Model Whirlpool KBRS19KTMS0 REFRIGERATOR – Common Parts &amp; Diagrams

1

13107539SQ Whirlpool Refrigerator DOR FIP Met Backorder WPL 13107539SQ $486.25

1

13107541SQ Whirlpool Refrigerator DOR-FIP MS Backorder WPL 13107541SQ $494.84

1

W10251970 Whirlpool Refrigerator Ladder Backorder WPL W10251970 $11.91

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $52.96

2

WPW10450021 Whirlpool Refrigerator Mat Backorder WPL WPW10450021 $32.34

3

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $9.68

3

W10273463 Whirlpool Refrigerator Ladder Backorder WPL W10273463 $11.38

3

W10480107 Whirlpool Refrigerator Plate Backorder WPL W10480107 $59.49

3

WP67003637 Whirlpool Dairy Door In Stock WPL WP67003637 $44.73

3

OVERLAY WPL W10207257 Contact Us For Availability

4

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $3.33

4

WP67001279 Whirlpool Refrigerator Dairy Tray Backorder WPL WP67001279 $48.97

5

W10802329 Whirlpool Refrigerator Shaft Backorder WPL W10802329 $43.52

5

WPW10371194 Whirlpool Refrigerator Door Shelf In Stock WPL WPW10371194 $44.12

6

W11402522 Whirlpool Refrigerator Glass Shelf Backorder WPL W11402522 $124.05

6

TUBE, DISCHARGE WPL W10217744 Contact Us For Availability

6

NAMEPLATE WPL W10046610 Contact Us For Availability

7

W11260592 Whirlpool Refrigerator Wire Harness Backorder WPL W11260592 $43.99

7

W11676571 Whirlpool Refrigerator FIP Gasket Backorder WPL W11676571 $83.93

7

WP67006642 Whirlpool Refrigerator Pin Backorder WPL WP67006642 $3.70

8

WPW10314517K Whirlpool Refrigerator Handle Backorder WPL WPW10314517K $120.76

9

W10829281 Whirlpool Refrigerator Screw In Stock WPL W10829281 $5.01

9

WPW10671238 Whirlpool Drawer Slide Rail In Stock WPL WPW10671238 $42.16

9

SCREW-HANDLE WPL W10290759 Contact Us For Availability

W11469652 Whirlpool Refrigerator Shield Backorder WPL W11469652 $10.76

WP12028505AP Whirlpool Closing Cam In Stock WPL WP12028505AP $43.13

WP12729127 Whirlpool Refrigerator Heater In Stock WPL WP12729127 $69.72

WP67005864 Whirlpool Humidity Control In Stock WPL WP67005864 $4.52

11

WPW10351081 Whirlpool Refrigerator Cantilever Backorder WPL WPW10351081 $46.23

12

WP2320150 Whirlpool Refrigerator Start Device In Stock WPL WP2320150 $68.25

13

67001139 Whirlpool Refrigerator Shelf Trim Backorder WPL 67001139 $55.48

13

WP12227302WD Whirlpool Refrigerator Shelf Sup Backorder WPL WP12227302WD $36.18

13

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $39.73

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $4.52

WP98165 Whirlpool Screw In Stock WPL WP98165 $2.51

WPW10231481 Whirlpool Refrigerator Shelf Trim In Stock WPL WPW10231481 $42.36

WPW10277025 Whirlpool Refrigerator Housing Backorder WPL WPW10277025 $54.90

W10833530 Whirlpool Refrigerator Crisper Pan Backorder WPL W10833530 $86.43

W11401472 Whirlpool Refrigerator Door Stop Backorder WPL W11401472 $10.76

W11689473 Whirlpool Door Hinge In Stock WPL W11689473 $26.41

WPW10196393 Whirlpool Control Damper In Stock WPL WPW10196393 $93.06

CLIP, EVAP. MOTOR WPL 13058002 Contact Us For Availability

16

WP67006113 Whirlpool Stud Bolt In Stock WPL WP67006113 $5.82

16

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $4.70

16

BASKET, FREEZER UPPER WPL W10169953 Contact Us For Availability

17

W11408990 Whirlpool Refrigerator Mat In Stock WPL W11408990 $31.77

17

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $3.70

W10241046 Whirlpool Refrigerator Divider Backorder WPL W10241046 $12.44

WP12566606ED Whirlpool Refrigerator Door Hing Backorder WPL WP12566606ED $16.98

WPW10280608 Whirlpool Refrigerator Bracket Backorder WPL WPW10280608 $36.87

WPW10280613 Whirlpool Refrigerator Bracket Backorder WPL WPW10280613 $36.87

19

W11658402 Whirlpool Drawer Slide Rail In Stock WPL W11658402 $75.69

20

A3189394 Whirlpool Refrigerator Gasket Backorder WPL A3189394 $10.76

20

W10503182 Whirlpool Refrigerator Freezer Bask Backorder WPL W10503182 $126.56

21

WPW10284684 Whirlpool Refrigerator Bracket In Stock WPL WPW10284684 $15.24

21

WPW10284685 Whirlpool Refrigerator Bracket In Stock WPL WPW10284685 $15.34

21

Divider, Lower Basket WPL W10205416 Contact Us For Availability

22

WP67006877 Whirlpool Refrigerator Glass Shelf Backorder WPL WP67006877 $119.79

23

WPW10671240 Whirlpool Refrigerator Frame In Stock WPL WPW10671240 $86.95

23

DAM (LIFT SIDE) WPL 12225602 Contact Us For Availability

W11613295 Whirlpool Condenser Motor In Stock WPL W11613295 $50.82

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $27.11

WPW10474715 Whirlpool Refrigerator Gear Backorder WPL WPW10474715 $10.96

WPW10474716 Whirlpool Refrigerator Gear Backorder WPL WPW10474716 $10.87

W10121318 Whirlpool Refrigerator Grommet In Stock WPL W10121318 $28.66

W10348259 Whirlpool Refrigerator Bracket Asse Backorder WPL W10348259 $31.90

W10348260 Whirlpool Refrigerator Bracket Backorder WPL W10348260 $31.90

W11673433 Whirlpool Clip Backorder WPL W11673433 $62.75

26

W10656984 Whirlpool Refrigerator Shelf Trim Backorder WPL W10656984 $29.21

26

WPW10128551 Whirlpool Evaporator Fan Motor In Stock WPL WPW10128551 $44.47

26

WPW10234024 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10234024 $176.20

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $15.50

27

SHAFT, RACK WPL 12812906WD Contact Us For Availability

28

W10210978 Whirlpool Refrigerator Back Cover Backorder WPL W10210978 $79.68

30

W10328331 Whirlpool Refrigerator Utility Pan Backorder WPL W10328331 $76.02

30

INSULATION, SOUND WPL 12820505 Contact Us For Availability

31

W11556315 Whirlpool Shroud In Stock WPL W11556315 $30.01

31

WP67001721 Whirlpool Refrigerator Support In Stock WPL WP67001721 $4.52

31

WP67001722 Whirlpool Refrigerator Support Backorder WPL WP67001722 $3.70

32

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $7.69

32

WP67001719 Whirlpool Refrigerator Track Backorder WPL WP67001719 $2.51

33

WP67001716 Whirlpool Refrigerator Shelf Suppo In Stock WPL WP67001716 $8.60

36

CLIP, EVAP (2) WPL 10623002 Contact Us For Availability

37

WPW10137529 Whirlpool Refrigerator Grommet Backorder WPL WPW10137529 $3.70

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $29.35

285006 Whirlpool Spray In Stock WPL 285006 $29.65

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.94

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $28.40

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $34.75

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

ICEMAKER In Stock WPL W11762633 $161.98

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.99

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.02

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

REFRIGERANT CHARGE (4.25 OZS. (R-134A)) WPL NP Contact Us For Availability

CLEANER, (STAINLESS STEEL) WPL 2217192 Contact Us For Availability

PAINT, BULK (1 QT.) (BISCUIT (UNCUT)) WPL 4392900 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability
