GE JB620GF4SA Electric Range Parts List

1

TRIM & BRACKET ASM (WM) GEN WB07X24039 Contact Us For Availability

View on Model

15

COVER CONTROL GEN WB02T10532 Contact Us For Availability

View on Model

18

WB27T11511 GE Range Black Faceplate Graphics In Stock GEN WB27T11511 $13.27

View on Model

22

CONTROL INFINITE SWITCH GEN WB24T10029 Contact Us For Availability

View on Model

23

WB24T10146 GE Range Surface Element Control In Stock GEN WB24T10146 $25.75

View on Model

24

INF SW CONTROL (2500W) GEN WB24T10025 Contact Us For Availability

View on Model

32

WB27T10668 GE Range Light Indicator In Stock GEN WB27T10668 $7.12

View on Model

33

WB25K10010 GE Oven Light Indicator Pilot In Stock GEN WB25K10010 $8.27

View on Model

34

WB25X24023 GE Range Indicator Light Lens In Stock GEN WB25X24023 $4.11

View on Model

51

WB62X20907 GE Black Glass Maintop Assembly Backorder GEN WB62X20907 $572.65

View on Model

55

WB02T10589 GE Range Gray Nameplate Badge Backorder GEN WB02T10589 $7.94

View on Model

56

WB30T10145 GE Oven Radiant Surface Element In Stock GEN WB30T10145 $94.08

View on Model

57

WB30T10132 GE Oven Radiant Burner In Stock GEN WB30T10132 $44.80

View on Model

58

WB30T10136 GE Oven 8" Halogen Element In Stock GEN WB30T10136 $99.86

View on Model

60

BRACKET RADIANT ELEMENT GEN WB02X20902 Contact Us For Availability

View on Model

61

BRACKET RADIANT ELEMENT GEN WB02X20901 Contact Us For Availability

View on Model

64

BRACKET RADIANT ELEMENT GEN WB02T10609 Contact Us For Availability

View on Model

91

PIN RANGETOP HINGE GEN WB10T10116 Contact Us For Availability

View on Model

102

WB35T10114 GE Oven Door Insulation Backorder GEN WB35T10114 $5.20

View on Model

103

INSULATION DOOR GEN WB35T10255 Contact Us For Availability

View on Model

111

WB04T10086 GE Oven Door Gasket In Stock GEN WB04T10086 $37.09

View on Model

112

WB55T10200 GE Range Door Liner Assembly (GY) Backorder GEN WB55T10200 $91.37

View on Model

113

WB56T10178 GE Oven Door Insulation Retainer Backorder GEN WB56T10178 $76.78

View on Model

119

TRIM OVN DR BTTM GEN WB07T10462 Contact Us For Availability

View on Model

132

DOOR PAD GEN WB01T10026 Contact Us For Availability

View on Model

136

WB15T10213 GE Range Handle LE-BK Backorder GEN WB15T10213 $94.68

View on Model

140

WB56T10287 GE Oven Door Side Frame (Black) Backorder GEN WB56T10287 $14.04

View on Model

204

WB55T10178 GE Oven Mechanical Drawer Body Ass Backorder GEN WB55T10178 $109.72

View on Model

217

WB34T10128 GE Oven Back Cover Backorder GEN WB34T10128 $36.22

View on Model

229

WB35T10017 GE Oven Vent Tube Insulation Backorder GEN WB35T10017 $5.20

View on Model

231

WB35T10209 GE Range Insulation Backorder GEN WB35T10209 $63.30

View on Model

232

WB35T10113 GE Range Insulation Assembly Backorder GEN WB35T10113 $29.98

View on Model

241

WB48T10063 GE Range Rack In Stock GEN WB48T10063 $43.16

View on Model

242

WB48T10068 GE Oven Wedge Drawer Backorder GEN WB48T10068 $16.91

View on Model

249

GASKET OVEN LIGHT GEN WB02T10027 Contact Us For Availability

View on Model

251

UNIT BAKE AS GEN WB44T10011 Contact Us For Availability

View on Model

253

WB21X22134 GE Oven Sensor Assembly In Stock GEN WB21X22134 $14.04

View on Model

254

WB17T10011 GE Oven Terminal Block In Stock GEN WB17T10011 $44.65

View on Model

256

RECEPTACLE PUSH-IN GEN WB08T10026 Contact Us For Availability

View on Model

258

WB02T10037 GE Oven Light Cup Backorder GEN WB02T10037 $5.20

View on Model

268

WB02T10578 GE Oven Anti-Tip Bracket Assembly In Stock GEN WB02T10578 $21.72

View on Model

269

WB17T10021 GE Oven Mount Terminal Block Backorder GEN WB17T10021 $14.60

View on Model

272

SIDE PANEL SUPPORT GEN WB02T10034 Contact Us For Availability

View on Model

277

WB10T10068 GE Oven Hinge Receiver Backorder GEN WB10T10068 $25.95

View on Model

281

WB10T10071 GE Range Door Hinge Backorder GEN WB10T10071 $51.79

View on Model

293

DRAWER SUPPORT FRT GEN WB48T10013 Contact Us For Availability

View on Model

296

LEG LEVELER GEN WB02X10521 Contact Us For Availability

View on Model

600

LEAD WIRE 18 GA Y GEN WB18T10466 Contact Us For Availability

View on Model

602

LEAD WIRE 14 GA GN GEN WB18T10470 Contact Us For Availability

View on Model

605

HARNESS WIRE MAINTOP GEN WB18T10591 Contact Us For Availability

View on Model

696

WB01T10103 GE Oven Screw 10-16 AB HXW .532 Backorder GEN WB01T10103 $5.20

View on Model

761

WB1X5364 GE Oven Mounting Screw In Stock GEN WB1X5364 $5.20

View on Model

847

WB02T10324 GE Oven Screw 6-20 GXB IHXW 3/8 NI Backorder GEN WB02T10324 $5.20

View on Model

919

SPACER GEN WB02T10175 Contact Us For Availability

View on Model

929

WB02T10026 GE Oven Strike Maintop Backorder GEN WB02T10026 $5.20

View on Model

1002

WB01T10017 GE Oven 8-18 AB Screw IHW 3/8 S NS Backorder GEN WB01T10017 $5.20

View on Model

1003

WB01T10067 GE Range Screw 10-16 PL PNT Backorder GEN WB01T10067 $5.20

View on Model

1005

SCREW 10-32 TR T GEN WB01T10008 Contact Us For Availability

View on Model

1006

SCR 8-32 TT FLP .270 GEN WB01X23501 Contact Us For Availability

View on Model
