Model Whirlpool KBFO42FSX00 42`` BOTTOM MOUNT BUILT IN REFRIGERATOR – Common Parts &amp; Diagrams

1

Crisper Pan Assembly (Includes 2) (Right) WPL 2268171 Contact Us For Availability

1

Door, Refrigerator (Includes Item 2) (Right) WPL 2307902 Contact Us For Availability

1

Door, Refrigerator (Includes Item 2) (Left) WPL 2307903 Contact Us For Availability

1

Breaker Trim (Not Serviced) WPL ARI78242A7 Contact Us For Availability

1

Tube, Transition (Condenser) WPL 2309072 Contact Us For Availability

2

8201809 Whirlpool Refrigerator Door Gasket In Stock WPL 8201809 $119.28

2

W10388653 Whirlpool Refrigerator Tube Backorder WPL W10388653 $13.93

2

W10744329 Whirlpool Refrigerator Support Backorder WPL W10744329 $125.33

2

WP2221240 Whirlpool Refrigerator Heater In Stock WPL WP2221240 $67.89

2

Cabinet Trim, Right Side WPL 2317102S Contact Us For Availability

3

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

3

W10841139 Whirlpool Refrigerator Compressor In Stock WPL W10841139 $319.55

3

W11624204 Whirlpool Screw Backorder WPL W11624204 $9.59

3

W11673500 Whirlpool Door Hinge In Stock WPL W11673500 $61.63

3

WP1163283 Whirlpool Air Conditioner Screw Backorder WPL WP1163283 $2.51

4

2307944 Whirlpool Clip Backorder WPL 2307944 $7.61

4

Spacer-Hinge, Top WPL 2256381 Contact Us For Availability

4

Cabinet Trim, Bottom WPL 2307783 Contact Us For Availability

4

Housing, Control Board WPL 2307683 Contact Us For Availability

5

WP2303091 Whirlpool Refrigerator Electronic C Backorder WPL WP2303091 $153.06

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $4.61

5

Screw WPL W10061370 Contact Us For Availability

5

Bracket, Mounting WPL 2307945 Contact Us For Availability

6

2313961S Whirlpool Refrigerator Cabinet Trim Backorder WPL 2313961S $126.70

6

876811 Whirlpool Grommet Backorder WPL 876811 $3.70

6

Tube, Suction WPL 2309076 Contact Us For Availability

6

SPACER, HINGE (BOTTOM) WPL 2257647 Contact Us For Availability

7

2313999S Whirlpool Refrigerator Door Trim Backorder WPL 2313999S $78.90

7

2316752 Whirlpool Refrigerator Door Hinge Backorder WPL 2316752 $79.60

7

2316857 Whirlpool Refrigerator Slide Backorder WPL 2316857 $9.10

7

2316858 Whirlpool Refrigerator Slide Backorder WPL 2316858 $34.18

7

W10219166 Whirlpool Refrigerator Heater Backorder WPL W10219166 $67.04

7

Bottom Hinge Assembly (Right) WPL 2316751 Contact Us For Availability

7

Support, Condenser (Right) WPL 2309002 Contact Us For Availability

8

2207457 Whirlpool Refrigerator Door Trim Backorder WPL 2207457 $42.33

8

2313998S Whirlpool Refrigerator Door Trim Backorder WPL 2313998S $118.49

8

WP1106508 Whirlpool Refrigerator Gasket Backorder WPL WP1106508 $4.14

8

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $4.56

8

Transformer WPL 2303033 Contact Us For Availability

8

Cover, Hinge WPL 2005782 Contact Us For Availability

8

Scroll Assembly WPL 2306178 Contact Us For Availability

9

2215676 Whirlpool Refrigerator Terminal Cover Backorder WPL 2215676 $28.80

9

2309021S Whirlpool Refrigerator Cover Trim Backorder WPL 2309021S $29.43

9

2309216 Whirlpool Refrigerator Door Gasket In Stock WPL 2309216 $119.21

9

W11669856 Whirlpool Grommet Backorder WPL W11669856 $5.51

9

Seal, Side Trim WPL 2005925 Contact Us For Availability

9

Ice Pan Assembly (Includes 10) WPL 2306174 Contact Us For Availability

2309022S Whirlpool Refrigerator Trim Cover Backorder WPL 2309022S $42.11

SCREW WPL W10004850 Contact Us For Availability

Cover, Trim WPL 2309033S Contact Us For Availability

Cabinet Trim, Left Side WPL 2317103S Contact Us For Availability

Support, Condenser (Left) WPL 2309001 Contact Us For Availability

Motor, Fan WPL 2259385 Contact Us For Availability

2309213S Whirlpool Refrigerator Cover Trim Backorder WPL 2309213S $28.80

8201663 Whirlpool Refrigerator Primary Fan Bl Backorder WPL 8201663 $49.98

W10219462 Whirlpool Refrigerator Electronic C Backorder WPL W10219462 $210.88

Switch Assembly, Icemaker (Includes emitter) WPL 2268299 Contact Us For Availability

2309230 Whirlpool Refrigerator Clip Backorder WPL 2309230 $9.33

2309231 Whirlpool Refrigerator Clip Backorder WPL 2309231 $30.58

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

WP2203075 Whirlpool Refrigerator Spacer Backorder WPL WP2203075 $6.59

Cover, Wiring (Icemaker) WPL 2306187 Contact Us For Availability

2256328 Whirlpool Bracket Assembly Backorder WPL 2256328 $28.20

2309073 Whirlpool Refrigerator Tube Backorder WPL 2309073 $26.21

2314030S Whirlpool Refrigerator Door Trim Backorder WPL 2314030S $131.08

2314064 Whirlpool Refrigerator Drain Tube Backorder WPL 2314064 $28.80

2317005 Whirlpool HVAC Air Duct Backorder WPL 2317005 $170.40

2207470 Whirlpool Refrigerator Hinge Shim Backorder WPL 2207470 $29.41

2309031S Whirlpool Refrigerator Door Trim Backorder WPL 2309031S $193.37

2316899 Whirlpool Refrigerator Cover Backorder WPL 2316899 $4.50

520965 Whirlpool Refrigerator Support Backorder WPL 520965 $10.14

Defrost Bi-Metal WPL 2310137 Contact Us For Availability

Cover, Evaporator WPL 2306100 Contact Us For Availability

2314028S Whirlpool Refrigerator Door Trim Backorder WPL 2314028S $103.08

2317078 Whirlpool Cover Backorder WPL 2317078 $7.87

2317829 Whirlpool Refrigerator Cover Backorder WPL 2317829 $12.35

489348 Whirlpool Refrigerator Tube Clamp Backorder WPL 489348 $5.38

W10195924 Whirlpool Refrigerator Evaporator Backorder WPL W10195924 $178.53

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

2307998 Whirlpool Refrigerator Condenser In Stock WPL 2307998 $261.55

WP2006346 Whirlpool Refrigerator Washer In Stock WPL WP2006346 $4.59

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.51

Heater, Drain Pan WPL 2316878 Contact Us For Availability

Screw (4) WPL 3400235 Contact Us For Availability

2207415 Whirlpool Refrigerator Nut Backorder WPL 2207415 $9.59

2306106 Whirlpool Refrigerator Track Backorder WPL 2306106 $11.07

2309431 Whirlpool Grommet Backorder WPL 2309431 $8.31

2310136 Whirlpool Refrigerator Wire Harness In Stock WPL 2310136 $63.97

W11500952 Whirlpool Refrigerator Hinge Bushin Backorder WPL W11500952 $12.32

DIFFUSER, CRISPER (COMPLETE)(2) WPL 2268249 Contact Us For Availability

Screw, Door Stop WPL W10005070 Contact Us For Availability

Hanger, Heater WPL 2209450 Contact Us For Availability

2258903 Whirlpool Refrigerator Door Trim Backorder WPL 2258903 $87.01

2306116 Whirlpool Refrigerator Slide Backorder WPL 2306116 $122.91

2306117 Whirlpool Refrigerator Slide Backorder WPL 2306117 $110.88

W11218690 Whirlpool Refrigerator Door Hinge Backorder WPL W11218690 $26.55

WP2187629 Whirlpool Refrigerator Wire Jumper In Stock WPL WP2187629 $37.61

WP2196483 Whirlpool Refrigerator Shelf Stud Backorder WPL WP2196483 $4.34

WP8281250 Whirlpool Refrigerator Screw In Stock WPL WP8281250 $4.56

Shield, Drain Pan WPL 2005908 Contact Us For Availability

2215648 Whirlpool Refrigerator Dampener Backorder WPL 2215648 $7.78

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $3.70

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

Mullion Assembly WPL 2307938 Contact Us For Availability

20

W10323746 Whirlpool Refrigerator Cantilever B Backorder WPL W10323746 $54.08

20

Divider, Freezer Bins (Includes receiver) WPL 2317925 Contact Us For Availability

20

Shield, Water Filter WPL 2316603 Contact Us For Availability

2006617 Whirlpool Refrigerator Bracket Backorder WPL 2006617 $28.80

2302952 Whirlpool Refrigerator Slide Backorder WPL 2302952 $124.83

2302953 Whirlpool Refrigerator Slide Backorder WPL 2302953 $124.94

W10323598 Whirlpool Refrigerator Cantilever B Backorder WPL W10323598 $55.04

W10716209 Whirlpool Refrigerator Support Backorder WPL W10716209 $28.04

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

W11403572 Whirlpool Refrigerator Bracket In Stock WPL W11403572 $24.28

WP628356 Whirlpool Refrigerator Fill Cup In Stock WPL WP628356 $15.77

WPW10131132 Whirlpool Refrigerator Door Compr Backorder WPL WPW10131132 $40.92

SHIELD WPL 2317927 Contact Us For Availability

Bracket, Fan Motor WPL 2215641 Contact Us For Availability

Clip, Heater WPL 2317920 Contact Us For Availability

2222795 Whirlpool Refrigerator Rail Backorder WPL 2222795 $31.71

2302956 Whirlpool Refrigerator Slide Backorder WPL 2302956 $118.28

2302957 Whirlpool Refrigerator Slide Backorder WPL 2302957 $87.50

W10181323 Whirlpool Refrigerator Condenser Fa In Stock WPL W10181323 $165.56

WP2001264 Whirlpool Refrigerator Drip Pan In Stock WPL WP2001264 $88.94

WP2209022 Whirlpool Refrigerator Housing In Stock WPL WP2209022 $91.73

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

SUPPORT, SLIDE LEFT WPL 2306105 Contact Us For Availability

WP2004517 Whirlpool Refrigerator Spring In Stock WPL WP2004517 $30.85

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $26.81

WP2222981 Whirlpool Refrigerator Gasket Backorder WPL WP2222981 $88.67

Blade, Fan WPL 2190685 Contact Us For Availability

Bracket, Evaporator Cover (Right Side) WPL 2317893 Contact Us For Availability

Bracket, Evaporator Cover (Left Side) WPL 2320512 Contact Us For Availability

Bracket, Drain Pan (Left) WPL 1113206 Contact Us For Availability

Bracket, Drain Pan (Right) WPL 1113207 Contact Us For Availability

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $37.11

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

WPW10323035 Whirlpool Refrigerator Cantilever Backorder WPL WPW10323035 $44.03

Orifice, Fan WPL 2003169 Contact Us For Availability

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

WPW10323172 Whirlpool Refrigerator Retainer E Backorder WPL WPW10323172 $3.70

WPW10323173 Whirlpool Refrigerator Retainer E Backorder WPL WPW10323173 $3.70

Bracket, Air Return WPL 2320513 Contact Us For Availability

8281160 Whirlpool Screw Backorder WPL 8281160 $5.33

WP2316859 Whirlpool Refrigerator Bushing In Stock WPL WP2316859 $22.56

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $41.93

Clip, Thermistor WPL 2209204 Contact Us For Availability

Butter Tray WPL 2165792 Contact Us For Availability

1116793 Whirlpool Refrigerator Cover Backorder WPL 1116793 $8.53

2314031S Whirlpool Refrigerator Door Trim Backorder WPL 2314031S $102.21

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

WP2004994 Whirlpool Refrigerator Hinge Bushin Backorder WPL WP2004994 $3.70

BRACKET, VIBRATION (CONDENSER) WPL 2317031 Contact Us For Availability

29

WP2188820 Whirlpool Refrigerator Thermistor In Stock WPL WP2188820 $18.70

29

ARM, VIBRATION (CONDENSER) WPL 2317030 Contact Us For Availability

30

2307566 Whirlpool Refrigerator Tube Backorder WPL 2307566 $10.16

30

W10075920 Whirlpool Refrigerator Washer Backorder WPL W10075920 $5.38

30

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

31

W10528578 Whirlpool Refrigerator Tube Backorder WPL W10528578 $14.62

31

W11474472 Whirlpool Screw In Stock WPL W11474472 $2.51

31

Washer (EPDM) WPL 2320526 Contact Us For Availability

32

WP8533928 Whirlpool Refrigerator Screw In Stock WPL WP8533928 $2.51

32

SKIRT, GRILLE (BOTTOM) WPL 2209025B Contact Us For Availability

33

2314023 Whirlpool Bushing Backorder WPL 2314023 $25.73

33

Gasket, Air Deflector WPL 2317943 Contact Us For Availability

33

Cover, Condenser WPL 2309000 Contact Us For Availability

34

Service Cord WPL 2259197 Contact Us For Availability

35

W10185556 Whirlpool Refrigerator Bracket Backorder WPL W10185556 $43.13

36

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94

36

W10847927 Whirlpool Refrigerator Extension In Stock WPL W10847927 $35.81

36

W11298172 Whirlpool Refrigerator Extension Backorder WPL W11298172 $30.43

37

WP2266802 Whirlpool Refrigerator Switch In Stock WPL WP2266802 $30.80

38

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $4.56

39

WP2186494B Whirlpool Refrigerator Filter Cap In Stock WPL WP2186494B $25.25

39

Wiring Harness, Unit Compartment WPL 2310179 Contact Us For Availability

2309432 Whirlpool Seal Strip Backorder WPL 2309432 $28.80

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

W11721628 Whirlpool Screw Assembly Backorder WPL W11721628 $8.11

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

Following Parts Not Illustrated and Optional WPL ARI78245A7 Contact Us For Availability

REFRIGERANT CHARGE 6.25 oz. (R-134A) WPL ARI78246A7 Contact Us For Availability

41

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68
