Model Whirlpool GX5FHTXVY03 REFRIGERATOR – Common Parts &amp; Diagrams

1

LINER (NOT A SERVICEABLE PART) WPL NP Contact Us For Availability

2

W10856123 Whirlpool Refrigerator Gasket Backorder WPL W10856123 $3.70

2

W11120581 Whirlpool Refrigerator Water Tube Backorder WPL W11120581 $43.54

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $35.43

2

TRIM, CRISPER WPL W10231508 Contact Us For Availability

2

MODULE, LIGHT WPL 12806302 Contact Us For Availability

3

W11173556 Whirlpool Refrigerator Shaft Backorder WPL W11173556 $10.87

3

W11448709 Whirlpool Refrigerator Bracket Backorder WPL W11448709 $11.69

3

WPW10180451 Whirlpool Refrigerator Overlay Backorder WPL WPW10180451 $31.16

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $7.69

4

WP12806407 Whirlpool Refrigerator Housing Backorder WPL WP12806407 $39.95

5

W10208593 Whirlpool Refrigerator Valve Cover Backorder WPL W10208593 $9.24

5

WP12544124 Whirlpool Refrigerator Valve In Stock WPL WP12544124 $109.42

5

WPW10128551 Whirlpool Evaporator Fan Motor In Stock WPL WPW10128551 $43.65

5

WPW10503278 Whirlpool Refrigerator Electronic In Stock WPL WPW10503278 $118.83

5

Basket, Freezer (Lower) WPL W10150039 Contact Us For Availability

6

W11285509 Whirlpool Refrigerator Shut-Off Arm Backorder WPL W11285509 $50.05

6

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

6

WP12722803AP Whirlpool Refrigerator Mullion R In Stock WPL WP12722803AP $100.73

6

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $3.70

6

WPW10233569 Whirlpool Refrigerator Tube Backorder WPL WPW10233569 $43.19

7

W11284721 Whirlpool Refrigerator Cover Backorder WPL W11284721 $36.31

7

W11592375 Whirlpool Door Hinge Backorder WPL W11592375 $10.07

8

12806601 Whirlpool Refrigerator Light Housing Backorder WPL 12806601 $43.32

8

WP67003924 Whirlpool Refrigerator Cover Backorder WPL WP67003924 $3.70

9

W10241046 Whirlpool Refrigerator Divider Backorder WPL W10241046 $12.44

9

W10829281 Whirlpool Refrigerator Screw Backorder WPL W10829281 $5.01

9

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $2.75

W10825088 Whirlpool Refrigerator Defrost Heat In Stock WPL W10825088 $76.49

W10847995 Whirlpool Divider Assembly Backorder WPL W10847995 $28.80

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $4.58

W11469652 Whirlpool Refrigerator Shield Backorder WPL W11469652 $10.76

67003900 Whirlpool Refrigerator Insert Damper In Stock WPL 67003900 $3.70

W11661170 Whirlpool Clip Backorder WPL W11661170 $4.39

W11727809 Whirlpool Evaporator Cover Backorder WPL W11727809 $32.79

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $28.80

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $2.51

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $26.81

WP400021-1 Whirlpool Screw In Stock WPL WP400021-1 $4.56

WPW10194431 Whirlpool Start Device In Stock WPL WPW10194431 $58.28

Nameplate WPL 2220214 Contact Us For Availability

12726003 Whirlpool Refrigerator Water Cover Backorder WPL 12726003 $7.16

W10121318 Whirlpool Refrigerator Grommet Backorder WPL W10121318 $27.29

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $37.84

WP12992902 Whirlpool Refrigerator Screw Backorder WPL WP12992902 $4.58

14

Backorder WPL W11750607 $18.30

14

WPW10277025 Whirlpool Refrigerator Housing Backorder WPL WPW10277025 $52.87

W10917988 Whirlpool Refrigerator Door Hinge Backorder WPL W10917988 $35.52

WP12028505AP Whirlpool Closing Cam In Stock WPL WP12028505AP $29.12

WPW10196393 Whirlpool Control Damper In Stock WPL WPW10196393 $74.68

CLIP, EVAP. MOTOR WPL 13058002 Contact Us For Availability

16

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.59

16

W11396033 Whirlpool Refrigerator Rocker Switc In Stock WPL W11396033 $14.15

16

W11592374 Whirlpool Refrigerator Top Door Hin Backorder WPL W11592374 $10.07

W11478401 Whirlpool Refrigerator Housing Backorder WPL W11478401 $83.33

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $3.70

WP12642303WD Whirlpool Refrigerator Drawer Su Backorder WPL WP12642303WD $43.11

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

18

W10815413 Whirlpool Refrigerator Funnel Backorder WPL W10815413 $27.69

18

WP13005401SP Whirlpool Can Rack In Stock WPL WP13005401SP $31.40

18

WP2300868 Whirlpool Refrigerator Fitting In Stock WPL WP2300868 $9.90

19

W11229977 Whirlpool Refrigerator Reservoir In Stock WPL W11229977 $59.89

19

WPM0500703 Whirlpool Refrigerator O-Ring Seal Backorder WPL WPM0500703 $4.72

19

WPW10169346 Whirlpool Refrigerator Beverage H Backorder WPL WPW10169346 $207.93

20

W10273463 Whirlpool Refrigerator Ladder Backorder WPL W10273463 $10.83

20

W11159728 Whirlpool Refrigerator Gasket In Stock WPL W11159728 $10.10

W10251969 Whirlpool Refrigerator Ladder Backorder WPL W10251969 $11.51

W11395888 Whirlpool Refrigerator Bypass Filte In Stock WPL W11395888 $24.32

WPB8381501 Whirlpool Refrigerator Door Gasket In Stock WPL WPB8381501 $3.70

WPW10211855 Whirlpool Refrigerator Back Cover Backorder WPL WPW10211855 $76.82

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $4.56

W10171558 Whirlpool Refrigerator Divider Backorder WPL W10171558 $27.72

WP67001668 Whirlpool Water Filter Housing In Stock WPL WP67001668 $6.31

WPW10175909 Whirlpool Grille Assembly In Stock WPL WPW10175909 $28.97

W11346623 Whirlpool Refrigerator Water Filter In Stock WPL W11346623 $55.58

WP13062602 Whirlpool Refrigerator Support Backorder WPL WP13062602 $28.80

WPW10167023 Whirlpool Refrigerator Shroud Backorder WPL WPW10167023 $34.13

Dam (Left Side) WPL 12225602 Contact Us For Availability

24

12918001 Whirlpool Refrigerator Funnel Backorder WPL 12918001 $7.69

24

WP12568001 Whirlpool Filter Cover In Stock WPL WP12568001 $44.58

24

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

W11673433 Whirlpool Clip Backorder WPL W11673433 $59.77

WP12575501 Whirlpool Refrigerator Micro Switc Backorder WPL WP12575501 $27.82

WPW10171529 Whirlpool Refrigerator Ice Pan In Stock WPL WPW10171529 $56.82

WPW10330991 Whirlpool Refrigerator Bracket In Stock WPL WPW10330991 $42.00

WPW10330993 Whirlpool Refrigerator Bracket Backorder WPL WPW10330993 $56.13

26

12831101 Whirlpool Refrigerator Tube Clamp Backorder WPL 12831101 $7.69

26

WP98165 Whirlpool Screw Backorder WPL WP98165 $2.51

26

Fiber, Acoustic WPL 12820505 Contact Us For Availability

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $13.98

27

WPW10280608 Whirlpool Refrigerator Bracket Backorder WPL WPW10280608 $35.12

27

WPW10280613 Whirlpool Refrigerator Bracket Backorder WPL WPW10280613 $35.12

28

W11658402 Whirlpool Drawer Slide Rail In Stock WPL W11658402 $74.88

29

W10348260 Whirlpool Refrigerator Bracket Backorder WPL W10348260 $30.38

29

WPW10284684 Whirlpool Refrigerator Bracket In Stock WPL WPW10284684 $14.42

29

WPW10284685 Whirlpool Refrigerator Bracket In Stock WPL WPW10284685 $14.51

30

W10348259 Whirlpool Refrigerator Bracket Asse Backorder WPL W10348259 $30.38

30

WP489474 Whirlpool Refrigerator Screw Backorder WPL WP489474 $2.75

12999501 Whirlpool Refrigerator Hinge Shim In Stock WPL 12999501 $33.89

12999502 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999502 $34.28

W10149389 Whirlpool Refrigerator Handle Backorder WPL W10149389 $28.80

W11028221 Whirlpool Refrigerator Shaft In Stock WPL W11028221 $11.31

W11556315 Whirlpool Shroud Backorder WPL W11556315 $27.80

32

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $8.86

32

WPW10474716 Whirlpool Refrigerator Gear Backorder WPL WPW10474716 $10.87

33

67002002 Whirlpool Refrigerator Pantry Slide Backorder WPL 67002002 $9.81

33

W11489993 Whirlpool Refrigerator Rail In Stock WPL W11489993 $8.14

33

W11489994 Whirlpool Refrigerator Rail In Stock WPL W11489994 $8.14

34

12531402 Whirlpool Refrigerator Bar Backorder WPL 12531402 $7.83

34

W10157765 Whirlpool Refrigerator Deflector Backorder WPL W10157765 $28.80

34

WP12777701 Whirlpool Refrigerator Filler Bloc Backorder WPL WP12777701 $4.15

35

WP12531601 Whirlpool Refrigerator Tunnel Backorder WPL WP12531601 $4.15

36

GASKET, PANTRY WPL 12531701 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP12868601 Whirlpool Refrigerator Wire Harnes Backorder WPL WP12868601 $48.29

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability
