W10555984 $14.60

5

W11028221 Whirlpool Refrigerator Shaft In Stock WPL W11028221 $11.31

5

WP12227305WD Whirlpool Drawer Support Backorder WPL WP12227305WD $42.82

5

WP13005705 Whirlpool Refrigerator Chute Backorder WPL WP13005705 $181.70

5

WPW10119841 Whirlpool Cantilever Bin In Stock WPL WPW10119841 $44.91

5

WPW10122563 Whirlpool Refrigerator Stripper A Backorder WPL WPW10122563 $32.68

5

WPW10123444K Whirlpool Refrigerator Wheel Backorder WPL WPW10123444K $30.40

6

W10165970 Whirlpool Refrigerator Clip Backorder WPL W10165970 $28.80

6

W11396033 Whirlpool Refrigerator Rocker Switc In Stock WPL W11396033 $14.15

6

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $37.11

6

WPW10217747 Whirlpool Refrigerator Tube Backorder WPL WPW10217747 $47.49

6

BIN, LOWER WPL 13002801SP Contact Us For Availability

7

12961602 Whirlpool Refrigerator Wire Cover Backorder WPL 12961602 $39.14

7

67006295 Whirlpool Refrigerator Target Ring Backorder WPL 67006295 $31.07

7

W10187469 Whirlpool Refrigerator Bracket Backorder WPL W10187469 $28.80

7

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $4.59

7

Grommet, Fan Motor WPL W10151687 Contact Us For Availability

7

SCREW-HANDLE WPL W10290759 Contact Us For Availability

7

COVER, LIGHT WPL 12905902 Contact Us For Availability

8

12656202 Whirlpool Refrigerator Housing Backorder WPL 12656202 $52.78

8

12806601 Whirlpool Refrigerator Light Housing Backorder WPL 12806601 $43.32

8

628532 Whirlpool Refrigerator Thermostat Backorder WPL 628532 $40.53

8

W10184227 Whirlpool Refrigerator Freezer Bin Backorder WPL W10184227 $63.40

8

FACADE, DISPENSER (APOLLO GREY) WPL W10310691 Contact Us For Availability

8

DIVIDER, ICE BOX WPL W10331711 Contact Us For Availability

9

M0108106 Whirlpool Refrigerator Clamp Backorder WPL M0108106 $28.80

9

W10001240 Whirlpool Refrigerator Screw Backorder WPL W10001240 $5.65

9

W10829281 Whirlpool Refrigerator Screw Backorder WPL W10829281 $5.01

9

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $2.75

9

WP67006113 Whirlpool Stud Bolt In Stock WPL WP67006113 $5.00

9

WP67006341 Whirlpool Refrigerator Gasket In Stock WPL WP67006341 $3.70

W10184223 Whirlpool Refrigerator Bracket Backorder WPL W10184223 $38.27

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $4.58

W11469652 Whirlpool Refrigerator Shield Backorder WPL W11469652 $10.76

W11592374 Whirlpool Refrigerator Top Door Hin Backorder WPL W11592374 $10.07

W11671282 Whirlpool Refrigerator Ice Auger Mo In Stock WPL W11671282 $65.49

WP12729123 Whirlpool Refrigerator Heater In Stock WPL WP12729123 $75.66

WPW10121440 Whirlpool Refrigerator Extension Backorder WPL WPW10121440 $28.80

Grille, Sump WPL W10187370 Contact Us For Availability

12960101 Whirlpool Refrigerator Cover Backorder WPL 12960101 $71.73

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

W10235358 Whirlpool Refrigerator Glide Backorder WPL W10235358 $142.79

W10275942 Whirlpool Refrigerator Water Tube Backorder WPL W10275942 $43.13

W10308421 Whirlpool Refrigerator Evaporator C Backorder WPL W10308421 $102.86

WPW10127427 Whirlpool Refrigerator Control In Stock WPL WPW10127427 $65.37

WPW10185233 Whirlpool Refrigerator Pad In Stock WPL WPW10185233 $34.95

WPW10235370 Whirlpool Refrigerator Glide In Stock WPL WPW10235370 $108.35

WP12565502 Whirlpool Refrigerator Spring Backorder WPL WP12565502 $3.70

WP67006331 Whirlpool Refrigerator Water Filte In Stock WPL WP67006331 $53.03

WPW10119846 Whirlpool Refrigerator Door Bin S In Stock WPL WPW10119846 $46.57

WPW10121444 Whirlpool Refrigerator Front Cove Backorder WPL WPW10121444 $28.80

WPW10197428 Whirlpool Start Device In Stock WPL WPW10197428 $40.46

WPW10235368 Whirlpool Refrigerator Glide Backorder WPL WPW10235368 $134.64

67006329 Whirlpool Refrigerator Lower Water T Backorder WPL 67006329 $83.31

W10826790 Whirlpool Refrigerator Retainer Backorder WPL W10826790 $28.49

W10826791 Whirlpool Refrigerator Retainer Backorder WPL W10826791 $28.49

W11676504 Whirlpool Insert Assembly Backorder WPL W11676504 $12.77

WP12656105 Whirlpool Drawer Support In Stock WPL WP12656105 $30.91

WP2313326 Whirlpool Refrigerator Switch Backorder WPL WP2313326 $7.94

EDR4RXD1 Whirlpool EveryDrop„¢ Filter 4 Re In Stock WPL EDR4RXD1 $55.44

W11434460 Whirlpool Refrigerator Housing Backorder WPL W11434460 $12.39

WP98165 Whirlpool Screw Backorder WPL WP98165 $2.51

WPW10312691 Whirlpool Refrigerator Air Baffle In Stock WPL WPW10312691 $116.63

15

67006325 Whirlpool Filter Base Bracket In Stock WPL 67006325 $41.96

15

W10312698 Whirlpool Refrigerator Wire Harness Backorder WPL W10312698 $112.21

16

67006346 Whirlpool Refrigerator Washer Backorder WPL 67006346 $9.24

16

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $2.51

16

WP12028505AP Whirlpool Closing Cam In Stock WPL WP12028505AP $29.12

67006324 Whirlpool Refrigerator Bracket Backorder WPL 67006324 $11.29

8201515 Whirlpool Refrigerator Motor and Gear In Stock WPL 8201515 $67.68

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $3.70

WP63052-2 Whirlpool Refrigerator Impeller In Stock WPL WP63052-2 $28.80

18

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

18

W10502642 Whirlpool Refrigerator Reservoir In Stock WPL W10502642 $92.64

18

W11592375 Whirlpool Door Hinge Backorder WPL W11592375 $10.07

12996601 Whirlpool Refrigerator Bushing Clip Backorder WPL 12996601 $6.92

W10273464 Whirlpool Refrigerator Ladder Backorder WPL W10273464 $11.03

W11395888 Whirlpool Refrigerator Bypass Filte In Stock WPL W11395888 $24.32

W11658403 Whirlpool Slide In Stock WPL W11658403 $74.88

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

W10251966 Whirlpool Refrigerator Ladder Backorder WPL W10251966 $28.80

W11547653 Whirlpool Refrigerator Drip Tray Backorder WPL W11547653 $29.39

WPW10121434 Whirlpool Refrigerator Insert Backorder WPL WPW10121434 $9.86

WPW10312696 Whirlpool Water Inlet Valve In Stock WPL WPW10312696 $113.26

Foil, Ice Box WPL W10142628 Contact Us For Availability

21

12999501 Whirlpool Refrigerator Hinge Shim In Stock WPL 12999501 $33.89

21

12999502 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999502 $34.28

21

13033601 Whirlpool Refrigerator Wire Cover Backorder WPL 13033601 $28.80

22

W11536253 Whirlpool Refrigerator Evaporator Backorder WPL W11536253 $105.14

22

WPW10243391 Whirlpool Refrigerator Nameplate Backorder WPL WPW10243391 $26.90

23

12987301 Whirlpool Refrigerator Cover Backorder WPL 12987301 $7.91

24

W10917988 Whirlpool Refrigerator Door Hinge Backorder WPL W10917988 $35.52

24

W11613295 Whirlpool Condenser Motor In Stock WPL W11613295 $50.00

24

WATERLINE, CABINET (W/NUT) WPL W10328203 Contact Us For Availability

25

W10118193 Whirlpool Refrigerator Cover Backorder WPL W10118193 $28.80

25

W11673433 Whirlpool Clip Backorder WPL W11673433 $59.77

25

W11686675 Whirlpool Screw Backorder WPL W11686675 $8.11

26

W10118194 Whirlpool Refrigerator Cover Backorder WPL W10118194 $28.80

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $13.98

28

W10854958 Whirlpool Refrigerator Screw Backorder WPL W10854958 $2.71

30

WPW10270394 Whirlpool Refrigerator Back Cover Backorder WPL WPW10270394 $77.72

31

W11556315 Whirlpool Shroud Backorder WPL W11556315 $27.80

31

WP12227304WD Whirlpool Refrigerator Drawer Su Backorder WPL WP12227304WD $43.13

32

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $3.70

33

Fiber, Acoustic WPL 12820505 Contact Us For Availability

34

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $3.70

36

WP12777701 Whirlpool Refrigerator Filler Bloc Backorder WPL WP12777701 $4.15

36

WPW10334458 Whirlpool Refrigerator Connector Backorder WPL WPW10334458 $8.62

100

WPW10300024 Whirlpool Ice Maker In Stock WPL WPW10300024 $122.14

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

W11033771 Whirlpool Refrigerator Coupling Backorder WPL W11033771 $13.21

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

WPW10324088 Whirlpool Refrigerator Ice Bin Backorder WPL WPW10324088 $218.52

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

Cleaner, Stnls Steel Magic WPL 20000008 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

REFINISHING MATERIAL (ENAMEL, BLACK (1 QT. UN WPL 799340 Contact Us For Availability
