Model Whirlpool KBLS22KVSS3 REFRIGERATOR – Common Parts &amp; Diagrams

2

W10231483 Whirlpool Refrigerator Trim Shelf Backorder WPL W10231483 $43.59

2

W10856123 Whirlpool Refrigerator Gasket Backorder WPL W10856123 $3.70

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $52.96

2

BRACKET, CONTROL AND LIGHTS WPL 12806301 Contact Us For Availability

3

W10480110 Whirlpool Refrigerator Plate Backorder WPL W10480110 $67.60

3

OVERLAY WPL W10217736 Contact Us For Availability

4

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $3.33

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $7.69

4

W11416469 Whirlpool Refrigerator Housing Backorder WPL W11416469 $87.50

5

W11715937 Whirlpool Shaft Backorder WPL W11715937 $39.80

5

WPW10319823-includeCORE Whirlpool WPW10319823 Backorder WPL WPW10319823-includeCORE $200.45

5

WPW10503183 Whirlpool Refrigerator Basket Backorder WPL WPW10503183 $136.97

5

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $29.06

6

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $14.06

6

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $5.40

6

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $4.70

6

TUBE, DISCHARGE WPL W10217745 Contact Us For Availability

7

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $9.68

7

W10911102 Whirlpool Refrigerator Wire Harness Backorder WPL W10911102 $40.33

7

W11284721 Whirlpool Refrigerator Cover Backorder WPL W11284721 $38.12

7

WP67006642 Whirlpool Refrigerator Pin Backorder WPL WP67006642 $3.70

8

12806601 Whirlpool Refrigerator Light Housing Backorder WPL 12806601 $45.48

8

WPW10655367 Whirlpool Refrigerator Drip Pan In Stock WPL WPW10655367 $69.53

9

W10829281 Whirlpool Refrigerator Screw In Stock WPL W10829281 $5.01

9

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $3.71

10

W10241046 Whirlpool Refrigerator Divider Backorder WPL W10241046 $12.44

10

W11469652 Whirlpool Refrigerator Shield Backorder WPL W11469652 $10.76

10

WP12729128 Whirlpool Defrost Heater In Stock WPL WP12729128 $67.69

11

67003900 Whirlpool Refrigerator Insert Damper In Stock WPL 67003900 $4.52

11

W10308415 Whirlpool Refrigerator Evaporator C Backorder WPL W10308415 $109.42

11

W11661170 Whirlpool Clip Backorder WPL W11661170 $4.39

W11402523 Whirlpool Refrigerator Glass Shelf Backorder WPL W11402523 $124.05

WP400021-1 Whirlpool Screw In Stock WPL WP400021-1 $5.38

WPW10197426 Whirlpool Refrigerator Start Devi Backorder WPL WPW10197426 $60.91

Nameplate (Apollo Grey) WPL W10046610 Contact Us For Availability

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $39.73

WPW10137529 Whirlpool Refrigerator Grommet Backorder WPL WPW10137529 $3.70

WPW10330991 Whirlpool Refrigerator Bracket In Stock WPL WPW10330991 $42.30

WPW10330993 Whirlpool Refrigerator Bracket In Stock WPL WPW10330993 $59.75

Backorder WPL W11750607 $19.22

WPW10165425 Whirlpool Bimetal Defrost Thermos In Stock WPL WPW10165425 $32.98

WPW10277025 Whirlpool Refrigerator Housing Backorder WPL WPW10277025 $54.90

Retainer, Door WPL 12690502 Contact Us For Availability

WP12607104ED Whirlpool Refrigerator Door Hing Backorder WPL WP12607104ED $49.87

WP67005149 Whirlpool Roller In Stock WPL WP67005149 $10.76

WPW10594329 Whirlpool Control Damper In Stock WPL WPW10594329 $97.22

CLIP, EVAP. MOTOR WPL 13058002 Contact Us For Availability

16

W11396033 Whirlpool Refrigerator Rocker Switc In Stock WPL W11396033 $15.68

16

WP12566606ED Whirlpool Refrigerator Door Hing Backorder WPL WP12566606ED $16.98

16

Screw WPL 12992101 Contact Us For Availability

17

WP12227303WD Whirlpool Refrigerator Crisper B Backorder WPL WP12227303WD $44.45

17

WP98165 Whirlpool Screw In Stock WPL WP98165 $2.51

17

WPW10169124 Whirlpool Refrigerator Grommet In Stock WPL WPW10169124 $4.52

18

WPW10280608 Whirlpool Refrigerator Bracket Backorder WPL WPW10280608 $36.87

18

WPW10280613 Whirlpool Refrigerator Bracket Backorder WPL WPW10280613 $36.87

18

WPW10346420 Whirlpool Refrigerator Condenser In Stock WPL WPW10346420 $115.08

19

10547003 Whirlpool Refrigerator Dryer Clip Backorder WPL 10547003 $4.59

19

W11658402 Whirlpool Drawer Slide Rail In Stock WPL W11658402 $75.69

20

W10273463 Whirlpool Refrigerator Ladder Backorder WPL W10273463 $11.38

20

W11451451 Whirlpool Refrigerator Gasket Backorder WPL W11451451 $4.85

20

WPW10292802 Whirlpool Refrigerator Drip Tray In Stock WPL WPW10292802 $69.65

W10251969 Whirlpool Refrigerator Ladder Backorder WPL W10251969 $11.51

WP33001882 Whirlpool Screw In Stock WPL WP33001882 $27.52

WPW10284684 Whirlpool Refrigerator Bracket In Stock WPL WPW10284684 $15.24

WPW10284685 Whirlpool Refrigerator Bracket In Stock WPL WPW10284685 $15.34

22

12001919 Whirlpool Refrigerator Evaporator Re Backorder WPL 12001919 $194.96

22

WPW10175909 Whirlpool Grille Assembly In Stock WPL WPW10175909 $40.86

23

WPW10167023 Whirlpool Refrigerator Shroud Backorder WPL WPW10167023 $35.83

23

Dam (Left Side) WPL 12225602 Contact Us For Availability

23

Dam (Right Side) WPL 12225702 Contact Us For Availability

24

W11613295 Whirlpool Condenser Motor In Stock WPL W11613295 $50.82

24

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $27.11

25

W11673433 Whirlpool Clip Backorder WPL W11673433 $62.75

25

W11690160 Whirlpool Grommet Backorder WPL W11690160 $3.22

26

W11024089 Whirlpool Refrigerator Evaporator F In Stock WPL W11024089 $44.33

26

INSULATION, SOUND WPL 12820505 Contact Us For Availability

26

HARNESS, UNIT WITH POWER CORD WPL W10234026 Contact Us For Availability

W10815413 Whirlpool Refrigerator Funnel Backorder WPL W10815413 $29.08

W11684617 Whirlpool Valve Cover Backorder WPL W11684617 $7.41

WP12531601 Whirlpool Refrigerator Tunnel Backorder WPL WP12531601 $4.15

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $15.50

28

WPM0500703 Whirlpool Refrigerator O-Ring Seal Backorder WPL WPM0500703 $4.72

28

COMPRESSOR (INCLUDES ITEMS 11,12,17,27) WPL W10130129 Contact Us For Availability

29

WPB8381501 Whirlpool Refrigerator Door Gasket In Stock WPL WPB8381501 $4.52

29

Clip, Evaporator WPL 10623002 Contact Us For Availability

30

67006434 Whirlpool Axle Pin In Stock WPL 67006434 $3.70

31

W11556315 Whirlpool Shroud In Stock WPL W11556315 $30.01

31

WP67003924 Whirlpool Refrigerator Cover Backorder WPL WP67003924 $3.70

32

WP489474 Whirlpool Refrigerator Screw Backorder WPL WP489474 $2.75

32

BOX, HV CONTROL WPL W10257665 Contact Us For Availability

33

W11226688 Whirlpool Refrigerator Cover Backorder WPL W11226688 $31.81

34

W11448709 Whirlpool Refrigerator Bracket Backorder WPL W11448709 $11.69

34

GASKET, HV BOX WPL 12957801 Contact Us For Availability

35

W11489993 Whirlpool Refrigerator Rail In Stock WPL W11489993 $8.97

35

W11489994 Whirlpool Refrigerator Rail In Stock WPL W11489994 $8.97

35

WPW10317076-includeCORE Whirlpool WPW10317076 Backorder WPL WPW10317076-includeCORE $280.30

36

EXTENSION, BASEPAN WPL W10206337 Contact Us For Availability

37

W10206339 Whirlpool Fastener Backorder WPL W10206339 $4.70

38

12961602 Whirlpool Refrigerator Wire Cover Backorder WPL 12961602 $41.10

39

W11686675 Whirlpool Screw Backorder WPL W11686675 $8.11

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $29.35

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.94

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $28.40

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $15.46

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $34.75

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $35.65

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $37.30

ICEMAKER In Stock WPL W11762633 $161.98

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $41.14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $60.73

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $23.99

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $28.02

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (BLACK (UNCUT)) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

REFRIGERANT CHARGE (5.25 OZS. (R-134A)) WPL NP Contact Us For Availability

HARNESS, CONTROLS (REFRIGERATOR) (INCLUDES TH WPL W10224290 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability
