Model Whirlpool KDRS483VSS04 RANGE/OVEN, DUAL FUEL, 48 INCH – Common Parts &amp; Diagrams

1

W10188323 Whirlpool Door Liner Backorder WPL W10188323 $149.04

1

WP9759413 Whirlpool Door Liner Backorder WPL WP9759413 $138.47

1

WPW10225969 Whirlpool Range Vent Backorder WPL WPW10225969 $171.36

2

4449748 Whirlpool Oven Screw Backorder WPL 4449748 $7.01

2

W10115994 Whirlpool Broil Element Backorder WPL W10115994 $124.01

2

W10145620 Whirlpool Bottom Model Backorder WPL W10145620 $42.57

2

W10340424 Whirlpool Orifice Spud Backorder WPL W10340424 $32.41

2

HINGE, DOOR (LEFT) WPL W10774089 Contact Us For Availability

2A

HINGE, DOOR (RIGHT) WPL W10774088 Contact Us For Availability

2B

W11051480 Whirlpool Orifice Assembly Backorder WPL W11051480 $35.10

3

W10105790 Whirlpool Bumper In Stock WPL W10105790 $4.85

3

W10846622 Whirlpool Orifice Holder Backorder WPL W10846622 $43.32

3

W11550107 Whirlpool Oven Rack Backorder WPL W11550107 $59.22

3

W11601369 Whirlpool Spark Module In Stock WPL W11601369 $48.87

3

WP4449259 Whirlpool Glass Window In Stock WPL WP4449259 $83.40

3

WPW10138054 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10138054 $16.58

3

WPW10245511 Whirlpool Blower In Stock WPL WPW10245511 $201.89

4

W10846623 Whirlpool Orifice Holder Backorder WPL W10846623 $43.32

4

W11186364 Whirlpool Oven Rack In Stock WPL W11186364 $142.36

4

WP4451722 Whirlpool Door Insulation Assembly Backorder WPL WP4451722 $68.58

5

W10116033 Whirlpool Bake Element Backorder WPL W10116033 $78.72

5

WP4457132 Whirlpool Retainer Backorder WPL WP4457132 $107.44

5

ELEMENT, HIDDEN BAKE WPL W10115995 Contact Us For Availability

6

W10115876 Whirlpool Cover Backorder WPL W10115876 $32.63

6

W10269216 Whirlpool Top Trim Backorder WPL W10269216 $129.66

6

W10495854 Whirlpool Transformer Backorder WPL W10495854 $86.64

6

W10859931 Whirlpool Foot Level Backorder WPL W10859931 $46.17

6

WPW10169757 Whirlpool Light Bulb In Stock WPL WPW10169757 $29.12

7

W10249333 Whirlpool Range Mounting Bracket Backorder WPL W10249333 $118.92

7

W10860984 Whirlpool Fan Motor In Stock WPL W10860984 $74.69

7

WP3177991 Whirlpool Screw Backorder WPL WP3177991 $2.51

7

WP9759225 Whirlpool Inner Door Glass Backorder WPL WP9759225 $87.13

7

WPW10307114 Whirlpool Light Backorder WPL WPW10307114 $51.06

8

W10169756 Whirlpool Light Lens Backorder WPL W10169756 $27.80

8

WPW10292297 Whirlpool Screw Backorder WPL WPW10292297 $2.51

8

WPW10385582 Whirlpool Burner Valve In Stock WPL WPW10385582 $141.33

9

W10261510 Whirlpool Knob Bezel Backorder WPL W10261510 $27.93

9

W10270397 Whirlpool Vent Seal Backorder WPL W10270397 $12.11

9

W10852683 Whirlpool Nameplate Backorder WPL W10852683 $78.45

9

W11321067 Whirlpool Complete Side Assembly Backorder WPL W11321067 $199.83

9

WP4455605 Whirlpool Left Hand Hinge In Stock WPL WP4455605 $56.11

9

WPW10160821 Whirlpool Fan Cover Backorder WPL WPW10160821 $106.90

9A

W10250466 Whirlpool Cabinet Panel Backorder WPL W10250466 $220.21

9A

WP4455606 Whirlpool Right Hand Hinge In Stock WPL WP4455606 $56.11

10

W10115869 Whirlpool Shaft Backorder WPL W10115869 $43.57

10

W10319835 Whirlpool Sensor Backorder WPL W10319835 $85.41

4453116 Whirlpool Range Adapter Backorder WPL 4453116 $72.36

W10115793 Whirlpool Shaft Backorder WPL W10115793 $33.69

W11643125 Whirlpool Element Backorder WPL W11643125 $46.65

WP4449751 Whirlpool Range Oven Thermostat Fix In Stock WPL WP4449751 $75.89

WP9761958 Whirlpool Range Terminal Block In Stock WPL WP9761958 $13.67

12

489504 Whirlpool Range Ring Backorder WPL 489504 $4.85

12

W10217130 Whirlpool Screw Backorder WPL W10217130 $5.29

12

W10852104-includeCORE Whirlpool W10852104 Ran Backorder WPL W10852104-includeCORE $242.84

W10115719 Whirlpool Door Handle Backorder WPL W10115719 $51.83

W10115720 Whirlpool Door Handle Backorder WPL W10115720 $114.01

W10467022 Whirlpool Box Terminal Backorder WPL W10467022 $52.58

WP4449743 Whirlpool Screw Backorder WPL WP4449743 $2.51

WP9755542 Whirlpool Oven Meat Probe In Stock WPL WP9755542 $58.23

WPW10256034 Whirlpool Burner Cap Backorder WPL WPW10256034 $73.85

13A

WPW10256032 Whirlpool Burner Cap Backorder WPL WPW10256032 $46.35

13B

WPW10364463 Whirlpool Burner Cap Backorder WPL WPW10364463 $28.05

9759721 Whirlpool Range Insulator Backorder WPL 9759721 $41.32

W10269192 Whirlpool Support Backorder WPL W10269192 $59.06

WPW10385583 Whirlpool Burner Valve Backorder WPL WPW10385583 $129.17

HANDLE, END CAP (LEFT) WPL W10226026 Contact Us For Availability

14A

W10226025 Whirlpool Handle Endcap Backorder WPL W10226025 $68.65

W11684564 Whirlpool Clip Assembly In Stock WPL W11684564 $4.48

WP9759229 Whirlpool Mounting Bracket Backorder WPL WP9759229 $63.73

WPW10131825 Whirlpool Oven Temperature Sensor In Stock WPL WPW10131825 $54.84

COVER, CHANNEL WPL W10618712 Contact Us For Availability

15A

W10775946 Whirlpool Door Gasket Backorder WPL W10775946 $53.86

4453115 Whirlpool Range Adapter Backorder WPL 4453115 $45.57

WP3196163 Whirlpool Screw In Stock WPL WP3196163 $2.51

WP4449154 Whirlpool Screw In Stock WPL WP4449154 $2.51

FRAME, FRONT WPL W10160895 Contact Us For Availability

W10276497 Whirlpool Drip Tray Backorder WPL W10276497 $189.27

WPW10116117 Whirlpool Range Membrane Switch Backorder WPL WPW10116117 $184.78

SCREW WPL 4449040 Contact Us For Availability

ASSEMBLY, DRAWER WPL W10235557 Contact Us For Availability

W10352969 Whirlpool Cooktop Assembly Backorder WPL W10352969 $135.65

W10570879 Whirlpool Range Rack Assembly Backorder WPL W10570879 $71.02

BRKT-MNTG Backorder WPL W10853036 $51.22

BRACKET, BURNER WPL W10560553 Contact Us For Availability

18A

W10352966 Whirlpool Cooktop Backorder WPL W10352966 $135.39

18B

W10352963 Whirlpool Cooktop Backorder WPL W10352963 $174.03

19

W10261523 Whirlpool Plate Backorder WPL W10261523 $27.12

19

WP3400015 Whirlpool Screw Backorder WPL WP3400015 $2.51

19A

WPW10256027 Whirlpool Burner Head Backorder WPL WPW10256027 $55.21

19B

WPW10282515 Whirlpool Burner Head Backorder WPL WPW10282515 $67.26

20

W10239444 Whirlpool Foam Seal Backorder WPL W10239444 $46.24

20

WPW10371235 Whirlpool Burner Valve Backorder WPL WPW10371235 $139.07

21

W10130760 Whirlpool Bracket Mounting Backorder WPL W10130760 $27.52

21

WP12990527 Whirlpool Microwave Screw In Stock WPL WP12990527 $2.51

21A

W10130759 Whirlpool Mounting Bracket Backorder WPL W10130759 $27.52

22

W10449141 Whirlpool Regulator Backorder WPL W10449141 $116.41

23

W10115715 Whirlpool Bracket Mounting Backorder WPL W10115715 $13.21

23

W10189177 Whirlpool Seal Switch Backorder WPL W10189177 $6.28

24

WP9759118 Whirlpool Mounting Plate Backorder WPL WP9759118 $31.49

25

WP9759117 Whirlpool Leveling Foot Backorder WPL WP9759117 $63.64

25

WPW10475147 Whirlpool Spark Module In Stock WPL WPW10475147 $145.85

25

SUPPORT, HANDLE WPL W10225964 Contact Us For Availability

27

W10061760 Whirlpool Screw In Stock WPL W10061760 $4.85

30

W10116151 Whirlpool Indicator Light Backorder WPL W10116151 $27.52

32

W10291193 Whirlpool Trim Top Backorder WPL W10291193 $57.11

34

WPW10116113 Whirlpool Infinite Switch Backorder WPL WPW10116113 $149.00

35

W10271524 Whirlpool Trim Top Backorder WPL W10271524 $88.85

37

W10625221 Whirlpool Module Backorder WPL W10625221 $722.92

38

WPW10298120-includeCORE Whirlpool WPW10298120 Backorder WPL WPW10298120-includeCORE $298.87

39

W10250476 Whirlpool Mounting Bracket Backorder WPL W10250476 $67.78

40

W10883622 Whirlpool Orifice Holder Backorder WPL W10883622 $41.25

41

W11676349 Whirlpool Screw Backorder WPL W11676349 $8.11

42

WPL 8286724 WPL 8286724 Contact Us For Availability

43

8286863 Whirlpool Oven Clip In Stock WPL 8286863 $26.21

44

8286930 Whirlpool Oven Gasket Backorder WPL 8286930 $32.57

46

4448520 Whirlpool Oven Bumper In Stock WPL 4448520 $10.76

4378577 Whirlpool Oven Bake Stone Backorder WPL 4378577 $36.58

4396096RB Whirlpool Griddle Backorder WPL 4396096RB $157.07

W10115777 Whirlpool Backsplash Backorder WPL W10115777 $208.56

W10116182 Whirlpool Wire Harness Backorder WPL W10116182 $59.82

W10123240 Whirlpool Broil Pan and Roasting Ra Backorder WPL W10123240 $72.40

W10160195 Whirlpool Cover Backorder WPL W10160195 $160.20

W10216179 Whirlpool Wok Ring In Stock WPL W10216179 $26.08

W10225948 Whirlpool Range Hood Tall Backsplas Backorder WPL W10225948 $709.67

W10280797 Whirlpool Gas Tubing Backorder WPL W10280797 $30.87

W10338986 Whirlpool Wire Harness Backorder WPL W10338986 $188.81

W10353141 Whirlpool Gas Tubing Assembly Backorder WPL W10353141 $62.12

W10353154 Whirlpool Gas Tubing Backorder WPL W10353154 $61.52

W10399621 Whirlpool Wire Harness Backorder WPL W10399621 $71.97

W10494088 Whirlpool Wire Harness Backorder WPL W10494088 $43.59

W10726866 Whirlpool Wire Harness Backorder WPL W10726866 $30.56

W10763503 Whirlpool Wire Harness Backorder WPL W10763503 $69.34

W11544575 Whirlpool Anti-Tip Bracket Backorder WPL W11544575 $19.47

W11675299 Whirlpool Tie Wire Backorder WPL W11675299 $7.72

WP3400968 Whirlpool Nut Backorder WPL WP3400968 $3.70

ACCESSORIES, CLEANER, COOKTOP WPL 31464 Contact Us For Availability

ACCESSORIES, APPLIANCE CLEANER WPL 31682 Contact Us For Availability
