Model Electrolux FGBD2445NQ5A DISHWASHER – Common Parts &amp; Diagrams

1

154825001 Frigidaire Dishwasher Round Heater In Stock WCI 154825001 $57.73

1

5304533200 Frigidaire Dishwasher Rack with Wh In Stock WCI 5304533200 $90.02

1

TUB ASSY, W/FRAME PARTS, DARK GREY, DF WCI 154729403 Contact Us For Availability

1A

154756401 Frigidaire Hinge Cable In Stock WCI 154756401 $2.33

2

154093301 Frigidaire Dishwasher ARM Assembly In Stock WCI 154093301 $1.33

2

154465101 Frigidaire Dishwasher Heating Eleme Backorder WCI 154465101 $7.13

2

5304532796 Frigidaire Dishwasher Strike In Stock WCI 5304532796 $7.11

3

154827601 Frigidaire Dishwasher Tub Gasket In Stock WCI 154827601 $17.86

3

5304535250 Frigidaire Dishwasher Upper Rack A In Stock WCI 5304535250 $79.52

3

807024601 Frigidaire Dishwasher Electrical Co Backorder WCI 807024601 $160.96

3

807047901 Frigidaire Dishwasher Inlet Water V In Stock WCI 807047901 $37.92

3A

5304513274 Frigidaire Dishwasher Counterbalan In Stock WCI 5304513274 $42.32

4

154718801 Frigidaire Dishwasher Cover Backorder WCI 154718801 $20.05

4

5304508587 Frigidaire Dishwasher Brace Backorder WCI 5304508587 $17.83

4

5304535381 Frigidaire Dishwasher Dishrack Whe In Stock WCI 5304535381 $1.91

4

808326801 Frigidaire Dishwasher Screw Backorder WCI 808326801 $1.76

5

5304506510 Frigidaire Dishrack Slide Rail Sto In Stock WCI 5304506510 $4.44

5

5304506916 Frigidaire Dishwasher Assembly-Rol In Stock WCI 5304506916 $10.70

5

DISPLAY BOARD, 7 SEGMENT WCI 154734301 Contact Us For Availability

6

154597801 Frigidaire Dishwasher Upper Rack Sl In Stock WCI 154597801 $5.58

6

5303943103 Frigidaire Dishwasher P-1 Screw Ki Backorder WCI 5303943103 $11.13

7

5304532229 Frigidaire Dishwasher Lower Rack W In Stock WCI 5304532229 $3.13

7

LINER, DOOR ASSEMBLY, DARK GREY, COMPLETE WCI 154743504 Contact Us For Availability

9

5304506521 Frigidaire Dishwasher Dispenser In Stock WCI 5304506521 $55.55

10

154103702 Frigidaire Dishwasher Screw Backorder WCI 154103702 $8.46

10

154294701 Frigidaire Dishwasher Screw Backorder WCI 154294701 $5.77

10

154724001 Frigidaire Lower Arm Support In Stock WCI 154724001 $6.22

11

154200701 Frigidaire Dishwasher Screw Backorder WCI 154200701 $8.46

11

154579201 Frigidaire Dishwasher Pulley Backorder WCI 154579201 $29.85

11

5304532945 Frigidaire Cup Shelf Backorder WCI 5304532945 $4.55

11A

154579202 Frigidaire Dishwasher Pulley Backorder WCI 154579202 $29.87

12

5304525218 Frigidaire Door Latch Assembly In Stock WCI 5304525218 $23.97

13

154246801 Frigidaire Dishwasher Primary Gaske Backorder WCI 154246801 $30.29

13

DUCT ASSEMBLY, VENT, W/TAPE WCI 154755801 Contact Us For Availability

13A

154740304 Frigidaire Dishwasher Fold-Down Tin In Stock WCI 154740304 $20.50

13B

5304506535 Frigidaire Dishwasher Fence In Stock WCI 5304506535 $14.70

14

154723801 Frigidaire Dishwasher SUMP Assembly In Stock WCI 154723801 $37.92

14

VENT ASSY, DRY, W/GASKETS WCI 154784401 Contact Us For Availability

14A

5304506508 Frigidaire Bracket Support In Stock WCI 5304506508 $3.53

15

5304506540 Frigidaire Dishwasher Leg Assembly In Stock WCI 5304506540 $6.68

16

154246502 Frigidaire Dishwasher Bracket In Stock WCI 154246502 $25.38

20

154758501 Frigidaire Power Cord Cover Backorder WCI 154758501 $12.46

20

5304506509 Frigidaire Dishwasher Handle Backorder WCI 5304506509 $8.44

20

DOOR ASSEMBLY, W/INSULLATION, BISQUE WCI 154874704 Contact Us For Availability

21

154754701 Frigidaire Dishwasher Screw Backorder WCI 154754701 $2.22

21

5304504913 Frigidaire Dishwasher Handle Backorder WCI 5304504913 $8.46

22

5304523457 Frigidaire Inlet Hose In Stock WCI 5304523457 $8.02

23

5304538466 Frigidaire Hose Clamp Backorder WCI 5304538466 $0.91

24

5304507158 Frigidaire Dishwasher Lower Wash A In Stock WCI 5304507158 $44.97

24

807117001 Frigidaire Dishwasher Drain Hose In Stock WCI 807117001 $21.14

24A

5304506740 Frigidaire Dishwasher Spray Arm Ce In Stock WCI 5304506740 $24.57

24B

5304506516 Frigidaire Dishwasher Upper Spray In Stock WCI 5304506516 $14.24

25

5304506520 Frigidaire Dishwasher Float Assemb In Stock WCI 5304506520 $8.00

28

154773201 Frigidaire Dishwasher Switch Assemb In Stock WCI 154773201 $34.76

29

5304525221 Frigidaire Dishwasher Thermostat In Stock WCI 5304525221 $10.22

30

154241101 Frigidaire Dishwasher Retainer Backorder WCI 154241101 $2.22

30

5304532268 Frigidaire Dishwasher Rack Adjustm In Stock WCI 5304532268 $16.53

32

5304507087 Frigidaire Dishwasher Tube In Stock WCI 5304507087 $42.32

32A

154406401 Frigidaire Delivery Tube Gasket In Stock WCI 154406401 $6.68

33

154478901 Frigidaire Dishwasher Gasket Backorder WCI 154478901 $38.37

49

809006501 Frigidaire Bottom Seal/Gasket Door In Stock WCI 809006501 $14.86

51

CLAMP, DRIP LOOP, WIRE WCI 154320301 Contact Us For Availability

55

5304534830 Frigidaire Dishwasher Bracket In Stock WCI 5304534830 $3.40

58

154246402 Frigidaire Dishwasher P-1 Ball Asse In Stock WCI 154246402 $35.20

59

154246901 Frigidaire Dishwasher Rear O-Ring f In Stock WCI 154246901 $35.65

59A

154247001 Frigidaire Dishwasher Pump Gasket S In Stock WCI 154247001 $35.65

61

5304506517 Frigidaire Dishwasher Grommet Asse In Stock WCI 5304506517 $9.79

62

5304518968 Frigidaire Lower Spray Arm Support In Stock WCI 5304518968 $7.13

63

5304506533 Frigidaire Dishwasher Filter Base In Stock WCI 5304506533 $13.81

65

154283005 Frigidaire Dishwasher Filter Assemb Backorder WCI 154283005 $148.68

66

5304532206 Frigidaire Trap In Stock WCI 5304532206 $4.66

70

154844301 Frigidaire Dishwasher Motor Kit In Stock WCI 154844301 $144.52

71

154762601 Frigidaire Dishwasher Turbidity Sen Backorder WCI 154762601 $48.50

154380601 Frigidaire Dishwasher Clamp Assembl In Stock WCI 154380601 $45.83

154406801 Frigidaire Dishwasher Anchor Kit (A Backorder WCI 154406801 $65.68

154647101 Frigidaire Dishwasher Pin Hinge Backorder WCI 154647101 $8.91

154686401 Frigidaire Dishwasher Bearing Backorder WCI 154686401 $6.68

154783101 Frigidaire Dishwasher Screw Backorder WCI 154783101 $4.44

5304525043 Frigidaire Dishwasher Insulation Backorder WCI 5304525043 $28.07

5304538695 Frigidaire Door Insulation Backorder WCI 5304538695 $0.91

808690701 Frigidaire Dishwasher Screw Backorder WCI 808690701 $2.22

HARNESS, WIRING, MAIN WCI 154870201 Contact Us For Availability

154106202 Frigidaire Dishwasher Heater Nut In Stock WCI 154106202 $4.80

154297701 Frigidaire Dishwasher Screw Backorder WCI 154297701 $8.46

154741501 Frigidaire Dishwasher Screw Backorder WCI 154741501 $8.46

154754901 Frigidaire Dishwasher Screw In Stock WCI 154754901 $2.66

154779601 Frigidaire Dishwasher Screw Backorder WCI 154779601 $0.85

5304525214 Frigidaire Dishwasher Shield Backorder WCI 5304525214 $6.22

SCREW, DRY DUCT, (3) WCI 154793401 Contact Us For Availability

NIB

154289801 Frigidaire Dishwasher Shield Backorder WCI 154289801 $4.89

NIB

154491101 Frigidaire Dishwasher Screw Backorder WCI 154491101 $2.22

NIB

807048001 Frigidaire Dishwasher Check Valve In Stock WCI 807048001 $5.78
