Model GE JBS27DM1CC Electric Range – Common Parts &amp; Diagrams

1

WB62K10080 GE Range White Top Backorder GEN WB62K10080 $117.53

1

WB62K10085 GE Oven Cooktop Black Backorder GEN WB62K10085 $129.03

2

WB03T10282 GE Oven Infinite Control Knob (Whi In Stock GEN WB03T10282 $14.27

2

WB03T10285 GE Oven Infinite Control Knob Backorder GEN WB03T10285 $9.70

2

GEN WB03T10281 GEN WB03T10281 Contact Us For Availability

3

WB24T10025 GE Oven Infinite Switch In Stock GEN WB24T10025 $25.03

3

WB24T10029 GE Oven Infinite Burner Switch In Stock GEN WB24T10029 $31.16

5

WB25K10002 GE Stove Oven Cooktop Pilot Lamp In Stock GEN WB25K10002 $10.38

43

WB23X5340 GE Oven Heat Sensor Probe Assembly In Stock GEN WB23X5340 $125.79

117

WB02K10075 GE Oven Plastic Nail Backorder GEN WB02K10075 $5.20

128

WB27K10255 GE Oven Overlay T09 Backorder GEN WB27K10255 $60.82

128

WB27K10256 GE Oven Overlay T09 In Stock GEN WB27K10256 $60.82

128

GEN WB27K10266 GEN WB27K10266 Contact Us For Availability

153

WB02K10026 GE Oven Rod Support In Stock GEN WB02K10026 $5.97

154

WB31T10010 GE Oven 6" Chrome Burner Drip Bowl In Stock GEN WB31T10010 $8.11

154

WB31T10014 GE Oven 6-Inch Black Drip Bowl In Stock GEN WB31T10014 $6.72

158

WB31T10011 GE Oven 8" Chrome Drip Bowl Burner In Stock GEN WB31T10011 $10.39

158

WB31T10015 GE Oven 8-Inch Drip Bowl In Stock GEN WB31T10015 $8.44

203

WB17T10011 GE Oven Terminal Block In Stock GEN WB17T10011 $43.44

205

WB34K10029 GE Oven Guard Terminal Backorder GEN WB34K10029 $24.56

207

WB02K10029 GE Oven Mounting Terminal Bracket Backorder GEN WB02K10029 $6.55

208

GEN WB63K10005 GEN WB63K10005 Contact Us For Availability

226

GEN WB09K10001 GEN WB09K10001 Contact Us For Availability

230

WB08T10026 GE Range Push-In Receptacle In Stock GEN WB08T10026 $5.20

242

GEN WB63K10009 GEN WB63K10009 Contact Us For Availability

245

WB02X10521 GE Oven Leveling Leg In Stock GEN WB02X10521 $9.04

247

WB63K10021 GE Oven Top Backorder GEN WB63K10021 $43.85

251

WB38K10002 GE Oven Vent Tube Backorder GEN WB38K10002 $7.30

251

GEN WB04K10002 GEN WB04K10002 Contact Us For Availability

253

WB64K10009 GE Oven Cooktop Box Backorder GEN WB64K10009 $78.35

254

SUPPORT ASM RIVET GEN WB10K10009 Contact Us For Availability

254

SUPPORT ASM RIVET GEN WB10K10010 Contact Us For Availability

255

WB02K10158 GE Oven Drawer Support In Stock GEN WB02K10158 $5.20

260

GASKET OVEN SEAL GEN WB32K10037 Contact Us For Availability

261

WB35K10108 GE Oven Insulation Wrap Backorder GEN WB35K10108 $45.55

262

WB35K10107 GE Back Oven Insulation Backorder GEN WB35K10107 $23.11

290

WB30X46987 GE Bake Element In Stock GEN WB30X46987 $69.15

291

WB02K10028 GE Oven Broil Support In Stock GEN WB02K10028 $6.99

292

WB30X46986 GE Broil Element In Stock GEN WB30X46986 $67.93

296

GEN WB34K10095 GEN WB34K10095 Contact Us For Availability

300

GEN WB58K10007 GEN WB58K10007 Contact Us For Availability

314

GEN WB57K10120 GEN WB57K10120 Contact Us For Availability

314

GEN WB57K10121 GEN WB57K10121 Contact Us For Availability

314

GEN WB57K10122 GEN WB57K10122 Contact Us For Availability

315

GEN WB55K10043 GEN WB55K10043 Contact Us For Availability

317

WB36K10212 GE Top Door Trim (Bisque) Backorder GEN WB36K10212 $35.78

317

WB7K403 GE Oven Top Door Trim Backorder GEN WB7K403 $46.21

317

GEN WB07K0400 GEN WB07K0400 Contact Us For Availability

318

WB35X29720 GE Oven Door Gasket In Stock GEN WB35X29720 $13.47

320

WB02K10161 GE Oven Spacer Backorder GEN WB02K10161 $5.86

329

WB1X558D GE Oven Screw Package Backorder GEN WB1X558D $15.19

330

WB35K10041 GE Oven Reflector Backorder GEN WB35K10041 $9.46

332

WB35K10114 GE Oven Door Insulation Backorder GEN WB35K10114 $24.47

336

WB01K10073 GE Oven Screw 10-16 PL PNT 2.22S Backorder GEN WB01K10073 $5.20

338

WB56K5 GE Oven Crystal Wind Backorder GEN WB56K5 $105.67

339

WB56K10032 GE Oven Guard Insulation Assembly Backorder GEN WB56K10032 $41.16

343

WB02K10061 GE Oven Drawer Glide Backorder GEN WB02K10061 $5.20

343

WB02K10062 GE Oven Drawer Glide In Stock GEN WB02K10062 $5.20

344

GEN WB02K10025 GEN WB02K10025 Contact Us For Availability

345

WB34K10034 GE Oven Drawer Cover Backorder GEN WB34K10034 $47.95

353

WB1K67 GE Oven Screw 8-22 Backorder GEN WB1K67 $5.20

354

WB01K10024 GE Oven Mounting Endcap Screw (Bis Backorder GEN WB01K10024 $4.94

354

WB1K62 GE Oven Door Assembly Backorder GEN WB1K62 $5.20

354

WB1K66 GE Screw Backorder GEN WB1K66 $5.31

359

WB07K10232 GE Oven Bottom Trim Assembly Backorder GEN WB07K10232 $12.52

359

WB07K10250 GE Oven Door Trim Assembly Range S In Stock GEN WB07K10250 $12.26

359

WB07K10269 GE Oven Bottom Trim Assembly Backorder GEN WB07K10269 $11.13

365

WB15K10099 GE Oven Handle Backorder GEN WB15K10099 $52.65

365

WB15K10100 GE Oven Handle Backorder GEN WB15K10100 $52.65

365

WB15K10101 GE Oven Handle Backorder GEN WB15K10101 $60.98

WB07K10248 GE Oven Trim Post Left Backorder GEN WB07K10248 $15.34

GEN WB07K10253 GEN WB07K10253 Contact Us For Availability

GEN WB07K10249 GEN WB07K10249 Contact Us For Availability

GEN WB07K10254 GEN WB07K10254 Contact Us For Availability

GEN WB07K10272 GEN WB07K10272 Contact Us For Availability

GEN WB07K10273 GEN WB07K10273 Contact Us For Availability

WB7X7188 GE Oven Left Endcap Backorder GEN WB7X7188 $10.38

GEN WB07K10128 GEN WB07K10128 Contact Us For Availability

GEN WB07K10129 GEN WB07K10129 Contact Us For Availability

GEN WB07X7181 GEN WB07X7181 Contact Us For Availability

GEN WB07X7182 GEN WB07X7182 Contact Us For Availability

GEN WB07X7187 GEN WB07X7187 Contact Us For Availability

457

WB56X31457 GE Drawer Panel Bisque Backorder GEN WB56X31457 $32.90

457

WB56X31458 GE Black Drawer Panel Backorder GEN WB56X31458 $49.45

457

WB56X31459 GE Oven Drawer Front Backorder GEN WB56X31459 $51.24

710

WB02K10384 GE Oven Anti-Tip Bracket Assembly Backorder GEN WB02K10384 $9.50

721

WB1X536 GE Oven Screw Backorder GEN WB1X536 $6.35

741

WB02K10133 GE Oven Receptacle Clip In Stock GEN WB02K10133 $5.20

1000

WB04K10021 GE Oven Front Frame Gasket In Stock GEN WB04K10021 $37.57

1120

WB02K10178 GE Oven Bumper Backorder GEN WB02K10178 $5.20

1120

WB02K10179 GE Range Bumper Backorder GEN WB02K10179 $5.20
