Model Whirlpool KFIS20XVMS2 REFRIGERATOR – Common Parts &amp; Diagrams

1

WPW10300025 Whirlpool Refrigerator Ice Mold Backorder WPL WPW10300025 $95.41

1

WPW10324088 Whirlpool Refrigerator Ice Bin Backorder WPL WPW10324088 $219.31

1

Use & Care Guide WPL 12828191SP Contact Us For Availability

1

GUIDE, ENERGY WPL W10202397 Contact Us For Availability

1

TECH SHEET WPL W10325347 Contact Us For Availability

2

W10121282 Whirlpool Refrigerator Insert Backorder WPL W10121282 $10.16

2

W11415785 Whirlpool Refrigerator Water Fill T In Stock WPL W11415785 $41.27

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $52.96

2

WPW10175514 Whirlpool Refrigerator Shut-Off A Backorder WPL WPW10175514 $44.85

2

Dispenser Keyboard WPL W10180050 Contact Us For Availability

3

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $9.68

3

W10121281 Whirlpool Refrigerator Shroud Backorder WPL W10121281 $27.52

3

W10327050 Whirlpool Refrigerator Cup Fill Backorder WPL W10327050 $35.34

3

W11727651 Whirlpool Plate Assembly Backorder WPL W11727651 $41.52

3

WP67003405 Whirlpool Pivot Block In Stock WPL WP67003405 $4.70

3

Board, L.V. WPL 13053103SP Contact Us For Availability

4

12921801 Whirlpool Refrigerator Light Cover Backorder WPL 12921801 $10.76

4

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $3.33

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $7.69

4

W10318914 Whirlpool Refrigerator Ejector Arm Backorder WPL W10318914 $13.89

4

WPW10162697 Whirlpool Refrigerator Motor Backorder WPL WPW10162697 $113.74

4

Sump, Dispenser (White) WPL W10184826 Contact Us For Availability

4

Sump, Dispenser (Black) WPL W10184827 Contact Us For Availability

4

Sump, Dispenser (Stainless) WPL W10187366 Contact Us For Availability

5

67005958 Whirlpool Refrigerator Top Hinge Cov In Stock WPL 67005958 $12.02

5

W11028221 Whirlpool Refrigerator Shaft In Stock WPL W11028221 $12.13

5

WP13005703B Whirlpool Refrigerator Chute Backorder WPL WP13005703B $192.05

5

WP13005703W Whirlpool Refrigerator Chute Backorder WPL WP13005703W $191.66

5

WP13005705 Whirlpool Refrigerator Chute Backorder WPL WP13005705 $191.58

5

WP67005956 Whirlpool Refrigerator Cover Backorder WPL WP67005956 $12.06

5

WPW10119841 Whirlpool Cantilever Bin In Stock WPL WPW10119841 $54.52

5

WPW10122563 Whirlpool Refrigerator Stripper A Backorder WPL WPW10122563 $34.31

5

WPW10191117 Whirlpool Refrigerator Cover Backorder WPL WPW10191117 $11.03

5

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $29.06

5

SCREW-HANDLE WPL W10290759 Contact Us For Availability

6

12981401B Whirlpool Refrigerator Filtration C Backorder WPL 12981401B $7.78

6

12981401W Whirlpool Refrigerator Cover Filter Backorder WPL 12981401W $7.78

6

W10191141 Whirlpool Refrigerator Tube Cover Backorder WPL W10191141 $8.88

6

WPW10217747 Whirlpool Refrigerator Tube Backorder WPL WPW10217747 $49.87

7

12961602 Whirlpool Refrigerator Wire Cover Backorder WPL 12961602 $41.10

7

67006295 Whirlpool Refrigerator Target Ring Backorder WPL 67006295 $32.63

7

Grommet, Fan Motor WPL W10151687 Contact Us For Availability

8

12656202 Whirlpool Refrigerator Housing Backorder WPL 12656202 $54.81

8

628532 Whirlpool Refrigerator Thermostat Backorder WPL 628532 $42.57

8

W11456069 Whirlpool Refrigerator Clamp In Stock WPL W11456069 $11.58

8

WPW10655368 Whirlpool Refrigerator Drip Pan In Stock WPL WPW10655368 $68.05

8

Facade, Dispenser (Black) WPL W10184486 Contact Us For Availability

8

Facade, Dispenser (White) WPL W10183198 Contact Us For Availability

8

FACADE, DISPENSER (APOLLO GREY) WPL W10188790 Contact Us For Availability

9

M0108106 Whirlpool Refrigerator Clamp Backorder WPL M0108106 $30.25

9

W10829281 Whirlpool Refrigerator Screw In Stock WPL W10829281 $5.01

9

WP8281196 Whirlpool Screw In Stock WPL WP8281196 $4.52

9

WPW10314515 Whirlpool Refrigerator Handle Backorder WPL WPW10314515 $122.50

W11592374 Whirlpool Refrigerator Top Door Hin In Stock WPL W11592374 $10.89

WP12729123 Whirlpool Refrigerator Heater In Stock WPL WP12729123 $82.30

WPW10121440 Whirlpool Refrigerator Extension Backorder WPL WPW10121440 $30.25

Grille, Sump WPL W10187370 Contact Us For Availability

12962106 Whirlpool Refrigerator Waterline Doo Backorder WPL 12962106 $82.54

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $10.41

W10170831 Whirlpool Refrigerator Pad Backorder WPL W10170831 $36.00

W10170832 Whirlpool Refrigerator Pad Backorder WPL W10170832 $36.71

W10204187 Whirlpool Refrigerator Retainer Backorder WPL W10204187 $5.71

W10308421 Whirlpool Refrigerator Evaporator C Backorder WPL W10308421 $108.00

WP67006380 Whirlpool Screw Backorder WPL WP67006380 $3.33

WPW10127427 Whirlpool Refrigerator Control In Stock WPL WPW10127427 $65.37

WPW10185233 Whirlpool Refrigerator Pad In Stock WPL WPW10185233 $54.87

WPW10235370 Whirlpool Refrigerator Glide Backorder WPL WPW10235370 $114.56

12

WP12565502 Whirlpool Refrigerator Spring Backorder WPL WP12565502 $4.52

12

WPW10119846 Whirlpool Refrigerator Door Bin S In Stock WPL WPW10119846 $51.89

12

WPW10197428 Whirlpool Start Device In Stock WPL WPW10197428 $41.28

W10337647 Whirlpool Refrigerator Cover Backorder WPL W10337647 $13.74

W11676504 Whirlpool Insert Assembly Backorder WPL W11676504 $12.77

WP12656105 Whirlpool Drawer Support In Stock WPL WP12656105 $33.27

WP2313326 Whirlpool Refrigerator Switch Backorder WPL WP2313326 $11.99

WPW10137529 Whirlpool Refrigerator Grommet Backorder WPL WPW10137529 $3.70

WPW10287601 Whirlpool Seal In Stock WPL WPW10287601 $15.21

WPW10337634 Whirlpool Refrigerator Cover Backorder WPL WPW10337634 $13.74

WPW10337648 Whirlpool Refrigerator Cover Backorder WPL WPW10337648 $12.22

WP12722813AP Whirlpool Refrigerator Mullion R Backorder WPL WP12722813AP $119.88

WP12722813W Whirlpool Refrigerator Mullion Ra Backorder WPL WP12722813W $117.93

WP489349 Whirlpool Refrigerator Screw In Stock WPL WP489349 $3.33

WP67006387 Whirlpool Refrigerator Thermostat In Stock WPL WP67006387 $38.96

WPW10312691 Whirlpool Refrigerator Air Baffle In Stock WPL WPW10312691 $125.74

13000002WD Whirlpool Refrigerator Door Hinge Backorder WPL 13000002WD $55.95

W10312698 Whirlpool Refrigerator Wire Harness Backorder WPL W10312698 $117.82

W10918168 Whirlpool Refrigerator Door Hinge Backorder WPL W10918168 $28.99

WP12227305WD Whirlpool Drawer Support Backorder WPL WP12227305WD $44.96

WP67005149 Whirlpool Roller In Stock WPL WP67005149 $10.76

16

WP12028505AP Whirlpool Closing Cam In Stock WPL WP12028505AP $43.13

16

WP67006390 Whirlpool Refrigerator High Voltag In Stock WPL WP67006390 $93.70

16

Screw WPL 12992101 Contact Us For Availability

12587703W Whirlpool Refrigerator Cover Backorder WPL 12587703W $10.76

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $29.10

67003485 Whirlpool Refrigerator Corner Cover Backorder WPL 67003485 $10.76

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $3.70

WPW10169124 Whirlpool Refrigerator Grommet In Stock WPL WPW10169124 $4.52

18

W10001240 Whirlpool Refrigerator Screw Backorder WPL W10001240 $5.65

18

W11592375 Whirlpool Door Hinge Backorder WPL W11592375 $10.07

18

WPW10346415 Whirlpool Refrigerator Condenser Backorder WPL WPW10346415 $152.87

12996601 Whirlpool Refrigerator Bushing Clip Backorder WPL 12996601 $6.92

W10273464 Whirlpool Refrigerator Ladder Backorder WPL W10273464 $11.03

W10281329 Whirlpool Clamp In Stock WPL W10281329 $6.59

W11395888 Whirlpool Refrigerator Bypass Filte In Stock WPL W11395888 $42.05

W11658403 Whirlpool Slides In Stock WPL W11658403 $79.44

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

WPW10515762 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10515762 $42.21

WPW10515763 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10515763 $49.66

67006564 Whirlpool Refrigerator Screw Backorder WPL 67006564 $3.33

W10251966 Whirlpool Refrigerator Ladder Backorder WPL W10251966 $28.80

W11451451 Whirlpool Refrigerator Gasket Backorder WPL W11451451 $4.85

W11547653 Whirlpool Refrigerator Drip Tray Backorder WPL W11547653 $30.85

WPW10121434 Whirlpool Refrigerator Insert Backorder WPL WPW10121434 $9.86

WPW10312696 Whirlpool Water Inlet Valve In Stock WPL WPW10312696 $93.10

12999501 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999501 $35.59

12999502 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999502 $36.00

13033601 Whirlpool Refrigerator Wire Cover Backorder WPL 13033601 $30.25

W10857648 Whirlpool Refrigerator Bracket Backorder WPL W10857648 $42.38

W10858097 Whirlpool Refrigerator Bracket Backorder WPL W10858097 $42.36

WP33001882 Whirlpool Screw In Stock WPL WP33001882 $27.52

12002730 Whirlpool Refrigerator Evaporator Ki Backorder WPL 12002730 $183.23

W11176847 Whirlpool Refrigerator Grille Backorder WPL W11176847 $45.13

WPW10243391 Whirlpool Refrigerator Nameplate Backorder WPL WPW10243391 $28.26

WPW10243392 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243392 $34.73

WPW10243393 Whirlpool Dishwasher Nameplate Backorder WPL WPW10243393 $37.53

WPW10534153 Whirlpool Refrigerator Black Kick In Stock WPL WPW10534153 $69.64

WPW10534154 Whirlpool Refrigerator Front Gril Backorder WPL WPW10534154 $57.79

WPW10534155 Whirlpool Refrigerator Gray Kickp In Stock WPL WPW10534155 $62.25

12963002SP Whirlpool Refrigerator Evaporator Backorder WPL 12963002SP $32.17

12987301 Whirlpool Refrigerator Cover Backorder WPL 12987301 $7.91

67006428 Whirlpool Refrigerator Lid, High Vol Backorder WPL 67006428 $27.52

W11700329 Whirlpool Evaporator Shroud Backorder WPL W11700329 $20.24

Dam (Right Side) WPL 12963102SP Contact Us For Availability

W10917988 Whirlpool Refrigerator Door Hinge Backorder WPL W10917988 $37.30

W10918113 Whirlpool Refrigerator Door Hinge Backorder WPL W10918113 $41.43

W10918164 Whirlpool Refrigerator Door Hinge Backorder WPL W10918164 $49.19

W11613295 Whirlpool Condenser Motor In Stock WPL W11613295 $50.82

WP67006337 Whirlpool Refrigerator Fan Blade In Stock WPL WP67006337 $48.33

WATERLINE, CABINET (W/NUT) WPL W10328203 Contact Us For Availability

W10118193 Whirlpool Refrigerator Cover Backorder WPL W10118193 $30.25

W11673433 Whirlpool Clip Backorder WPL W11673433 $62.75

W11676465 Whirlpool Grommet Backorder WPL W11676465 $5.38

W11686675 Whirlpool Screw Backorder WPL W11686675 $8.11

26

W10850438 Whirlpool Refrigerator Evaporator M In Stock WPL W10850438 $161.23

26

W11666013 Whirlpool Wire Harness Backorder WPL W11666013 $40.19

27

W10815413 Whirlpool Refrigerator Funnel Backorder WPL W10815413 $29.08

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $15.50

28

W10160407 Whirlpool Refrigerator Compressor In Stock WPL W10160407 $328.61

28

W10854958 Whirlpool Refrigerator Screw Backorder WPL W10854958 $2.71

28

WPM0500703 Whirlpool Refrigerator O-Ring Seal Backorder WPL WPM0500703 $4.72

29

WPB8381501 Whirlpool Refrigerator Door Gasket In Stock WPL WPB8381501 $4.52

29

WPL 12957801 WPL 12957801 Contact Us For Availability

29

Clip, Evaporator WPL 10623002 Contact Us For Availability

30

67006434 Whirlpool Axle Pin In Stock WPL 67006434 $3.70

30

WPW10270394 Whirlpool Refrigerator Back Cover Backorder WPL WPW10270394 $81.61

W10619951 Whirlpool Drain Tube with Grommet In Stock WPL W10619951 $25.33

W11556315 Whirlpool Shroud In Stock WPL W11556315 $30.01

WP12227304WD Whirlpool Refrigerator Drawer Su Backorder WPL WP12227304WD $45.29

WP67003924 Whirlpool Refrigerator Cover Backorder WPL WP67003924 $3.70

32

WP489474 Whirlpool Refrigerator Screw Backorder WPL WP489474 $2.75

33

WPL 12820505 WPL 12820505 Contact Us For Availability

34

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $4.70

35

WPW10312695-includeCORE Whirlpool WPW10312695 Backorder WPL WPW10312695-includeCORE $204.74

100

WPW10300024 Whirlpool Ice Maker In Stock WPL WPW10300024 $140.28

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $29.35

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.94

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $27.52

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $34.75

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.99

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.02

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

REFINISHING MATERIAL (ENAMEL, WHITE (1 QT. UN WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

REFRIGERANT CHARGE (5.25 OZS. (R-134A)) WPL NP Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability
