Model Whirlpool 5WRS315NHW00 REFRIGERATOR, SIDE-BY-SIDE – Common Parts &amp; Diagrams

2

WP2256101 Whirlpool Dairy Door In Stock WPL WP2256101 $51.86

2

WPW10304660 Whirlpool Wheel Assembly In Stock WPL WPW10304660 $29.99

2

WPW10318948 Whirlpool Wire Shelf Backorder WPL WPW10318948 $111.89

3

W10803534 Whirlpool Screw Backorder WPL W10803534 $5.01

3

W11048608 Whirlpool Refrigerator Cover Backorder WPL W11048608 $32.87

3

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

3

WPW10269173 Whirlpool Dishwasher Cantilever B Backorder WPL WPW10269173 $42.13

4

W11396033 Whirlpool Refrigerator Rocker Switc In Stock WPL W11396033 $14.15

5

DUCT, FREEZER AIR WPL 2203594 No Longer Available

5

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $4.72

5

WPW10318947 Whirlpool Wire Shelf In Stock WPL WPW10318947 $39.73

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

7

W11036715 Whirlpool Refrigerator Plate Backorder WPL W11036715 $9.52

7

W11368751 Whirlpool Shelf Frame In Stock WPL W11368751 $71.11

7

WP2309941 Whirlpool Refrigerator Door Bar Tri In Stock WPL WP2309941 $43.04

7

WPW10130299 Whirlpool Refrigerator Cup Backorder WPL WPW10130299 $9.50

7

WPW10384183 Whirlpool Thermistor In Stock WPL WPW10384183 $45.35

7

HARNESS, UNIT (INCLUDES POWER CORD) WPL W11327502 Contact Us For Availability

8

W10900030 Whirlpool Refrigerator Cover Backorder WPL W10900030 $39.18

8

W11397972 Whirlpool Refrigerator Door Cam In Stock WPL W11397972 $4.90

8

W11751592 Whirlpool Sleeve In Stock WPL W11751592 $12.17

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $13.65

9

W11371713 Whirlpool Shelf Frame In Stock WPL W11371713 $71.11

9

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $4.58

9

W11505709 Whirlpool Refrigerator Door Hinge Backorder WPL W11505709 $23.72

9

W11661926 Whirlpool Refrigerator Door Cam Backorder WPL W11661926 $4.90

9

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

9A

W11505710 Whirlpool Refrigerator Door Hinge Backorder WPL W11505710 $23.72

W10745337 Whirlpool Tube Backorder WPL W10745337 $12.70

W11557261 Whirlpool Refrigerator Bracket Asse Backorder WPL W11557261 $7.39

W11679635 Whirlpool Door Cam Backorder WPL W11679635 $4.90

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $3.70

WPW10318961 Whirlpool Refrigerator Wire Shelf In Stock WPL WPW10318961 $42.46

11

W10683556 Whirlpool Refrigerator Clip Backorder WPL W10683556 $7.05

11

W11223753 Whirlpool Refrigerator Nameplate In Stock WPL W11223753 $39.33

12

2321245 Whirlpool Refrigerator Capacitor Backorder WPL 2321245 $46.87

W10318945 Whirlpool Refrigerator Wire Shelf Backorder WPL W10318945 $53.27

W10858105 Whirlpool Refrigerator Tube Backorder WPL W10858105 $125.90

W11687636 Whirlpool Refrigerator Door Hinge Backorder WPL W11687636 $26.77

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $4.56

14

DEVICE, START WPL W10796753 Contact Us For Availability

15

W10803597 Whirlpool Refrigerator Air Scoop Backorder WPL W10803597 $32.87

15

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $9.59

15

WPW10304659 Whirlpool Wheel Assembly In Stock WPL WPW10304659 $35.45

16

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $192.85

16A

W11219642 Whirlpool Refrigerator Filler Backorder WPL W11219642 $7.16

18

W10837641 Whirlpool Refrigerator Condenser Mo Backorder WPL W10837641 $97.18

19

W11164129 Whirlpool Refrigerator Evaporator T Backorder WPL W11164129 $54.33

20

W10194475 Whirlpool Refrigerator Shield Backorder WPL W10194475 $53.71

20

W11398787 Whirlpool Refrigerator Door Cam In Stock WPL W11398787 $4.90

21

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $13.98

22

W11566763 Whirlpool Fitting In Stock WPL W11566763 $18.87

22

SCREW WPL 489473 Contact Us For Availability

23

W10900445 Whirlpool Frame Backorder WPL W10900445 $30.05

23

W11512417 Whirlpool Drain Connector In Stock WPL W11512417 $13.03

24

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

25

W11399415 Whirlpool Refrigerator Door Hinge In Stock WPL W11399415 $25.57

25

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $5.67

26

WPW10123653 Whirlpool Refrigerator Heater Backorder WPL WPW10123653 $65.27

27

CLIP, DEFROST HEATER WPL 2161324 Contact Us For Availability

28

W10183407 Whirlpool Refrigerator Compressor Backorder WPL W10183407 $361.52

29

W10836504 Whirlpool Refrigerator Grommet Backorder WPL W10836504 $8.67

30

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $4.56

31

W10896764 Whirlpool Refrigerator Air Baffle Backorder WPL W10896764 $36.11

32

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

33

W10897560 Whirlpool Refrigerator Unit Cover Backorder WPL W10897560 $55.08

34

GUARD, FAN WPL 1110663 Contact Us For Availability

35

W11678305 Whirlpool Tube In Stock WPL W11678305 $23.50

36

COVER, CONTROL WPL W11407236 Contact Us For Availability

37

W11604765-includeCORE Whirlpool W11604765 Ref Backorder WPL W11604765-includeCORE $229.25

38

2323186 Whirlpool Refrigerator Housing Backorder WPL 2323186 $33.96

39

WPW10171469 Whirlpool Refrigerator Screw In Stock WPL WPW10171469 $4.58

40

FILTER, EMI WPL W10738041 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $6.86

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

8003RP Whirlpool Refrigerator 25' 1/4" Copper In Stock WPL 8003RP $21.98

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

W10134625 Whirlpool Refrigerator Touch-Up Pai In Stock WPL W10134625 $7.48

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

WPW10300794 Whirlpool Refrigerator Hardware P Backorder WPL WPW10300794 $55.40

VALVE, ACCESS (5/8") WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108") WPL 479502 Contact Us For Availability

TORX SCREW WRENCH, TORX KEY WPL 1117510 Contact Us For Availability

PEDESTAL (REFER TO COLOR VARIATION PARTS PAGE WPL NP Contact Us For Availability

PAINT, BULK (1 QT. BISCUIT/BISQUE) WPL 4392900 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability
