Model Whirlpool G32026PEKS5 REFRIGERATOR – Common Parts &amp; Diagrams

1

W11125512 Whirlpool Refrigerator Glass Shelf Backorder WPL W11125512 $147.11

1

DOOR, LEFT (STAINLESS) WPL 13024077SQ Contact Us For Availability

1

Owners Manual WPL 12828189SP Contact Us For Availability

1

TECH SHEET WPL W10239995 Contact Us For Availability

2

WP12463911 Whirlpool Refrigerator Glass Shelf Backorder WPL WP12463911 $138.51

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $40.95

2

BRACKET, CONTROL AND LIGHTS WPL 12806302 Contact Us For Availability

2

DOOR, RIGHT (STAINLESS) WPL 13024075SQ Contact Us For Availability

3

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $9.20

3

WP67003405 Whirlpool Pivot Block In Stock WPL WP67003405 $4.03

3

WP67003637 Whirlpool Dairy Door Backorder WPL WP67003637 $48.32

3

KEYBOARD WPL 12816517 Contact Us For Availability

3

Screw WPL 12990601 Contact Us For Availability

4

B5759655 Whirlpool Refrigerator Gasket Backorder WPL B5759655 $7.98

4

W11812285 Whirlpool Support Backorder WPL W11812285 $22.76

4

WP67001279 Whirlpool Refrigerator Dairy Tray Backorder WPL WP67001279 $53.90

4

WPW10464769 Whirlpool Refrigerator Housing Backorder WPL WPW10464769 $42.75

5

W11028221 Whirlpool Refrigerator Shaft In Stock WPL W11028221 $11.74

5

WP12227305WD Whirlpool Drawer Support Backorder WPL WP12227305WD $49.48

5

WP12566606ED Whirlpool Refrigerator Door Hing Backorder WPL WP12566606ED $18.70

5

WPW10324005 Whirlpool Refrigerator Cantilever Backorder WPL WPW10324005 $47.46

5

WPW10708492-includeCORE Whirlpool WPW10708492 Backorder WPL WPW10708492-includeCORE $216.69

6

A3076901 Whirlpool Refrigerator Plug Backorder WPL A3076901 $5.74

6

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $16.36

6

WP67001719 Whirlpool Refrigerator Track Backorder WPL WP67001719 $2.60

6

MULLION, DOOR (BLACK) WPL 12722811BKV Contact Us For Availability

7

67001656 Whirlpool Refrigerator Bottle Trivet Backorder WPL 67001656 $35.00

7

W11284721 Whirlpool Refrigerator Cover Backorder WPL W11284721 $41.95

7

W11311945 Whirlpool Refrigerator Screw Backorder WPL W11311945 $9.96

8

12806601 Whirlpool Refrigerator Light Housing Backorder WPL 12806601 $50.05

8

W11368721 Whirlpool Refrigerator French Door In Stock WPL W11368721 $119.82

8

Divider, Upper Basket WPL 12693802 Contact Us For Availability

9

67002329 Whirlpool Refrigerator Pantry Gasket Backorder WPL 67002329 $11.17

9

WP67002552 Whirlpool Refrigerator Light Bulb In Stock WPL WP67002552 $6.65

9

WP8281196 Whirlpool Screw Backorder WPL WP8281196 $3.84

9

HANDLE, DOOR (STAINLESS) WPL 12850919 Contact Us For Availability

10

12656202 Whirlpool Refrigerator Housing Backorder WPL 12656202 $60.35

10

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $4.75

10

WP67001098 Whirlpool Refrigerator Tube Cover Backorder WPL WP67001098 $3.84

11

67003900 Whirlpool Refrigerator Insert Damper Backorder WPL 67003900 $3.84

11

W11573362 Whirlpool Screw Assembly Backorder WPL W11573362 $9.96

11

W11708403 Whirlpool Door Stop Backorder WPL W11708403 $5.26

12

W11772394 Whirlpool Screw In Stock WPL W11772394 $8.02

12

WP67003793 Whirlpool Refrigerator Temperature Backorder WPL WP67003793 $31.16

12

Nameplate WPL 61002504 Contact Us For Availability

13

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $43.72

13

MOUNT, HANDLE WPL 12945201 Contact Us For Availability

13

Cover, Left Hinge (Black) WPL 12684201B Contact Us For Availability

14

W11750607 Whirlpool Insulation Backorder WPL W11750607 $21.15

14

WP489349 Whirlpool Refrigerator Screw In Stock WPL WP489349 $2.60

14

WPW10235370 Whirlpool Refrigerator Glide Backorder WPL WPW10235370 $125.32

15

W10918168 Whirlpool Refrigerator Door Hinge Backorder WPL W10918168 $31.90

15

WP67003639 Whirlpool Refrigerator Closer In Stock WPL WP67003639 $32.15

15

Control, Damper (Incl. Harness) WPL W10177399 Contact Us For Availability

16

WP12656018 Whirlpool Drawer Support In Stock WPL WP12656018 $32.60

16

WP12656105 Whirlpool Drawer Support In Stock WPL WP12656105 $35.70

16

WPW10289494 Whirlpool Refrigerator Cantilever Backorder WPL WPW10289494 $53.56

17

67003485 Whirlpool Refrigerator Corner Cover Backorder WPL 67003485 $11.17

17

WP67002659 Whirlpool Crisper Pan In Stock WPL WP67002659 $78.00

WP12227304WD Whirlpool Refrigerator Drawer Su Backorder WPL WP12227304WD $49.86

WP12566607ED Whirlpool Refrigerator Door Hing Backorder WPL WP12566607ED $34.01

WPW10281115 Whirlpool Refrigerator Bracket Backorder WPL WPW10281115 $30.59

WPW10281116 Whirlpool Bracket Backorder WPL WPW10281116 $30.59

W11658403 Whirlpool Slides In Stock WPL W11658403 $86.57

ROLLER-CAB In Stock WPL W11820444 $15.94

ROLLER-CAB In Stock WPL W11820445 $15.94

TRIM, CRISPER WPL W10231346 Contact Us For Availability

20

67006564 Whirlpool Refrigerator Screw Backorder WPL 67006564 $2.60

20

WP67006185 Whirlpool Refrigerator Crisper Fra Backorder WPL WP67006185 $118.51

21

WP67006655 Whirlpool Refrigerator Crisper Gla Backorder WPL WP67006655 $131.17

21

Shim, Hinge WPL 12579702 Contact Us For Availability

22

W10273463 Whirlpool Refrigerator Ladder Backorder WPL W10273463 $11.82

22

WPW10534153 Whirlpool Refrigerator Black Kick In Stock WPL WPW10534153 $64.01

23

W10251971 Whirlpool Ladder Assembly Backorder WPL W10251971 $38.87

23

DAM (LEFT SIDE) WPL 12225602 Contact Us For Availability

24

W10918164 Whirlpool Refrigerator Door Hinge Backorder WPL W10918164 $54.13

24

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $14.17

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $2.60

W10121318 Whirlpool Refrigerator Grommet Backorder WPL W10121318 $31.54

W10709795 Whirlpool Refrigerator Screw Backorder WPL W10709795 $8.11

W11673433 Whirlpool Clip Backorder WPL W11673433 $69.09

26

W10234312 Whirlpool Wire Harness Backorder WPL W10234312 $186.86

26

WP67006415 Whirlpool Refrigerator Screw In Stock WPL WP67006415 $3.84

27

W11684617 Whirlpool Valve Cover Backorder WPL W11684617 $7.70

27

WP67005864 Whirlpool Humidity Control In Stock WPL WP67005864 $3.84

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $15.24

28

67003794 Whirlpool Refrigerator Temperature C Backorder WPL 67003794 $8.40

28

W10183407 Whirlpool Refrigerator Compressor Backorder WPL W10183407 $345.09

28

WP7101P126-60 Whirlpool Screw Backorder WPL WP7101P126-60 $2.60

29

W11490183 Whirlpool Refrigerator Utility Pan Backorder WPL W11490183 $84.17

29

CLIP, EVAPORATOR WPL 10623002 Contact Us For Availability

12002355 Whirlpool Refrigerator Thermistor Ki In Stock WPL 12002355 $27.89

67006434 Whirlpool Axle Pin Backorder WPL 67006434 $3.84

W11498983 Whirlpool Refrigerator Knob Backorder WPL W11498983 $11.57

COVER, UNIT WPL W10212203 Contact Us For Availability

31

W10619951 Whirlpool Drain Tube with Grommet In Stock WPL W10619951 $22.05

31

W10827015 Whirlpool Refrigerator Pantry Drawe In Stock WPL W10827015 $120.38

31

SHROUD WPL W10189187 Contact Us For Availability

32

EXTENSION-BASEPAN WPL W10225121 Contact Us For Availability

32

BASKET, FREEZER (LOWER) WPL 13016004 Contact Us For Availability

33

W10206339 Whirlpool Fastener Backorder WPL W10206339 $4.88

33

Insulation, Sound WPL 12820505 Contact Us For Availability

33

DIVIDER, LOWER BASKET WPL 12659606 Contact Us For Availability

34

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $4.03

34

BASKET, FREEZER (UPPER) WPL 12896404 Contact Us For Availability

35

WP67002321 Whirlpool Refrigerator Divider Pan Backorder WPL WP67002321 $18.20

35

Cover, Right Hinge (Black) WPL 12684202B Contact Us For Availability

36

WP98165 Whirlpool Screw In Stock WPL WP98165 $2.60

36

CABINET (NOT A SERVICABLE PART) WPL NP Contact Us For Availability

39

RACK, ICE TRAY WPL 12646501 Contact Us For Availability

41

WP67006908 Whirlpool Refrigerator Screw Backorder WPL WP67006908 $2.60

42

WP841180A Whirlpool Microwave Glass Turntable In Stock WPL WP841180A $22.80

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $31.41

285006 Whirlpool Spray In Stock WPL 285006 $46.08

350930 Whirlpool White Spray Paint In Stock WPL 350930 $22.23

350942 Whirlpool Spray Paint Backorder WPL 350942 $52.25

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $30.29

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $10.93

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $10.93

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.84

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $110.98

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $23.44

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $37.34

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $39.24

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $41.04

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $45.28

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $66.85

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $25.50

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $29.93

Valve, Access (5/8``) WPL 978029 Contact Us For Availability

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

REFINISHING MATERIAL (ENAMEL, WHITE (1 QT. UN WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

Valve, Access (1/2``) WPL 978028 Contact Us For Availability

Harness, Control (Refrigerator) WPL 12973603 Contact Us For Availability

Cleaner, Stnls Steel Magic WPL 20000008 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

Refinishing Material (Enamel, Black (1 Qt. Un WPL 799340 Contact Us For Availability

Kit, Evaporator Repair (Aluminum Epoxy) WPL 799833 Contact Us For Availability

ICE MAKER FIELD INSTALLABLE (IC514) WPL W10261455 Contact Us For Availability
